Article

Retrospective Study of Functional and Esthetic Outcomes Using Narrow-Diameter Implants for Single Upper Central Incisor Replacements

by
Eduardo Anitua
1,2,*,
Aitana Tarazona
1 and
Mohammad Hamdan Alkhraisat
1,2,3
1
University Institute for Regenerative Medicine and Oral Implantology—UIRMI (UPV/EHU-Fundación Eduardo Anitua), 01007 Vitoria, Spain
2
BTI Biotechnology Institute, 01005 Vitoria, Spain
3
Oral and Maxillofacial Surgery, Oral Medicine and Periodontics Department, Faculty of Dentistry, University of Jordan, Amman 11942, Jordan
*
Author to whom correspondence should be addressed.
Dent. J. 2025, 13(4), 144; https://doi.org/10.3390/dj13040144
Submission received: 12 February 2025 / Revised: 19 March 2025 / Accepted: 24 March 2025 / Published: 26 March 2025
(This article belongs to the Special Issue Esthetic Dentistry: Current Perspectives and Future Prospects)
Browse Figures
Versions Notes

Abstract

Objectives: The upper central incisors play a central role in esthetics, symmetry, and function. The purpose of this study is to evaluate the use of narrow-diameter implants (NDIs) for replacing single missing upper central incisors, addressing the gap in research regarding specific tooth types and their esthetic outcomes. Methods: This retrospective study included adult patients with a single missing upper central incisor replaced by NDIs. Exclusion criteria included patients who lost adjacent teeth during follow-up and patients with non-loaded implants. The primary outcome was peri-implant bone stability, while secondary outcomes included implant survival, technical complications, patient satisfaction, and esthetic evaluation using the Pink Esthetic Score (PES) and the White Esthetic Score (WES). Descriptive statistical analysis was performed. Results: A total of 64 NDIs were placed in 64 patients (mean age 55 ± 15 years; 40 females, 24 males). Implant diameters were 3.3 and 3.5 mm, with lengths ranging from 6.5 to 11.0 mm. The mean follow-up period was 42 ± 19 months. Marginal bone loss was −0.7 ± 0.9 mm mesially and −0.5 ± 0.7 mm distally. No implant failures were recorded. Esthetic outcomes were satisfactory, with a mean PES of 7.0 ± 2.6 and a mean WES of 7.9 ± 2.0. Conclusions: NDIs demonstrated high survival rates, marginal bone stability, and acceptable esthetic outcomes in the replacement of single upper central incisors.

1. Introduction

The upper central incisors play a central role in esthetics, symmetry, and function [1]. Replacing a single missing central incisor is always a challenge, as it is noticeable when smiling and it affects facial esthetics. The loss of a central incisor can have psychological implications for patients, often affecting their confidence and overall quality of life [2,3]. Since the upper central incisors receive occlusal forces, careful biomechanical planning is also necessary to prevent technical complications [4]. These considerations highlight the importance of achieving an optimal balance between esthetic and functional requirements to ensure the durability and effectiveness of implant-supported restorations. Meticulous treatment planning and execution are essential to achieve ideal gingival contour, symmetry, and papillary fill between the implant and adjacent teeth [5,6].
The anatomy of the central incisor region, along with the delicate balance between soft and hard tissues and the alveolar bone remodeling following tooth loss, can complicate implant placement [7,8,9]. Achieving proper positioning of the dental implant often requires alveolar ridge augmentation, which may involve bone and/or soft tissue procedures [10]. Standard-diameter implants (≥3.75 mm) may not be suitable in certain cases, necessitating the use of narrow-diameter implants [11,12].
Compared to standard-diameter implants, narrow-diameter implants (NDIs) have a reduced osseointegration surface and lower resistance to loading forces [13,14]. These limitations have prompted the development and implementation of clinical studies to evaluate the predictability and effectiveness of NDIs in oral rehabilitation. This is particularly important in cases where NDIs are selected to replace a single missing tooth [11,12,15,16]. Splinting multiple implants offers a distinct advantage by enhancing their capacity to withstand lateral forces and reducing the received mechanical stress [17,18].
Several systematic reviews and meta-analysis have evaluated the outcomes of NDIs as single-unit implants in the esthetic zone [11,12,15,16]. The diameters of the two-piece NDIs have been 2.9, 3.0, 3.25, and 3.3 mm [19,20,21,22,23,24,25,26,27,28,29]. These studies consistently indicate no significant differences in implant survival or success rates between NDIs and standard-diameter implants. The cumulative implant survival and success rates have been remarkably high, at 97.5% (95% confidence interval (CI): 94.5–98.9%) and 97.2% (95% CI: 94.2–98.7%), respectively, over a follow-up period of up to 36 months [12]. Mean marginal bone loss (MBL) after one year has been reported to be 0.44 mm (standard deviation (SD): 0.04; 95% CI: 0.36–0.52), with meta-analysis revealing a negligible mean difference of 0.02 mm (95% CI: −0.23 to 0.10) between the two implant types. Implant success rate, as reported by Telles et al., has ranged from 93.8% to 100% over a maximum follow-up of three years [15]. However, in a meta-analysis that included randomized and non-randomized clinical studies reported higher MBL in NDIs, likely due to narrower alveolar ridges in non-randomized studies [15]. Parize et al. have performed a fixed-effect meta-analysis, revealing no significant survival rate differences between NDIs and regular-diameter implants, with success rates ranging from 84.2% to 100% (mean: 95.2%) [16]. The analysis of the MBL has indicated a mean difference of 0.02 mm (95% CI: −0.21 to 0.25; p = 0.87), with no differences between both implants. Roccuzzo et al. have compared two diameters of narrow-diameter implants—2.9 mm and 3.3 mm—and have reported no statistically significant differences in the outcomes of marginal bone stability, mechanical complications, biological complications, and esthetics [19].
In these studies, narrow-diameter implants have been utilized in both the anterior and posterior regions of the maxilla and mandible, making it challenging to provide specific recommendations for a particular tooth type [11,12,15,16]. Additionally, there is a need for more studies that evaluate not only functional outcomes but also esthetic results [16]. Achieving optimal results in cases of tissue destruction caused by dental disease often requires multiple clinical procedures. However, in clinical practice, patients may decline treatment plans involving extensive regenerative and restorative procedures. In such cases, a compromise is necessary while ensuring patient satisfaction and long-term stability. This study presents the outcomes of this approach. To address this gap, this retrospective study has been designed to assess the use of narrow-diameter implants for replacing a single missing upper central incisor. The aims of this study have been to evaluate radiographic changes at the level of the crestal bone, assess the survival rate of narrow implants, and evaluate the esthetic outcome of the restorations.

