The Integration of Vacuum Insulated Glass in Unitized Façade for the Development of Innovative Lightweight and Highly Insulating Energy Efficient Building Envelope—The Results of Eensulate Façade System Design

R&D Department and Innovation Department, Focchi S.p.A., 47824 Poggio Torriana, Italy
*
Author to whom correspondence should be addressed.
Designs 2020, 4(4), 40; https://doi.org/10.3390/designs4040040
Received: 18 August 2020 / Revised: 17 September 2020 / Accepted: 22 September 2020 / Published: 24 September 2020
The European Commission has identified the building industry as one of the key sectors to achieve its 2020 strategy to create conditions for smart, sustainable, and inclusive growth. In this frame, the aim of Horizon 2020′s Eensulate project is the development of innovative lightweight and highly insulating energy efficient unitized building façades, suitable for both new and existing buildings. The Eensulate façade module integrates two components developed within the project: Vacuum Insulated Glass (VIG) for architectural purposes, with a U-value of 0.3 W/sqm∙K; a highly insulating foam for automated manufacturing and insulation for the spandrel part. This article presents the Eensulate façade system design simulations and achievements related to VIG integration to solve issues that emerged by the utilization of its innovative components (sealant thermal bridge and getter strips). VIG design and testing have gradually changed the façade module and consequently, façade components have been progressively designed to achieve the expected target of 0.641 W/sqm∙K for thermal transmittance. The results demonstrate that the target can be achieved by aluminum profiles, Ethylene Propylene Diene Monomer (EPDM) thermal bridge, and additional insulating components, obtaining a new product for unitized façades able to reduce energy consumption in buildings with large glass surfaces. View Full-Text
Keywords: vacuum insulted glass; sealant; unitized façade; glazed building; energy efficiency; lightweight; retrofitting; new construction vacuum insulted glass; sealant; unitized façade; glazed building; energy efficiency; lightweight; retrofitting; new construction
