A miniaturized traveling wave tube (TWT) was studied by proposing a novel metamaterial (MTM) slow wave structure (SWS). The dispersion results show that n = −1 space harmonic of the fundamental mode exhibits the “forward” wave properties, which is the foundation of the MTM-inspired TWT. Meanwhile, the interaction impedance for mode 2 of the novel MTM SWS can be sharply decreased by introducing four blend edges to weaken the corresponding longitudinal electric field. Also, two coaxial couplers are presented to input/output the signals. The transmission results show that the reflection is as low as −15 dB from 2.90 GHz to 3 GHz, which ensures the amplified signal can be effectively outputted. The MTM-inspired TWT exhibits miniaturized superiority for its compact high frequency structure including the MTM SWS and the coaxial couplers. Especially, for the high-frequency structure, the transverse and longitudinal sizes are ~λ/5 and ~3λ, respectively (λ is the free-space wavelength at the operating frequencies). The simulation of the beam wave interaction shows that the proposed MTM-inspired TWT yields output powers of kW levels from 2.90 GHz to 3 GHz, with a gain of 23.5–25.8 dB and electronic efficiency of 14–22% when the beam current is 0.5 A and the beam voltage is 13 kV. The results indicate that the gain per wavelength is as high as 8.5 dB in the operating bands. The simulation results confirm that it is possible to weaken the backward wave oscillation from the higher mode in the miniaturized MTM-inspired TWT. Full article

The applications of terahertz (THz) devices in communication, imaging, and plasma diagnostic are limited by the lack of high-power, miniature, and low-cost THz sources. To develop high-power THz source, the high-harmonic traveling wave tube (HHTWT) is introduced, which is based on the theory that electron beam modulated by electromagnetic (EM) waves can generate high harmonic signals. The principal analysis and simulation results prove that amplifying high harmonic signal is a promising method to realize high-power THz source. For further improvement of power and bandwidth, two novel dual-beam schemes for high-power 346 GHz TWTs are proposed. The first TWT is comprised of two cascaded slow wave structures (SWSs), among which one SWS can generate a THz signal by importing a millimeter-wave signal and the other one can amplify THz signal of interest. The simulation results show that the output power exceeds 400 mW from 340 GHz to 348 GHz when the input power is 200 mW from 85 GHz to 87 GHz. The peak power of 1100 mW is predicted at 346 GHz. The second TWT is implemented by connecting a pre-amplification section to the input port of the HHTWT. The power of 600 mW is achieved from 338 GHz to 350 GHz. The 3-dB bandwidth is 16.5 GHz. In brief, two novel schemes have advantages in peak power and bandwidth, respectively. These two dual-beam integrated schemes, constituted respectively by two TWTs, also feature rugged structure, reliable performance, and low costs, and can be considered as promising high-power THz sources. Full article
