Article
An Optimalization Study on the Surface Texture and Machining Parameters of 60CrMoV18-5 Steel by EDM
by Panagiotis Karmiris-Obratański, Emmanouil L. Papazoglou, Beata Leszczyńska-Madej, Nikolaos E. Karkalos and Angelos P. Markopoulos
Materials 2022, 15(10), 3559; https://doi.org/10.3390/ma15103559 - 16 May 2022
Cited by 19 | Viewed by 2481
Abstract
As a non-conventional machining technology, EDM is used extensively in modern industry, particularly in machining difficult-to-cut materials. CALMAX is a chromium-molybdenum-vanadium tool steel with exceptional toughness, ductility, and wear resistance that has a wide range of applications. Despite the fact that EDM is [...] Read more.
As a non-conventional machining technology, EDM is used extensively in modern industry, particularly in machining difficult-to-cut materials. CALMAX is a chromium-molybdenum-vanadium tool steel with exceptional toughness, ductility, and wear resistance that has a wide range of applications. Despite the fact that EDM is routinely used in CALMAX machining, the related published research is brief and limited. The current research gives a complete experimental study of CALMAX machining using EDM. A Taguchi Design of Experiment (DOE) was used, using pulse-on current, pulse-on time, and open-circuit voltage as control parameters. Material Removal Rate (MRR), Tool Material Removal Rate (TMRR), and Tool Wear Ratio (TWR) were used to evaluate machining performance, while Ra and Rz were used to estimate Surface Quality (SQ). The produced White Layer (WL) parameters were determined using optical and SEM microscopy, as well as EDX measurements and micro-hardness studies. Finally, for each of the aforementioned indexes, Analysis of Variance (ANOVA) was performed, and multi-objective optimization was based on Grey Relational Analysis (GRA). The results show that higher open-circuit voltage produces lower WL thickness, although by increasing the pulse-on time, the TWR is increased. The average hardness of the WL is increased about 400% compared to the micro-hardness of the bulk material. Full article
Show Figures

Graphical abstract

15 pages, 10930 KiB
Concept Paper
Investigation of Surface Modification of 60CrMoV18-5 Steel by EDM with Cu-ZrO2 Powder Metallurgy Green Compact Electrode
by Maria Balanou, Panagiotis Karmiris-Obratański, Beata Leszczyńska-Madej, Emmanouil L. Papazoglou and Angelos P. Markopoulos
Machines 2021, 9(11), 268; https://doi.org/10.3390/machines9110268 - 3 Nov 2021
Cited by 12 | Viewed by 2485
Abstract
Electrical discharge machining (EDM) is a non-conventional machining process, which is mostly used for machining of difficult-to-cut materials. These materials are often used in engineering applications that require improved surface properties; thus, surface modification is desirable in these cases. In the recent past, [...] Read more.
Electrical discharge machining (EDM) is a non-conventional machining process, which is mostly used for machining of difficult-to-cut materials. These materials are often used in engineering applications that require improved surface properties; thus, surface modification is desirable in these cases. In the recent past, it has been observed that EDM is an alternative surface modification process due to migration of material from the electrode to the workpiece surface. Surface modification can be done with powder metallurgy (P/M) electrode as tool. The aim of this work is to examine the surface modification of the tool steel Calmax (Uddeholm) by EDM process using Cu-30 wt.% ZrO2 P/M green compact electrode. The influence of peak current (Ip) and pulse-on (Ton) on the Material Transfer Rate (MTR) and Surface Roughness (SR) was investigated and the surface characteristics were also evaluated by scanning electron microscopy (SEM). The experimental results confirm the material migration from the electrode to the machined surface and show that the higher MTR of 46.5 mgr/min is achieved on the combination of Ip = 9 A and Ton = 25 μs and the Ra varies from 3.72 μm to 7.12 μm. Full article
(This article belongs to the Special Issue Feature Papers to Celebrate the First Impact Factor of Machines)
