Pulse compression technology can augment the likelihood of target discernment without degradation and without amplifying system hardware requisites. However, radar-communication integrated waveforms may cause mismatches in reception due to communication modulation, leading to increased loss in processing gain (LPG). This method aims to achieve communication transmission while suppressing near-range sidelobe interference (NRSI) with a minor sacrifice in LPG. An environment-based weighted mismatched filter (EWMF) design methodology is proposed to attenuate NRSI to the requisite level, with further control of LPG possible by adjusting communication modulation parameters. Moreover, the alternating direction method of multipliers is employed to jointly optimize the integrated waveform and filter design. The effectiveness of this method is demonstrated using the average sidelobe level over a specified region as the performance metric. Theoretical evaluation and experimental results confirm the applicability of waveforms using EWMF, effectively suppressing NRSI, and this method is suitable for all waveforms based on pulse compression processing. Notably, it offers cost-reduction advantages without requiring modifications to the radar transmitter or receiver. Full article

To assist in the detection of ship targets in complex sea conditions, a numerical simulation method is proposed to obtain synthetic aperture radar (SAR) images of time-varying ocean ship wakes under various radar, ship, and sea surface parameters. This method addresses the limitations of recent simulations, which failed to simultaneously incorporate different types of time-varying ship wakes, simulate based on the echo data, and discuss the velocity bunching (VB) effect on the image results. To address these issues, firstly, the time-varying wave height and velocity fields of the sea surface, Kelvin wakes, and turbulence wakes are simulated using the linear filtering method, classic fluid dynamics models, and attenuation function method, respectively. Secondly, raw data of the ocean ship wakes are obtained by calculating the backscattering fields using geophysical model functions (GMFs), as well as by determining the changing slant range varying with the elevation and velocity fields. Thirdly, by applying the Range-Doppler algorithm (RDA) for pulse compression and range cell migration correction (RCMC) on the echo data, SAR images with and without the VB effect are generated. Our simulation also accounts for the influence of speckle noise. The SAR imaging results indicate that whether the VB effect is considered or not, the radar electromagnetic wavebands, polarization modes, wind speeds, and the relative wind directions have distinct impacts on the SAR image intensity, and the texture and morphology of ship wakes vary significantly with the wind speeds, ship speeds, and the relative radar looking directions. When considering the VB effect, the azimuthal offset and blur in the images caused by the more intense wave motion also increase with the wave speeds. Full article

The Chinese Chang’E-5 probe landed in the Mons Rümker of Oceanus Procellarum on the near side of the Moon. The lunar regolith penetrating radar (LRPR) carried by the Chang’E-5 probe allows for the determination of in situ lunar regolith dielectric properties, which are probably related to the age and chemical composition of the regolith. In this paper, we analyze the Chang’E-5 LRPR data with the frequency shift method to estimate the loss tangent of the lunar regolith within a depth of ∼2.8 m. The loss tangent of the Chang’E-5 landing site is constrained to be 0.0148 ± 0.0016, which is substantially higher than that of the typical lunar regolith. The high loss tangent is found to be characteristic of the young basalt age (∼2.0 Ga) and high TiO${}_2$+FeO content (28.21 ± 1.57%) of the Chang’E-5 landing site. Integrated analysis of results from Chang’E-3, Chang’E-4, and Chang’E-5 show that the younger is the geologic age of the mare unit, the greater is the loss tangent of the lunar regolith, and the weaker is the radar electromagnetic signal penetrating ability. Full article

Scan-on-receive (SCORE) digital beamforming (DBF) in elevation can significantly improve the signal-to-noise ratio (SNR) and suppress range ambiguities in spaceborne synthetic aperture radar (SAR). It has been identified as one of the important methods to obtain high-resolution wide-swath (HRWS) SAR images. However, with the improvement of geometric resolution and swath width, the residual pulse extension loss (PEL) due to the long pulse duration in the conventional spaceborne onboard DBF processor must be considered and reduced. In this paper, according to the imaging geometry of the spaceborne DBF SAR system, the reason for the large attenuation of the receiving gain at the edge of the wide swath is analyzed, and two improved onboard DBF methods to mitigate the receive gain loss are given and analyzed. Taking account of both the advantages and drawbacks of the two improved DBF methods presented, a novel onboard DBF processor with multi-frequency and multi-group time delays in HRWS SAR is proposed. Compared with the DBF processor only with multi-group time delays, the downlink data rate was clearly reduced, while focusing performance degradation due to phase and amplitude errors between different frequency bands could be mitigated compared with the DBF processor only with multi-frequency time delays. The simulation results of both point and distributed targets validate the proposed DBF processor. Full article

