The Pancharatnam–Berry (PB)-phase liquid crystal (LC) planar optical elements, featuring large apertures and a light weight, are emerging as the new generation optics. The primary method for fabricating large-aperture LC planar optical elements is through photo-alignment, utilizing polarization laser direct writing. However, conventional polarization direct writing suffers from an inertia-induced stopping step during splicing, leading to suboptimal optical effects. Here, we propose a novel highly efficient method for arbitrary polarization patterning, significantly reducing interface splicing errors in these optical elements. (We call it dynamic polarization patterning technology). This process involves simultaneous mobile splicing and real-time generation of different polarization patterns for exposure, eliminating the inertia-related splicing interruption. As a demonstration, we fabricated a lens with an aperture of approximately 1 cm within 30 min at 633 nm. Furthermore, we developed a 100% fill-factor lens array (3 × 3) with an element lens diameter of approximately 7 mm within 1.5 h at 532 nm. Their focal lengths were uniformly set at 30 cm, demonstrating superior convergence capabilities within their designated working wavelengths, alongside commendable performance in converging light across various other wavelengths. Our measurements confirmed the good focusing performance of these samples. The convergence spot size of the lens deviated by approximately 40% from the theoretical diffraction limit, whereas the lens array exhibited a deviation of around 30%. The dynamic polarization direct writing during uniform platform movement reduced splicing errors to a mere 100–200 nm. The enhancement in imaging quality can be primarily attributed to the innovative use of mobile polarization splicing exposure technology, coupled with the inherent self-smoothing properties of LC molecules. This synergy significantly mitigates the impact of seam diffraction interference. Full article

The tunability of plasmonic resonances in gold and silver nanosphere arrays on a glass substrate, embedded in a liquid crystal matrix, was explored. The calculations involving the finite element method revealed that the optical properties of these arrays can be modulated by reorienting the liquid crystal. When the liquid crystal director was reoriented between planar and homeotropic configurations in the plane containing the incident wave polarization vector, the plasmonic resonance wavelength shifted within an approximately 100 nm range. A reduced shift of about 40 nm was observed when the reorientation occurred in the plane perpendicular to the polarization. Both metal nanosphere arrays showed notable near-field amplification. Gold achieved up to 18 times the amplification of the incident wave electric field, while silver reached 16 times but showed a remarkable 40 times amplification at the inter-band transition resonance wavelength. This research underscores the potential of using liquid crystal reorientation for controlling the plasmonic lattice resonance in metal nanosphere arrays, opening up new possibilities for adaptable plasmonic devices. Full article

The mesomorphic stability and optical activity of new group-based benzotrifluoride liquid crystals, (E)-4-(((4-(trifluoromethyl) phenyl) imino) methyl) phenyl 4-(alkyloxy)benzoate, or In, were investigated. The end of the molecules connected to the benzotrifluoride moiety and the end of the phenylazo benzoate moiety have terminal alkoxy groups which can range in chain length from 6 to 12 carbons. The synthesized compounds’ molecular structures were verified using FT-IR, ¹H NMR, mass spectroscopy, and elemental analysis. Mesomorphic characteristics were verified using differential scanning calorimetry (DSC) and a polarized optical microscope (POM). All of the homologous series that have been developed display great thermal stability across a broad temperature range. Density functional theory (DFT) determined the examined compounds’ geometrical and thermal properties. The findings showed that every compound is entirely planar. Additionally, by using the DFT approach, it was possible to link the experimentally found values of the investigated compounds’ investigated compounds’ mesophase thermal stability, mesophase temperature ranges, and mesophase type to the predicted quantum chemical parameters. Full article

Solid-state multi-focal and volumetric technologies highlight the future of 3D-display development. One of the most convenient implementations of multi-focal 3D displays are stacks of transparent liquid crystal displays. In this work, the core element is dissected—a switching optical diffuser element based on cholesteric liquid crystals, playing the role of a transparent display. In the present study, high-speed synchronized optical spectroscopy is used. We analyzed the kinetic and electro-optical characteristics of the diffuser element, the operation of which is based on the switching between diffuse and transparent states of this element. The underlying aim of this study was to investigate ways to improve some of these characteristics. It has been found that the transient peak in the optical transmission during field-off state, which is reducing the intensity of the light scattered by the diffuser element, is likely not associated to the assumed formation of the transient planar state. As the origin of this peak, we suggest a transient state possessing uniform lying helix structure, formed due the material flow taking place in the cell during relaxation of the liquid crystal. The role of the contacting surface’s pre-tilt angle in the switching process of the liquid crystal diffuser was established. Full article

