Pneumatic down-the-hole (DTH) hammer drilling technology has been used extensively in the fields of heat reservoir exploitation and geological exploration owing to its advantages of high efficiency and low pollution. However, the vibration near the bit is up to 40 g while DTH hammer drilling, which significantly affects the performance and longevity of the near-bit measurement while drilling (MWD). To enhance the environmental adaptability of the near-bit MWD in pneumatic DTH operations, a design method for a vibration-damping system based on the parameter optimization of a non-dominated sorting genetic algorithm II (NSGA-II) is proposed in this study. First, the whole structure of the near-bit MWD is designed, including the MWD sub-shell, sensors, measurement circuits, batteries, and connecting structures (the circuit unit). Secondly, this study analyzes the vibration characteristics of the pneumatic DTH hammer near the bit. According to the damping structure, the vibration response model for the circuit unit and the damping model are established. Thirdly, NSGA-II is employed to optimize the parameters of the damping model in terms of the low-frequency, high-intensity vibration characteristics near the bit in pneumatic DTH operations, thereby devising a damping scheme tailored to the unique conditions of DTH hammer drilling. Finally, vibration experiments were conducted to verify the effectiveness of the vibration-damping device. The experimental results indicate that within the vibration frequency range of 5–20 Hz and vibration level of 10–40 g, the peak attenuation rate of the circuit unit is more than 86.446%, and the improvement rate of the vibration stability of the system is more than 75.214%; the anti-vibration performance of the near-bit MWD system in DTH hammer drilling is improved remarkably. This study provides strong technical support for the stability of MWD equipment under such special working conditions. It has broad engineering application prospects. Full article

The downhole engineering parameters measurement sub is a key component of the rotary steerable drilling system. To enable a measurement sub to serve reliably under downhole complex conditions, the structural parameters optimization of its key but weak elastic cell is systematically studied. First, the multiple relations among measurement sensitivities, structural stiffnesses, and strength during structural parameters design are summarized. Second, the selection of the structural parameters of the elastic cell is characterized as a multi-objective optimization model, which is solved using the non-dominated sorting genetic algorithm II (NSGA-II). Furthermore, the finite element method (FEM) is used to verify the measurement performance and static strength of the proposed structure. Finally, transient dynamics analysis is applied to investigate the dynamic strength of the designed structure. The results show that the proposed parameters optimization strategy can quickly obtain the database for the structural parameters design of an elastic cell. The static analysis results based on the FEM further verify the effectiveness of the proposed method. Transient dynamic analysis also reveals the relative rigor of the proposed methodology framework to some extent. This work has practical significance for improving the drilling efficiency and reducing drilling risks. In addition, this proposed methodology has good extensibility. Full article