2. Materials and Methods

This retrospective clinical study adhered to the STROBE (Strengthening the Reporting of Observational Studies in Epidemiology) guidelines for observational studies [30] (Supplementary Material). All procedures complied with the ethical principles outlines in the Declaration of Helsinki (1964) for research involving humans and with the standards set by institutional and national research committees. This study was part of a broader study assessing narrow-diameter implants, approved by the Ethics Committee of the Araba University Hospital (FIBEA-01-ER-23-Estrechos) on 30 July 2024.
An anonymized database was used to select patients for inclusion. The inclusion criteria were as follows: adult patients (age ≥ 18 years) with a single missing upper central incisor replaced by a single-unit narrow-diameter implant (diameter ≤ 3.5 mm), where the definitive crown had been delivered and peri-apical radiographs were available at the time of implant loading and at a subsequent follow-up. The exclusion criteria included the loss of adjacent teeth during the follow-up period and non-loaded implants.

2.1. Surgical Procedure

Preoperative assessment included cone beam computed tomography (CBCT) (NewTom, Imola, Italy) to evaluate bone quality and quantity at the implant site, as well as the height and width of the crestal bone. Measurements and surgical planning were conducted using BTI Scan software (BTI Scan IV; BTI Biotechnology Institute, Vitoria, Spain).
Plasma rich in growth factors (PRGFs) was used in all surgeries. For that, peripheral blood was drawn from each patient into 9 mL collection tubes containing 3.8% sodium citrate (KMU 15, BTI Biotechnology Institute, Vitoria, Spain). The blood was centrifuged at room temperature for 8 min to separate components. The plasma column was divided into two fractions: Fraction 1 (F1), used to create fibrin membranes, and Fraction 2 (F2), with a higher platelet concentration, used to regenerate [31]. To activate the platelets and the coagulation cascade, 20 µL of 10% calcium chloride (BTI Biotechnology Institute, Vitoria, Spain) was added per 1 mL of PRGFs.
Patients received 2 g of amoxicillin and 1 g of paracetamol 60 min before surgery as prophylactic medication. Procedures were performed under sedation and local infiltration anesthesia. Intrasulcular incisions with full-thickness flap elevation were made, followed by bone drilling using the biological drilling technique [32,33]. The initial drill operated at 800 rpm with saline irrigation, while subsequent drills, at 125 rpm, were used without irrigation. Autologous bone collected during drilling was mixed with liquid F2 for subsequent use. All implants (UnicCa®, BTI Biotechnology Institute, Vitoria, Spain), with body diameters of 3.3 mm or 3.5 mm and prosthetic platforms of 3.5 mm or 4.1 mm, were placed yuxtacrestally by the same surgical team. Where necessary, the labial alveolar bone plate was overcorrected using a bone graft combined with activated F2 in a 2:1 (w/v) ratio. The graft material consisted of autologous bone, anorganic bovine bone, or a mixture of the two. A fibrin membrane derived from F1 was used to cover the surgical area before flap closure.
Postoperative instructions, including oral hygiene recommendations, were provided to ensure cleanliness and care of the operated area.

2.2. Prosthetic Rehabilitation

All patients included in the study were restored using the same prosthetic concept, employing an intermediate abutment (UNIT®, BTI Biotechnology Institute, Vitoria, Spain). The definitive restorations included single-unit screw-retained prostheses. The restorations were fabricated from IPS e.max® (Ivoclar, Schaan, Liechtenstein), a monolithic lithium disilicate ceramic, by the same laboratory using the same technique for all cases.

2.3. Study Variables

The primary variable of the study was peri-implant bone stability. Secondary variables included implant survival, technical complications, patient satisfaction, and esthetic evaluated using the Pink Esthetic Score (PES) and the White Esthetic Score (WES). In the absence of natural unrestored reference tooth, previous clinical pictures or digital records were used. Additionally, clinically relevant variables related to the patient (gender and age), the surgery (need for additional surgical techniques), and the implant (diameter and length) were also assessed.
To evaluate marginal bone stability, radiographic examinations were performed using standardized digital periapical radiographs (Figure 1). Peri-implant bone levels were measured using specialized software (DIGORA® for Windows 2.9.113.490, Soredex, Milwaukee, WI, USA) at two time points: at the time of implant loading and on the most recent radiograph available at the time of the study. The measurements were calibrated based on the known implant length, and the distance between the implant shoulder and the most coronal bone-to-implant contact (mesially and distally) was recorded. Positive values indicated that the bone level was above the implant platform, while negative values signified that the bone level was below the implant platform. Changes in marginal bone levels were calculated as the difference between the bone level at loading and the most recent recorded level.
Technical complications (screw loosening, screw fracture, and chipping, among others) survival of the crown were assessed. For esthetics, intraoral photographs of all patients were taken, clearly capturing the soft tissues and implant-supported restorations, including the tooth under study and the adjacent teeth. Pink Esthetic Score (PES): The PES was used to evaluate seven variables: mesial papilla, distal papilla, soft tissue level, soft tissue contour, alveolar process deficiency, soft tissue color, and soft tissue texture. Each variable was scored from 0 to 2, where 0 represented the worst outcome and 2 represented the best outcome. The highest possible score was 14, indicating perfect peri-implant soft tissues. A threshold of 8 was considered clinically acceptable, while a score of 12 or more was deemed nearly perfect peri-implant soft tissues, as described by Fürhauser et al. [34]. White Esthetic Score (WES): The WES was used to assess five variables: overall tooth shape, tooth contour, tooth color (hue and value), surface texture, and translucency. Each variable was scored from 0 to 2, with 0 indicating the worst outcome and 2 indicating the best outcome. The implant-supported tooth was compared with the contralateral reference tooth to evaluate white esthetics. A maximum score of 10 was awarded for the best replication of the contralateral tooth. Thresholds for clinically acceptable or nearly perfect implant-supported crowns were set to be 6 and 9, respectively.

2.4. Statistical Analysis

The statistical analysis was conducted using specialized software [SPSS Statistics version 15 (IBM, Armonk, NY, USA)]. Categorical variables were expressed as absolute and relative frequencies. Continuous variables were mean and standard deviation, and range.

3. Results

The database included 1243 implants that had been placed in the upper central incisor; however, 64 implants supported single crowns. This study evaluated 64 narrow-diameter dental implants placed in 64 patients to replace a single missing central incisor. All the implants were placed between 2016 and 2022. The mean age of the participants was 55 ± 15 years (range: 18–85), comprising 40 females and 24 males. All the patients lost their central incisor due to periodontal disease. Data description according to the patients’ sex is provided in the Supplementary Material.
The narrow dental implants were 3.3 and 3.5 mm in diameter (Table 1) and their lengths varied between 6.5 and 11.0 mm, with 7.5 and 8.5 mm being the most common lengths.
At the implant site, the width of the alveolar bone at crest was 5.6 ± 1.5 mm. Bone type II was the most frequent (51 implants), and the bone density was 741 ± 151 units. The implants were placed with a mean insertion torque of 28 ± 15 Ncm. However, most implants (49 out of 64) required overcorrection of the vestibular plate (Table 2).
All the implants were connected to intermediate definitive abutment for screw-retained single crown. The length of the abutments varied from 1.5 to 3.5 mm, with 2 and 2.5 mm being the most frequently used (27 cases) (Table 2).
The mean follow-up period was 42 ± 19 months. Marginal bone level was evaluated at loading and at the last follow-up. At loading, the mesial marginal bone level was 0.7 ± 1.0 mm, and the distal marginal bone level was 0.4 ± 0.9 mm. By the last follow-up, the mesial and distal marginal bone levels were 0.0 ± 0.9 mm −0.1 ± 0.6 mm, respectively. Thus, the implants had a marginal bone loss of −0.7 ± 0.9 mm (mesial) and −0.5 ± 0.7 mm (distal). No implant failures were recorded during the follow-up period.
The esthetic outcomes were satisfactory, with a mean Pink Esthetic Score of 7.0 ± 2.6 and a mean White Esthetic Score of 7.9 ± 2.0 (Table 3). Few technical complications were reported. Four cases required a change of the intermediate abutment, one case experienced pressure on the peri-implant mucosa, and two cases had prosthetic screw loosening (Table 4).
Figure 2 and Figure 3 show two clinical cases that were treated with narrow-diameter implants.

