Representative Sampling Implementation in Online VFA/TIC Monitoring for Anaerobic Digestion

1
bwe Energiesysteme GmbH Co. KG, Zeppelinring 12-16, 26127 Friesoythe, Germany
2
Department of Engineering Science, University of Applied Sciences Aschaffenburg, Würzburger Str. 45, D-63743 Aschaffenburg, Germany
3
Faculty for Agricultural and Environmental Sciences, University of Rostock, Justus-von-Liebig-Weg 6, D-18059 Rostock, Germany
*
Author to whom correspondence should be addressed.
Energies 2019, 12(6), 1179; https://doi.org/10.3390/en12061179
Received: 25 February 2019 / Revised: 20 March 2019 / Accepted: 22 March 2019 / Published: 26 March 2019
  |
PDF [10496 KB, uploaded 28 March 2019]
  |

Abstract

This paper describes an automatic sampling system for anaerobic reactors that allows taking representative samples following the guidelines of Gy’s (1998) theory of sampling. Due to the high heterogeneity degree in a digester the sampling errors are larger than the analysis error, making representative sampling a prerequisite for successful process control. In our system, samples are automatically processed, generating a higher density of data and avoiding human error by sample manipulation. The combination of a representative sampling system with a commercial automate titration unit generates a robust online monitoring system for biogas plants. The system was successfully implemented in an operating biogas plant to control a feeding-on-demand biogas system. View Full-Text
Keywords: anaerobic digestion; representative sampling; online monitoring; experimental design; power-on-demand anaerobic digestion; representative sampling; online monitoring; experimental design; power-on-demand
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Wilches, C.; Vaske, M.; Hartmann, K.; Nelles, M. Representative Sampling Implementation in Online VFA/TIC Monitoring for Anaerobic Digestion. Energies 2019, 12, 1179.
