Augmented reality (AR) technology has been widely applied across a variety of fields, with head-up displays (HUDs) being one of its prominent uses, offering immersive three-dimensional (3D) experiences and interaction with digital content and the real world. AR-HUDs face challenges such as limited field of view (FOV), small eye-box, bulky form factor, and absence of accommodation cue, often compromising trade-offs between these factors. Recently, optical waveguide based on pupil replication process has attracted increasing attention as an optical element for its compact form factor and exit-pupil expansion. Despite these advantages, current waveguide displays struggle to integrate visual information with real scenes because they do not produce accommodation-capable virtual content. In this paper, we introduce a lensless accommodation-capable holographic system based on a waveguide. Our system aims to expand the eye-box at the optimal viewing distance that provides the maximum FOV. We devised a formalized CGH algorithm based on bold assumption and two constraints and successfully performed numerical observation simulation. In optical experiments, accommodation-capable images with a maximum horizontal FOV of 7.0 degrees were successfully observed within an expanded eye-box of 9.18 mm at an optimal observation distance of 112 mm. Full article

Diffraction gratings are becoming a preferred option for waveguide head-mounted in–out coupling devices due to their flexible optical properties and small size and light weight. At present, diffraction waveguide coupling devices for AR head-mounted displays (HMD) have difficulties such as a long development cycle and complicated processing. In this paper, we first establish a set of two-dimensional (2D) grating ray tracing models, based on which we determine the initial architecture of the dual-region two-dimensional exit pupil expansion (2D-EPE) AR-HMD holographic waveguide diffraction system. Second, we propose a honeycomb coupled grating array and optimize the optical energy utilization and brightness uniformity of the holographic waveguide and use a custom dynamic linked library (DLL) function to implement the ray tracing of the 2D grating and add a probabilistic splitting function to the DLL, which reduces the single simulation time from 11.853 min to 1.77 min. We also propose a holographic lithography device composed of holographic optical elements (HOEs) and a method for preparing HOEs. Finally, in order to obtain the diffraction efficiency preoptimized by the above DLL for the uniformity of the exit pupil brightness and light energy utilization, we inverse design with the preparation process parameters as the optimization variables and develop the adaptable electromagnetic calculation program Holo-RCWA. Using Holo-RCWA with nondominated sorting genetic algorithm II (NSGA-II), we inverse design to obtain the process parameters satisfying the diffraction efficiency distribution, and the optimization time of the whole system is reduced from 2–3 days to 10 h. This work is of great significance for AR/VR applications. Full article

Near-eye display (NED) devices are required to provide visual instructions in the fields of education, navigation, military operations, construction, healthcare, etc. The issues with conventional NEDs are the form factor and vergence–accommodation conflict (VAC). The Maxwellian display alleviates the VAC in NEDs by providing consistently focused virtual images to the viewer, regardless of the depth of focus of the human eye. The main limitation of the Maxwellian display is its limited exit pupil size. Due to misalignment of the device or eyeball rotation, the user may miss the eye box, and the image will become lost. To mitigate this limitation, exit pupil expansion can be obtained either statically or dynamically. This paper reviews the various techniques employed to expand the exit pupil. The review includes the principle, advantages, and drawbacks of various techniques for expanding the exit pupil of the Maxwellian display. The structure of the paper starts with an introduction and the principle of the Maxwellian display, followed by a discussion of the main limitations that arise with various techniques, along with potential solutions. Full article

Diffraction gratings play an increasingly important role in various planar optical systems, such as near-eye display systems for virtual reality (VR) and augmented reality (AR). The slanted gratings have more advantages than other elements. A 1 × 2 transmission two-dimensional (2D) slanted grating based on a double-layer cylindrical structure was proposed in this paper. In the initial phase of this study, this kind of grating was proposed and designed. We used rigorous coupled-wave analysis (RCWA) and simulated annealing algorithm (SA) to optimize the grating parameters. The effects of the grating geometric parameters on the diffraction efficiency were investigated using rigorous coupled-wave analysis (RCWA). The simulated annealing algorithm (SA) optimization results show that the diffraction efficiency of the (0, −1) and (−1, 0) order exceed 35% under normal incidence in the range of 429–468 nm wavelength for TE and TM polarization. Meanwhile, the total diffraction efficiency can reach up to 78%. In the last section, we discuss the tolerances for the grating parameters to ensure high quality manufacturing processes. The total effective efficiency is greater than 75% when the MgF₂ thickness is from 300 nm to 350 nm and the SiO₂ thickness is from 525 nm to 550 nm. Moreover, the grating period has a 53 nm fabrication tolerance, and the slanted angle has a 8.8-degree fabrication tolerance. The relatively large tolerances ensure that it is easy to fabricate the two-dimensional slanted grating and to achieve the targeted objectives. The proposed 2D slanted grating can be applied to 2D exit pupil expansion, which is of great importance in AR/VR applications. Full article

In this paper, we demonstrate a waveguide display structure which can realize a large field of view on a two-dimensional plane and a larger exit pupil size at the same time. This waveguide structure has three polarization volume gratings as its coupling elements. We use Zemax to simulate the effect of monochromatic and full-color two-dimensional exit pupil expansion and actually prepared a monochromatic waveguide with a two-dimensional exit pupil expansion structure. For the red, green, and blue light beams, it can achieve a large diffraction angle and can achieve diffraction efficiency of more than 70%. The waveguide structure shown can have an angle of view of 35° in the horizontal direction and 20° in the vertical direction, and an exit pupil of 18 mm long and 17 mm wide was achieved at the same time. As measured, the overall optical efficiency was measured as high as 118.3 cd/m² per lumen with a transparency of 72% for ambient light. Full article

We propose a see-through near-eye display featuring an exit pupil expander (EPE), which is composed of two multiplexed slanted gratings. Via a two-dimensional expansion, the exit pupil (EP) is able to be enlarged up to 10 × 8 mm². Besides, the prescription for correcting the refractive errors can be integrated as well. The design rules are set forth in detail, followed by the results and discussion regarding the efficiency, field of view (FOV), exit pupil, angular resolution (AR), modulation transfer function (MTF), contrast ratio (CR), distortion, and simulated imaging. Full article