4. Discussion

Meticulous planning of the implant position mesio-distally, corono-apically and oro-facially is of paramount importance when replacing a single missing upper central incisor with a dental implant [35,36]. The ITI consensus in 2004 defined a comfort zone of implant positioning in these three dimensions to avoid implant malpositioning and to minimize the risk of esthetic complications [35,36]. Adhering to these guidelines may impose constraints on the size of the dental implants, making narrow-diameter implants a viable and suitable option [36].
Narrow-diameter implants, initially used as transitional implants, are now being employed as definitive implants to support single crowns, partial prostheses, and complete prostheses in both the anterior and posterior regions of the maxilla and the mandible [16,37,38,39,40]. Narrow-diameter implants have a reduced osseointegration surface and lower resistance to loading forces than wider implants [13,14]. In the molar region, a single NDI is less reliable in supporting a single crown than standard implants or two NDIs [41]. Thus, it is important to take measures that enhance the biomechanical situation of the NDIs, aiming to reduce the loads received by the NDIs [38,39,42]. For example, splinting the implant together and reducing occlusal table and cusp inclination would enhance force distribution and reduce the lateral forces [17,18]. Taking these measures would make NDIs a reliable alternative in cases of horizontal atrophy, even in posterior sectors [42,43,44]. Some reports have indicated narrow-diameter implants as a risk factor for implant fracture, particularly in posterior regions and single restorations [45,46,47]. However, implant fracture is multifactorial where patient factors, implant design, prosthesis design, and marginal bone loss play a role [45]. Current evidence from several systematic reviews supports their clinical reliability [11,12,15,16]. The use of NDIs would minimize the need for alveolar ridge augmentation, thus reducing the number of surgical interventions required to restore prosthetically the clinical case [38,39].
In a study by Zhang et al. [48], NDIs (3.5 mm in diameter) have been compared with standard-diameter implants (4.3 mm in diameter) combined with lateral bone augmentation. No implant loss has been observed in either group during a 3-year follow-up. However, patient satisfaction ratings have been significantly higher in the narrow-diameter implant group compared to the standard-diameter implant group with lateral bone augmentation. Additionally, the total cumulative cost of treatment per patient has been significantly lower in the group of 3.5 mm implants (USD 2849.60, 95% CI: USD 2726.80–2972.40) compared to the 4.3 mm implant group with bone augmentation (USD 3581.40, 95% CI: USD 3460.90–3701.90) [48].
Narrow-diameter implants are generally classified into two main designs: one-piece and two-piece dental implants [16,49]. One-piece dental implants provide limited prosthetic options [16]. In contrast, two-piece dental implants offer the advantage of reversibility, allowing for the adaptation of the intermediate component of the implant system to potential changes in the peri-implant tissue. This adaptability is particularly valuable as both implants and patients age, requiring clinicians to address changes in peri-implant soft tissues through minimally invasive approaches [50]. In this context, the use of screw-retained crowns further facilitates the handling of clinical changes and complications [51].
This study addresses the gap in evidence regarding the management of specific tooth type and the esthetic outcomes of NDIs. Specifically, single missing upper central incisors were replaced with single crowns supported by 3.3 mm or 3.5 mm diameter implants. The follow-up period was 42 months, during which none of the 64 implants failed. This high survival rate aligns with findings from several systematic reviews reporting similarly high implant survival rates [11,12,15,16]. In a meta-analysis by Zhang et al., survival rates of narrow-diameter implants have ranged from 93.8% to 100% [11]. Cao et al. reported an implant survival rate of 97.5% (95% CI: 94.5%–98.9%) [12]. Telles et al. have documented implant success rates between 93.8% and 100% over a maximum follow-up of three years [15]. Similarly, Parize et al. have reported a mean success rate of 95.2% (rang: 84.2% to 100%) [16]. Narrow-diameter implants can be manufactured from titanium or titanium–zirconium alloy. In this study, the implants were made from commercially pure titanium. According to Cao et al., in their study of narrow-diameter implants with follow-up periods of up to 36 months, no significant differences have been observed between commercially pure titanium implants and titanium–zirconium implants in terms of survival or success rates [12].
The mean marginal bone observed in this study was −0.7 ± 0.8 mm mesially and −0.5 ± 0.6 mm distally. These findings are in agreement with reported data in several studies [11,12,15,16]. Cao et al. have reported a mean marginal bone loss (MBL) of 0.44 mm (SD: 0.04, 95% CI: 0.36–0.52) after one year of function [12]. Similarly, other studies have reported a mean marginal bone loss between 0.4 and 0.58 mm [15,52,53,54,55]. However, a higher MBL of 1.62 mm (SD: 0.61 mm) has been reported by Zarone et al. [56].
The use of definitive intermediate abutment may have favored the marginal bone stability around the NDIs. Studies suggest that intermediate abutments of at least 2 mm of height significantly minimizes the marginal bone loss [57,58]. Additionally, employing the “one abutment one time” protocol would also enhance the stability of marginal bone by avoiding repeated abutment connection/disconnection and thus the apical migration of the connective tissue [59,60]. In a histological human study, maintaining the definitive abutment without disconnection was identified as a factor that minimized trauma to peri-implant tissues and contributed to the prevention of marginal bone loss [61]. This approach would also reduce inflammation in the peri-implant tissues [62]. Furthermore, the use of original components would enhance the seal quality at the abutment–implant interface. A hermetic seal at this interface maintains peri-implant bone stability, minimizes stress, and prevents microorganism colonization [63,64,65,66]. Achieving this seal depends on precise machining of intermediate abutments, internal connection implants, and optimal screw preload to ensure proper fit, stress distribution, and resistance to loosening [67,68].
Esthetics is a key factor in the oral rehabilitation of the anterior maxillary region, where the upper central incisors play a pivotal role. Achieving optimal and stable esthetic outcomes depends on adequate treatment planning and execution. Proper 3D implant positioning allows for an optimal configuration of the esthetic zones in the transition of the prosthetic restoration from the implant platform to the oral cavity through the free gingival margin [69]. A soft tissues with a thickness of 2–3 mm is required to maintain a stable marginal bone level and to camouflage the underlying abutment [70,71]. It is important to adapt the design of the restoration to support long-term stability of the soft tissue, regarding shape and position [69]. Patients are mainly concerned by discoloration and recession of the buccal gingiva [20]. Additionally, they place significant importance on dentogingival esthetic parameters, including dental, gingival, and occlusal features, that are largely influenced by the proportion, shape, and position of the central incisors, as well as their relationship with adjacent dental structures [1]. To objectively evaluate esthetics, several indices have been used in the clinical practice such as the PES and the WES [72]. While esthetic outcomes assessed using the PES and WES may not always correlate with patients’ subjective perceptions, these indices remain valuable tools for monitoring implant performance [73,74]. In this study, the mean PES score was 7 and the mean WES score was 8, reflecting an acceptable result. Notably, all patients expressed satisfaction with their prosthesis. The goal of any treatment is to ensure patient satisfaction and long-term stability [75]. In this study, all the patients have lost the upper central incisor as a consequence of periodontal disease, indicating advanced periodontal disease that would influence negatively the PES score [76]. Tissue destruction will lead to the need for multidisciplinary clinical procedures to compensate for tissue loss. The increased number of procedures would affect time and cost and thus the willingness of the patients to accept them. The expectations of the patients would assist the clinician in adapting the treatment plan [77]. The study outcomes have indicated that the described clinical procedure, followed in this study, has resulted in patient satisfaction and long-term stability. According to Pieri et al. (2014), mean scores of 6.96 (±0.92) for the Pink Esthetic Score and 7.1 (±1.09) for the White Esthetic Score were reported [21]. No significant differences were observed in either parameter when comparing baseline (crown placement) with the 3-year follow-up [21]. In another study, a significant improvement in the Pink Esthetic Score has been observed, increasing from 6.3 (±0.4) at baseline to 10.5 (±2.5) after a 1-year follow-up [29]. Zhang et al. have found that soft tissue dehiscence occurred more frequently in regular-diameter implants combined with alveolar bone augmentation compared to narrow-diameter implants [11]. Additionally, the narrow-diameter implants would achieve more rapid esthetic improvements. The acceptable esthetic results observed in this study could be influenced by the inclusion of single missing central incisors. The formation of interdental papilla is more likely between natural tooth and implant rather than two adjacent implants [16,52]. Furthermore, the stability of the marginal alveolar bone likely contributes to the stability of the soft tissues around the dental implants [16]. Additionally, the use of narrow implants would provide additional space for the peri-implant tissue [15].
Abutment screw loosening is one of the most commonly reported prosthetic complications in clinical studies on NDIs. This issue may result from various factors, including component misfit, inadequate tightening, screw settling, suboptimal screw design, or excessive loading [78]. In our study, two events of screw loosening, which were resolved by applying the correct torque to the screw, were observed. Thus, screw loosening in this case could be most probably related to inadequate tightening torque.
This study has several limitations, including the absence of a control group and a relatively short follow-up period. As a retrospective analysis of previously collected data, this study inherently depends on the availability and quality of the database, which poses the risk of missing or incomplete information. This study has not assessed the changes in the MBL at different time points in the follow-up; instead, the MBL has been assessed at baseline and in the last available radiograph. Patient-reported outcomes have not been assessed due to the retrospective nature of the study. However, the retrospective design provides insights into real-world scenarios and daily clinical practice. It is important to interpret the results with caution, as the limitations may affect the generalizability of the findings. Furthermore, this study specifically assessed cases of single missing upper central incisors, where the presence of adjacent natural dentition likely contributed to the stability of peri-implant tissues.

