Potential Threats Posed by New or Emerging Marine Biotoxins in UK Waters and Examination of Detection Methodology Used in Their Control: Brevetoxins
Abstract
:1. Introduction
2. Potential Brevetoxin-Producing Phytoplankton Threats for UK Waters
3. Potential New/Emerging Brevetoxin Threats for UK Waters
4. Brevetoxin-Producing Phytoplankton Detection Methods
4.1. Sample Collection
4.2. Sample Enumeration
4.3. Particle Counting Methods
4.4. Molecular Methods
4.5. Indirect Estimates of Phytoplankton Biomass
4.6. Future Monitoring of Karenia
5. Toxin Testing Methods
5.1. Mouse Bioassays
5.2. Chemical Methods
5.2.1. Extraction
5.2.2. Conventional Chromatography Methods
5.2.3. LC–MS Methods
5.3. Biomolecular Methods
5.3.1. Cytotoxicity Assay
5.3.2. Receptor Binding Assays
5.3.3. Immunoassays
5.3.4. Biosensor Methods
6. Suitability of Toxin Testing Methods
6.1. Suitability of Existing and Potential Methods for Brevetoxin Testing
Method | Advantages | Disadvantages |
---|---|---|
Microscopy | Detection of Karenia genus | Detection not species-specific |
Fulfils requirement of legislation | No evidence for shellfish toxicity | |
Particle counting methods | Detection of Karenia genus | Detection may be compromised when analysing dense blooms |
Potentially a more rapid enumeration of cells | Little evidence for suitability for field based monitoring | |
Potential for in-situ analysis | Sample preservation compromises detection | |
Detection not species-specific | ||
Molecular techniques | Enables identification of different Karenia species | Methods still under development, with no reports of application to official testing to date |
Toxic species can be identified for verification purposes | Requires expensive instrumentation and highly trained analysts | |
Mouse bioassay (MBA) | Primary tool for toxicity assessment | Inability to detect all BTXs |
History of use and prevention of sickness | Ethical issues | |
Relatively simple technology | Variable performance | |
Not validated | ||
Cytotoxicity assay | Sensitive functional assay | Matrix effects, high variability |
Use of cultured vs. primary cells | Poor correlation with MBA | |
Used to detect all analogues | Noting limited data on performance characteristics of method | |
Time consuming | ||
Receptor binding assays (RBA) | Simple, sensitive, rapid | Variable affinity for BTX metabolites |
Good performance in collaborative study | Requirement for animal tissues and radiolabel | |
Promising fluorescence-based binding assay | Matrix effects | |
Limited development to date with fluorescence-based binding assay | ||
Immunoassays | Specific for type-B and sensitive | Lower cross reactivity for type-A BTXs |
High throughout, fast turnaround and “in the field” | Screening tool only—no toxicity or profile data provided | |
Low matrix effects | Valuable quantities of toxin required to produce antibodies | |
Good correlation with MBA and LC–MS | Potential issues with commercial kits, with manufacturers changing properties or performance characteristics | |
Good single lab validation and multi-lab study anticipated | ||
Conventional chromatography | Use of MEKC-LIF, LC-UV and LC-FLD reported | Very limited data available for determination of low numbers of toxins |
Some degree of specificity | Lack of standards and equipment | |
Proof of concept required for all appropriate toxins | ||
LC–MS (MS) | Highly specific | Expensive instrumentation |
Sensitive | Lack of all suitable standards | |
Single laboratory validation performed | ||
Biosensor methods | Useful research screening tools | Lack of specificity |
High sensitivity | Expensive instrumentation for biosensors | |
Matrix effects can be diluted |
6.2. Identification of Knowledge Gaps Which Might be Addressed through Further Research or Method Development
- Understanding and identification of additional algal species which produce brevetoxins, in particular those found to grow well in water conditions relevant to the UK at present or in the future;
- Analysis of algal cultures by suitable methods for assessment of presence of BTXs in water samples;
- Identified shellfish species that accumulate BTXs, together with associated accumulation and depuration rates;
- The determination of BTX metabolites by LC-MS profile studies in relevant bivalve species;
- Continued evaluation of MBA-replacement methods, in particular including ELISA and LC–MS/MS;
- Understanding of BTX and BTX metabolites toxicity in relation to human exposure, including long term assessment of intoxicated people to determine potential long term affects.
6.3. Global Regimes
7. Conclusions: Proposed Options for Routine Monitoring of Phytoplankton and Toxins to Meet Legal Requirements
