Blockages in sewers and drains often result in overflows and flooding that cause significant environmental pollution and public health risks, particularly in hospitals, where the consequences can be catastrophic. Due to their low “visibility”, sewers and drains are inherently difficult to monitor and maintain, resulting in a reactive management approach whereby maintenance or repair is carried out only after a system failure has occurred. This paper investigates the feasibility of applying the reflected wave technique, a unique sonar-like monitoring approach capable of identifying changes in the geometry of closed-pipe conduits, as a means of proactive system monitoring. The technique uses a 10 Hz sinusoidal air pressure wave which is transmitted into the drainpipe. When the pressure wave encounters a system boundary, a reflection is generated which alters the measured test pressure response. Analysis of the reflections generated by a changed system boundary, such as the formation of a blockage, can provide information related to the location of that boundary within the system. An experimental setup was developed to simulate a horizontal drain using standard pipework of 100 mm diameter and 70 m length. The technique was able to detect applied blockages with cross-sectional coverage of 30% and 75%, and lengths ranging from 30 mm to 3000 mm. Accuracy was improved when the pressure sensor was positioned closer to the blockage. When the sensor was 3.4 m from the blockage, location estimates were very accurate (−2% to 3% error). At a 14 m distance from the blockage, the error increased to between 4% and 33%. The accuracy of blockage detection and location improved with increasing blockage cross-sectional area and length. Overall, the reflected wave technique could provide a potentially continuous monitoring solution for blockage detection in sewers and drains. Full article

The discharge of groundwater and the load on the lining structure are both significantly impacted by the obstruction of the tunnel drainage system. In this study, the fluid–structure interaction model was established based on the finite difference software FLAC^3D. Then, this research explored the effects of symmetric and asymmetric blockage in the circular drainpipe, the transverse drainpipe and at the pipe joint in the tunnel on the pore water pressure, displacement and stress of surrounding rock. Our research revealed the following points: (1) When a symmetrical or asymmetrical blockage occurred in a circular drainpipe, only the blocked part of the drainpipe would be affected, but the pore water pressure at the back side of the tunnel crown and side wall lining between two adjacent circular drainpipes would increase by 200%, stress increase would increase by 22% and displacement would increase by 41%. (2) When a symmetrical or asymmetrical blockage occurred in a transverse drainpipe, the pore water pressure at the back side of the tunnel crown and side wall lining between two adjacent circular drainpipes increased by a maximum of 146%, the stress on the tunnel crown lining increased by a maximum of 4% and the tunnel crown lining was displaced by 8% to a maximum extent. (3) Both symmetrical and asymmetrical blockage of the tunnel drain joint led to the failures of the circular drainpipe and the transverse drainpipe connected with the tunnel drain joint. This increased the pore water pressure on the back side of the lining between the two adjacent drain sections and had an impact on the pore water pressure, stress and displacement of the surrounding rock nearby. Full article

Crystal blockage of tunnel drainage pipes is one of the main causes of problems such as lining cracking and water leakage. The study of the crystal development rule is of great significance for the design of tunnel drainage systems and the long-term safety of tunnel support structures. In this paper, a series of experimental studies on the crystallization development law of drain pipes are conducted. The effects of the connection method of the drain, the diameter of the pipe, the spacing of the circular drain, and the material of the drain on the crystallization development pattern are investigated. The results show that the groundwater environment has a great influence on the crystallization development of the drain pipe. As the drain diameter and the spacing between two adjacent circular drains increased, the time for complete blockage of the drain is prolonged. The rate of crystallization on the drainage pipe can be effectively reduced by changing the material of the drainage pipe from polyamide (PA) to polypropylene (PP). The present study provides a reference for research work related to crystallization blockage in tunnel drainage pipes. Full article

With the increasing operation time of tunnels, the drainage system cannot fulfil its proper function as a result of the deterioration of traditional waterproof and drainage systems (TWDS), such as the blockage of drainage blind pipes and the failure of drainage boards. Therefore, the lining bears a high water pressure and even causes disasters such as tunnel leakage and lining cracking. An effective solution to mitigate these issues is to adjust the tunnel drainage scheme. In view of this, a composite waterproof and drainage system (CWDS) is proposed in this paper. To verify the effectiveness of the proposed system, a series of model experiments were conducted to study the change law of the seepage field of two drainage systems under different blockage conditions. The study results showed that longitudinal blind pipe blockage caused a more significant increase in water pressure than circular blind pipe blockage. In the case of blind pipe blockage, the water pressure of the TWDS tunnels rise rapidly, while the CWDS tunnels could effectively drain and reduce pressure. Full article

The crystalline blockage of tunnel drainage pipes in a karst area seriously affects the normal operation of drainage system and buries hidden dangers for the normal operation of the tunnel. In order to obtain the influencing factors and laws of tunnel drainage pipe crystallization in a karst area, based on the field investigation of crystallization pipe plugging, the effects of groundwater velocity, drainage pipe diameter, drainage pipe material, and structure on the crystallization law of tunnel drainage pipe in karst area are studied by indoor model test. The results show that: (1) With the increase of drainage pipe diameter (20–32 mm), the crystallinity of drainage pipes first increases and then decreases. (2) With the increase of water velocity in the drainage pipe (22.0–63.5 cm·s⁻¹), the crystallinity of the drainage pipes gradually decreases from 1.20 g to 0.70 g. (3) The crystallinity of existing material drainage pipe is: M3 (poly tetra fluoroethylene) > M2 (pentatricopeptide repeats) > M4 (high density polyethylene) > M1 (polyvinyl chloride); M8 (polyvinyl chloride + coil magnetic field) is used to change the crystallinity of drain pipe wall material. (4) When the groundwater flow rate is 34.5 cm·s⁻¹, M1 (polyvinyl chloride) and M8 (polyvinyl chloride + coil magnetic field) can be selected for the tunnel drainage pipe. The research on the influencing factors of tunnel drainage pipe crystallization plugging fills a gap in the research of tunnel drainage pipe crystallization plugging. The research results can provide a basis for the prevention and treatment technology of tunnel drainage pipe crystallization plugging. Full article

As a solution to avoid the blockage of the drainage pipe by traditional vacuum preloading, step vacuum preloading (SVP) has been progressively studied. However, the effectiveness of this technique has yet to be systematically analyzed. In this study, an indoor model test was conducted in which vacuum pressure was applied in five stages (10, 20, 40, 60, and 80 kPa) to dredger soil with high clay content at a reclamation site in Binhai New Area, Tianjin, China. The extent of the consolidation effect of the soil was determined, and the effectiveness of the step vacuum preloading method to address drainage pipe blockage was evaluated. The results indicate that soil settlement increases at each stage of vacuum pressure treatment and the degree of vertical consolidation at each stage exceeds 90%. At the end of the treatment stage with vacuum pressure of 80 kPa, the weakly bound water was discharged. Dissipation of pore water pressure occurred in all stages. On the basis of these results, it is shown that SVP can efficiently reinforce dredger fill. Moreover, after SVP, the grain size of the soil and void ratio are still uniformly distributed. Regardless of their location from the drainage pipe, soil exhibits permeability coefficients within the same order of magnitude. The consolidation effect of soil in each stage and the increased drainage rate in the initial stage of vacuum preloading with 80 kPa indicate that the test in the current study can decrease the horizontal displacement of fine particles and can avoid drainage pipe blockage. Full article
