Single Snorkel Furnace (SSF) vacuum refining furnace is a novel external refining equipment for high clean steel production. RH is a molten steel refining technology developed by Rheinstahl-Heraeus company. Compared with the traditional RH furnace, the SSF furnace has the advantages of a simple structure, high refining efficiency, and low production cost. However, because the upward flow and the downward flow are in a single snorkel, the flow phenomenon is more complex than that in the RH device. Therefore, the gas–liquid two-phase flow law in SSF furnaces plays an important role in improving equipment efficiency and accurate control. In addition, the evolution and movement behavior of bubbles have an important influence on the two-phase flow. In this study, the Population Balance Model (PBM) model is employed to study the bubble properties, taking into account the effect of bubble coalescence and breakup on the flow field. The simulation results with this model are consistent with the experimental values, and the comparison with the results of the model without the PBM is revealed to be closer with less error. The results show that with the PBM model the flow field is more homogeneously distributed, the flow velocity is more stable, and the area distribution of the upward flow and downward flow in the snorkel is more symmetrical. In the case of this study, as the fluid level rises, the bubble diameter will increase due to the decrease in hydrostatic pressure. Full article

The improvement in mixing conditions in a vacuum refining unit plays an important role in enhancing the purity and decarburization of molten steel. Mixing time is an important index to evaluate the operation efficiency of a metallurgical reactor. However, in water models, the effect of salt tracer dosages on the measured mixing time in a vacuum reactor is not clear. In this study, a water model of a Single Snorkel Refining Furnace (SSRF) was established to study the effect of salt solution tracer dosages on the mixing time of monitor points. The experimental results show that, in some areas at the top of the ladle, the mixing time decreases first and then increases when increasing the tracer dosage. Numerical simulation results show that, when the tracer dosage increases, the tracer flows downwards at a higher pace from the vacuum chamber to the bottom of the ladle. This may compensate for the injection time interval of large dosage cases. However, the mass fraction of the KCl tracer at the right side of the bottom is the highest, which indicates that there may be a dead zone. For the dimensionless concentration time curves and a 99% mixing time, at the top of the vacuum chamber, the curve shifts to the right side and the mixing time decreases gradually with the increase in tracer dosage. At the bottom of the ladle, with the increase in tracer dosage, the peak value of the dimensionless concentration time curve is increased slightly. The mixing time of the bottom of the ladle decreases significantly with the increase in tracer dosage. However, in the dead zone, the mixing time will increase when the tracer dosage is large. At the top of the ladle, the effect of the tracer dosage is not obvious. The mixing time of the top of the ladle decreases first and then increases when increasing the tracer dosage. In addition, the mixing time of the top of the ladle is the shortest, which means that sampling at the top of the ladle in industrial production cannot represent the entire mixing state in the ladle. Full article

With the demand of high-quality steel and miniaturization of the special steel production, single snorkel vacuum refining process has been widely concerned in China recently, because of its simple structure and good performance of degassing and decarburization. In this study, a water model experimental system and a three-dimensional mathematical model based on two-fluid multiphase flow model have been built to analyze the refining efficiency limitation of the single snorkel vacuum refining furnace from the flow pattern and gas distribution. The results showed that there is a limited gas flow rate, and beyond this flow rate the gas column deviates to the wall and the redundant bubbles escape from the free surface, which will not further improve the refining efficiency and will lead to the erosion of the snorkel. In this case, the limited flow rate is 900 NL/h. Furthermore, the fluctuation of the free surface and the different structural parameters have significant effects on the flow field in single-snorkel vacuum refining furnace (SSF). Full article
