Load Rejection Overvoltage Suppression and Parameter Design Method of UHV AC Transmission Line
by Guanqun Sun, Wang Ma, Yingge Wang, Dian Xu, Haiguang Liu, Rusi Chen and Yixing Ding
Electronics 2025, 14(3), 619; https://doi.org/10.3390/electronics14030619 - 5 Feb 2025
Viewed by 1143
Abstract
UHV (ultra-high voltage) by instant AC transmission system is accompanied by huge reactive power transmission. When the load drops sharply, it is easy to produce serious power frequency overvoltage, which is also defined as load rejection overvoltage. This paper makes an in-depth analysis [...] Read more.
UHV (ultra-high voltage) by instant AC transmission system is accompanied by huge reactive power transmission. When the load drops sharply, it is easy to produce serious power frequency overvoltage, which is also defined as load rejection overvoltage. This paper makes an in-depth analysis from the perspective of voltage increase caused by instantaneous load unloading, and obtains the causes and key influencing factors of load rejection overvoltage. Taking the UHV AC transmission line of a practical project as an example, the suppression effect of the suppression strategy represented by the installation of opening resistance and shunt reactor on the load rejection overvoltage is analyzed. The simulation results show that the above method has an obvious inhibitory effect on load rejection overvoltage. Based on the optimal suppression principle, the optional interval range of the opening resistance and shunt reactor parameters are designed. Full article
(This article belongs to the Special Issue Advanced Online Monitoring and Fault Diagnosis of Power Equipment)
Show Figures

Figure 1

29 pages, 4359 KiB
Review
Electric Power Network Interconnection: A Review on Current Status, Future Prospects and Research Direction
by Imdadullah, Basem Alamri, Md. Alamgir Hossain and M. S. Jamil Asghar
Electronics 2021, 10(17), 2179; https://doi.org/10.3390/electronics10172179 - 6 Sep 2021
Cited by 46 | Viewed by 11273
Abstract
An interconnection of electric power networks enables decarbonization of the electricity system by harnessing and sharing large amounts of renewable energy. The highest potential renewable energy areas are often far from load centers, integrated through long-distance transmission interconnections. The transmission interconnection mitigates the [...] Read more.
An interconnection of electric power networks enables decarbonization of the electricity system by harnessing and sharing large amounts of renewable energy. The highest potential renewable energy areas are often far from load centers, integrated through long-distance transmission interconnections. The transmission interconnection mitigates the variability of renewable energy sources by importing and exporting electricity between neighbouring regions. This paper presents an overview of regional and global energy consumption trends by use of fuel. A large power grid interconnection, including renewable energy and its integration into the utility grid, and globally existing large power grid interconnections are also presented. The technologies used for power grid interconnections include HVAC, HVDC (including LCC, VSC comprising of MMC-VSC, HVDC light), VFT, and newly proposed FASAL are discussed with their potential projects. Future trends of grid interconnection, including clean energy initiatives and developments, UHV AC and DC transmission systems, and smart grid developments, are presented in detail. A review of regional and global initiatives in the context of a sustainable future by implementing electric energy interconnections is presented. It presents the associated challenges and benefits of globally interconnected power grids and intercontinental interconnectors. Finally, in this paper, research directions in clean and sustainable energy, smart grid, UHV transmission systems that facilitate the global future grid interconnection goal are addressed. Full article
Show Figures

