With the continuous advancement of science and technology, the application of high-temperature superconductivity has developed rapidly. The high-temperature superconducting (HTS) motor replacing the copper coil in the traditional motor with HTS winding is increasingly used in power equipment, and the effective thermal management of HTS winding is vital in ensuring the life and effective operation of the HTS motor. In this study, five enhancement structures of indirect oil cooling channels were designed to improve the heat dissipation capacity of the HTS motor winding, and the enhancement effects of the different structures were comprehensively evaluated through numerical simulation using Fluent software 2022R1. The best enhancement structure was selected through structural optimization. The results showed that the Nusselt number of the gap-type enhanced structure was higher than that of the V- and staggered-type structures at the same flow velocity and 68% higher than that of the bare pipe. At the same inlet flow velocity and with a pressure drop limit of 30 kPa, the performance evaluation criterion value of the gap-type structure was 39% and 63% higher than that of the staggered- and V-type structures, respectively. The gap type is the optimal enhancement structure and can effectively improve the heat dissipation of the HTS winding coil. Full article

In line with global environmental regulations, the demand for eco-friendly and highly efficient aircraft propulsion systems is increasing. The combination of axial flux motors and superconductors could be a key technology used to address these needs. In this paper, an axial flux high temperature superconducting (HTS) motor for aircraft propulsion was designed and its characteristics were analyzed. A 2G HTS wire with high magnetic flux characteristic was used for the field winding of the 120 kW axial flux HTS motor, and the rotational speed and rated voltage of the motor were 2000 rpm and 220 V, respectively. The axial flux HTS motor implements a revolving armature type for solid cooling of the HTS field coil. The electromagnetic and thermal features of the motor were analyzed and designed utilizing a 3D finite element method program. The HTS coil was maintained at the target temperature by effectively designing the current lead and cooling system to minimize heat loss. These results can be effectively used in the design of propulsion systems for large commercial aircraft in the future as well as for the design of small aircraft with less than 4 seats. Full article

As the demand for eco-friendly energy increases, hydrogen energy and liquid hydrogen storage technologies are being developed as an alternative. Hydrogen has a lower liquefaction point and higher thermal conductivity than nitrogen or neon used in general cryogenic systems. Therefore, the application of hydrogen to cryogenic systems can increase efficiency and stability. This paper describes the design and analysis of a cryogenic cooling system for an electric propulsion system using liquid hydrogen as a refrigerant and energy source. The proposed aviation propulsion system (APS) consists of a hydrogen fuel cell, a battery, a power distribution system, and a motor. For a lab-scale 5 kW superconducting motor using a 2G high-temperature superconducting (HTS) wire, the HTS motor and cooling system were analyzed for electromagnetic and thermal characteristics using a finite element method-based analysis program. The liquid hydrogen-based cooling system consists of a pre-cooling system, a hydrogen liquefaction system, and an HTS coil cooling system. Based on the thermal load analysis results of the HTS coil, the target temperature for hydrogen gas pre-cooling, the number of buffer layers, and the cryo-cooler capacity were selected to minimize the thermal load of the hydrogen liquefaction system. As a result, the hydrogen was stably liquefied, and the temperature of the HTS coil corresponding to the thermal load of the designed lab-scale HTS motor was maintained at 30 K. Full article

Taking a technology from the laboratory to industry is a long and resource-consuming process. Discovered more than a century ago, the phenomenon of superconductivity is testament to this process. Despite the promise of this technology, currently the only major use of superconductors outside the laboratory is in MRI machines. The advent of high-temperature superconductors in 1986 heralded a new dawn. Machines which do not require cooling with liquid helium are a very attractive target. A myriad range of different superconductors were rapidly discovered over the next decade. This process of discovery continues to this day with, most recently, a whole new class, the pnictides, being discovered in 2006. Many different usages have been identified, including in motors, generators, wind turbines, fault current limiters, and high-current low-loss cables. This Special Issue looks at some of the different factors which will help to realise these devices and thereby bring about a superconducting world Full article

This article concentrates on the steady-state thermal characteristics of the Axial-Radial Flux-Type Permanent Magnet Synchronous Motor (ARFTPMSM). Firstly, the three-dimensional mathematical models for electromagnetic calculation and analyses are established, and the machine loss, including the stator loss, armature winding loss, rotor loss, and axial structure loss is calculated by using time-step Finite Element Method (FEM). Then, the loss distribution is assigned as the heat source for the thermal calculation. Secondly, the mathematical model for thermal calculation is also established. The assumptions and the boundary conditions are proposed to simplify the calculation and to improve convergence. Thirdly, the three-dimensional electromagnetic and thermal calculations of the machine, of which the armature winding and axial field winding are developed by using copper wires, are solved, from which the temperature distributions of the machine components are obtained. The experiments are carried out on the prototype with copper wires to validate the accuracy of the established models. Then, the temperature distributions of machine components under different Axial Magnetic Motive Force (AMMF) are investigated. Since the machine is finally developing by using HTS wires, the temperature distributions of machine developed by utilizing High Temperature Superconducting (HTS) wires, are also studied. The temperature distribution differences of the machine developed by using copper wires and HTS wires are drawn. All of these above will provide a helpful reference for the thermal calculation of the ARFTPMSM, as well as the design of the HTS coils and the cryogenic cooling system. Full article

Large electric superconducting machines are being sought to solve emissions challenges in aircraft and provide a solution to >12 MW wind turbine electricity generation. Superconducting motors with only high temperature superconducting (HTS) armatures can offer advantages of high reliability, high power density, and high efficiency compared with conventional superconducting motors. In this paper, a novel HTS squirrel-cage induction motor is proposed for high speed operation, which adopts the structure of HTS windings with a certain inclination angle in the stator slots. Due to the limitation of curvature radius of superconducting tapes, the pitch of HTS windings can be only set to 1 and adopt the short pitch arrangement structure, which such design details of the HTS motor would ensure the superconducting coils can undertake larger current and reduce AC losses. In order to keep the HTS windings in superconducting state and larger current density, a special fixed cryogenic cooling system below 70 K with the method of gas extraction and decompression, which is made of aramid fiber, has been fabricated and the whole structure of the stator is placed in liquid nitrogen. According to the motor control principles and electromagnetic field theory, the electrical performances of the novel designed stator-HTS motor, which driven by the variable-voltage variable-frequency (VVVF) inverter, are analyzed including the flux density distributions, the torque, the induced electromotive force, losses and efficiency by using the finite element method. Finally, the components of HTS squirrel-cage induction motor have been manufactured according to the designed parameters. Next step, the motor will be assembled and tested. Full article