We present an experimental and theoretical investigation of the optical diffractive properties of electrically tuneable optical transmission gratings assembled as stacks of periodic slices from a conventional nematic liquid crystal (E7) and a standard photoresist polymer (SU-8). The external electric field causes a twist-type reorientation of the LC molecules toward a perpendicular direction with respect to initial orientation. The associated field-induced modification of the director field is determined numerically and analytically by minimization of the Landau–de Gennes free energy. The optical diffraction properties of the associated periodically modulated structure are calculated numerically on the basis of rigorous coupled-wave analysis (RCWA). A comparison of experimental and theoretical results suggests that polymer slices provoke planar surface anchoring of the LC molecules with the inhomogeneous surface anchoring energy varying in the range 5–20 μJ/m². The investigated structures provide a versatile approach to fabricating LC-polymer-based electrically tuneable diffractive optical elements (DOEs). Full article

Photo-alignment is a versatile tool to pattern the alignment at the confining substrates in a liquid crystal (LC) cell. Arbitrary alignment patterns can be created by using projection with a spatial light modulator (SLM) for the illumination. We demonstrate that a careful design of the alignment patterns allows the stabilization of topological solitons in nematic liquid crystal (NLC) cells, without the need for chirality or strong confinement. The created LC configurations are stabilized by the anchoring conditions imposed at the substrates. The photo-aligned background at both substrates is uniformly planar aligned, and ring-shaped regions with a 180° azimuthal rotation are patterned with an opposite sense of rotation at the top and bottom substrate. A disclination-free structure containing a closed ring of vertically oriented directors is formed when the patterned rings at the top and bottom substrate overlap. Thanks to the topological stability, a vertical director orientation in the bulk is observed even when the centra of both patterned rings are shifted over relatively large distances. The combination of numerical simulations with experimental measurements allows identification of the 3D director configuration in the bulk. A finite element (FE) Q-tensor simulation model is applied to find the equilibrium director configuration and optical simulations are used to confirm the correspondence with experimental microscopy measurements. The created LC configurations offer opportunities in the field of optical devices, light guiding and switching, particle trapping and studies of topological LC structures. Full article

Liquid crystal-based reflective polarization volume grating (PVG), also known as a linear Bragg–Berry phase optical element or a member of volume Bragg gratings (VBGs), is a functional planar structure with patterned orientation of optical axis. Due to the strong polarization selectivity, nearly 100% diffraction efficiency, large diffraction angle, and simple fabrication process, PVGs have found potential applications in novel photonic devices and emerging near-eye displays. In this review paper, we describe the operation principles, discuss the optical properties, present the fabrication methods, and provide promising applications of PVGs for near-eye displays and novel photonic devices. Full article

A Schiff base supramolecular 4-[(4-(hexyloxy)phenylimino)methyl]benzoic acid and a new series of Schiff base/ester linkages named 4-substitutedphenyl 4-[(4-(hexyloxy)phenylimino)methyl]benzoate liquid crystals were synthesized. The thermal stability, mesomorphic, and optical behavior of the prepared compounds were characterized by differential scanning calorimetry (DSC), Thermogravemetric analysis (TGA), polarized optical microscopy (POM), and UV spectroscopy. FT-IR, ¹H-NMR, ¹³C-NMR, and elemental analyses were carried out to elucidate and confirm the molecular structures of the synthesized compounds. The investigated series comprising different sized terminal polar groups changed between CH(CH₃)₂, H, I, and F. It was found that the supramolecular imino acid dimer is enantiotropic dimorphic, with a wide SmA phase and a good N phase range. The other series of terminally substituted Schiff base/esters are mesomorphic with a high thermal stable SmA phase, except the iodo derivative, which showed dimorphic SmA and N phases. The effect of the position and the orientation of the cores, as well as the terminal substituent of the type and the stability of the mesophase, were studied. A computational theoretical study of the effects of the van der Waal’s volume, the Hammett substituent coefficient, the inductive sigma constant, and other geometrical parameters were discussed. The study revealed that the planarity of the two phenyl rings attached with an imino linking group impacted the resonance effect of the terminal substituents rather than their inductive effect. A detailed study on the effect of the estimated thermal parameters, as well as their geometrical planarity with the type and stability of the formed mesophase, was discussed. Full article

Optical planar waveguide sensors, able to detect and process information from the environment in a fast, cost-effective, and remote fashion, are of great interest currently in different application areas including security, metrology, automotive, aerospace, consumer electronics, energy, environment, or health. Integration of networks of these systems together with other optical elements, such as light sources, readout, or detection systems, in a planar waveguide geometry is greatly demanded towards more compact, portable, and versatile sensing platforms. Herein, we report an optical temperature sensor with a planar waveguide architecture integrating inkjet-printed luminescent light coupling-in and readout elements with matched emission and excitation. The first luminescent element, when illuminated with light in its absorption band, emits light that is partially coupled into the propagation modes of the planar waveguide. Remote excitation of this element can be performed without the need for special alignment of the light source. A thermoresponsive liquid crystal-based film regulates the amount of light coupled out from the planar waveguide at the sensing location. The second luminescent element partly absorbs the waveguided light that reaches its location and emits at longer wavelengths, serving as a temperature readout element through luminescence intensity measurements. Overall, the ability of inkjet technology to digitally print luminescent elements demonstrates great potential for the integration and miniaturization of light coupling-in and readout elements in optical planar waveguide sensing platforms. Full article
