Ionospheric disturbances are mainly caused by solar and Earth surface activity. The electromagnetic data collected by the CSES (China Seismo-Electromagnetic Satellite, popularly known as the Zhangheng-1 satellite) can capture many space disturbances. Different spatial disturbances can exhibit distinctive shapes on spectrograms. Constant-frequency electromagnetic disturbances (CFEDs) such as artificially transmitted VLF radio waves, power line harmonics, and satellite platform disturbances can appear as horizontal lines on spectrograms. Therefore, we used computer vision and machine learning techniques to extract the frequency of global CFEDs and analyze their strong spatial signal characteristics. First, we obtained time-frequency spectrograms from CSES VLF electric-field waveform data using Fourier transform. Next, we employed an unsupervised clustering algorithm to automatically recognize CFED horizontal lines on spectrograms, merging horizontal lines from different spectrograms, to obtain the CFED horizontal-line frequency range. In the third stage, we verified the presence of CFEDs in power spectrograms, thus extracting their true frequency values. Finally, for strong CFED signals, we generated eight revisited periods, resulting in 10,230 power spectrograms for analyzing each CFED’s spatial characteristics using a combined periodic sequence and spatial region that included frequency offsets, frequency fluctuations, and signal non-observation areas. These findings contribute to enhancing the quality of CSES observational data and provides a theoretical basis for constructing global CFED spatial background fields and earthquake monitoring and early prediction systems. Full article

The electromagnetic data observed with the CSES (China Seismo-Electromagnetic Satellite, also known as Zhangheng-1 satellite) contain numerous spatial disturbances. These disturbances exhibit various shapes on the spectrogram, and constant frequency electromagnetic disturbances (CFEDs), such as artificially transmitted very-low-frequency (VLF) radio waves, power line harmonics, and interference from the satellite platform itself, appear as horizontal lines. To exploit this feature, we proposed an algorithm based on computer vision technology that automatically recognizes these lines on the spectrogram and extracts the frequencies from the CFEDs. First, the VLF waveform data collected with the CSES electric field detector (EFD) are converted into a time–frequency spectrogram using short-time Fourier Transform (STFT). Next, the CFED automatic recognition algorithm is used to identify horizontal lines on the spectrogram. The third step is to determine the line frequency range based on the proportional relationship between the frequency domain of the satellite’s VLF and the height of the time–frequency spectrogram. Finally, we used the CSES power spectrogram to confirm the presence of CFEDs in the line frequency range and extract their true frequencies. We statistically analyzed 1034 orbit time–frequency spectrograms and power spectrograms from 8 periods (5 days per period) and identified approximately 200 CFEDs. Among them, two CFEDs with strong signals persisted throughout an entire orbit. This study establishes a foundation for detecting anomalies due to artificial sources, particularly in the study of short-term strong earthquake prediction. Additionally, it contributes to research on other aspects of spatial electromagnetic interference and the suppression and cleaning of electromagnetic waves. Full article

Since the CSES (China Seismo-Electromagnetic Satellite) has been in orbit, it has detected a large number of constant-frequency electromagnetic disturbances (CFEDs), which are horizontal lines on the spectrum. In this paper, we present an algorithm for automatic recognition of CFEDs based on computer vision technology. The relevant results are of great significance for analysis of perturbation events and mining of the transformation laws of global space events. First, a grayscale spectrogram is obtained; then, a horizontal convolution kernel is used to enhance the horizontal edge features of the grayscale graph, and finally, black-and-white binarization is performed to complete data preprocessing. The preprocessed data are then fed into an unsupervised cluster model for training and recognition to realize automatic recognition of CFEDs. Experimental results show that the CFED recognition algorithm proposed in this paper is effective, with a recognition accuracy of more than 98%. Full article
