10 pages, 2503 KiB
Article
Femtosecond-Level Frequency Transfer at 10 GHz over Long Fiber Link with Optical–Electronic Joint Compensation
by Wantao Huang, Yang Li, Peng Zhang, Lujun Fang and Dong Hou
Appl. Sci. 2022, 12(21), 11262; https://doi.org/10.3390/app122111262 - 7 Nov 2022
Cited by 2 | Viewed by 2293
Abstract
We report a fiber-optic 10 GHz frequency transfer technique based on an optical–electronic joint phase compensator. A highly stable frequency signal at 10 GHz was transferred in a 50-km long fiber link by using this technique. Two key parameters of the frequency dissemination, [...] Read more.
We report a fiber-optic 10 GHz frequency transfer technique based on an optical–electronic joint phase compensator. A highly stable frequency signal at 10 GHz was transferred in a 50-km long fiber link by using this technique. Two key parameters of the frequency dissemination, the timing fluctuation and frequency stability were both measured. The experimental results show the root-mean-square timing fluctuation of the transferred microwave is about 103 fs within 10,000 s, and the frequency stability for the transmission link is 2.2 × 10−14 at 1 s and 8.5 × 10−17 at 2000 s. The technique proposed in this paper provides a powerful tool which can be used to transfer atomic clocks (e.g., commercial H-master and Cs clocks) in a long fiber link. Full article
(This article belongs to the Special Issue New Chances of Optical Fiber Network)
Show Figures

Figure 1

13 pages, 14794 KiB
Article
Microstructure and Mechanical Properties of Butt Joints between Stainless Steel SUS304L and Aluminum Alloy A6061-T6 by TIG Welding
by Van Nhat Nguyen, Quoc Manh Nguyen and Shyh-Chour Huang
Materials 2018, 11(7), 1136; https://doi.org/10.3390/ma11071136 - 4 Jul 2018
Cited by 19 | Viewed by 5513
Abstract
The tungsten inert gas (TIG) welding method most commonly used to weld ferrous metals, nonferrous metals, and other metals since it is simple, easily implemented, and achieves consistent high-quality welds. In this study, butt joints produced between aluminum alloy A6061-T6 and stainless steel [...] Read more.
The tungsten inert gas (TIG) welding method most commonly used to weld ferrous metals, nonferrous metals, and other metals since it is simple, easily implemented, and achieves consistent high-quality welds. In this study, butt joints produced between aluminum alloy A6061-T6 and stainless steel SUS304L have been achieved by using TIG welding with ER4047 filler metal. The macrostructure and microstructure of the resulting specimens were analyzed by means of an optical microscope (OM), a scanning electron microscope (SEM), and an energy dispersive X-ray spectrometer (EDS). A uniform intermetallic layer was found at the interface between the stainless steel and the weld seam having a thickness of 2 µm, and the intermetallic compound (IMC) includes Fe4Al13, Fe2Al5, and FeAl3 phases. The micro-hardness and tensile strength of the weld joints were also investigated. Due to Si content in the compensating metal, there was a prevention of iron diffusion into the aluminum, thus hindering the development of the IMC layer and reducing its thickness in such a way that the weld joint strength increases. The analyzed results show that the average micro-hardness of the stainless steel, weld seam, aluminum alloys, and IMC layer were 218 HV, 88.3 HV, 63.3 HV, and 411 HV, respectively. The fracture occurred at the brazed interface, and the ultimate tensile strength value reached 225 MPa. Full article
Show Figures

Figure 1

15 pages, 4684 KiB
Article
High-Speed, High-Performance DQPSK Optical Links with Reduced Complexity VDFE Equalizers
by Maki Nanou, Christina (Tanya) Politi, Alexandros Stavdas, Kristina Georgoulakis and George-Othon Glentis
Photonics 2017, 4(1), 13; https://doi.org/10.3390/photonics4010013 - 26 Feb 2017
Cited by 2 | Viewed by 4555
Abstract
Optical transmission technologies optimized for optical network segments sensitive to power consumption and cost, comprise modulation formats with direct detection technologies. Specifically, non-return to zero differential quaternary phase shift keying (NRZ-DQPSK) in deployed fiber plants, combined with high-performance, low-complexity electronic equalizers to compensate [...] Read more.
Optical transmission technologies optimized for optical network segments sensitive to power consumption and cost, comprise modulation formats with direct detection technologies. Specifically, non-return to zero differential quaternary phase shift keying (NRZ-DQPSK) in deployed fiber plants, combined with high-performance, low-complexity electronic equalizers to compensate residual impairments at the receiver end, can be proved as a viable solution for high-performance, high-capacity optical links. Joint processing of the constructive and the destructive signals at the single-ended DQPSK receiver provides improved performance compared to the balanced configuration, however, at the expense of higher hardware requirements, a fact that may not be neglected especially in the case of high-speed optical links. To overcome this bottleneck, the use of partially joint constructive/destructive DQPSK equalization is investigated in this paper. Symbol-by-symbol equalization is performed by means of Volterra decision feedback-type equalizers, driven by a reduced subset of signals selected from the constructive and the destructive ports of the optical detectors. The proposed approach offers a low-complexity alternative for electronic equalization, without sacrificing much of the performance compared to the fully-deployed counterpart. The efficiency of the proposed equalizers is demonstrated by means of computer simulation in a typical optical transmission scenario. Full article
(This article belongs to the Special Issue Optical Networks for Communications)
Show Figures

Figure 1
