10 pages, 3417 KiB
Communication
Phase Measurement of Guided-Mode Resonance Device Using Digital Micromirror Device Gratings
by Min-Xu Chiang, Jaturon Tongpakpanang and Wen-Kai Kuo
Photonics 2021, 8(5), 136; https://doi.org/10.3390/photonics8050136 - 23 Apr 2021
Cited by 6 | Viewed by 3815
Abstract
This paper reports on the measurement system of the phase difference between s- and p-polarization components of the light passing through a guided-mode resonance (GMR) device using a digital micromirror device (DMD) gratings as a digital phase-shifting device. The phase of [...] Read more.
This paper reports on the measurement system of the phase difference between s- and p-polarization components of the light passing through a guided-mode resonance (GMR) device using a digital micromirror device (DMD) gratings as a digital phase-shifting device. The phase of the non-zeroth order diffraction beams of the grating pattern displayed on the DMD can exhibit a phase change when the grating pattern is shifted. Two nearest different diffraction orders of p-polarized and s-polarized beams can be used as the reference and measurement beams, respectively, and are combined to implement the phase-shifting interferometry (PSI). The phase difference between the s- and the p-polarization components of the incident light passing through the GMR device can be obtained by applying the four-step phase-shift algorithm to the DMD-based PSI system. Experimental results show that this measurement system has a phase detection limit of 1° and was able to obtain the abrupt phase difference curve of the GMR device versus the incident angle. Full article
Show Figures

Figure 1

13 pages, 3200 KiB
Article
Scanning Micro-Mirror with an Electrostatic Spring for Compensation of Hard-Spring Nonlinearity
by Takashi Izawa, Takashi Sasaki and Kazuhiro Hane
Micromachines 2017, 8(8), 240; https://doi.org/10.3390/mi8080240 - 4 Aug 2017
Cited by 25 | Viewed by 6975
Abstract
A scanning micro-mirror operated at the mechanical resonant frequency often suffer nonlinearity of the torsion-bar spring. The torsion-bar spring becomes harder than the linear spring with the increase of the rotation angle (hard-spring effect). The hard-spring effect of the torsion-bar spring generates several [...] Read more.
A scanning micro-mirror operated at the mechanical resonant frequency often suffer nonlinearity of the torsion-bar spring. The torsion-bar spring becomes harder than the linear spring with the increase of the rotation angle (hard-spring effect). The hard-spring effect of the torsion-bar spring generates several problems, such as hysteresis, frequency shift, and instability by oscillation jump. In this paper, a scanning micro-mirror with an electrostatic-comb spring is studied for compensation of the hard-spring effect of the torsion-bar spring. The hard-spring effect of the torsion-bar spring is compensated with the equivalent soft-spring effect of the electrostatic-comb spring. The oscillation curve becomes symmetric at the resonant frequency although the resonant frequency increases. Theoretical analysis is given for roughly explaining the compensation. A 0.5 mm square scanning micro-mirror having two kinds of combs, i.e., an actuator comb and a compensation comb, is fabricated from a silicon-on-insulator wafer for testing the compensation of the hard-spring in a vacuum and in atmospheric air. The bending of the oscillation curve is compensated by applying a DC voltage to the electrostatic-comb spring in vacuum and atmosphere. The compensation is attributed by theoretical approach to the soft-spring effect of the electrostatic-comb spring. Full article
(This article belongs to the Special Issue MEMS Mirrors)
Show Figures

Figure 1

13 pages, 4274 KiB
Article
In-Plane Optical Beam Collimation Using a Three-Dimensional Curved MEMS Mirror
by Yasser M. Sabry, Diaa Khalil, Bassam Saadany and Tarik Bourouina
Micromachines 2017, 8(5), 134; https://doi.org/10.3390/mi8050134 - 25 Apr 2017
Cited by 12 | Viewed by 7424
Abstract
The collimation of free-space light propagating in-plane with respect to the substrate is an important performance factor in optical microelectromechanical systems (MEMS). This is usually carried out by integrating micro lenses into the system, which increases the cost of fabrication/assembly in addition to [...] Read more.
The collimation of free-space light propagating in-plane with respect to the substrate is an important performance factor in optical microelectromechanical systems (MEMS). This is usually carried out by integrating micro lenses into the system, which increases the cost of fabrication/assembly in addition to limiting the wavelength working range of the system imposed by the dispersion characteristic of the lenses. In this work we demonstrate optical fiber light collimation using a silicon micromachined three-dimensional curved mirror. Sensitivity to micromachining and fiber alignment tolerance is shown to be low enough by restricting the ratio between the mirror focal length and the optical beam Rayleigh range below 5. The three-dimensional curvature of the mirror is designed to be astigmatic and controlled by a process combining deep, reactive ion etching and isotropic etching of silicon. The effect of the micromachining surface roughness on the collimated beam profile is investigated using a Fourier optics approach for different values of root-mean-squared (RMS) roughness and correlation length. The isotropic etching step of the structure is characterized and optimized for the optical-grade surface requirement. The experimental optical results show a beam-waist ratio of about 4.25 and a corresponding 12-dB improvement in diffraction loss, in good agreement with theory. This type of micromirror can be monolithically integrated into lensless microoptoelectromechanical systems (MOEMS), improving their performance in many different applications. Full article
(This article belongs to the Special Issue MEMS Mirrors)
Show Figures

Figure 1
