The railway system is one of the safest, most efficient, and environmentally friendly means of land transport for people and goods. However, as the demand for mobility has increased, the current railway system has shown some weaknesses, requiring an increase in catenary power in order to be able to supply power to longer trains and faster locomotives, as well as to increase rail traffic. This paper proposes a control algorithm to be implemented in a sectioning post-Rail Power Conditioner (sp-RPC). The sp-RPC is connected to the neutral section between two traction power substations (TPS). With the control algorithm, it is possible to minimize the existing unbalance of the active powers of each TPS. In a regenerative braking condition, this surplus energy can be used to assist the traction of another locomotive on the existing overhead line. In this way, it is possible to increase the capacity of the overhead line. The analysis was performed with computer models using a modular multilevel converter (MMC) topology for the sp-RPC. Quantitative results for different consumption events of the locomotives and the analysis of the response to these variations are presented. Full article

Rail power conditioner (RPC) has the ability to improve the power quality in AC railway power grids. This power conditioner can increase the loading capacity of traction substations, balance the active power between the feeder load sections, and compensate for reactive power and current harmonics. At present, there is increasing use of multilevel converter topologies, which provide scalability and robust performance under different conditions. In this framework, modular multilevel converter (MMC) is emerging as a prominent solution for medium-voltage applications. Serving that purpose, this paper focuses on the implementation, testing, and validation of a reduced-scale laboratory prototype of a proposed RPC based on an MMC. The developed laboratory prototype, designed to be compact, reliable, and adaptable to multipurpose applications, is presented, highlighting the main control and power circuit boards of the MMC. In addition, MMC parameter design of the filter inductor and submodule capacitor is also explained. Experimental analysis and validation of a reduced-scale prototype RPC based on MMC topology, are provided to verify the power quality improvement in electrified railway power grids. Thus, two experimental case studies are presented: (1) when both of the load sections are unequally loaded; (2) when only one load section is loaded. Experimental results confirm the RPC based on MMC is effective in reducing the harmonic contents, solving the problem of three-phase current imbalance and compensating reactive power. Full article

This paper presents a deadbeat predictive current control methodology to reduce the circulating currents in a modular multilevel converter (MMC) when it operates as a rail power conditioner (RPC) in a conventional railway system-based V/V connection. For this purpose, a half-bridge MMC based on half-bridge submodules, operating as an RPC is explained, and the total system is denominated as a simplified rail power conditioner (SRPC). The SRPC in this study is used to compensate harmonics, reactive power, and the negative sequence component of currents. This paper explains the SRPC system architecture, the key control algorithms, and the deadbeat predictive current control methodology. Mathematical analysis, based on the MMC equivalent circuit, is described and the reference equations are presented. Moreover, simulation results of the deadbeat predictive current control methodology are compared with the results of the conventional proportional-integral (PI) controller. This comparison is to verify the effectiveness of the proposed control strategy. Simulation results of the SRPC show reduced circulating currents in the MMC phases when using the predictive control approach, besides accomplishing power quality improvement at the three-phase power grid side. Full article