Figure 1

13 pages, 6296 KiB
Article
Experimental Assessment on Air Clearance of Multiple Valve Unit Considering Switching Impulse and DC Superimposed Switching Impulse
by Jae-Hong Koo, Jae-Kyu Seong, Ryul Hwang and Bang-Wook Lee
Energies 2020, 13(11), 2958; https://doi.org/10.3390/en13112958 - 9 Jun 2020
Cited by 2 | Viewed by 2326
Abstract
Multiple valve unit (MVU), which converts AC to DC and DC to AC, is one of the key elements of high voltage DC (HVDC) transmission. Therefore, the insulation design of MVU against overvoltage should be considered for the stable and reliable operation of [...] Read more.
Multiple valve unit (MVU), which converts AC to DC and DC to AC, is one of the key elements of high voltage DC (HVDC) transmission. Therefore, the insulation design of MVU against overvoltage should be considered for the stable and reliable operation of HVDC transmission system. Especially, the air clearance of MVU should be calculated based the switching impulse, since it is fatal to MVU in terms of electrical insulation. However, the previous studies were limited to wave front, and the air clearance of the switching impulse is specified only for an ultra-high voltage (UHV) above 750 kV. As a result, it is difficult to calculate the air clearance of MVU which must endure for a switching impulse under 750 kV. In addition, when the switching impulse introduced while the MVU is in normal operation, it is superimposed to DC and creates the most severe situation, but the studies on such subjects are also insufficient. Therefore, as a fundamental step to calculate the air clearance of MVU, the dielectric characteristics of switching impulse and DC superimposed switching impulse in air have been investigated. The experiments on switching impulse showed that the critical flashover voltage was varied according to the curvature of electrode in the gap distance, up to eight times of the electrode radius. However, beyond that gap distance, the critical flashover voltage became similar, regardless of the radius of electrodes. In case of the superimposed experiment, it was performed according to DC pre-stress level and the polarities of switching impulse. The results were most severe when the positive switching impulse was superimposed on the positive DC, and the peak voltage at which flashover occurs was independent of DC pre-stress. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1

14 pages, 1967 KiB
Article
AC Tie-Line Power Oscillation Mechanism and Peak Value Calculation for a Two-Area AC/DC Parallel Interconnected Power System Caused by LCC-HVDC Commutation Failures
by Li Sun, Hongbo Liu and Chenglian Ma
Energies 2020, 13(5), 1221; https://doi.org/10.3390/en13051221 - 6 Mar 2020
Cited by 5 | Viewed by 2678
Abstract
With the rapid development of ultra-high-voltage (UHV) AC/DC, especially the step-by-step upgrading of the UHV DC transmission scale, security presents new challenges. Commutation failure (CF) is a common fault in line commutated converter (LCC) high-voltage direct current (HVDC) power systems. Once failure happens, [...] Read more.
With the rapid development of ultra-high-voltage (UHV) AC/DC, especially the step-by-step upgrading of the UHV DC transmission scale, security presents new challenges. Commutation failure (CF) is a common fault in line commutated converter (LCC) high-voltage direct current (HVDC) power systems. Once failure happens, it may cause power oscillations in a system. In this paper, taking a two-area AC/DC parallel interconnected power system as the example, based on the impulse response model of second-order linear system, the mechanism of power oscillation on the AC tie-line caused by CF are clarified. It is proved that the peak value of the AC tie-line power oscillation is mainly determined by the DC power and the equivalent CF duration, the frequency and damping ratio of dominant area oscillation mode. Meanwhile, the peak time is mainly determined by the oscillation frequency. Finally, the correctness and effectiveness of the algorithms are verified by a simulation analysis of an extended IEEE-39-bus AC/DC parallel interconnected power system. These research results can provide a basis for the arrangement of the operating modes and the formulation of control measures for interconnected power grids. Full article
Show Figures

Graphical abstract

11 pages, 1743 KiB
Article
Insulation Reconstruction for OPGW DC De-Icing and Its Influence on Lightning Protection and Energy Conservation
by Xiangxin Li, Ming Zhou, Yazhou Luo, Chao Xia, Bin Cao and Xiujuan Chen
Energies 2018, 11(9), 2441; https://doi.org/10.3390/en11092441 - 14 Sep 2018
Cited by 6 | Viewed by 3074
Abstract
In order to satisfy demands for DC de-icing of optical fiber composite overhead ground wire (OPGW) and solve questions such as those relating to circulating current loss and liability of suffering from lightning strike, the grounding method of OPGW must be changed from [...] Read more.
In order to satisfy demands for DC de-icing of optical fiber composite overhead ground wire (OPGW) and solve questions such as those relating to circulating current loss and liability of suffering from lightning strike, the grounding method of OPGW must be changed from the current commonly used method of being grounded at every tower to being grounded at one tower. The OPGW would be connected to the tower by an insulator, which is often shunt connected with a protective discharge clearance. The recommended value of the discharge clearance is from 70 to 80 mm. The lightning impulse discharge voltage of such a clearance is generally not more than 100 kV. However, as the transmission line is struck by lightning, over-voltage on the clearance is 885 kV at least, even up to a few MV. The clearance can be broken down reliably. The influence of insulation reconstruction for OPGW on the induced current and the power loss of the AC transmission line was studied by means of theoretical analysis and simulation calculations. Results indicate that change of the OPGW grounding mode could reduce the induced current of the ground wire to below 1 A and reduce the power loss of the line to below 1 W/km. Power loss could be reduced by over 99%. Adoption of a suitable grounding mode for OPGW is of great significance for DC de-icing, lightning protection safety, and energy savings for UHV projects. Full article
Show Figures

