Effect of Potassium Formate on Alkali–Silica Reaction in Aggregates with Different Categories of Reactivity †
Abstract
:1. Introduction
2. Materials
3. Methods
4. Results and Discussion
5. Conclusions
- -
- The presence of reactive minerals: micro- and cryptocrystalline quartz was found in the quartzite and granite aggregate. In addition, strained quartz was present in one granite aggregate.
- -
- The accelerated mortar bar test confirmed different categories of reactivity of the tested aggregate.
- -
- Regardless of the aggregate reactivity category, the mortar bars stored in the 50% potassium formate solution reached very high expansion values, including granite G1 with the R0 reactivity category.
- -
- Reduction in the expansion rate of quartzite aggregate in potassium formate solution was probably associated with the depletion of fast-reacting minerals (micro- and cryptocrystalline quartz). Such phenomena were not observed in mortars with granite aggregate, in which strained quartz (a slow-reacting mineral) was the main reactive mineral.
- -
- The presence of ASR products was found in all analyzed mortar bar specimens.
- -
- The chemical composition of the gel varied depending on the mortar storage solution (NaOH, HCOOK). The gel identified in the cracks of aggregate grains in the mortar in the potassium formate solution was characterized by a higher alkali content, specifically potassium.
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
- Stanton, T.E. Expansion of concrete through reactionn between cement and aggregate. Proc. Am. Soc. Civ. Eng. 1940, 66, 1781–1811. [Google Scholar]
- Fournier, B.; Bérubé, M.A. Alkali-aggregate reaction in concrete: A review of basic concepts and engineering implications. Can. J. Civ. Eng. 2000, 27, 167–191. [Google Scholar] [CrossRef]
- Wang, K.; Nelsen, D.E.; Nixon, W.A. Damaging effects of deicing chemicals on concrete materials. Cem. Concr. Compos. 2006, 28, 173–188. [Google Scholar] [CrossRef]
- Giebson, C.; Seyfarth, K.; Stark, J. Influence of acetate and formate-based deicers on ASR in airfield concrete pavements. Cem. Concr. Res. 2010, 40, 537–545. [Google Scholar] [CrossRef]
- Jain, J.; Olek, J.; Janusz, A.; Jóźwiak-Niedźwiedzka, D. Effects of Deicing Salt Solutions on Physical Properties of Pavement Concretes. Transp. Res. Rec. 2012, 2290, 69–75. [Google Scholar] [CrossRef]
- Broekmans, M.A.T.M. Deleterious Reactions of Aggregate With Alkalis in Concrete. Rev. Mineral. Geochem. 2012, 74, 279–364. [Google Scholar] [CrossRef]
- Kowalska, D.; Pietruszewski, P. Wpływ środków odladzających na beton przeznaczony na nawierzchnie lotniskowe. In Dni Betonu, Monografie Technologii Betonu; Stowarzyszenie Producentów Cementu: Krakow, Poland, 2016; Volume 2, pp. 111–129. [Google Scholar]
- Rangaraju, P.R.; Sompura, K.R.; Olek, J. Investgation into Potential of Alkali-Acetate-Based Deicers to Cause Alkali-Silica Reaction in Concrete. Transp. Res. Rec. 1979, 1, 69–78. [Google Scholar]
- Fernandes, I.; Noronha, F.; Teles, M. Microscopic analysis of alkali-aggregate reaction products in a 50-year-old concrete. Mater. Charact. 2004, 53, 295–306. [Google Scholar] [CrossRef]
- Procedura Badawcza GDDKiA PB/1/18, Instrukcja badania reaktywności kruszyw metodą przyspieszoną w 1M roztworze NaOH w temperaturze 80 °C. 2018. Available online: https://www.gov.pl/web/gddkia/reaktywnosc-kruszyw (accessed on 15 February 2022).
- Garbacik, A.; Glinicki, M.A.; Jóźwiak-Niedźwiedzka, D.; Adamski, G.; Gibas, K. Technical Guidelines for the Classification of Domestic Aggregates and Prevention of the Alkali-Aggregate Reaction in Concrete Used in Road Pavements and Road Engineering Facilities, The Institute of Ceramics and Building Materials, Institute of Fundamental Technological Research Polish Academy of Sciences. 2019. Available online: https://www.gddkia.gov.pl/pl/1118/dokumenty-techniczne (accessed on 15 February 2022). (In Polish)
- ASTM Standard C 1260; Standard Test Method for Potential Alkali Reactivity of Aggregates (Mortar-Bar Method). ASTM International: West Conshohocken, PA, USA, 2016.
- AC 150/5370-10H; FAA Advisory Circular: Standard Specifications for Construction of Airports (Item P-501 Cement Concrete Pavement). Mead & Hunt: Watertown, SD, USA, 2018.
- Shayan, A. Alkali reactivity of deformed granitic rocks: A case study. Cem. Concr. Res. 1993, 23, 1229–1236. [Google Scholar] [CrossRef]
- Antolik, A.; Jóźwiak-Niedźwiedzka, D. Assessment of the alkali-silica reactivity potential in granitic rocks. Constr. Build. Mater. 2021, 295, 123690. [Google Scholar] [CrossRef]
- Velasco-Torres, A.; Alaejos, P.; Soriano, J. Comparative study of the alkali-silica reaction (ASR) in granitic aggregates. Estud. Geol. 2010, 66, 105–114. [Google Scholar] [CrossRef]
- Desai, J. Investigation into Mitigation of Alkali-Silica Reaction Using Selected SCMs in Presence of Potassium Acetate Deicer. Ph.D. Thesis, Clemson University, Clemson, SC, USA, 2007. Volume 139. p. 307. [Google Scholar]
- Rangaraju, P.R. Mitigation of ASR in Presence of Pavement Deicing Chemicals; IPRF 01-G-002-04-8; Innovative Pavement Research Foundation: Skokie, IL, USA, 2007; p. 99. [Google Scholar]
- Leemann, A.; Shi, Z.; Lindgård, J. Characterization of amorphous and crystalline ASR products formed in concrete aggregates. Cem. Concr. Res. 2020, 137, 106190. [Google Scholar] [CrossRef]
Category of ASR Reactivity | Reactivity | 14-Day Expansion [%] |
---|---|---|
R0 | Non-reactive | ≤0.10 |
R1 | Moderately reactive | >0.10; ≤0.30 |
R2 | Highly reactive | >0.30; ≤0.45 |
R3 | Very highly reactive | >0.45 |
