Complex Heat Pump Operational Mode Identification and Comparison for Use in Electric Vehicles
Abstract
:1. Introduction
1.1. Low Temperature Issues with EVs
1.2. Potential Solutions
- Ambient
- Battery
- Inverter
- Motor
- Transmission
- Thermal Battery
- Cabin exhaust air
2. Aims
3. Model Development
3.1. Model Details
3.1.1. Battery
3.1.2. Motor
3.1.3. Thermal Storage
3.1.4. Transmission
3.1.5. Cabin
3.1.6. Heat Pump
3.1.7. PTC Heater
3.2. Parametrisation
3.3. Model Usage Cases
- Motor
- Transmission
- Battery
- Thermal Battery
- Cabin Exhaust
4. Results
4.1. Baseline
4.2. Heat Pump with Variable Heat Sources
- Run all 32 operational modes over all drive cycles and temperatures.
- For each scenario (temperature, cycle), reduce list of modes to those which reach cabin target temperature.
- If cabin temperature is not reached, limit operational mode choice to the one with highest cabin temperature.
- Identify best performing mode during each interval of drive cycle.
5. Discussion
6. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
