Tonal powertrain noise can have a strong negative impact on passengers’ quality and comfort perception in the interior of electric vehicles. Therefore, in the vehicle development process, the assessment of the perceptibility of tonal powertrain noise is essential. As wind and tire noise can possibly mask tonal noises, engineers use modern masking models to determine the masking threshold of tonal powertrain noise from vehicle interior measurements. In the presently used method, the masking threshold is mostly generated with torque-free deceleration measurements. However, the influence of torque on masking tire noise must be considered. As this requires time-consuming and costly road measurements, an extension of the method is being developed, which will also enable the use of roller dynamometer measurements for the assessment. For the extension of the method, however, the influence of the torque must also be considered. This paper presents a novel calculation method that quantifies the influence of torque on the masking threshold and converts masking thresholds from an arbitrary torque level to another. By identifying the frequency and speed range that is mainly affected by the torque-dependent tire noise, a regression model with respect to the tractive force on the tires can be used to calculate a torque-dependent correction factor. The developed method can significantly improve the validity of masking thresholds and quantitatively, the method generalizes well across different vehicle segments. The error can be reduced to below 2 dB above 2000 rpm and to below 1 dB above 4000 rpm. By using this method, more valid target level settings for tonal powertrain noise can be derived. Full article

The transition to alternative electrical energy solutions for drone propulsion systems presents several challenges, particularly in managing noise. This noise, compounded by that from the propellers, can produce spectra that are either unpleasant to humans or detrimental to mission objectives. This study explores potential solutions to mitigate noise produced by a micro turboshaft engine, focusing on the solutions’ impact on weight, power output, and acoustic level. We propose two modular, scalable designs—one for the intake and one for the exhaust—based on well-known applications in cold and hot flows. These designs aim to operate effectively across the audible frequency spectrum and incorporate various Helmholtz resonator geometries, including combinations of different lengths, perforated metal sheet parameters, and cavity-filling materials, to enhance bandwidth and noise reduction. Experimental results indicate that these designs can achieve tonal noise reductions of up to 40 dB. While the results are promising, further analysis is required to evaluate the practical applicability and comprehensive impact of these solutions on drone performance. Full article

Tonal powertrain noise can have a strong negative impact on vehicle sound quality. Therefore, an assessment of the perceptibility of tonal noise with respect to masking noise is essential for the vehicle development process. In electric vehicles, due to the missing masking by the combustion engine, new methods are required for this purpose. In this study, listening tests were conducted to determine the masking threshold in the electric vehicle interior for various driving speeds (30 km/h, 60 km/h, and 90 km/h) with an Adaptive-Forced-Choice method. The novelty of this study is that it used vehicle interior noise as a masker, compared to broadband or narrowband white and pink noises. It could be shown that the masking threshold in electric vehicles strongly depends on the driving speed, and the investigated interior noise mainly affects frequencies up to 6400 Hz in this speed range. For frequencies greater than 6400 Hz, the masking noise has no significant effect on perceptibility of tonal noise in the investigated vehicle, and only the subjects’ individual absolute threshold of hearing is relevant. Additionally, a strong variation in the masking threshold between the subjects was found for high frequencies. With these results, methods that estimate masking thresholds in electric vehicles can be improved. Furthermore, threshold targets can be adjusted for different customer groups. Full article

Low-frequency audible noise generated by the magnetostriction effect inherent to the operation of power transformers has become a major drawback, especially in cases where the electrical substation is located in urban areas subject to strict environmental regulations that impose noise limits, differing for day and night periods. Such regulations apply a +5 dB penalty if a tonal component of noise is present, which is clearly the case of magnetostriction noise, typically concentrated at twice the industrial frequency (50 Hz or 60 Hz, depending on the country). The strategy used to eliminate the tonal characteristics, therefore contributing to establish compliance with the applicable regulation and to alleviate the discomfort it causes to the human ear, consisted in superimposing to the substation noise a masking sound synthesized from “sounds of nature” with suitable intensities, to flatten the noise spectrum while enhancing the soundscape. The masking system (heavy-duty speakers powered by a microprocessor platform) was validated at an already judicialized urban scenario. Measurement results confirmed that the masking solution was capable of flattening the tonal frequencies, whose beneficial effect yielded the cancellation of the public civil action filed by the neighbors. The proposed solution is ready to be replicated in other scenarios. Full article

