The prevalence of Low Probability of Interception (LPI) and Low Probability of Exploitation (LPE) radars in contemporary Electronic Warfare (EW) presents an ongoing challenge to defense mechanisms, compelling constant advances in protective strategies. Noise radars are examples of LPI and LPE systems that gained substantial prominence in the past decade despite exhibiting a common drawback of limited Doppler tolerance. The Advanced Pulse Compression Noise (APCN) waveform is a stochastic radar signal proposed to amalgamate the LPI and LPE attributes of a random waveform with the Doppler tolerance feature inherent to a linear frequency modulation. In the present work, we derive closed-form expressions describing the APCN signal’s ambiguity function and spectral containment that allow for a proper analysis of its detection performance and ability to remove range ambiguities as a function of its stochastic parameters. This paper also presents a more detailed address of the LPI/LPE characteristic of APCN signals claimed in previous works. We show that sophisticated Electronic Intelligence (ELINT) systems that employ Time Frequency Analysis (TFA) and image processing methods may intercept APCN and estimate important parameters of APCN waveforms, such as bandwidth, operating frequency, time duration, and pulse repetition interval. We also present a method designed to intercept and exploit the unique characteristics of the APCN waveform. Its performance is evaluated based on the probability of such an ELINT system detecting an APCN radar signal as a function of the Signal-to-Noise Ratio (SNR) in the ELINT system. We evaluated the accuracy and precision of the random variables characterizing the proposed estimators as a function of the SNR. Results indicate a probability of detection close to 1 and show good performance, even for scenarios with a SNR slightly less than $-10$ dB. The contributions in this work offer enhancements to noise radar capabilities while facilitating improvements in ESM systems. Full article

The process of recognising and classifying radar signals and their radiation sources is currently a key element of operational activities in the electromagnetic environment. Systems of this type, called ELINT class systems, are passive solutions that detect, process, and analyse radio-electronic signals, providing distinctive information on the identified emission source in the final stage of data processing. The data processing in the mentioned types of systems is a very sophisticated issue and is based on advanced machine learning algorithms, artificial neural networks, fractal analysis, intra-pulse analysis, unintentional out-of-band emission analysis, and hybrids of these methods. Currently, there is no optimal method that would allow for the unambiguous identification of particular copies of the same type of radar emission source. This article constitutes an attempt to analyse radar signals generated by six radars of the same type under comparable measurement conditions for all six cases. The concept of the SEI module for the ELINT system was proposed in this paper. The main aim was to perform an advanced analysis, the purpose of which was to identify particular copies of those radars. Pioneering in this research is the application of the author’s algorithm for the data particle geometrical divide, which at the moment has no reference in international publication reports. The research revealed that applying the data particle geometrical divide algorithms to the SEI process concerning six copies of the same radar type allows for almost three times better accuracy than a random labelling strategy within approximately one second. Full article

The paper presents the concept of mission planning for a short-range tactical class Unmanned Aerial Vehicle (UAV) that recognizes targets using the sensors it has been equipped with. Tasks carried out by such systems are mainly associated with aerial reconnaissance employing Electro Optical (EO)/Near Infra-Red (NIR) heads, Synthetic Aperture Radar (SAR), and Electronic Intelligence (ELINT) systems. UAVs of this class are most often used in NATO armies to support artillery actions, etc. The key task, carried out during their activities, is to plan a reconnaissance mission in which the flight route will be determined that optimally uses the sensors’ capabilities. The paper describes the scenario of determining the mission plan and, in particular, the UAV flight routes to which the recognition targets are assigned. The problem was decomposed into several subproblems: assigning reconnaissance tasks to UAVs with choosing the reconnaissance sensors and designating an initial UAV flight plan. The last step is planning a detailed flight route taking into account the time constraints imposed on recognition and the characteristics of the reconnaissance sensors. The final step is to generate the real UAV flight trajectory based on its technical parameters. The algorithm for determining exact flight routes for the indicated reconnaissance purposes was also discussed, taking into account the presence of enemy troops and available air corridors. The task scheduling algorithm—Vehicle Route Planning with Time Window (VRPTW)—using time windows is formulated in the form of the Mixed Integer Linear Problem (MILP). The MILP formulation was used to solve the UAV flight route planning task. The algorithm can be used both when planning individual UAV missions and UAV groups cooperating together. The approach presented is a practical way of establishing mission plans implemented in real unmanned systems. Full article

This paper presents a novel approach to fast and accurate non-linear pulse signal reconstruction dedicated for electromagnetic sensors and their applications such as ELectronic INTelligence (ELINT), electronic warfare (EW), electronic reconnaissance (ER) systems, as well as for passive bistatic radar purposes in which other pulse radars are used as a source of illumination. The method is based on the instantaneous chirp rate (CR) estimation in the time-frequency (TF) domain providing a calculation of the frequency rate between every two consecutive samples. Such a new method allows for the precise reconstruction of the non-linear frequency modulated (NLFM) signal to be carried out in significantly shorter time in comparison to methods known in the literature. The presented approach was tested and validated using both simulated and real-life radar signals proving the usability of the proposed solution in practical applications. The results were compared with the precise extended generalized chirp transform (EGCT) method as a reference technique, using optimal matched filtration as the main concept. Full article
