Characterization of the Relationship between the Loess Moisture and Image Grayscale Value
Abstract
:1. Introduction
2. Test Materials
2.1. Loess Soil
2.2. Sample Preparation
3. Test Apparatus and Methods
3.1. Test Instruments and Procedures
3.2. Data Processing
4. Results
4.1. Effect of Dry Density on WGCC
4.2. Effect of Particle Size Distribution on WGCC
4.3. Influence of Illumination on WGCC
5. Discussion
5.1. Intrinsic Correlation between Soil Water Type and WGCC Stage Transition
5.2. WGCC Model
5.3. WGCC Model Parameters and Implications
5.4. Validation of WGCC Model
6. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
