Electrical power consumption and distribution and ensuring its quality are important for industries as the power sector mandates a clean and green process with the least possible carbon footprint and to avoid damage of expensive electrical components. The harmonics elimination has emerged as a topic of prime importance for researchers and industry to realize the maintenance of power quality in the light of the 7th Sustainable Development Goals (SDGs). This paper implements a Hybrid Shunt Active Harmonic Power Filter (HSAHPF) to reduce harmonic pollution. An ANN-based control algorithm has been used to implement Hardware in the Loop (HIL) configuration, and the network is trained on the model of pq0 theory. The HIL configuration is applied to integrate a physical processor with the designed filter. In this configuration, an external microprocessor (Raspberry PI 3B+) has been employed as a primary data server for the ANN-based algorithm to provide reference current signals for HSAHPF. The ANN model uses backpropagation and gradient descent to predict output based on seven received inputs, i.e., 3-phase source voltages, 3-phase applied load currents, and the compensated voltage across the DC-link capacitors of the designed filter. Moreover, a real-time data visualization has been provided through an Application Programming Interface (API) of a JAVA script called Node-RED. The Node-RED also performs data transmission between SIMULINK and external processors through serial socket TCP/IP data communication for real-time data transceiving. Furthermore, we have demonstrated a real-time Supervisory Control and Data Acquisition (SCADA) system for testing HSAHPF using the topology based on HIL topology that enables the control algorithms to run on an embedded microprocessor for a physical system. The presented results validate the proposed design of the filter and the implementation of real-time system visualization. The statistical values show a significant decrease in Total Harmonic Distortion (THD) from 35.76% to 3.75%. These values perfectly lie within the set range of IEEE standard with improved stability time while bearing the computational overheads of the microprocessor. Full article

Among sub-items of energy consumption in public buildings, lighting sockets play an important role in energy-saving analysis. So, the energy consumption data quality of lighting sockets is important. However, limited by the initial cost of energy monitoring platform, it is difficult to install electricity meters covering all branches and to retrofit the incompact classification electricity branches, which results in a mixture of the lighting socket energy consumption and other components. In this study, a separation methodology is proposed. First, the abnormal data in the energy monitoring platform are cleaned and screened using a clustering algorithm. Second, the average outdoor air temperature partitioning model (OATPM) method and the k-nearest neighbor (KNN) clustering algorithm method are proposed for identifying and separating the abnormal data. These two methods have complementary advantages in the best applicable scenarios, including calculation accuracy and other aspects. The verification results for three buildings show that the relative error of this separation methodology is less than 15%. Finally, this paper presents the optimization parameters of the KNN method. Through this methodology, building managers need only historical data in an energy monitoring platform to separate the combined power consumption of the lighting sockets and air-conditioning online, independent of detailed information statistics. Full article

In general, the sensor lamps in the corridors, stairwells, or toilets of buildings will change from completely dark to full brightness when someone passes by. It will make the human eyes feel very uncomfortable, and when the sensor lamp is completely dark, the whole corridor and stairwell will be dark, making women and children feel insecure at night. If the lighting is changed to be sensor-less, there is a serious problem of wasted energy. To solve this dilemma, we developed a new type of “LED sensor lamp with low-light mode” that changes the original “full dark mode” to “low-light mode”. As such, when someone approaches the sensor lamp, their eyes will not be uncomfortable with the momentary illumination. Furthermore, when no one passes by, the sensor lamp will stay in low-light mode, so that people returning home at night no longer have to go through dark corridors, thereby achieving safety, aesthetics, and energy-saving purposes. This new sensor lamp’s power consumption in low-light mode is only 1/10 of the high-light mode, but its brightness can be up to half of the high-light mode, making it very suitable for parking lots, corridors, stairways, or toilets of buildings. It only requires the replacement of the lamp but not the original lamp socket, yet the basic brightness can be maintained. Take the general 15W T8 LED lamp (sensor-less) as an example: if it is replaced by this new type of sensor lamp, and the place where it is installed is rarely passed by people, the power saving rate will be as high as 90%. Assuming that there are 12 passers-by per hour, the saving rate is still 81%. Full article