5. Conclusions

The use of narrow-diameter dental implants to support single crowns replacing a single missing upper central incisor has demonstrated high implant survival rates, marginal bone stability, patient satisfaction, and acceptable esthetic outcomes. Nevertheless, more studies are needed to assess the use of narrow-diameter implants to replace a single missing central incisor, as it plays a central role in esthetics.

Supplementary Materials

The following supporting information can be downloaded at https://www.mdpi.com/article/10.3390/dj13040144/s1. Table S1: STROB checklist and data described according to patients’ sex.

Author Contributions

All authors have made substantial contributions to the conception or design of the work and the acquisition, analysis, and interpretation of data. They have also contributed to drafting the work and revising it critically for important intellectual content and have given final approval of the version to be published. They agree to be accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

This study was part of a broader study assessing narrow-diameter implants, approved by the Ethics Committee of the Araba University Hospital (Expte. 2024-031) on 30 July 2024.

Informed Consent Statement

Patient consent was waived and authorized by the ethical committee due to the retrospective nature of the study, and the analysis was based on an anonymized database.

Data Availability Statement

The datasets used and/or analyzed during the current study are available from the corresponding author upon reasonable request.

Conflicts of Interest

Eduardo Anitua is the scientific director of BTI Biotechnology Institute, a dental implant company that investigates the fields of oral implantology and PRGF–Endoret technology. Aitana Tarazona has no competing interests. Mohammad Hamdan Alkhraisat is a researcher at BTI Biotechnology Institute.

