The article presents continued considerations presented in a prior publication on the development of a model for calculating the bending stiffness BS of cellular honeycomb paperboards, applying the strength properties of paper raw materials used for the production of paperboard and the geometric parameters of cellular board. The results of BS calculations obtained by using the analytical model presented in the prior publication were significantly overestimated in relation to the value obtained by measurements. The calculation error in relation to the measurement value for the tested group of paperboards in the case of bending stiffness in the machine direction MD was within the range from 23% to 116%, and the average error was 65%, while in the cross direction CD, it was within the range from 2% to 54%, and the average error was 31%. The calculation model proposed in this work based on the physical properties of cellular paperboard reduces the error values for bending stiffness in both the machine and cross directions. The value of the average error for both main directions in the paperboard plane was 10%. The method enables more accurate determination of BS in the machine direction MD and in the cross direction CD at the paperboard design stage. In order to validate the proposed analytical model, the calculation results were compared with the results of BS laboratory measurements performed using the four-point bending method and, in order to expand the group of tested paperboards, with the measurement results presented in the prior article for cardboards with different raw material composition and different geometric parameters. Full article

In the process of logistics, shock and vibration are the most important factors contributing to product damage. Assembling honeycomb paperboard and EPE is commonly used to provide cushioning and anti-vibration effects to materials. Therefore, it is necessary to study the vibration transmission properties of this kind of assembly in the anti-vibration process. The aim of this paper was to experimentally determine the vibration transmission properties of assemblies with honeycomb paperboard and expanded polyethylene (EPE). Through a sinusoidal sweep vibration test of this assembly, the vibration transmission characteristic curves of assemblies with honeycomb paperboard and EPE of different thicknesses were obtained and compared. Assuming the assembly and mass block as a single degree of freedom with a small damping linear system, the damping energy dissipation of the assembly and the resonance frequency were obtained. The vibration transmission property curves of the assembly can be divided into four regions. With an excitation acceleration of 0.5 g and a honeycomb paperboard with a thickness of 60 mm (F60), the vibration transmission rate and the resonance frequency—of the material dampened with EPE at a thickness of 60 mm (E60), and the assembly (F30/E30) with a 30 mm thick honeycomb paperboard and 30 mm thick EPE—increased by −2.5% and −17.5%, −86.9% and 79.3%, and −95.9% and −85.7%, respectively. Compared to the assembly with 20 mm thick honeycomb and 20 mm thick EPE (F20/E20), the vibration transmission rate, the resonance frequency, and the material damping and damping energy dissipation of F40/E20, F30/E30, and F20/E40 increased by 75.6%, 48.3%, and 66.1%; 1.2%, −21.5%, and −38.9%; 241.5%, 82.8%, and 13.3%; and 12.5%, 98.9%, and 106.8%, respectively. Compared to F60 and E60, the damping energy dissipation of F30/E30 increased by 2816.7% and 133.3%, respectively. The assembly of F30/E30 has the smallest vibration transmission rate and the most vibration energy dissipation among these assemblies. This means that the assembly of F30/E30 absorbs the most external vibration energy, while the acceleration that is transmitted to the internal product is minimal. Therefore, in the design of cushioning packaging, according to the characteristics and natural frequency of the internal products, an appropriate assembly can be selected, which should have a lower vibration transmission rate and more vibration energy dissipation, and should not resonate with the internal product. This will provide a theoretical basis for the design of cushioning packaging. Full article

This article analyzes the influence of the initial deflection of the flat layers on the bending stiffness (BS) of honeycomb paperboards and presents two methods for its calculation. Both methods allow for the determination of BS in the main directions in the plane of the paperboard, i.e., the machine direction (MD) and the cross direction (CD). In addition, they have been verified by comparing the calculation results with the results of the BS measurements. The first method allowed for the calculation of the BS of cellular paperboard based on the mechanical properties of the paper used for its production. The second method allowed for the estimation of the BS of cellular paperboard based on the bending stiffness of other honeycomb paperboards with the same raw material composition and the same core cell size but with different thicknesses. In the first analytical method for the calculation of the bending stiffness of cellular paperboard, which does not include the deflections of the flat layers, the calculation results significantly differ from the measurement results, and they are overestimated. The second of the presented BS calculation methods allowed for a much more accurate assessment of paperboard’s bending stiffness depending on its thickness. Full article

This paper presents an experimental and numerical analysis using the finite element method (FEM) of the bending of honeycomb-core panel. Segments of honeycomb paperboard of several thicknesses were subjected to four-point flexure tests to determine their bending stiffness and maximum load. Several mechanical properties of orthotropic materials were taken into account to account for the experimental results. The numerical analysis of the damage prediction was conducted by using well-known failure criteria such as maximum stress, maximum strain and Tsai-Wu. The present study revealed how to model the honeycomb panel to obtain curves close to experimental ones. This approach can be useful for modelling more complex structures made of honeycomb paperboard. Moreover, thanks to the use of variously shaped cells in numerical models, i.e., the shape of a regular hexagon and models with a real shape of the core cell, results of the calculation were comparable with the results of the measurements. It turned out that the increase of maximum loads and rise in stiffness for studied samples were almost either linearly proportional or quadratically proportional as a function of the panel thickness, respectively. On the basis of failure criteria, slightly lower maximum loads were attained in a comparison to empiric maximum loads. Full article

The article presents the method of calculating the edge crush test (ECT) of honeycomb paperboard. Calculations were made on the basis of mechanical properties of paper raw materials used for the production of cellular paperboard and geometrical parameters describing cellular paperboard. The presented method allows ECT calculation of honeycomb paperboard in the main directions in the paperboard plane; i.e., machine direction (MD) and cross direction (CD). The proposed method was verified by comparing the results of calculations with the results of ECT measurements of paperboard with different geometrical parameters made of different fibrous materials. Full article
