Profile measurement is a key technical enabler in the manufacturing of highly curved freeform surfaces due to their complex geometrical shape. A current optical probe was used to measure nearly rotary freeform surfaces with the help of one rotation axis, because the probe needs to measure along the normal vector of the surface under the limitation of the numerical aperture (NA). This kind of measuring system generally has a high cost due to the high-precision, multi-axis platform. In this paper, we propose a low-cost, dual-axis rotation scanning method for a highly curved freeform surface with an arbitrary shape. The optical probe can scan the surface profile while always keeping consistent with the normal vector of the measuring points with the help of the double rotation axis. This method can adapt to the changes in curvature in any direction for a highly curved freeform surface. In addition, the proposed method provides a system error calibration technique for the rotation axis errors. This technique can be used to avoid the dependence of the measuring system on the high-precision platform. The three key system errors that affect the measurement accuracy such as installation error of the B-axis, A-axis, and XZ perpendicularity error are first analyzed through establishing an error model. Then, the real error values are obtained by the optimal calculation in the calibration process. Finally, the feasibility of the measurement method is verified by measuring one cone mirror and an F-theta mirror and comparing the results to those obtained using commercial equipment. The maximum measurable angle of the system is ±90°, the maximum measurable diameter is 100 mm, and the measurement accuracy of the system reaches the micron level in this paper. Full article

With the rapid development of material science, more and more workpieces, especially workpieces with complex curved surfaces, are being made of composite materials. Robotic non-destructive testing (NDT) systems for complex curved surface composite material parts are being used more and more. Despite the emergence of such flexible NDT systems, the detection of semi-enclosed parts is also a challenge for robotic NDT systems. In order to overcome the problem, this paper establishes an NDT solution for semi-enclosed workpieces based on a dual-robot system of synchronous motion, in which an extension arm is installed on one of the robots and presents a trajectory planning method that always ensures the extension arm is parallel to the rotary axis of a semi-enclosed workpiece and that the ultrasonic probes are perpendicular to the workpiece surface. Trajectory analysis experiments and ultrasonic NDT experiments utilizing the optimal water path distance determined by simulation result of multi-Gaussian beam model for two types of semi-enclosed workpieces are performed with the dual-robot NDT system. Experimental results prove that the dual-robot NDT scheme functions well and the planned trajectories are correct. All the hole-shaped artificial defects with diameters ≥3 mm are detected by using 2.25 MHz ultrasonic probes through the transmission testing method. Vivid 3D C-scan image of a small diameter cylindrical workpiece based on the testing result is provided for convenience of observation. Full article
