Multiparametric ultrasound (mpUS) enhances prostate cancer (PCa) diagnosis by using multiple imaging modalities. Tissue-mimicking materials (TMM) phantoms, favoured over animal models for ethical and consistency reasons, were created using polyvinyl alcohol (PVA) with varying molecular weights (Mw). Methods: Four PVA samples, varying in Mw with constant concertation, were mixed with glycerol, silicon carbide (SiC), and aluminium oxide (Al₂O₃). Phantoms with varying depth and inclusion sizes were created and tested using shear-wave elastography (SWE). An mpUS phantom was developed to mimic prostate tissue, including isoechoic and hypoechoic inclusions and vessels. The phantom was scanned using supersonic ultrasound, strain elastography, and Doppler ultrasound. Validation was performed using radical prostatectomy data and shear-wave elastography. Results: The acoustic properties varied with enhancers like glycerol and Al₂O₃. Low Mw PVA samples had a speed of sound ranging from 1547.50 ± 2 to 1553.70 ± 2.2 m/s and attenuation of 0.61 ± 0.062 to 0.63 ± 0.05 dB/cm/MHz. High Mw PVA samples ranged from 1555 ± 2.82 to 1566 ± 4.5 m/s and 0.71 ± 0.02 to 0.73 ± 0.046 dB/cm/MHz. Young’s modulus ranged from 11 ± 2 to 82.3 ± 0.5 kPa across 1 to 10 freeze-thaw cycles. Inclusion size, depth, and interaction statistically affect the SWE measurements with p-value = 0.056327, p-value = 8.0039 × 10⁻⁸, and p-value = 0.057089, respectively. SWE showed isoechoic inclusions, prostate tissue, and surrounding tissue only. The Doppler velocity was measured in three different inner diameters. Conclusion: PVA mixed with enhancer materials creates an mpUS phantom with properties that mimic normal and abnormal prostate tissue, blood vessels, and soft tissue, facilitating advanced diagnostic training and validation. Full article

Hemorrhage is the leading cause of preventable death in both civilian and military medicine. Junctional hemorrhages are especially difficult to manage since traditional tourniquet placement is often not possible. Ultrasound can be used to visualize and guide the caretaker to apply pressure at physiological pressure points to stop hemorrhage. However, this process is technically challenging, requiring the vessel to be properly positioned over rigid boney surfaces and applying sufficient pressure to maintain proper occlusion. As a first step toward automating this life-saving intervention, we demonstrate an artificial intelligence algorithm that classifies a vessel as patent or occluded, which can guide a user to apply the appropriate pressure required to stop flow. Neural network models were trained using images captured from a custom tissue-mimicking phantom and an ex vivo swine model of the inguinal region, as pressure was applied using an ultrasound probe with and without color Doppler overlays. Using these images, we developed an image classification algorithm suitable for the determination of patency or occlusion in an ultrasound image containing color Doppler overlay. Separate AI models for both test platforms were able to accurately detect occlusion status in test-image sets to more than 93% accuracy. In conclusion, this methodology can be utilized for guiding and monitoring proper vessel occlusion, which, when combined with automated actuation and other AI models, can allow for automated junctional tourniquet application. Full article

The purpose of this study was to create a Doppler ultrasound training phantom aimed at aiding beginners in comprehending and effectively utilizing critical parameters during the learning process. Our designed training phantom does not require the use of a water pump or an automated injector. The fabrication of the vessel-mimicking phantom was accomplished using agarose gel. We utilized LEGO blocks to introduce a height difference that simulated blood flow within the phantom. The imitation blood material was prepared using glycerin. Ultrasound images were obtained using an Accuvix V10 device. This study utilized a Doppler ultrasound training phantom to facilitate stable imaging for beginners during scanning, due to its secure fixation. Furthermore, the fabricated vessel-mimicking phantom offers the advantage of adjusting the diameter of vessels during the fabrication process. Additionally, the easy adaptability, to tailor the phantom specifically for certain conditions by modifying only the vascular components, is another notable advantage. The experimental values for parameters such as the color box, scale, and color gain were collected. The spectral Doppler was used for a rough assessment of blood flow velocity. Color Doppler images, acquired via adjusting the color box to the left and right, displayed blood flow information in blue on the left, and red on the right. At a scale setting of 4 kHz and 0.6 kHz for color Doppler imaging, aliasing was absent at 4 kHz, but appeared at 0.6 kHz. Experiments involving various gain settings (2 dB, 5 dB, 10 dB, 35 dB, 60 dB, and 100 dB) demonstrated that the blood flow information was diminished at 2 dB, and exaggerated at 100 dB. Full article
