Establishing the manner of death is one of the most challenging tasks for forensic pathologists. We present the case of a 24-year-old woman found dead in the early morning on a flyover. The body was sitting on the ground with the back leaning against a wall. The neck was encircled by a white phone charger cable knotted to the staircase’s handrail. The victim had argued with her boyfriend and tried to jump out of his car while coming home from a wedding party the night before. After that, she left home alone with her phone charger in her hand. Due to self-harm behaviors, the first hypothesis was suicide by hanging. However, the ligature crossed immediately beneath the thyroid cartilage and encircled the neck twice horizontally; the two ends of the cable overlapped, forming a cross-over point in the front-right of the neck. Then, the ligature passed obliquely through the nape, gradually disappearing, forming a gap in the mark. The mark was sharply defined, stiff, yellow, and parchment-like. The investigators performed a three-dimensional scene reconstruction using the Trimble X7 Laser Scanner and the PC-Crash Multibody System. Even though the geometry of the ligature mark in the present case raised doubts about the manner of death, the three-dimensional reconstruction confirmed that the hanging was feasible without any external intervention. Full article

Forensic crash investigation often requires developing detailed profiles showing the location and extent of vehicle damage to identify impact areas, impact direction, deformation, and estimated vehicle speeds at impact. Traditional damage profiling techniques require extended and comprehensive setups for mapping and measurement that are quite labor- and time-intensive. Due to the time involved, this damage profiling is usually done in a remote holding area after the crash scene is cleared. Light detection and ranging (LiDAR) scanning technology in consumer handheld electronic devices, such as smartphones and tablets, holds significant potential for conducting this damage profile mapping in just a few minutes, allowing the mapping to be conducted at the scene before the vehicle(s) are moved. However, there is limited research and even scarcer published literature on field procedures and/or accuracy for these emerging smartphones and tablets with LiDAR. This paper proposes a methodology and subsequent measurement accuracy comparisons for survey-grade terrestrial laser scanning (TLS) and handheld alternatives. The maximum root mean square error (RMSE) obtained for profile distance between handheld (iPad) and survey-grade TLS LiDAR scans for a damaged vehicle was observed to be 3 cm, a level of accuracy that is likely sufficient and acceptable for most forensic studies. Full article

Small unmanned aircraft systems (sUASs) have emerged as promising platforms for the purpose of crash scene reconstruction through structure-from-motion (SfM) photogrammetry. However, auto crashes tend to occur under adverse weather conditions that usually pose increased risks of sUAS operation in the sky. Wind is a typical environmental factor that can cause adverse weather, and sUAS responses to various wind conditions have been understudied in the past. To bridge this gap, commercial and open source sUAS flight simulation software is employed in this study to analyze the impacts of wind speed, direction, and turbulence on the ability of sUAS to track the pre-planned path and endurance of the flight mission. This simulation uses typical flight capabilities of quadcopter sUAS platforms that have been increasingly used for traffic incident management. Incremental increases in wind speed, direction, and turbulence are conducted. Average 3D error, standard deviation, battery use, and flight time are used as statistical metrics to characterize the wind impacts on flight stability and endurance. Both statistical and visual analytics are performed. Simulation results suggest operating the simulated quadcopter type when wind speed is less than 11 m/s under light to moderate turbulence levels for optimal flight performance in crash scene reconstruction missions, measured in terms of positional accuracy, required flight time, and battery use. Major lessons learned for real-world quadcopter sUAS flight design in windy conditions for crash scene mapping are also documented. Full article

Light Detection and Ranging (LiDAR) is a technology that uses laser beams to measure ranges and generates precise 3D information about the scanned area. It is rapidly gaining popularity due to its contribution to a variety of applications such as Digital Building Model (DBM) generation, telecommunications, infrastructure monitoring, transportation corridor asset management and crash/accident scene reconstruction. To derive point clouds with high positional accuracy, estimation of mounting parameters relating the laser scanners to the onboard Global Navigation Satellite System/Inertial Navigation System (GNSS/INS) unit, i.e., the lever-arm and boresight angles, is the foremost and necessary step. This paper proposes a LiDAR system calibration strategy for a Unmanned Aerial Vehicle (UAV)-based mobile mapping system that can directly estimate the mounting parameters for spinning multi-beam laser scanners through an outdoor calibration procedure. This approach is based on the use of conjugate planar/linear features in overlapping point clouds derived from different flight lines. Designing an optimal configuration for calibration is the first and foremost step in order to ensure the most accurate estimates of mounting parameters. This is achieved by conducting a rigorous theoretical analysis of the potential impact of bias in mounting parameters of a LiDAR unit on the resultant point cloud. The dependency of the impact on the orientation of target primitives and relative flight line configuration would help in deducing the configuration that would maximize as well as decouple the impact of bias in each mounting parameter so as to ensure their accurate estimation. Finally, the proposed analysis and calibration strategy are validated by calibrating a UAV-based LiDAR system using two different datasets—one acquired with flight lines at a single flying height and the other with flight lines at two different flying heights. The calibration performance is evaluated by analyzing correlation between the estimated system parameters, the a-posteriori variance factor of the Least Squares Adjustment (LSA) procedure and the quality of fit of the adjusted point cloud to planar/linear features before and after the calibration process. Full article

This paper presents an efficient and low-cost approach for energy analysis of road accidents using images obtained using consumer-grade digital cameras and smartphones. The developed method could be used by security forces in order to improve the qualitative and quantitative analysis of traffic accidents. This role of the security forces is crucial to settle arguments; consequently, the remote and non-invasive collection of accident related data before the scene is modified proves to be essential. These data, taken in situ, are the basis to perform the necessary calculations, basically the energy analysis of the road accident, for the corresponding expert reports and the reconstruction of the accident itself, especially in those accidents with important damages and consequences. Therefore, the method presented in this paper provides the security forces with an accurate, three-dimensional, and scaled reconstruction of a road accident, so that it may be considered as a support tool for the energy analysis. This method has been validated and tested with a real crash scene simulated by the local police in the Academy of Public Safety of Extremadura, Spain. Full article
