Search Results (2)

Search Parameters:
Keywords = three-dimensional heterogenous-integration (3DHI)

Order results
Result details
Results per page
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:
11 pages, 5443 KB
Article
3D Heterogenous Integrated Wideband Switchable Bandpass Filter Bank for Millimeter Wave Applications
by Zhiyu Wang, Yujian Shu, Siyuan Ma, Xi Guo, Wei Yang, Xu Ding, Xiaofeng Lyu and Faxin Yu
Electronics 2023, 12(1), 194; https://doi.org/10.3390/electronics12010194 - 30 Dec 2022
Cited by 1 | Viewed by 2213
Abstract
This article proposes a three-dimensional heterogenous-integrated (3DHI) switchable bandpass filter bank with two independent wideband filter channels that cover 26–40 GHz and 32.5–40 GHz, respectively. An accurate wafer-level process with a high hollowed ratio of the applied 8-inch high-resistivity-silicon (HR-Si) interposer wafers is [...] Read more.
This article proposes a three-dimensional heterogenous-integrated (3DHI) switchable bandpass filter bank with two independent wideband filter channels that cover 26–40 GHz and 32.5–40 GHz, respectively. An accurate wafer-level process with a high hollowed ratio of the applied 8-inch high-resistivity-silicon (HR-Si) interposer wafers is presented to form both compact filter channels. Above the interdigital filter patterns fabricated on the bottom interposer wafer, deep cavities are etched in the cap interposer wafer to improve the quality factor of the filter bank. Besides the cavities, the cap interposer wafer is 35% hollow inside, which two bare dies of GaAs single-pole double-throw (SPDT) switches and two thin film resistors are attached to the bottom interposer after the wafer-to-wafer (W2W) bonding. To ensure good out-of-band performance, a 3D EM co-simulation of the switch layout at the chip level and filter patterns at the package level is applied. Measurement results show that the switchable filter bank achieves a high isolation of 50 dB and a competitive shape factor (BW30dB/BW3dB) of about 1.3. In addition, the size of the switchable filter bank is only 7.0 mm × 3.5 mm × 0.6 mm, and the weight is only 0.1 g. Full article
(This article belongs to the Section Semiconductor Devices)
►▼ Show Figures

Figure 1

15 pages, 9984 KB
Article
Design and Implementation of RF Front-End Module Based on 3D Heterogenous-Integrated Wafer-Level Packaging
by Faxin Yu, Qi Zhou, Zhiyu Wang, Jiongjiong Mo and Hua Chen
Electronics 2021, 10(16), 1893; https://doi.org/10.3390/electronics10161893 - 6 Aug 2021
Cited by 2 | Viewed by 4237
Abstract
In this paper, a three-dimensional heterogenous-integrated (3DHI) wafer-level packaging (WLP) process is proposed, and a radio frequency (RF) front-end module with two independent ultra-high frequency (UHF) receiving channels are designed and implemented, which covers 400 MHz–600 MHz and 2050 MHz–2200 MHz respectively for [...] Read more.
In this paper, a three-dimensional heterogenous-integrated (3DHI) wafer-level packaging (WLP) process is proposed, and a radio frequency (RF) front-end module with two independent ultra-high frequency (UHF) receiving channels are designed and implemented, which covers 400 MHz–600 MHz and 2050 MHz–2200 MHz respectively for unmanned aerial vehicle (UAV) applications. The module is formed by wafer-to-wafer (W2W) bonding of two high-resistivity silicon (HR-Si) interposers with embedded bare dies and through silicon via (TSV) interconnections. Double-sided deep reactive ion etching (DRIE) and conformal electroplating process are introduced to realize the high-aspect-ratio TSV connection within 290 µm-thick cap interposer. Co-plane waveguide (CPW) transmission lines are fabricated as the process control monitor (PCM), the measured insertion loss of which is less than 0.18 dB/mm at 35 GHz. The designed RF front-end module is fabricated and measured. The measured return loss and gain of each RF channel is better than 13 dB and 21 dB, and the noise figure is less than 1.5 dB. In order to evaluate the capability of the 3DHI process for multi-layer interposers, the module is re-designed and fabricated with four stacked high-resistivity silicon interposers. After W2W bonding of two pairs of interposers and wafer slicing, chip-to chip (C2C) bonding is applied to form a four-layer module with operable temperature gradient. Full article
(This article belongs to the Section Microelectronics)
►▼ Show Figures

Figure 1
