The intricate nature of ships and floating structures presents a significant challenge for ship designers when determining suitable structural dimensions for maritime applications. This study addresses a critical research gap by focusing on a three-cargo hold model for a multipurpose cargo ship. The complex composition of these structures, including stiffening plates, deck plates, bottom plates, frames, and bulkheads, necessitates thorough structural analysis to facilitate effective and cost-efficient design evaluation. To address this challenge, the research utilises FEMAP-integrated NX NASTRAN software (2021.2) to assess hull girder stress. Furthermore, a novel approach is introduced, integrating the Design of Experiments (DOE) principles within Minitab 21.4.1 software to identify critical parameters affecting hull girder stress and production costs. This method determined the top five key parameters influencing hull girder stress: Hatch coaming plate, Hatch coaming top plate, Main deck plate, Shear strake plate, and Bottom plate, while also highlighting key parameters that impact production costs: the inner bottom plate, Inner side shell plate, Bottom plate, Web frame spacing, and Side shell plate. Ship design optimisation is then carried out by incorporating regression equations from Minitab software into the Non-dominated Sorting Genetic Algorithm II (NSGA-II), which is managed using Python software (PyCharm Community Editon 2020.3.1). This optimisation process yields a significant 10% reduction in both ship weight and production costs compared to the previous design, achieved through prudent adjustments in plate thickness, web frame positioning, and stiffener arrangement. The optimally designed midship section undergoes rigorous validation to ensure conformity with industry standards and classification society regulations. Necessary adjustments to inner bottom plates and double bottom side girders are made to meet these stringent requirements. This research offers a comprehensive framework for the structural optimisation of ship hulls, potentially enhancing safety, sustainability, and competitiveness within the maritime engineering industry. Full article

With the increase of ship size, the stiffness of the hull structure becomes smaller. This means that the frequency of wave excitation tends to be closer to the natural frequency of the hull vibration, which in turn makes the hydroelastic responses more significant. An accurate assessment of the wave loads and motion responses of hulls is the key to ship design and safety assessment. In this paper, the coupled CFD (Computational Fluid Dynamics)-FEM (Finite Element Method) method is used to investigate the non-linear hydroelasticity effect of a 6750-TEU (Twenty-foot Equivalent Unit) container ship. First, by comparing the heave, pitch, and vertical bending moment at midship section (VBM4) against experimental results reported in the literature, the validity of the numerical method in this paper is illustrated. Secondly, the ship responses under different wave length–ship length ratio, wave frequency-structure natural frequency, wave steepness, and ship speeds are studied. It is found that the wave length–ship length ratio has a more important influence on the hydroelastic response than that from wave frequency-structure natural frequency ratio, and the effect of wave non-linearity will behave differently under different wave length–ship length ratio. The increase of rigid body motion caused by forward speed will not correspondingly increase the non-linearity of the hydroelastic response. Full article

Structural failures in the barge midship sections can cause operational delay, sinking, cargo loss and environmental damage. These failures can be generated by the barge and cargo weights, and wave load effects on the midships sections. These load types must be considered in the design of the barge midship sections. Here, we present the structural analysis of a barge midship section that has decreased up to 36.4% of its deck thickness caused by corrosion. This analysis is developed using finite element method (FEM) models that include the barge and cargo weights, and wave load effects. The FEM models regarded three cargo tanks in the midship section, containing the main longitudinal and transverse structural elements. In addition, the hull girder section modulus and the required deck thickness of the barge were calculated using Lloyd’s Register rules. These rules were applied to estimate the permissible bending stresses at deck and bottom plates under sagging and hogging conditions, which agreed well with those of the FEM models. Based on FEM models, the maximum compressive normal stress and von Mises stress of the hull girder structure were 175.54 MPa and 215.53 MPa, respectively. These stress values do not overcome the yield strength (250 MPa) of the barge material, allowing a safe structural behavior of the barge. The structural modeling of the barge midship section can predict its structural behavior under different sagging and hogging conditions, considering the cargo, weight and wave loads. Full article