References

  1. Del Monte, S.; Afrashtehfar, K.I.; Emami, E.; Abi Nader, S.; Tamimi, F. Lay preferences for dentogingival esthetic parameters: A systematic review. J. Prosthet. Dent. 2017, 118, 717–724. [Google Scholar] [CrossRef] [PubMed]
  2. Gautam, R.; Nene, P.; Mehta, K.; Nene, S.; Hegde, A.; Jaju, R. Treatment strategies for missing maxillary central incisor—An orthodontist’s perspective. J. Prosthodont. 2014, 23, 509–513. [Google Scholar] [CrossRef] [PubMed]
  3. Pithon, M.M.; Vargas, E.O.A.; da Silva Coqueiro, R.; Lacerda-Santos, R.; Tanaka, O.M.; Maia, L.C. Impact of oral-health-related quality of life and self-esteem on patients with missing maxillary lateral incisor after orthodontic space closure: A single-blinded, randomized, controlled trial. Eur. J. Orthod. 2021, 43, 208–214. [Google Scholar] [CrossRef]
  4. Jivraj, S.; Chee, W. Treatment planning of implants in the aesthetic zone. Br. Dent. J. 2006, 201, 77–89. [Google Scholar] [CrossRef]
  5. Giglio, G.D.; Giglio, A.B. Achieving optimal implant esthetics using a team approach Part 1 a review of evidence-based criteria in implant treatment. J. Prosthet. Dent. 2023, 130, 661–662. [Google Scholar] [CrossRef]
  6. Schincaglia, G.P.; Nowzari, H. Surgical treatment planning for the single-unit implant in aesthetic areas. Periodontol. 2000 2001, 27, 162–182. [Google Scholar] [CrossRef]
  7. Zhang, W.; Skrypczak, A.; Weltman, R. Anterior maxilla alveolar ridge dimension and morphology measurement by cone beam computerized tomography (CBCT) for immediate implant treatment planning. BMC Oral Health 2015, 15, 65. [Google Scholar] [CrossRef]
  8. Monje, A.; Roccuzzo, A.; Buser, D.; Wang, H.L. Influence of buccal bone wall thickness on the peri-implant hard and soft tissue dimensional changes: A systematic review. Clin. Oral Implant. Res. 2023, 34 (Suppl. S26), 8–27. [Google Scholar] [CrossRef]
  9. Avila-Ortiz, G.; Chambrone, L.; Vignoletti, F. Effect of alveolar ridge preservation interventions following tooth extraction: A systematic review and meta-analysis. J. Clin. Periodontol. 2019, 46 (Suppl. S21), 195–223. [Google Scholar] [CrossRef]
  10. Couso-Queiruga, E.; Mansouri, C.J.; Alade, A.A.; Allareddy, T.V.; Galindo-Moreno, P.; Avila-Ortiz, G. Alveolar ridge preservation reduces the need for ancillary bone augmentation in the context of implant therapy. J. Periodontol. 2022, 93, 847–856. [Google Scholar] [CrossRef]
  11. Zhang, Y.; Wen, G.; Dong, W. Clinical outcomes of narrow- and regular-diameter implants with bone augmentation in the anterior maxilla: A systematic review and meta-analysis. Clin. Oral Investig. 2024, 28, 196. [Google Scholar] [CrossRef] [PubMed]
  12. Cao, R.; Chen, B.; Xu, H.; Fan, Z. Clinical outcomes of titanium-zirconium alloy narrow-diameter implants for single-crown restorations: A systematic review and meta-analysis. Br. J. Oral Maxillofac. Surg. 2023, 61, 403–410. [Google Scholar] [CrossRef]
  13. Ivanoff, C.J.; Sennerby, L.; Johansson, C.; Rangert, B.; Lekholm, U. Influence of implant diameters on the integration of screw implants. An experimental study in rabbits. Int. J. Oral Maxillofac. Surg. 1997, 26, 141–148. [Google Scholar] [CrossRef] [PubMed]
  14. Shemtov-Yona, K.; Rittel, D.; Machtei, E.E.; Levin, L. Effect of dental implant diameter on fatigue performance. Part II: Failure analysis. Clin. Implant Dent. Relat. Res. 2014, 16, 178–184. [Google Scholar] [CrossRef]
  15. Telles, L.H.; Portella, F.F.; Rivaldo, E.G. Longevity and marginal bone loss of narrow-diameter implants supporting single crowns: A systematic review. PLoS ONE 2019, 14, e0225046. [Google Scholar] [CrossRef]
  16. Parize, H.N.; Bohner, L.O.L.; Gama, L.T.; Porporatti, A.L.; Mezzomo, L.A.M.; Martin, W.C.; Goncalves, T. Narrow-diameter implants in the anterior region: A meta-analysis. Int. J. Oral Maxillofac. Implant. 2019, 34, 1347–1358. [Google Scholar] [CrossRef] [PubMed]
  17. Anitua, E.; Tapia, R.; Luzuriaga, F.; Orive, G. Influence of implant length, diameter, and geometry on stress distribution: A finite element analysis. Int. J. Periodontics Restor. Dent. 2010, 30, 89–95. [Google Scholar]
  18. Pierrisnard, L.; Renouard, F.; Renault, P.; Barquins, M. Influence of implant length and bicortical anchorage on implant stress distribution. Clin. Implant Dent. Relat. Res. 2003, 5, 254–262. [Google Scholar] [CrossRef]
  19. Roccuzzo, A.; Imber, J.C.; Lempert, J.; Hosseini, M.; Jensen, S.S. Narrow diameter implants to replace congenital missing maxillary lateral incisors: A 1-year prospective, controlled, clinical study. Clin. Oral Implant. Res. 2022, 33, 844–857. [Google Scholar] [CrossRef]
  20. Trbakovic, A.; Bongenhielm, U.; Thor, A. A clinical and radiological long-term follow-up study of narrow diameter implants in the aesthetic area. Clin. Implant Dent. Relat. Res. 2018, 20, 598–605. [Google Scholar] [CrossRef]
  21. Pieri, F.; Siroli, L.; Forlivesi, C.; Corinaldesi, G. Clinical, esthetic, and radiographic evaluation of small-diameter (3.0-mm) implants supporting single crowns in the anterior region: A 3-year prospective study. Int. J. Periodontics Restor. Dent. 2014, 34, 825–832. [Google Scholar] [CrossRef] [PubMed]
  22. Degidi, M.; Nardi, D.; Piattelli, A. Immediate versus one-stage restoration of small-diameter implants for a single missing maxillary lateral incisor: A 3-year randomized clinical trial. J. Periodontol. 2009, 80, 1393–1398. [Google Scholar] [CrossRef]
  23. MacLean, S.; Hermans, M.; Villata, L.; Polizzi, G.; Sisodia, N.; Cherry, J.E. A retrospective multicenter case series evaluating a novel 3.0-mm expanding tapered body implant for the rehabilitation of missing incisors. Quintessence Int. 2016, 47, 297–306. [Google Scholar] [CrossRef]
  24. Polizzi, G.; Fabbro, S.; Furri, M.; Herrmann, I.; Squarzoni, S. Clinical application of narrow Branemark System implants for single-tooth restorations. Int. J. Oral Maxillofac. Implant. 1999, 14, 496–503. [Google Scholar]
  25. Oyama, K.; Kan, J.Y.; Rungcharassaeng, K.; Lozada, J. Immediate provisionalization of 3.0-mm-diameter implants replacing single missing maxillary and mandibular incisors: 1-year prospective study. Int. J. Oral Maxillofac. Implant. 2012, 27, 173–180. [Google Scholar]
