Open AccessFeature PaperReview

An Overview of Active Control Techniques for Vortex Rope Mitigation in Hydraulic Turbines

by Sergey Shtork, Daniil Suslov, Sergey Skripkin, Ivan Litvinov and Evgeny Gorelikov

Energies 2023, 16(13), 5131; https://doi.org/10.3390/en16135131 - 3 Jul 2023

Cited by 14 | Viewed by 2410

This review addresses the current state of research into active control and suppression of vortex rope in hydroturbines under off-design operating conditions. Only active control methods that can be “switched on” when required under off-design operating conditions are considered in this work. The review focuses on air addition into the flow, as well as various auxiliary fluid jets. It includes all the best practices for vortex rope suppression in numerical and experimental studies. It can be inferred from the review that a modern flow control system should be comprehensive, designed for a specific hydroturbine geometry, and obtain feedback from the flow. Injecting ~2% of air from the impeller fairing cone appears optimal for suppressing pressure pulsations without significant efficiency loss. The cost of air injection is rarely estimated, but the use of an automatic venting system can minimize overheads and potentially improve efficiencies at low gas contents. Fluid jets ranging from 3% to 12% of the main flow rate can efficiently suppress pressure pulsations, but their high energy requirements limit their use. Azimuthal perturbation of the flow appears promising as it does not require significant energy loss, but practical implementation remains challenging as one needs to accurately know the system dynamics and be capable of real-time manipulation of the flow. Full article

► Show Figures

Figure 1

24 pages, 43961 KiB

Open AccessArticle

Investigation of Flow-Induced Instabilities in a Francis Turbine Operating in Non-Cavitating and Cavitating Part-Load Conditions

by Mohammad Hossein Arabnejad, Håkan Nilsson and Rickard E. Bensow

Fluids 2023, 8(2), 61; https://doi.org/10.3390/fluids8020061 - 10 Feb 2023

Cited by 5 | Viewed by 2743

Abstract

The integration of intermittent renewable energy resources to the grid system requires that hydro turbines regularly operate at part-load conditions. Reliable operation of hydro turbines at these conditions is typically limited by the formation of a Rotating Vortex Rope (RVR) in the draft tube. In this paper, we investigate the formation of this vortex using the scale-resolving methods SST-SAS, wall-modeled LES (WMLES), and zonal WMLES. The numerical results are first validated against the available experimental data, and then analyzed to explain the effect of using different scale-resolving methods in detail. It is revealed that although all methods can capture the main features of the RVRs, the WMLES method provides the best quantitative agreement between the simulation results and experiment. Furthermore, cavitating simulations are performed using WMLES method to study the effect of cavitation on the flow in the turbine. These effects of cavitation are shown to be highly dependent on the amount of vapor in the RVR. If the amount of vapor is small, cavitation induces broadband high-frequency fluctuations in the pressure and forces exerted on the turbine. As the amount of cavitation increases, these fluctuations tend to have a distinct dominant frequency which is different from the frequency of the RVR. Full article

(This article belongs to the Special Issue Recent Advances in Fluid Mechanics: Feature Papers, 2022)

► Show Figures

Figure 1

21 pages, 9173 KiB

Open AccessFeature PaperArticle

Numerical Simulation of the Flow in a Kaplan Turbine Model during Transient Operation from the Best Efficiency Point to Part Load

by Raluca G. Iovănel, Georgiana Dunca, Diana M. Bucur and Michel J. Cervantes

Energies 2020, 13(12), 3129; https://doi.org/10.3390/en13123129 - 16 Jun 2020

Cited by 15 | Viewed by 4305

Abstract

The aim of this study is to develop a reliable numerical model that provides additional information to experimental measurements and contributes to a better exploitation of hydraulic turbines during transient operation. The paper presents a numerical analysis of the flow inside a Kaplan turbine model operated at a fixed runner blade angle during load variation from the best efficiency point (BEP) to part load (PL) operation. A mesh displacement is defined in order to model the closure of the guide vanes. Two different types of inlet boundary conditions are tested for the transient numerical simulations: linear flow rate variation (InletFlow) and constant total pressure (InletTotalPressure). A time step analysis is performed and the influence of the time discretization over the fluctuating quantities is discussed. Velocity measurements at the corresponding operating points are available to validate the simulation. Spectrogram plots of the pressure signals show the times of appearance of the plunging and rotating modes of the rotating vortex rope (RVR) and the stagnation region developed around the centerline of the draft tube is captured. Full article

(This article belongs to the Special Issue State-of the-Art, Challenges and Perspectives in Hydraulic Machines and Systems)

► Show Figures

Figure 1
