Phase wrapping is a common phenomenon in optical full-field imaging or measurement systems. It arises from large phase retardations and results in wrapped-phase maps that contain essential information about surface roughness and topology. However, these maps are often degraded by noise, such as speckle and Gaussian, which reduces the measurement accuracy and complicates phase reconstruction. Denoising such data is a fundamental problem in computer vision and plays a critical role in biomedical imaging modalities like Full-Field Optical Interferometry. In this paper, we propose WPD-Net (Wrapped-Phase Denoising Network), a lightweight deep learning-based neural network specifically designed to restore phase images corrupted by high noise levels. The network architecture integrates a shallow feature extraction module, a series of Residual Dense Attention Blocks (RDABs), and a dense feature fusion module. The RDABs incorporate attention mechanisms that help the network focus on critical features and suppress irrelevant noise, especially in high-frequency or complex regions. Additionally, WPD-Net employs a growth-rate-based feature expansion strategy to enhance multi-scale feature representation and improve phase continuity. We evaluate the model’s performance on both synthetic and experimentally acquired datasets and compare it with other state-of-the-art deep learning-based denoising methods. The results demonstrate that WPD-Net achieves superior noise suppression while preserving fine structural details even with mixed speckle and Gaussian noises. The proposed method is expected to enable fast image processing, allowing unwrapped biomedical images to be retrieved in real time. Full article

In this paper, a generalized-mode phase averaging technique is proposed to suppress air turbulence and random noise in optical shop testing. This approach eliminates the need to repeatedly unwrap and thus greatly improves processing efficiency. By removing the random tilt component of the wrapped phase, a set of wrapped phases that are corrupted by random vibrations can be unified into the same mode, some of which obey a circular distribution. Therefore, the circular mean technique can be used for wrapped phase averaging; only one unwrapping process is required for a set of wrapped phases. A criterion based on maximum likelihood estimation is proposed to determine scenarios for the use of this method. The effects of noise and air disturbances on this method are discussed. Finally, the effectiveness of the method is demonstrated by simulations and experiments. Full article

Weld stability is directly related to the safety and reliability of engineering, and continuous improvement of its detection technology has great research significance. This paper presents a novel method for weld stability detection based on color digital holography. A color digital holography optical path was designed to capture the holograms of welds under varying loads. Several common denoising algorithms were used to deal with speckle noise in the wrapped phase, among which the 4-f optical simulation integrated cycle-consistent generative adversarial network (4f-CycleGAN) denoising algorithm based on deep learning was more suitable for the color digital holographic detection system. The three-dimensional deformation fields of three samples (lap-jointed, butt-jointed, and defective butt-jointed aluminum alloy plates) under different loads were calculated. The center profile of the deformation field in the direction of load and holographic reconstruction images are used to determine the position of the weld. The coefficient of variation near the weld was used to evaluate the weld stability. The coefficient of variation for lap-jointed, butt-jointed and defective butt-jointed plates are 0.0335 (<0.36, good stability), 0.1240 (<0.36, good stability) and 0.3965 (>0.36, poor stability), respectively. The research results of this paper provide a new strategy for detecting weld stability. Full article

Speckle-shearing technology is widely used in defect detection due to its high precision and non-contact characteristics. However, the wrapped-phase recording defect information is often accompanied by a lot of speckle noise, which affects the evaluation of defect information. To solve the problems of traditional denoising algorithms in suppressing speckle noise and preserving the texture features of wrapped phases, this study proposes a speckle denoising algorithm called a speckle denoising convolutional neural network (SDCNN). The proposed method reduces the loss of texture information and the blurring of details in the denoising process by optimizing the loss function. Different from the previous simple assumption that the speckle noise is multiplicative, this study proposes a more realistic wrapped image-simulation method, which has better training results. Compared with representative algorithms such as BM3D, SDCNN can handle a wider range of speckle noise and has a better denoising effect. Simulated and real speckle-noise images are used to evaluate the denoising effect of SDCNN. The results show that SDCNN can effectively reduce the speckle noise of the speckle-shear wrapping phase and retain better texture details. Full article

The interferometric synthetic aperture radar (InSAR) imaging technique computes relative distances or surface maps by measuring the absolute phase differences of returned radar signals. The measured phase difference is wrapped in a 2$\pi$ cycle due to the wave nature of light. Hence, the proper multiple of 2$\pi$ must be added back during restoration and this process is known as phase unwrapping. The noise and discontinuity present in the wrapped signals pose challenges for error-free unwrapping procedures. Separate denoising and unwrapping algorithms lead to the introduction of additional errors from excessive filtering and changes in the statistical nature of the signal. This can be avoided by joint unwrapping and denoising procedures. In recent years, research efforts have been made using deep-learning-based frameworks, which can learn the complex relationship between the wrapped phase, coherence, and amplitude images to perform better unwrapping than traditional signal processing methods. This research falls predominantly into segmentation- and regression-based unwrapping procedures. The regression-based methods have poor performance while segmentation-based frameworks, like the conventional U-Net, rely on a wrap count estimation strategy with very poor noise immunity. In this paper, we present a two-stage phase unwrapping deep neural network framework based on U-Net, which can jointly unwrap and denoise InSAR phase images. The experimental results demonstrate that our approach outperforms related work in the presence of phase noise and discontinuities with a root mean square error (RMSE) of an order of magnitude lower than the others. Our framework exhibits better noise immunity, with a low average RMSE of 0.11. Full article

This paper presents a variational model for the denoising of wrapped phase images. By enforcing the required Pythagorean trigonometric identity between the real and imaginary components of the signal, this model improves the signal-to-noise ratio of the restored signal. To preserve phase map discontinuities, the model is based on total variation. The existence and uniqueness of the model’s solution are demonstrated using standard techniques. In addition, the convergence of a rapid fixed-point method to determine the numerical solution is demonstrated. Experiments on both synthetic and actual patterns validate the model’s performance. Full article

This paper presents a new processing method for denoising interferograms obtained by digital holographic speckle pattern interferometry (DHSPI) to serve in the structural diagnosis of artworks. DHSPI is a non-destructive and non-contact imaging method that has been successfully applied to the structural diagnosis of artworks by detecting hidden subsurface defects and quantifying the deformation directly from the surface illuminated by coherent light. The spatial information of structural defects is mostly delivered as local distortions interrupting the smooth distribution of intensity during the phase-shifted formation of fringe patterns. Distortions in fringe patterns are recorded and observed from the estimated wrapped phase map, but the inevitable electronic speckle noise directly affects the quality of the image and consequently the assessment of defects. An effective method for denoising DHSPI wrapped phase based on deep learning is presented in this paper. Although a related method applied to interferometry for reducing Gaussian noise has been introduced, it is not suitable for application in DHSPI to reduce speckle noise. Thus, the paper proposes a new method to remove speckle noise in the wrapped phase. Simulated data and experimental captured data from samples prove that the proposed method can effectively reduce the speckle noise of the DHSPI wrapped phase to extract the desired information. The proposed method is helpful for accurately detecting defects in complex defect topography maps and may help to accelerate defect detection and characterization procedures. Full article
