Crystal Structure of the Disordered Non-Centrosymmetric Compound Fe0.43Mo2.56SbO9.5

Department of Materials and Environmental Chemistry, Stockholm University, SE-106 91 Stockholm, Sweden
Department of Chemistry, University of Kalyani, Kalyani, Nadia, West Bengal-741235, India
Division of Polymer and Materials Chemistry, CAS, Lund University, 22241 Lund, Sweden
Authors to whom correspondence should be addressed.
Received: 11 December 2018 / Revised: 8 January 2019 / Accepted: 10 January 2019 / Published: 15 January 2019
(This article belongs to the Section Crystalline Materials)
Full-Text   |   PDF [1396 KB, uploaded 15 January 2019]   |


Single crystals of Fe0.43Mo2.56SbO9.5 were obtained by hydrothermal techniques at 230 °C. The crystal structure was determined from single crystal X-ray diffraction data. The compound crystallizes in the non-centrosymmetric space group Pc with unit cell parameters a = 4.0003(2) Å, b = 7.3355(3) Å, c = 12.6985(6) Å, β = 90°. The crystal structure comprises five crystallographically independent M atoms and one Sb3+ atom, M atoms are of two kinds of partially occupied sites Mo6+ and Fe3+. The building blocks consist of [SbO3O0.5O0.5E] octahedra (E = lone electron pair) and [(Mo/Fe)O6] octahedra. The M = (Mo, Fe) and O atoms are arranged in a distorted hexagonal 2D-net, not the Sb atoms. The distortion of the net and consequently the symmetry reduction results mainly from the location of the Sb atoms. Disorder manifests itself as a splitting of the metal sites and as a consequent shortening of the Mo–Fe distances. Six (Mo/Fe)O6 octahedra are connected to form a pseudohexagonal channel. The Sb3+ atom is displaced from the pseudo-six-fold axis. View Full-Text
Keywords: hydrothermal synthesis; non-centrosymmetric (NCS) materials; X-ray diffraction; disordered structure hydrothermal synthesis; non-centrosymmetric (NCS) materials; X-ray diffraction; disordered structure

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
