14 pages, 12951 KiB
Article
Experimental Research on the Effect of Sugarcane Stalk Lifting Height on the Cutting Breakage Mechanism Based on the Sugarcane Lifting–Cutting System (SLS)
by Qingqing Wang, Guoan Zhou, Xin Huang, Jiale Song, Dongbo Xie and Liqing Chen
Agriculture 2022, 12(12), 2078; https://doi.org/10.3390/agriculture12122078 - 3 Dec 2022
Cited by 5 | Viewed by 3586
Abstract
The sugarcane lifting–cutting System (SLS) is the core component of the sugarcane harvester, and the influence of its stalk lifting height on the mechanism of perennial root-cutting damage is still unclear. The test was conducted with the vertical height of centroid (VHC), forward [...] Read more.
The sugarcane lifting–cutting System (SLS) is the core component of the sugarcane harvester, and the influence of its stalk lifting height on the mechanism of perennial root-cutting damage is still unclear. The test was conducted with the vertical height of centroid (VHC), forward velocity, and cutter rotational speed. Numerical quantification of perennial root based on the cutting breakage effect and cutting breakage grade (CBG) classification was used as the evaluation index. The test results showed that the VHC had a highly significant effect on the CBG of the perennial root. The CBG of the stalk decreased significantly with the lifting height. The average CBG was greater than 2.0 when the stalk lifting height was severely collapsed. The CBG ≤ 1.6 was considered qualified, and the requirements were met when the VHC of the stalk was about 0.85~1.0 m at a forward velocity of 1~3 km/h. The inverted angle of the stalk being lifted was selected to be 45° as the evaluation standard to measure the qualified lifting of the spiral sugarcane lifter. This study provides technical support for the optimal design and selection of operating parameters of the sugarcane harvester. Full article
(This article belongs to the Section Agricultural Technology)
Show Figures

Figure 1

15 pages, 5427 KiB
Article
Lodged Sugarcane/Crop Dividers Interaction: Analysis of Robotic Sugarcane Harvester in Agriculture via a Rigid-Flexible Coupled Simulation Method
by Qingqing Wang, Qianwei Zhang, Yin Zhang, Guoan Zhou, Zhiqiang Li and Liqing Chen
Actuators 2022, 11(1), 23; https://doi.org/10.3390/act11010023 - 13 Jan 2022
Cited by 10 | Viewed by 5006
Abstract
As a critical component of the sugarcane harvester, the primary function of the crop dividers is to lift the lodged sugarcane (LS) and reduce the loss rate of the sugarcane harvest. In this study, a rigid-flexible coupling simulation method is proposed to improve [...] Read more.
As a critical component of the sugarcane harvester, the primary function of the crop dividers is to lift the lodged sugarcane (LS) and reduce the loss rate of the sugarcane harvest. In this study, a rigid-flexible coupling simulation method is proposed to improve the lifting efficiency of the crop dividers on severely LS and analyze the nature of interaction between the sugarcane stalk and the crop dividers. The model’s accuracy was verified using field experiments, and the operational performance of the crop dividers on sugarcane in different lodging postures was investigated. The results showed that the curve of the vertical height of the center (VHC) fluctuated more and slipped with highest frequency during the lifting process of side and forward LS. The speed of VHC was fastest during the lifting operation of side LS. The effect of side angle on the lifting effect of sugarcane was significant; the qualified values of the VHC of sugarcane being lifted in different lodged postures were: side and reverse lodged > side lodged > side and forward lodged. The coupling method and experimental results described in this paper can provide guidance for the optimal design and field operation of the crop dividers. Full article
Show Figures

Figure 1
