Article

Statistical Evaluation of the Perpendicularity of Boreholes in Concrete for Post-Installed Fasteners

Institute of Structural Engineering, Department of Civil Engineering and Natural Hazards, University of Natural Resources and Life Science (BOKU), Vienna 1190, Austria
*
Author to whom correspondence should be addressed.
CivilEng 2020, 1(3), 253-263; https://doi.org/10.3390/civileng1030016
Received: 8 October 2020 / Revised: 29 October 2020 / Accepted: 30 October 2020 / Published: 31 October 2020
(This article belongs to the Special Issue Connections in Concrete)
The form and the perpendicularity of boreholes influence the ultimate behaviour of post-installed fasteners and are restricted with regard to the concrete surface to 5° in Europe and to 6° in the United States in various regulations (e.g., EAD 330232-00-0601 resp. ACI 355.2-19). It is assumed that the deviation of the borehole from the vertical axis has an effect on the load transfer behaviour of an anchorage. This article investigates on the perpendicularity of vertically downward drilled boreholes using different drilling tools considering hammer drilling, hollow drilling and diamond core drilling. It can be shown that the requirements of e.g., EAD 330232-00-0601 of a maximum deviation to the concrete surface of 5° can be fulfilled for approximately 95% of the determined values for different drilling methods. This is based on a considerable number of measurements (generated from drilled boreholes) in different concrete types. As a result, a detailed statistical evaluation is provided to describe the borehole perpendicularity by means of statistical methods. View Full-Text
Keywords: fastening systems; perpendicularity of boreholes; drilling methods; drilled concrete boreholes fastening systems; perpendicularity of boreholes; drilling methods; drilled concrete boreholes
Show Figures
