Robot-Assisted Augmented Reality (AR)-Guided Surgical Navigation for Periacetabular Osteotomy
Abstract
:1. Introduction
- We propose a robot-assisted, AR-guided surgical navigation system for PAO, built on a robot arm and a Microsoft HoloLens 2 headset (Microsoft, Redmond, USA), which is a state-of-the-art (SOTA) OST-HMD. Our system automatically aligns a bone saw with a preoperatively planned osteotomy plane and then provides surgeons with both virtual constraints and AR visual guidance, improving surgical accuracy and safety.
- We propose an optical marker-based AR registration method. Specifically, we control a robot arm to align an optical marker attached to the robot flange with predefined virtual models, collecting point sets in the optical tracker COS and the virtual space COS, respectively. The transformation is then estimated based on paired-point matching.
- Comprehensive experiments were conducted to evaluate both AR registration accuracy and osteotomy accuracy of the proposed system. Experimentally, the proposed AR registration method can accurately align virtual models with the corresponding physical counterparts while the navigation system achieved accurate osteotomy on sheep pelvises.
2. Related Works
2.1. Surgical Navigation in PAO
2.2. Robot Assistance in Osteotomy
2.3. AR Guidance in CAOS
3. Method
3.1. Overview of the Proposed Navigation System
3.2. Preoperative Planning
3.3. Image–Patient Registration
3.4. Bone Saw Calibration
3.5. AR Registration
3.6. Robot-Assisted AR-Guided Osteotomy
3.6.1. Robot Assistance
3.6.2. AR Guidance
4. Experiments and Results
4.1. Tasks and Evaluation Metrics
4.1.1. Evaluation of AR Registration Accuracy
4.1.2. Ablation Study
4.1.3. Evaluation of Time Cost of the Proposed AR Registration
4.1.4. Evaluation of Osteotomy Accuracy
4.2. Experimental Results
4.2.1. Accuracy of AR Registration
4.2.2. Ablation Study
4.2.3. Time Cost of the Proposed AR Registration
4.2.4. Osteotomy Accuracy
5. Discussion and Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
Abbreviations
API | application programming interface |
AR | augmented reality |
CAOS | computer-assisted orthopedic surgeries |
COS | coordinate system |
CT | computed tomography |
DDH | developmental dysplasia of the hip |
DRB | dynamic reference base |
EM | electromagnetic |
FoV | field of view |
PAO | periacetabular osteotomy |
MR | magnetic resonance |
mADE | mean absolute distance error |
OST-HMD | optical see-through head-mounted display |
SOTA | state of the art |
3D | three-dimension |
