Model of Magnetically Shielded Ferrite-Cored Eddy Current Sensor

1
Faculty of Electrical Engineering and Computing, University of Zagreb, 10000 Zagreb, Croatia
2
INETEC Institute for Nuclear Technology, 10250 Zagreb, Croatia
*
Author to whom correspondence should be addressed.
Academic Editors: Leandro Maio, Vittorio Memmolo and Marco Laracca
Sensors 2022, 22(1), 326; https://doi.org/10.3390/s22010326
Received: 26 November 2021 / Revised: 25 December 2021 / Accepted: 28 December 2021 / Published: 2 January 2022
Computationally fast electromagnetic models of eddy current sensors are required in model-based measurements, machine interpretation approaches or in the sensor design phase. If a sensor geometry allows it, the analytical approach to the modeling has significant advantages in comparison to numerical methods, most notably less demanding implementation and faster computation. In this paper, we studied an eddy current sensor consisting of a transmitter coil with a finitely long I ferrite core, which was screened with a finitely thick magnetic shield. The sensor was placed above a conductive and magnetic half-layer. We used vector magnetic potential formulation of the problem with a truncated region eigenfunction expansion, and obtained expressions for the transmitter coil impedance and magnetic potential in all subdomains. The modeling results are in excellent agreement with the results using the finite element method. The model was also compared with the impedance measurement in the frequency range from 5 kHz to 100 kHz and the agreement is within 3% for the resistance change due to the presence of the half-layer and 1% for the inductance change. The presented model can be used for measurement of properties of metallic objects, sensor lift-off or nonconductive coating thickness. View Full-Text
Keywords: ferrite core; magnetic shield; eddy current; probe; coil; truncated domain; eigenfunction expansion ferrite core; magnetic shield; eddy current; probe; coil; truncated domain; eigenfunction expansion
