The operations of electricity and natural gas transmission networks in the U.S. are increasingly interdependent, due to the growing number of installations of gas fired generators and the penetration of renewable energy sources. This development suggests the need for closer communication and coordination between gas and power transmission system operators in order to improve the efficiency and reliability of the combined energy system. In this paper, we present a co-simulation platform for examining the interdependence between natural gas and electricity transmission networks based on a direct current unit-commitment and economic dispatch model for the power system and a transient hydraulic gas model for the gas system. We analyze the value of day-ahead coordination of power and natural gas network operations and show the importance of considering gas system constraints when analyzing power systems operation with high penetration of gas generators and renewable energy sources. Results show that day-ahead coordination contributes to a reduction in curtailed gas during high stress periods (e.g., large gas offtake ramps) and a reduction in energy consumption of gas compressor stations. Full article

Gas and power networks are tightly coupled and interact with each other due to physically interconnected facilities. In an integrated gas and power network, a contingency observed in one system may cause iterative cascading failures, resulting in network wide disruptions. Therefore, understanding the impacts of the interactions in both systems is crucial for governments, system operators, regulators and operational planners, particularly, to ensure security of supply for the overall energy system. Although simulation has been widely used in the assessment of gas systems as well as power systems, there is a significant gap in simulation models that are able to address the coupling of both systems. In this paper, a simulation framework that models and simulates the gas and power network in an integrated manner is proposed. The framework consists of a transient model for the gas system and a steady state model for the power system based on AC-Optimal Power Flow. The gas and power system model are coupled through an interface which uses the coupling equations to establish the data exchange and coordination between the individual models. The bidirectional interlink between both systems considered in this studies are the fuel gas offtake of gas fired power plants for power generation and the power supply to liquefied natural gas (LNG) terminals and electric drivers installed in gas compressor stations and underground gas storage facilities. The simulation framework is implemented into an innovative simulation tool named SAInt (Scenario Analysis Interface for Energy Systems) and the capabilities of the tool are demonstrated by performing a contingency analysis for a real world example. Results indicate how a disruption triggered in one system propagates to the other system and affects the operation of critical facilities. In addition, the studies show the importance of using transient gas models for security of supply studies instead of successions of steady state models, where the time evolution of the line pack is not captured correctly. Full article