Figure 1

11 pages, 4432 KiB
Article
Alternating Current Discharge Characteristics and Simulation Analysis of Rod-Plane Short Air Gaps under Salt Fog Conditions
by Yunpeng Liu, Shuo Jiang, Zheng Zhong, Jianghai Geng and Fangcheng Lv
Energies 2018, 11(9), 2251; https://doi.org/10.3390/en11092251 - 27 Aug 2018
Cited by 3 | Viewed by 3322
Abstract
In this paper, smog meteorological conditions in the natural environment is simulated by the salt fog method. The study of the alternating current (AC) discharge characteristics of rod-plane short air gaps in salt fog environments has important guiding significance for how to strengthen [...] Read more.
In this paper, smog meteorological conditions in the natural environment is simulated by the salt fog method. The study of the alternating current (AC) discharge characteristics of rod-plane short air gaps in salt fog environments has important guiding significance for how to strengthen the external insulation strength of ultra-high voltage (UHV) transmission lines and electrical equipment in smog environments. The rod-plane short air gap is selected as the model to simulate the extremely uneven electric field. The AC discharge test is carried out in the salt fog environment with different conductivity, and the finite element method (FEM) is used to simulate the distribution of electric field in air gap under salt fog environment conditions. The results show that under clean fog conditions the AC discharge voltage in the air gap increased by 15.1% to 35.5% compared to that under dry conditions. With the increased conductivity of salt fog, the AC discharge voltage in air gap decreased by 4.1% to 9.2% compared to that under clean fog conditions, and the reduction is within 10%. The distortion of the electric field and the adsorption of free electrons in the gap by droplets lead to the decrease of the electric field intensity in the air gap. With the increase of the conductivity, the electric field intensity in the air gap increases slightly. Meanwhile, the influence of salt fog and its conductivity on the AC discharge voltage of rod-plane short air gap is examined, becoming saturated with the increase of the gap distance and the conductivity of salt fog. Full article
Show Figures

Figure 1

12 pages, 3761 KiB
Article
Audible Noise Performance of Conductor Bundles Based on Cage Test Results and Comparison with Long Term Data
by Baoquan Wan, Wangling He, Chunming Pei, Xiaorui Wu, Yuchao Chen, Yemao Zhang and Lei Lan
Energies 2017, 10(7), 958; https://doi.org/10.3390/en10070958 - 10 Jul 2017
Cited by 18 | Viewed by 4646
Abstract
A reasonable acoustic power formula is vital to precisely evaluate the audible noise (AN) level of ultra-high-voltage (UHV) AC power lines. This study derived a formula by taking several AN measurements under heavy rain conditions, using multiple conductor bundles in a UHV corona [...] Read more.
A reasonable acoustic power formula is vital to precisely evaluate the audible noise (AN) level of ultra-high-voltage (UHV) AC power lines. This study derived a formula by taking several AN measurements under heavy rain conditions, using multiple conductor bundles in a UHV corona cage, and then subjecting these measured values to least squares fitting. The validity of the proposed formula was subsequently verified with statistical data obtained from two long-term stations at Henan and Hubei Province, which are located under the Jindongnan-Nanyang-Jingmen UHV AC transmission lines operating at 1000 kV. The deviation between the prediction and the long-term (L50) value was 0.76 dB for the Henan station and 0.17 dB for the Hubei station. It shows that the acoustic power formula derived in this paper is more accurate than the widely used Bonneville Power Administration formula, in which the corresponding deviations are much larger (3.07 and 2.53 dB). Full article
(This article belongs to the Section F: Electrical Engineering)
