Unmanned aerial vehicle (UAV) remote sensing technology is vigorously driving the development of digital cities. For experimental objects such as large, protruding, and structurally complex steel truss railway bridge structures, commonly used oblique photography and cross-circular photography techniques can lead to blurring, missing, or lower accuracy of fine texture in the models. Therefore, this paper proposes a real-scene three-dimensional modeling method that combines oblique photography with inclined photography and compares it with oblique photography and cross-circular photography techniques. Experimental results demonstrate that the model generated by combining oblique photography with inclined photography exhibits clearer textures, more complete lines, and higher accuracy, meeting the accuracy requirements of 1:500 topographic map control points. This method plays a beneficial auxiliary role in the inspection of ailments such as steel structure coating corrosion and high-strength bolt loss in steel truss railway arch bridges. Full article

Steel-truss-arch bridges have been applied in high-speed railway bridges due to their excellent dynamic and static structural performance. Under the action of high-speed trains, the steel connections between hangers and decks suffer from repeated stresses, inducing potential fatigue problems or even fatigue failure. In this study, a multiaxial fatigue evaluation method was first created and established based on critical damage-plane methodology, following which the fatigue evaluation procedure was also created and recommended. The methodology was applied to real-life strain data from a high-speed railway bridge from which an assessment of fatigue damage and predicted fatigue life was estimated. The connection between the shortest hanger and deck on the downstream side was selected as the target due to its relatively high stress. A multiscale finite-element model of this bridge was created according to the design profile and monitoring results of traffic flow, where the finite-element model was calibrated and validated by comparing the calculation results with the monitoring data. Influence analysis was then carried out to investigate two factors—i.e., the total traffic flow and compositions of freight trains—having effects on the fatigue life of the steel connection. The results indicate that the applied multiaxial fatigue method is suitable for online fatigue evaluation of actual bridges. In addition, by using the multiaxial fatigue method, the fatigue-damage accumulation rate can be nearly 60 times that obtained by the uniaxial fatigue method. If freighting is taken into consideration, the fatigue damage will increase rapidly, and for the case 10% of proportion traffic as freighting, the actual fatigue life is estimated to be shorter than the design life. Full article

The long length and complex service load form conflicts with the low limits of longitudinal and transverse displacements of jointless bridge design. The longitudinal displacements of the Nanjing Dashengguan Yangtze River Bridge, a jointless steel-truss arch railway bridge, and its girder end reliability are investigated in this article. The time–frequency characteristics of the longitudinal displacements of bearings and expansion joints are analyzed using the empirical wavelet transform. The long-term characteristics of the longitudinal displacements of bearings and expansion joints in the operation period are explored. Furthermore, the relative transverse displacements of the bridge girder end are calculated using longitudinal displacement monitoring data. The mechanical behaviors of the expansion device under relative transverse displacements are studied. The reliability of expansion devices and crossing trains under the effects of relative transverse displacements is studied using kernel density estimation. The main results demonstrate that: (1) The longitudinal displacements of bearings and expansion joints are mainly influenced by environmental temperature. (2) The maximum relative transverse displacement of the expansion joint is close to 1 mm in long-term bridge operation, with the transverse rail deflection at the expansion device approaching 1 mm, which reduces the stability of cross high-speed trains. Full article
