Aiming at the problem that the blast load, generated by the explosion of the tandem-shaped-charge warhead, may cause damage to the warhead structure, material failure and even phase change, the material damage and structural protective capacity of the near-field blast load on the sandwich structure with foam-aluminum core were investigated by experimental test and numerical simulation. Firstly, the near-field blast test was performed to observe the deformation of sandwich structure and to collect the acceleration signals of fuze. Then, the mechanical properties of foam materials were tested, and a numerical model of blast load environment was established in the explicit dynamics software ANSYS/LS–DYNA 2020 R2. Finally, the experimental test data and simulation results were compared and analyzed. The strong agreement between the experiment and the simulation results indicates that the calculation method and simulation model are reasonable. Furthermore, the damage mode of foam-aluminum core materials with different densities and cell diameters under near-field blast load were carefully analyzed by simulation method. The simulation results show that, with the decrease of the density of foam-aluminum material and the increase of the cell chamber diameter, the deformation of the foam-aluminum panel gradually increases; the acceleration peak value of the fuze gradually decreases, and the pulse width barely changes and remains basically constant; the start and end times of the peak stress of the fuze cover gradually lag behind, and the peak stress hold-up time increases gradually; the maximum displacement deformation of the fuze cover decreases firstly and then increases. This work is expected to provide basic data and design guidelines for the graded foam sandwich panels of the blasting warhead fuze against the near-field blast load. Full article

To investigate the plastic deformation (PD) response of a liner material during the shaped-charge jet (SCJ) formation process, the state of motion of liner material and the pattern of change in its deformation environment under explosive loading were theoretically analyzed and modeled. The distribution patterns of the characteristic PD parameters (that is, strain, strain rate, temperature, and flow stress) of the jet at any given time were theoretically predicted. The distribution patterns of the characteristic PD parameters of jets formed from two materials, namely, oxygen-free high-thermal-conductivity copper (OFHC-Cu) and molybdenum (Mo), during their formation process were theoretically analyzed. A series of experimental and numerical simulation studies were conducted to examine the accuracy of the theoretical predictions. As per the results, the developed theoretical model is effective in predicting the one-dimensional distribution of the characteristic PD parameters in the direction of jet formation. At any given time, the distribution of the characteristic PD parameters varies considerably between different parts of the jet. There is no significant difference in the distribution of the strain and strain rate between the jets formed from the two materials in the presence of the same warhead structure. A theoretical analysis predicted average temperatures of 804 and 2277.8 K and average flow stresses of 193.1 and 344.3 MPa for the OFHC-Cu and Mo jets, respectively. A hardness analysis of the jet fragments revealed average strengths of 144.32 and 286.66 MPa for the OFHC-Cu and Mo jets during their formation process, respectively. These results differed by 34% and 20% from the corresponding theoretical predictions. Full article

Machining V-shaped grooves to the internal surface of cylindrical shells is one of the most common technologies of controlled fragmentation for improving warhead lethality against targets. The fracture strain of grooved shells is a significant concern in warhead design. However, there is as yet no reasonable theory for predicting the fracture strain of a specific grooved shell; existing approaches are only able to predict this physical regularity of non-grooved shells. In this paper, through theoretical analysis and numerical simulations, a new model was established to study the fracture strain of explosively driven cylindrical shells with internal longitudinal V-grooves. The model was built based on an energy conservation equation in which the energy consumed to create a new fracture surface in non-grooved shells was provided by the elastic deformation energy stored in shells. We modified the energy approach so that it can be applicable to grooved shells by adding the elastic energy liberated for crack penetration and reducing the required fracture energy. Cylinders with different groove geometric parameters were explosively expanded to the point of disintegration to verify the proposed model. Theoretical predictions of fracture strain showed good agreement with experimental results, indicating that the model is suitable for predicting the fracture strain of explosively driven metal cylinders with internal V-grooves. In addition, this study provides an insight into the mechanism whereby geometric defects promote fracturing. Full article

The casing of deformable warheads warps under the action of deforming charges. The deformation profiles may be concave-, convex-, or D-shaped, but they are all symmetrical. The D-shape is considered the optimal deformation profile. The width of the deformed surface affects the number of fragments in the target area. In order to evaluate the deformable surface width of the cylindrical casing, a criterion α was established and its optimum range was determined as 20 to 30%. Based on our previous theoretical analysis, a MATLAB program that can rapidly evaluate the projectile deformation surface was compiled, which was verified using LS-DYNA and experiments. The laws influencing the deforming charge width on the deformed surface of the filled cylindrical casing were also studied using the MATLAB rapid evaluation program. As the deforming charge width increased, the deformation profile of the casing gradually transferred from “inner-concave” to the “outer-convex”. In addition, a formula that can better reflect the relationship between the deforming charge width φ and the criterion value α was fitted and verified. The conclusions obtained in this paper provide rapid guidance for the structural design of deformable warheads. Full article
