The strong airflow beneath a rotary drone generates a wind vortex within the rice canopy; precise control of the wind vortex distance and wind vortex area can improve pesticide utilization efficiency. This paper calculates the flight parameter curve based on the wind vortex target from the wind vortex target parameter control model of the four-rotor plant protection drone, designs a flight control system using a Cube Orange flight controller and a Jetson AGX Xavier onboard computer, and implements flight parameter control using both PID control and fuzzy control algorithms. Experimental results indicate that when using PID control and fuzzy control, the average deviation values of UAV flight altitude and speed are 0.08 m, 0.08 m/s, 0.06 m, and 0.08 m/s, respectively. When using PID control, the average distance and area errors of the target downwind and upwind are 0.17 m and 0.37 m² and 0.20 m and 0.46 m², respectively. The corresponding values for fuzzy control are 0.12 m, 0.38 m², 0.09 m, and 0.31 m². In the twelve voyage experiments, the target parameter variance using fuzzy control was relatively smaller for eight voyages compared to PID control, which had a smaller variance for four voyages. On the whole, the effect of fuzzy control is superior. The wind vortex control method proposed in this paper can effectively enable precise pesticide spraying by drones. This has significant implications for reducing agricultural production costs and safeguarding the natural environment. Full article

To solve the problem of increased grain impurity rate and grain loss rate caused by clogging of sieve holes during the cleaning process of ratooning rice, a spiral step cleaning device was designed, which disturbed the flow field at the sieve holes through vortex in the slot and disrupted the force balance of the blockages at the sieve holes. The device mainly includes a cleaning separation core and a cleaning separation core shell. Firstly, the main parameters of the cleaning separation core were determined, and the critical shear airflow velocity was obtained through theoretical analysis. Through energy loss analysis, the fan wind speed was determined to be 11.5 m/s. Secondly, the CFD-DEM coupling method was used to analyze the flow patterns inside the slot and the movement patterns of blockages on the sieve surface, confirming the effectiveness of vortex guided blockage removal. Finally, a prototype was designed and built for testing, and the results showed that when the wind speed of the fan was 11.5 m/s, the grain impurity rate was 1.35%, the grain loss rate was 2.13%, and the average sieve blockage rate was ≤0.1%. All indicators were better than traditional cleaning devices and could meet the cleaning requirements. During the continuous operation of the spiral step cleaning device, performance indicators such as sieve hole blockage rate remained basically unchanged. Full article

The downwash airflow generated by the rotors can enhance the penetration of pesticide droplets, allowing them to penetrate deeper into the canopy and more comprehensively control pests. Downwash air will produce a “wind vortex” in plant canopy, and the parameters of a “wind vortex” represent the effect of pesticide deposition to a certain extent. To obtain the corresponding relationship between wind vortices and flight parameters and control the effect of pesticide spraying, this paper carried out unmanned aerial vehicle (UAV) flight experiments in the field. Wind vortices were generated in rice canopy by downwash airflow, and the parameters of wind vortices were obtained by identifying wind-vortex images using the inter-frame difference method. The wind-vortex parameter control model was established, which can calculate the altitude and speed of the UAV when applying pesticide according to the target wind-vortex parameter. The deviations in the altitude were determined to be 0.67 and 0.43 m, and the deviations in the speed were 0.29 and 0.35 m/s during downwind and headwind UAV operations, respectively. The model relation functions were established, and their accuracies were found to be 97.1%, 92.3%, 69%, and 58% (downwind), and 97%, 78.4%, 62%, and 57% (upwind), respectively, indicating that downwind UAV operation leads to a clear relation between the wind-vortex parameters and the UAV-flight parameters. The model establishes the corresponding relationship between the wind-vortex parameters and flight parameters, which provides a theoretical basis for studying the precise application control method of UAV. Full article
