20 pages, 10575 KiB
Article
Numerical Simulation Analysis of the Correlation between Hydrodynamic Noise of Hydraulic Turbines and Defects in Runner Blades
by Yuchen Liu, Fengrong Yu, Jing Qian, Hongjiang Pan and Ruihong Xu
Water 2024, 16(10), 1380; https://doi.org/10.3390/w16101380 - 12 May 2024
Cited by 1 | Viewed by 1528
Abstract
To investigate the hydrodynamic noise characterization of hydraulic turbines with runner blade defects, this article establishes the intact machine model and three kinds of models with runner blade defects. Using the Computational Fluid Dynamic (CFD) and Computational Acoustic (CA) hybrid simulation computational methods, [...] Read more.
To investigate the hydrodynamic noise characterization of hydraulic turbines with runner blade defects, this article establishes the intact machine model and three kinds of models with runner blade defects. Using the Computational Fluid Dynamic (CFD) and Computational Acoustic (CA) hybrid simulation computational methods, the hydrodynamic noise field of the hydraulic turbine is numerically simulated, and the results of the acoustic near field and acoustic far field are shown. 1. The double-row leaf grille and the runner are the primary sound source areas of the hydraulic turbine, and the intensity of sound radiation from these areas is positively correlated with the degree of runner blade defects. 2. As the runner blade defects develop, the sound power level (SWL) increases more significantly in the guide vanes near the nose of the spiral case in the double-row leaf grille. The most pronounced increase in the SWL is observed at the defective craters on the runner blades. 3. The frequency of the defective noise signal is primarily concentrated in the low-frequency band. The dominant frequency amplitude associated with runner blade defects increases and rises after the occurrence of defects. Secondary frequency changes are also observed, and the location of these changes varies at different receiving points. Full article
Show Figures

Figure 1

17 pages, 7328 KiB
Article
Effect of Preheat Temperature and Welding Sequence on the Temperature Distribution and Residual Stress in the Weld Overlay Repair of Hydroturbine Runner
by Jimiao He, Min Wei, Lixin Zhang, Changrong Ren, Jin Wang, Yuqi Wang and Wenkai Qi
Materials 2022, 15(14), 4867; https://doi.org/10.3390/ma15144867 - 13 Jul 2022
Cited by 4 | Viewed by 2097
Abstract
The hydroturbine runner is the core of the whole hydroelectric generating unit, which is employed to transform water energy into mechanical energy. In the process of service, the runner frequently suffers from abrasion due to erosion and cavitation. Defects are usually repaired by [...] Read more.
The hydroturbine runner is the core of the whole hydroelectric generating unit, which is employed to transform water energy into mechanical energy. In the process of service, the runner frequently suffers from abrasion due to erosion and cavitation. Defects are usually repaired by welding. To acquire suitable weld cladding repair process parameters, a combination of experimental and numerical simulation was applied to investigate the temperature and weld residual stress distribution in the repair zone under the different welding repair approaches. The results illustrate that the temperature and welding residual stress distribution of the blade and the shroud are out of symmetry, the temperature conduction rate is faster on the blade side, and the high-stress zone is predominantly concentrated in the weld and its adjacent area. When the preheating temperature is up to 150 °C, the peak value of welding residual stress reaches a minimum of 796.29 MPa. The welding sequence can adjust the distribution trend of welding residual stresses. The welding sequence of three-stage welding can effectively reduce the welding residual stresses near the shroud at the water outlet side of the blade. The results of the study will provide theoretical guidance for the welding repair of hydraulic turbine runners. Full article
Show Figures

Figure 1
