Search Results (4)

Offshore winches are crucial in marine engineering, particularly in marine scientific research and deep-sea exploration. The use of fibre ropes presents significant opportunities for the weight reduction of winches as a consequence of the low length–strength ratio and characteristics of corrosion resistance. Nonetheless, a challenge arises in underestimating the stress load levels in load assessments of multi-layer winch systems using synthetic fibre ropes. Traditional computational methods reliant on symmetrically rotational models fall short in accurately predicting and assessing practical applications. This paper introduces a finite element analysis model based on a non-rotationally symmetric approach with four surfaces subjected to various radial pressure on account of the deformation of the fibre ropes. In the design model, sixteen stress detection paths have been incorporated to identify and confirm non-linear stresses. The outcomes of the finite element simulations have been compared with experimental results with two synthetic fibre ropes, each with distinct deformation characteristics utilised. The findings demonstrate that the application of the model aligns well with experimental results, showcasing its relevance and practical value in real-world scenarios. Precise theoretical calculations and experimental validation are pivotal to ensuring that equipment reliability and safety are maintained alongside the pursuit of light-weighting. Full article

Fibre ropes offer beneficial properties for mooring of floating offshore wind turbines (FOWTs). However, the mooring line’s stiffness is both load-history and load-rate dependent. A quasi-static stiffness is observed for slow loading, with a higher stiffness related to rapid, cyclic loading (dynamic stiffness). Design standards provide different guidelines for how to combine these in the mooring analysis. This paper describes procedures for adapting laboratory test stiffness results to the Syrope and a bi-linear model and investigates the consequence of using the models for load calculations. The Syrope model accounts for the quasi-static and permanent rope elongation, while performing the analyses with the dynamic stiffness. The bi-linear model applies both the quasi-static and dynamic stiffness in the dynamic analyses. Based on fibre rope tests performed by Bridon-Bekaert, a Syrope model and two bi-linear models are adapted to the same fibre rope. Fatigue damage and ultimate loads on the mooring lines of Saitec’s SATH FOWT are calculated. The bi-linear model artificially reduces the tension ranges, particularly if there is a large difference between the quasi-static and dynamic stiffness of the fibre rope. This leads to a longer predicted fatigue lifetime. Differences in the extreme loads are caused by the permanent elongation of the Syrope model. This may be countered if the elongation is known and included in the bi-linear model. Finally, the bi-linear model introduces an amplitude-dependency in the horizontal natural periods. Full article

Synthetic fibre mooring lines are used as an alternative to traditional steel wire ropes due to their higher strength to weight ratio. Benefits are also found in relative ease of handling, and therefore the marine industry has largely accepted this type of mooring line. By rules and regulations, the design of mooring lines should be based on a coupled dynamic analysis of a particular mooring system and moored vessel. This approach incorporates damping and inertial forces (i.e., hydrodynamic reactions) acting directly on the mooring lines due to their motion through the seawater. On the basis of the outer diameter of the synthetic fibre rope, the Morison equation gives estimations of the mooring line hydrodynamic reactions. In comparison to the traditional steel wire ropes, the synthetic mooring lines usually have relatively larger elongations and consequently larger reductions of the outer diameter. Furthermore, the lower diameter certainly leads to reduced values of damping and added mass (of mooring lines) that should be considered in the coupled model. Therefore, the aim of this study was to develop a new numerical model that includes diameter changes and axial deformations when estimating the hydrodynamic reactions. The development of the model is carried out with a nonlinear finite element method for mooring lines with the assumption of large three-dimensional motions. The obtained results show the effectiveness of the newly developed model as a more accurate approach in calculation of hydrodynamic reactions. Full article

Innovation in materials and test protocols, as well as physical and numerical investigations, is required to address the technical challenges arising due to the novel application of components from conventional industries to the marine renewable energy (MRE) industry. Synthetic fibre ropes, widely used for offshore station-keeping, have potential application in the MRE industry to reduce peak mooring line loads. This paper presents the results of a physical characterisation study of a novel hybrid polyester-polyolefin rope for MRE mooring applications through a round robin testing (RRT) approach at two test facilities. The RRT was performed using standard guidelines for offshore mooring lines and the results are verified through the numerical modelling of the rope tensile behaviour. The physical testing provides quantifiable margins for the strength and stiffness properties of the hybrid rope, increases confidence in the test protocols and assesses facility-specific influences on test outcomes. The results indicate that the adopted guidance is suitable for rope testing in mooring applications and there is good agreement between stiffness characterisation at both facilities. Additionally, the numerical model provides a satisfactory prediction of the rope tensile behaviour and it can be used for further parametric studies. Full article
