A Review of Thermoplastic Resin Transfer Molding: Process Modeling and Simulation
Abstract
:1. Introduction
2. T-RTM Equipment and Process Parameters
3. The Kinetic Modeling of Polymerization and Crystallization
3.1. Reaction Chemistry
3.2. Polymerization Kinetic Models
3.2.1. The Malkin Model (1979–1984)
3.2.2. The Camargo Model (1983)
3.2.3. The Lin Model (1985)
3.2.4. The Kamal-Sourour Model (1973–1976) adopted by Teuwen (2011–2013)
3.3. AROP Crystallization Kinetic Models
3.3.1. The Avrami Model Adapted by Bolgov (1979–1981)
3.3.2. The Malkin Model (1984)
3.3.3. The Lee and Kim Model (1988)
3.3.4. The Kim Model (1997)
3.3.5. The Tonoyan Model (2007)
3.3.6. The Johnson-Mehl-Avrami-Kolmogorov (JMAC) Equation Adapted by Vicard (2017)
3.4. Experimental Methods of the Investigation of the Kinetics of the AROP of CL
3.4.1. Adiabatic Reactor Tests
3.4.2. DSC Tests
3.4.3. The Extrapolation Technique
3.4.4. The Curve-Resolving Technique
4. Rheokinetic Modeling
4.1. The Malkin Model (1981)
4.2. The Sibal Model (1983)
4.3. The Castro-Macosko Model (1982) Adopted by Taki (2017)
4.4. Rheokinetic Models for Thermosets
4.5. Experimental Methods for the Rheokinetic Investigation of the AROP of CL
5. The Influence of Pressure on Reaction Rate and Pressure-Volume-Temperature Modeling
5.1. The Behavior of Thermosets under Pressure
5.2. Thermoplastic Behavior under Pressure
5.3. Thermoplastic Behavior under Pressure
5.4. Experimental Methods for Measuring pvT Behavior
6. Simulation of the T-RTM Process
7. Conclusions and Future Prospects
Funding
Conflicts of Interest
Abbreviations
ABC | adipol-bis-caprolactam; |
AROP | anionic ring opening polymerization; |
C8H13NO2 | N-acetylcaprolactam; |
CFD | computational fluid dynamic; |
CL | caprolactam; |
DEA | Dielectric Analysis; |
DSC | Differential Scanning Calorimetry; |
EtMgBr | ethyl magnesium bromide; |
HCC | hexamethylene-1,6-bis(carbamidecaprolactam); |
HMDI | hexamethylenediisocyanate; |
KL | potassium salt of lactam; |
LCM | liquid composite molding; |
LiL | lithium salt of lactam; |
NaH | sodium hydrate; |
NMR | Nuclear Magnetic Resonance; |
PA | polyamide; |
T-RTM | thermoplastic resin transfer molding; |
XRD | X-Ray Diffraction; |
compressibility factor; | |
the degree of crystallinity at the termination of the crystallization process; | |
[A] | activator concentration; |
[I] | initiator concentration; |
[M0] | initial monomer concentration; |
crystallization enthalpy; | |
polymerization enthalpy; | |
activation volume for the reaction; | |
a | thermal diffusivity; |
C | heat capacity; |
E | activation energy of the process; |
ms | sample mass; |
Mw | molecular weight of the polymer; |
P | pressure; |
P0 | reference pressure; |
Q | thermal effect of the reaction; |
R | universal gas constant; |
T | processing temperature; |
t0 | characteristic crystallization time; |
Tc | crystallization temperature; |
Tm | melting temperature of the polymer; |
Tp | polymerization temperature; |
Tref | reference temperature; |
α | degree of crystallinity; |
αeq | equilibrium degree of crystallinity; |
β | conversion degree; |
γg, γ | reaction ratio of the monomer at gelation and at any time up to gelation; |
η | viscosity; |
η0 | viscosity of the monomer; |
θ | crystallization induction period. |