  26. King, P.; Maiorana, C.; Luthardt, R.G.; Sondell, K.; Oland, J.; Galindo-Moreno, P.; Nilsson, P. Clinical and Radiographic Evaluation of a Small-Diameter Dental Implant Used for the Restoration of Patients with Permanent Tooth Agenesis (Hypodontia) in the Maxillary Lateral Incisor and Mandibular Incisor Regions: A 36-Month Follow-Up. Int. J. Prosthodont. 2016, 29, 147–153. [Google Scholar] [CrossRef] [PubMed]
  27. Galindo-Moreno, P.; Nilsson, P.; King, P.; Becktor, J.; Speroni, S.; Schramm, A.; Maiorana, C. Clinical and radiographic evaluation of early loaded narrow diameter implants—1-year follow-up. Clin. Oral Implant. Res. 2012, 23, 609–616. [Google Scholar] [CrossRef]
  28. Galindo-Moreno, P.; Padial-Molina, M.; Nilsson, P.; King, P.; Worsaae, N.; Schramm, A.; Maiorana, C. The influence of the distance between narrow implants and the adjacent teeth on marginal bone levels. Clin. Oral Implant. Res. 2017, 28, 704–712. [Google Scholar] [CrossRef]
  29. Kolinski, M.; Hess, P.; Leziy, S.; Friberg, B.; Bellucci, G.; Trisciuoglio, D.; Wagner, W.; Moergel, M.; Pozzi, A.; Wiltfang, J.; et al. Immediate provisionalization in the esthetic zone: 1-year interim results from a prospective single-cohort multicenter study evaluating 3.0-mm-diameter tapered implants. Clin. Oral Investig. 2018, 22, 2299–2308. [Google Scholar] [CrossRef]
  30. von Elm, E.; Altman, D.G.; Egger, M.; Pocock, S.J.; Gotzsche, P.C.; Vandenbroucke, J.P.; Initiative, S. The Strengthening the Reporting of Observational Studies in Epidemiology (STROBE) statement: Guidelines for reporting observational studies. Lancet 2007, 370, 1453–1457. [Google Scholar] [CrossRef]
  31. Anitua, E. Plasma rich in growth factors: Preliminary results of use in the preparation of future sites for implants. Int. J. Oral Maxillofac. Implant. 1999, 14, 529–535. [Google Scholar]
  32. Anitua, E.; Alkhraisat, M.H.; Pinas, L.; Orive, G. Efficacy of biologically guided implant site preparation to obtain adequate primary implant stability. Ann. Anat. 2015, 199, 9–15. [Google Scholar] [CrossRef] [PubMed]
  33. Anitua, E.; Carda, C.; Andia, I. A novel drilling procedure and subsequent bone autograft preparation: A technical note. Int. J. Oral Maxillofac. Implant. 2007, 22, 138–145. [Google Scholar]
  34. Furhauser, R.; Florescu, D.; Benesch, T.; Haas, R.; Mailath, G.; Watzek, G. Evaluation of soft tissue around single-tooth implant crowns: The pink esthetic score. Clin. Oral Implant. Res. 2005, 16, 639–644. [Google Scholar] [CrossRef]
  35. Buser, D.; Martin, W.; Belser, U.C. Optimizing esthetics for implant restorations in the anterior maxilla: Anatomic and surgical considerations. Int. J. Oral Maxillofac. Implant. 2004, 19, 43–61. [Google Scholar]
  36. Chen, S.T.; Buser, D.; Sculean, A.; Belser, U.C. Complications and treatment errors in implant positioning in the aesthetic zone: Diagnosis and possible solutions. Periodontol. 2000 2023, 92, 220–234. [Google Scholar] [CrossRef]
  37. Anitua, E.; Alkhraisat, M.H. Is Alveolar Ridge Split a Risk Factor for Implant Survival? J. Oral Maxillofac. Surg. 2016, 74, 2182–2191. [Google Scholar] [CrossRef]
  38. Anitua, E.; Fernandez-de-Retana, S.; Anitua, B.; Alkhraisat, M.H. Long-Term Retrospective Study of 3.0-mm-Diameter Implants Supporting Fixed Multiple Prostheses: Immediate Versus Delayed Implant Loading. Int. J. Oral Maxillofac. Implant. 2020, 35, 1229–1238. [Google Scholar] [CrossRef]
  39. Anitua, E.; Saracho, J.; Begona, L.; Alkhraisat, M.H. Long-Term Follow-Up of 2.5-mm Narrow-Diameter Implants Supporting a Fixed Prostheses. Clin. Implant Dent. Relat. Res. 2016, 18, 769–777. [Google Scholar] [CrossRef]
  40. Antiua, E.; Escuer, V.; Alkhraisat, M.H. Short Narrow Dental Implants versus Long Narrow Dental Implants in Fixed Prostheses: A Prospective Clinical Study. Dent. J. 2022, 10, 39. [Google Scholar] [CrossRef]
  41. Freitas-Junior, A.C.; Bonfante, E.A.; Martins, L.M.; Silva, N.R.; Marotta, L.; Coelho, P.G. Effect of implant diameter on reliability and failure modes of molar crowns. Int. J. Prosthodont. 2011, 24, 557–561. [Google Scholar] [PubMed]
  42. Javed, F.; Romanos, G.E. Role of implant diameter on long-term survival of dental implants placed in posterior maxilla: A systematic review. Clin. Oral Investig. 2015, 19, 1–10. [Google Scholar] [CrossRef]
  43. Esposito, M.; Barausse, C.; Pistilli, R.; Bellini, P.; Buti, J.; Felice, P. Immediate loading of 3 mm-diameter implants as an alternative to horizontal bone augmentation for placing 4 mm-diameter implants: One-year post-loading results from a multicentre randomised controlled trial. Clin. Trials Dent. 2020, 2, 61–76. [Google Scholar]
  44. Assaf, A.; Saad, M.; Daas, M.; Abdallah, J.; Abdallah, R. Use of narrow-diameter implants in the posterior jaw: A systematic review. Implant Dent. 2015, 24, 294–306. [Google Scholar] [CrossRef]
  45. Manfredini, M.; Poli, P.P.; Giboli, L.; Beretta, M.; Maiorana, C.; Pellegrini, M. Clinical Factors on Dental Implant Fractures: A Systematic Review. Dent. J. 2024, 12, 200. [Google Scholar] [CrossRef]
  46. Lee, D.-W.; Kim, N.-H.; Lee, Y.; Oh, Y.-A.; Lee, J.-H.; You, H.-K. Implant fracture failure rate and potential associated risk indicators: An up to 12-year retrospective study of implants in 5,124 patients. Clin. Oral Implant. Res. 2019, 30, 206–217. [Google Scholar] [CrossRef]
  47. Lee, J.-H.; Kim, Y.-T.; Jeong, S.-N.; Kim, N.-H.; Lee, D.-W. Incidence and pattern of implant fractures: A long-term follow-up multicenter study. Clin. Implant Dent. Relat. Res. 2018, 20, 463–469. [Google Scholar] [CrossRef]
  48. Zhang, X.M.; Liu, B.L.; Qian, S.J.; Shi, J.Y.; Zhang, X.; Lai, H.C. Clinical evaluation of narrow-diameter implants versus standard-diameter implants with lateral bone augmentation in posterior jaws: Three-year results of a randomized controlled trial. Clin. Oral Implant. Res. 2022, 33, 1245–1253. [Google Scholar] [CrossRef]
  49. Zadrożny, Ł.; Górski, B.; Baldoni, E.; Lumbau, A.I.; Meloni, S.M.; Pisano, M.; Tallarico, M. Minimally Invasive Treatment of Lateral Incisors with Guided One-Piece or Two-Piece Titanium-Made Narrow Diameter Implants: A Retrospective Comparative Study with Up to Two Years Follow-Up. J. Clin. Med. 2023, 12, 3711. [Google Scholar] [CrossRef]
