Double-sided permanent magnet linear synchronous machine with 120° phase belt toroidal windings (120°-TWDSPMLSM) suffers from large detent force due to the end effect and slot effect. Many existing methods can reduce the detent force of the 120°-TWDSPMLSM effectively. But they also minimize the back electromotive force (back-EMF) and thrust simultaneously. To alleviate this problem, this paper adopts a method of combining slot-shift structure with rearranging the 120° phase belt toroidal windings (120°-TW) to suppress the detent force and improve the back-EMF and thrust of the 120°-TWDSPMLSM simultaneously. First, the slots on the two sides of the primary part are stagger by an optimal distance to reduce the detent force. The models of the detent force, including the end force and cogging force, is established theoretically, and then verified by finite-element analysis (FA). Then, the 120°-TW are rearranged to improve the back-EMF and average thrust. And the electromagnetic characteristics of the 120°-TWDSPMLSM under different shifted distances are analyzed and compared in detail. Finally, the result shows that the detent force of optimized machine is 70.19% lower than that of the original machine, and the thrust fluctuation reduces 19.21%. Besides, the back-EMF of optimized machine is 6.84% lower than that of the original machine, but 31.86 higher than the machine with shifting slots and without rearranging the 120°-TW. Therefore, the optimal method in this paper is available in the detent force reduction and thrust improvement of the 120°-DSPMLSM. Full article

120° phase belt toroidal winding solid rotor induction motor (120°PBTWSRIM) has advantages of simple structure, short end winding, and high overload capacity, thus it has good development prospects. To study the influence of different structural parameters on 120°PBTWSRIM performance, the 2D finite element model is established, and the electromagnetic characteristics are analyzed. The influence of six structure parameters on the average output torque, power factor, and torque ripple are analyzed, which are slot opening width, slot opening height, slot width, slot height, slot radius, and copper layer thickness. It is found that copper layer thickness has a significant effect on the performance of 120°PBTWSRIM. When the copper layer thickness is 0.5 mm, locked average output torque is increased to 2.784 Nm, locked power factor is increased by 64.6%, and locked torque ripple is reduced by 79.7%. Finally, a prototype of 120°PBTWSRIM is built and experimented, the correctness of performance influence analysis is verified by the comparison of results of the simulation and the experiment. Full article
