Hybrid Atmosphere Processing of Lead-Free Piezoelectric Sodium Potassium Niobate-Based Ceramics

Department of Energy Conversion and Storage, Technical University of Denmark, Frederiksborgvej 399, 4000 Roskilde, Denmark
Ceramics 2019, 2(3), 460-471;
Received: 20 May 2019 / Revised: 11 June 2019 / Accepted: 5 July 2019 / Published: 17 July 2019
PDF [10560 KB, uploaded 17 July 2019]


K0.5Na0.5NbO3-based ceramics, a promising group of lead-free piezoelectrics, are challenging to sinter dense while avoiding alkali evaporation. This work explores hybrid atmosphere processing, a new approach where reducing atmospheres is used during heating to avoid coarsening from alkali carbonates and hydroxides, and oxidizing atmospheres is used during sintering to avoid alkali evaporation. Discs of Li0.06(K0.52Na0.48)0.94Nb0.71Ta0.29O3 with 0.25 mol% Mn (KNNLTM) were sintered in air, N2, 9% H2 in N2, or 9% H2 in N2 during heating and air during sintering (hybrid atmosphere processing). The highest density was obtained by sintering in 9% H2 in N2, but resulted in high alkali loss and decomposition of the surface, followed by low piezoelectric response. However, with the hybrid H2/air processing it was possible to both avoid surface decomposition and leakage currently associated with alkali evaporation during sintering in H2, and to obtain a denser, more phase-pure and small-grained KNNLTM ceramic with a higher piezoelectric response than obtained by sintering in air or N2. View Full-Text
Keywords: piezoelectrics; ferroelectrics; lead-free ceramics; sintering; microstructure piezoelectrics; ferroelectrics; lead-free ceramics; sintering; microstructure

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