  50. Anitua, E. Implant Dentistry from One-Way Direction to the Reversibility of the Osseointegration. Eur. J. Dent. 2022, 16, 464. [Google Scholar] [CrossRef]
  51. Anitua, E.; Flores, C.; Pinas, L.; Alkhraisat, M.H. Frequency of Technical Complications in Fixed Implant Prosthesis: The Effect of Prosthesis Screw Emergence Correction by Computer-Aided Design/Computer-Aided Manufacturing. J. Oral Implantol. 2018, 44, 427–431. [Google Scholar] [CrossRef] [PubMed]
  52. Andersen, E.; Saxegaard, E.; Knutsen, B.M.; Haanaes, H.R. A prospective clinical study evaluating the safety and effectiveness of narrow-diameter threaded implants in the anterior region of the maxilla. Int. J. Oral Maxillofac. Implant. 2001, 16, 217–224. [Google Scholar]
  53. Ioannidis, A.; Gallucci, G.O.; Jung, R.E.; Borzangy, S.; Hammerle, C.H.; Benic, G.I. Titanium-zirconium narrow-diameter versus titanium regular-diameter implants for anterior and premolar single crowns: 3-year results of a randomized controlled clinical study. J. Clin. Periodontol. 2015, 42, 1060–1070. [Google Scholar] [CrossRef]
  54. de Souza, A.B.; Sukekava, F.; Tolentino, L.; Cesar-Neto, J.B.; Garcez-Filho, J.; Araujo, M.G. Narrow- and regular-diameter implants in the posterior region of the jaws to support single crowns: A 3-year split-mouth randomized clinical trial. Clin. Oral Implant. Res. 2018, 29, 100–107. [Google Scholar] [CrossRef] [PubMed]
  55. Benic, G.I.; Gallucci, G.O.; Mokti, M.; Hammerle, C.H.; Weber, H.P.; Jung, R.E. Titanium-zirconium narrow-diameter versus titanium regular-diameter implants for anterior and premolar single crowns: 1-year results of a randomized controlled clinical study. J. Clin. Periodontol. 2013, 40, 1052–1061. [Google Scholar] [CrossRef]
  56. Zarone, F.; Sorrentino, R.; Vaccaro, F.; Russo, S. Prosthetic treatment of maxillary lateral incisor agenesis with osseointegrated implants: A 24-39-month prospective clinical study. Clin. Oral Implant. Res. 2006, 17, 94–101. [Google Scholar] [CrossRef]
  57. Spinato, S.; Galindo-Moreno, P.; Bernardello, F.; Zaffe, D. Minimum Abutment Height to Eliminate Bone Loss: Influence of Implant Neck Design and Platform Switching. Int. J. Oral Maxillofac. Implant. 2018, 33, 405–411. [Google Scholar] [CrossRef]
  58. Tajti, P.; Solyom, E.; Vancsa, S.; Matrai, P.; Hegyi, P.; Varga, G.; Hermann, P.; Borbely, J.; Sculean, A.; Mikulas, K. Less marginal bone loss around bone-level implants restored with long abutments: A systematic review and meta-analysis. Periodontol. 2000 2024, 94, 627–638. [Google Scholar] [CrossRef]
  59. Abrahamsson, I.; Berglundh, T.; Lindhe, J. The mucosal barrier following abutment dis/reconnection. An experimental study in dogs. J. Clin. Periodontol. 1997, 24, 568–572. [Google Scholar] [CrossRef]
  60. Koutouzis, T.; Gholami, F.; Reynolds, J.; Lundgren, T.; Kotsakis, G.A. Abutment Disconnection/Reconnection Affects Peri-implant Marginal Bone Levels: A Meta-Analysis. Int. J. Oral Maxillofac. Implant. 2017, 32, 575–581. [Google Scholar] [CrossRef]
  61. Romanos, G.E.; Traini, T.; Johansson, C.B.; Piattelli, A. Biologic width and morphologic characteristics of soft tissues around immediately loaded implants: Studies performed on human autopsy specimens. J. Periodontol. 2010, 81, 70–78. [Google Scholar] [CrossRef] [PubMed]
  62. Kuppusamy, M.; Watanabe, H.; Kasugai, S.; Kuroda, S. Effects of Abutment Removal and Reconnection on Inflammatory Cytokine Production Around Dental Implants. Implant Dent. 2015, 24, 730–734. [Google Scholar] [CrossRef] [PubMed]
  63. Coelho, A.L.; Suzuki, M.; Dibart, S.; DA Silva, N.; Coelho, P.G. Cross-sectional analysis of the implant-abutment interface. J. Oral Rehabil. 2007, 34, 508–516. [Google Scholar] [CrossRef] [PubMed]
  64. Duarte, A.R.; Rossetti, P.H.; Rossetti, L.M.; Torres, S.A.; Bonachela, W.C. In vitro sealing ability of two materials at five different implant-abutment surfaces. J. Periodontol. 2006, 77, 1828–1832. [Google Scholar] [CrossRef]
  65. Dibart, S.; Warbington, M.; Su, M.F.; Skobe, Z. In vitro evaluation of the implant-abutment bacterial seal: The locking taper system. Int. J. Oral Maxillofac. Implant. 2005, 20, 732–737. [Google Scholar]
  66. Jansen, V.K.; Conrads, G.; Richter, E.J. Microbial leakage and marginal fit of the implant-abutment interface. Int. J. Oral Maxillofac. Implant. 1997, 12, 527–540. [Google Scholar]
  67. Welander, M.; Abrahamsson, I.; Berglundh, T. Subcrestal placement of two-part implants. Clin. Oral Implant. Res. 2009, 20, 226–231. [Google Scholar] [CrossRef]
  68. Maeda, Y.; Satoh, T.; Sogo, M. In vitro differences of stress concentrations for internal and external hex implant-abutment connections: A short communication. J. Oral Rehabil. 2006, 33, 75–78. [Google Scholar] [CrossRef]
  69. Gomez-Meda, R.; Esquivel, J.; Blatz, M.B. The esthetic biological contour concept for implant restoration emergence profile design. J. Esthet. Restor. Dent. 2021, 33, 173–184. [Google Scholar] [CrossRef]
  70. Linkevicius, T.; Puisys, A.; Steigmann, M.; Vindasiute, E.; Linkeviciene, L. Influence of Vertical Soft Tissue Thickness on Crestal Bone Changes Around Implants with Platform Switching: A Comparative Clinical Study. Clin. Implant Dent. Relat. Res. 2015, 17, 1228–1236. [Google Scholar] [CrossRef]
  71. van Brakel, R.; Noordmans, H.J.; Frenken, J.; de Roode, R.; de Wit, G.C.; Cune, M.S. The effect of zirconia and titanium implant abutments on light reflection of the supporting soft tissues. Clin. Oral Implant. Res. 2011, 22, 1172–1178. [Google Scholar] [CrossRef]
  72. Dash, S.; Srivastava, G.; Padhiary, S.K.; Samal, M.; Cakmak, G.; Roccuzzo, A.; Molinero-Mourelle, P. Validation of the pink esthetic score/white esthetic score at single tooth-supported prostheses in the esthetic zone: A randomized clinical trial. J. Esthet. Restor. Dent. 2024, 36, 976–984. [Google Scholar] [CrossRef]
  73. Gehrke, P.; Lobert, M.; Dhom, G. Reproducibility of the pink esthetic score—Rating soft tissue esthetics around single-implant restorations with regard to dental observer specialization. J. Esthet. Restor. Dent. 2008, 20, 375–384, discussion 385. [Google Scholar] [CrossRef] [PubMed]