Due to its significance in astrobiology, assessing the amount and state of liquid water present on Mars today has become one of the drivers of its exploration. Subglacial water was identified by the Mars Advanced Radar for Subsurface and Ionosphere Sounding (MARSIS) aboard the European Space Agency spacecraft Mars Express through the analysis of echoes, coming from a depth of about 1.5 km, which were stronger than surface echoes. The cause of this anomalous characteristic is the high relative permittivity of water-bearing materials, resulting in a high reflection coefficient. A determining factor in the occurrence of such strong echoes is the low attenuation of the MARSIS radar pulse in cold water ice, the main constituent of the Martian polar caps. The present analysis clarifies that the conditions causing exceptionally strong subsurface echoes occur solely in the Martian polar caps, and that the detection of subsurface water under a predominantly rocky surface layer using radar sounding will require thorough electromagnetic modeling, complicated by the lack of knowledge of many subsurface physical parameters. Higher-frequency radar sounders such as SHARAD cannot penetrate deep enough to detect basal echoes over the thickest part of the polar caps. Alternative methods such as rover-borne Ground Penetrating Radar and time-domain electromagnetic sounding are not capable of providing global coverage. MARSIS observations over the Martian polar caps have been limited by the need to downlink data before on-board processing, but their number will increase in coming years. The Chinese mission to Mars that is to be launched in 2020, Tianwen-1, will carry a subsurface sounding radar operating at frequencies that are close to those of MARSIS, and the expected signal-to-noise ratio of subsurface detection will likely be sufficient for identifying anomalously bright subsurface reflectors. The search for subsurface water through radar sounding is thus far from being concluded. Full article

The new Chinese Ka-band solid-state transmitter cloud radar (CR) uses four operational modes with different pulse widths and coherent integration and non-coherent integration numbers to meet long-term cloud measurement requirements. The CR and an instrument-equipped aircraft were used to observe clouds and precipitation on the east side of Taihang Mountain in Hebei Province in 2018. To resolve the data quality problems caused by attenuation in the precipitation area; we focused on developing an algorithm for attenuation correction based on rain drop size distribution (DSD) retrieved from the merged Doppler spectral density data of the four operational modes following data quality control (QC). After dealiasing Doppler velocity and removal of range sidelobe artifacts; we merged the four types of Doppler spectral density data. Vertical air speed and DSD are retrieved from the merged Doppler spectral density data. Finally, we conducted attenuation correction of Doppler spectral density data and recalculated Doppler moments such as reflectivity; radial velocity; and spectral width. We evaluated the consistencies of reflectivity spectra from the four operational modes and DSD retrieval performance using airborne in situ observation. We drew three conclusions: First, the four operational modes observed similar reflectivity and velocity for clouds and low-velocity solid hydrometeors; however; three times of coherent integration underestimated Doppler reflectivity spectra for velocities greater than 2 m s⁻¹. Reflectivity spectra were also underestimated for low signal-to-noise ratios in the low-sensitivity operational mode. Second, QC successfully dealiased Doppler velocity and removed range sidelobe artifacts; and merging of the reflectivity spectra mitigated the effects of coherent integration and pulse compression on radar data. Lastly, the CR observed similar DSD and liquid water content vertical profiles to airborne in situ observations. Comparing CR and aircraft data yielded uncertainty due to differences in observation space and temporal and spatial resolutions of the data. Full article

Ground Penetrating Radar (GPR) systems fall into the category of ultra-wideband (UWB) devices. Most GPR equipment covers a frequency range between an octave and a decade by using short-time pulses. Each signal recorded by a GPR gathers a temporal log of attenuated and distorted versions of these pulses (due to the effect of the propagation medium) plus possible electromagnetic interferences and noise. In order to make a good interpretation of this data and extract the most possible information during processing, a deep knowledge of the wavelet emitted by the antennas is essential. Moreover, some advanced processing techniques require specific knowledge of this signal to obtain satisfactory results. In this work, we carried out a series of tests in order to determine the source wavelet emitted by a ground-coupled antenna with a 500 MHz central frequency. Full article