Recently in Japan, noises from wind turbines and domestic use heat sources sometimes cause an increase in noise annoyance owing to low-frequency tonal components. The purpose of this study was to investigate the effects of the tonal components on the annoyance of the environmental noise. The authors conducted an auditory test in the laboratory to evaluate the annoyance of tonal noise using a seven-step rating method. The stimuli were composed of a broadband noise modeling of the environmental noise (25, 30, and 35 dB) and a low-frequency tonal component. With the tonal component added to the broadband noise, the frequency and tonal audibility were varied to 40, 50, 100, 200, and 400 Hz and 0, 3, 6, 9, and 12 dB, respectively. The amount of increase in annoyance owing to the addition of the tonal component was quantitatively evaluated as a tonal adjustment by comparing it with broadband noise. As a result, tonal adjustment ranged from 0 to 7 dB, and the higher the tonal frequency, the larger the value. For the test background noise level, the lower the background noise level of the test sound, the greater the value. This trend suggests that the influence of tonal components on subjective impressions is stronger in quiet environments such as residential areas. This result may provide a basis for the evaluation method, which varies the penalty in the noise evaluation according to the frequency of the pure tones and the noise level. Full article

Vertical axis wind turbines (VAWT) are a source of renewable energy and are used for both industrial and domestic purposes. The study of noise characteristics of a VAWT is an important performance parameter for the turbine. This study focuses on the development of a linear microphone array and measuring acoustic signals on a cambered five-bladed 45 W VAWT in an anechoic chamber at different tip speed ratios. The sound pressure level spectrum of VAWT shows that tonal noises such as blade passing frequencies dominate at lower frequencies whereas broadband noise corresponds to all audible ranges of frequencies. This study shows that the major portion of noise from the source is dominated by aerodynamic noises generated due to vortex generation and trailing edge serrations. The research also predicts that dynamic stall is evident in the lower Tip speed ratio (TSR) region making smaller TSR values unsuitable for a quiet VAWT. This paper compares the results of linear aeroacoustic array with a 128-MEMS acoustic camera with higher resolution. The study depicts a 3 dB margin between two systems at lower TSR values. The research approves the usage of the 8 mic linear array for small radius rotary machinery considering the results comparison with a NORSONIC camera and its resolution. These observations serve as a basis for noise reduction and blade optimization techniques. Full article

Increasing quality demands of combustion engines require, amongst others, improvements of the engine’s acoustics and all (sub)components mounted to the latter. A significant impact to the audible tonal noise spectrum results from the vibratory motions of fast-rotating turbocharger rotor systems in multiple hydrodynamic bearings such as floating bearing rings. Particularly, the study of self-excited non-linear vibrations of the rotor-bearing systems is crucial for the understanding, prevention or reduction of the noise and, consequently, for a sustainable engine acoustics development. This work presents an efficient modeling approach for the investigation, optimization, and design improvement of complex turbocharger rotors in hydrodynamic journal bearings, including floating bearing rings with circular and non-circular bearing geometries. The capability of tonal non-synchronous vibration prevention using non-circular bearing shapes is demonstrated with dynamic run-up simulations of the presented model. These findings and the performance of our model are compared and validated with results of a classical Laval/Jeffcott rotor-bearing model and a specific turbocharger model found in the literature. It is shown that the presented simulation method yields fast and accurate results and furthermore, that non-circular bearing shapes are an effective measure to reduce or even prevent self-excited tonal noise. Full article