  74. Altay, M.A.; Sindel, A.; Tezerisener, H.A.; Yildirimyan, N.; Ozarslan, M.M. Esthetic evaluation of implant-supported single crowns: A comparison of objective and patient-reported outcomes. Int. J. Implant Dent. 2019, 5, 2. [Google Scholar] [CrossRef] [PubMed]
  75. Maia, N.G.; Normando, D.; Maia, F.A.; Ferreira, M.A.; do Socorro Costa Feitosa Alves, M. Factors associated with long-term patient satisfaction. Angle Orthod. 2010, 80, 1155–1158. [Google Scholar] [CrossRef]
  76. Kolerman, R.; Mijiritsky, E.; Barnea, E.; Dabaja, A.; Nissan, J.; Tal, H. Esthetic Assessment of Implants Placed into Fresh Extraction Sockets for Single-Tooth Replacements Using a Flapless Approach. Clin. Implant Dent. Relat. Res. 2017, 19, 351–364. [Google Scholar] [CrossRef] [PubMed]
  77. Palmer, R.M. Risk management in clinical practice. Part 9. Dental implants. Br. Dent. J. 2010, 209, 499–506. [Google Scholar] [CrossRef]
  78. Patil, P.G. A technique for repairing a loosening abutment screw for a cement-retained implant prosthesis. J. Prosthodont. 2011, 20, 652–655. [Google Scholar] [CrossRef]
Dentistry 13 00144 g001
Figure 1. Periapical radiograph showing the measurement of marginal bone level. The known implant length was used to calibrate the radiographic measurements. Then, the mesial and distal marginal bone levels (MBLs) were measured.
Figure 1. Periapical radiograph showing the measurement of marginal bone level. The known implant length was used to calibrate the radiographic measurements. Then, the mesial and distal marginal bone levels (MBLs) were measured.
Dentistry 13 00144 g001
Dentistry 13 00144 g002
Figure 2. Clinical case treated by a single-unit narrow-diameter implant. (A) Clinical picture showing the baseline condition with the diagnosis of hopeless tooth #2.1 due to endo-periodontal disease. (B) The provisional prosthesis. (C) The definitive prosthesis. (D) The definitive prosthesis at higher magnification. (E) Periapical radiograph showing the insertion of the 3.5 mm × 8.5 mm dental implant. (F) Periapical radiograph at the implant loading. (G) Periapical radiograph after three years of implant insertion.
Figure 2. Clinical case treated by a single-unit narrow-diameter implant. (A) Clinical picture showing the baseline condition with the diagnosis of hopeless tooth #2.1 due to endo-periodontal disease. (B) The provisional prosthesis. (C) The definitive prosthesis. (D) The definitive prosthesis at higher magnification. (E) Periapical radiograph showing the insertion of the 3.5 mm × 8.5 mm dental implant. (F) Periapical radiograph at the implant loading. (G) Periapical radiograph after three years of implant insertion.
Dentistry 13 00144 g002
Dentistry 13 00144 g003
Figure 3. Clinical case treated by a single-unit narrow-diameter implant. (A) Clinical picture showing the baseline condition with missing #1.1 replaced by a fixed prosthesis. (B) The provisional prosthesis. (C) The definitive prosthesis. (D) Periapical radiograph showing the insertion of a 3.3 mm × 7.5 mm dental implant. (E) Periapical radiograph at the implant loading. (F) Periapical radiograph after four years of implant insertion.
Figure 3. Clinical case treated by a single-unit narrow-diameter implant. (A) Clinical picture showing the baseline condition with missing #1.1 replaced by a fixed prosthesis. (B) The provisional prosthesis. (C) The definitive prosthesis. (D) Periapical radiograph showing the insertion of a 3.3 mm × 7.5 mm dental implant. (E) Periapical radiograph at the implant loading. (F) Periapical radiograph after four years of implant insertion.
Dentistry 13 00144 g003
Table 1. The lengths and diameters of the dental implants placed to replace a missing central incisor.
Table 1. The lengths and diameters of the dental implants placed to replace a missing central incisor.
Length (mm)Total
6.57.58.510.011.0
Diameter (mm)3.3510102027
3.5514143137
Total1024245164
Table 2. Surgical-related parameters.
Table 2. Surgical-related parameters.
Variable Value
Width of the alveolar bone at crest (mean ± SD)5.6 ± 1.5
Bone type (number)Type I6
Type II51
Type III7
Bone density (A.U) (mean ± SD)741 ± 152
Insertion torque (N.cm) (mean ± SD)28 ± 15
Overcorrection of the vestibular plateYes49
No15
Intermediate abutment lengths1.5 mm3
2 mm27
2.5 mm21
3.0 mm11
3.5 mm2
SD: standard deviation.
Table 3. Dental-implant-related variables.
Table 3. Dental-implant-related variables.
Variable Value
Follow-up time (months) 42 ± 19
Mesial MBL (mm) (mean ± SD)Loading0.7 ± 1.0
Distal MBL (mm) (mean ± SD)0.4 ± 0.9
Mesial MBL (mm) (mean ± SD)Last radiograph0.0 ± 0.9
Distal MBL (mm) (mean ± SD)−0.1 ± 0.6
Variation in MBL–mesial (mm) (mean ± SD) −0.7 ± 0.9
Variation in MBL–distal (mm) (mean ± SD) −0.5 ± 0.7
Implant failure (frequency) 0
Pink Esthetic Score 7.0 ± 2.6
White Esthetic Score 7.9 ± 2.0
MBL: marginal bone level; SD: standard deviation.
Table 4. Technical complications and their frequency.
Table 4. Technical complications and their frequency.
VariableValue
Change the intermediate abutment 4
Pressure on peri-implant mucosa1
Screw loosening2
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Anitua, E.; Tarazona, A.; Alkhraisat, M.H. Retrospective Study of Functional and Esthetic Outcomes Using Narrow-Diameter Implants for Single Upper Central Incisor Replacements. Dent. J. 2025, 13, 144. https://doi.org/10.3390/dj13040144

AMA Style

Anitua E, Tarazona A, Alkhraisat MH. Retrospective Study of Functional and Esthetic Outcomes Using Narrow-Diameter Implants for Single Upper Central Incisor Replacements. Dentistry Journal. 2025; 13(4):144. https://doi.org/10.3390/dj13040144

Chicago/Turabian Style

Anitua, Eduardo, Aitana Tarazona, and Mohammad Hamdan Alkhraisat. 2025. "Retrospective Study of Functional and Esthetic Outcomes Using Narrow-Diameter Implants for Single Upper Central Incisor Replacements" Dentistry Journal 13, no. 4: 144. https://doi.org/10.3390/dj13040144

APA Style

Anitua, E., Tarazona, A., & Alkhraisat, M. H. (2025). Retrospective Study of Functional and Esthetic Outcomes Using Narrow-Diameter Implants for Single Upper Central Incisor Replacements. Dentistry Journal, 13(4), 144. https://doi.org/10.3390/dj13040144

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
