Crystals, Volume 7, Issue 6 (June 2017) – 34 articles

Cover Story (view full-size image): Ordered shells might be instrumental in the realization of scaled crystals. The shells are expected to play the role of atoms and topological defects (TDs) within the crystals to determine their valence. A plot of orientation ordering on a shell is indicated in the figure below The cores of TDs are essentially melted (i.e., ). Left: superimposed orientation and amplitude field. Right: the shell’s shape with the corresponding amplitude profile presented from different perspectives.
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
2101 KiB
Letter
Switchable Two-Dimensional Liquid Crystal Grating in Blue Phase
by Bing-Yau Huang, Shih-Hung Lin, Ke-Chin Lin and Chie-Tong Kuo
Crystals 2017, 7(6), 182; https://doi.org/10.3390/cryst7060182 - 21 Jun 2017
Cited by 4 | Viewed by 4902
Abstract
We demonstrate a switchable two-dimensional phase grating in blue phase liquid crystal (BPLC), which is fabricated by sawtooth in-plane-switch (IPS) electrodes. They are used to generate the horizontal electric field on a single indium-tin-oxide (ITO) glass substrate and, as a result, the 1-D [...] Read more.
We demonstrate a switchable two-dimensional phase grating in blue phase liquid crystal (BPLC), which is fabricated by sawtooth in-plane-switch (IPS) electrodes. They are used to generate the horizontal electric field on a single indium-tin-oxide (ITO) glass substrate and, as a result, the 1-D and 2-D phase gratings can be mutual switched via different polarizations of incident light with an applied voltage. The first-order diffraction efficiency is up to 20% and 10% for the 1-D and 2-D phase grating at V = 150 V, respectively. Moreover, the rise and decay time is 0.9 and 1.1 ms, respectively, which is suitable for wide applications of high-speed optical manipulations. Full article
Show Figures

Figure 1

4761 KiB
Article
Combining Single- and Poly-Crystalline Measurements for Identification of Crystal Plasticity Parameters: Application to Austenitic Stainless Steel
by Samir El Shawish and Leon Cizelj
Crystals 2017, 7(6), 181; https://doi.org/10.3390/cryst7060181 - 21 Jun 2017
Cited by 18 | Viewed by 5326
Abstract
Crystal plasticity finite element models have been extensively used to simulate various aspects of polycrystalline deformations. A common weakness of practically all models lies in a relatively large number of constitutive modeling parameters that, in principle, would require dedicated measurements on proper length [...] Read more.
Crystal plasticity finite element models have been extensively used to simulate various aspects of polycrystalline deformations. A common weakness of practically all models lies in a relatively large number of constitutive modeling parameters that, in principle, would require dedicated measurements on proper length scales in order to perform reliable model calibration. It is important to realize that the obtained data at different scales should be properly accounted for in the models. In this work, a two-scale calibration procedure is proposed to identify (conventional) crystal plasticity model parameters on a grain scale from tensile test experiments performed on both single crystals and polycrystals. The need for proper adjustment of the polycrystalline tensile data is emphasized and demonstrated by subtracting the length scale effect, originating due to grain boundary strengthening, following the Hall–Petch relation. A small but representative volume element model of the microstructure is identified for fast and reliable identification of modeling parameters. Finally, a simple hardening model upgrade is proposed to incorporate the grain size effects in conventional crystal plasticity. The calibration strategy is demonstrated on tensile test measurements on 316L austenitic stainless steel obtained from the literature. Full article
(This article belongs to the Special Issue Plasticity of Crystals and Interfaces)
Show Figures

Figure 1

5711 KiB
Article
Microstructure Analysis and Thermoelectric Properties of Melt-Spun Bi-Sb-Te Compounds
by Weon Ho Shin, Jeong Seop Yoon, Mahn Jeong, Jae Min Song, Seyun Kim, Jong Wook Roh, Soonil Lee, Won Seon Seo, Sung Wng Kim and Kyu Hyoung Lee
Crystals 2017, 7(6), 180; https://doi.org/10.3390/cryst7060180 - 20 Jun 2017
Cited by 8 | Viewed by 4432
Abstract
In order to realize high-performance thermoelectric materials, a way to obtain small grain size is necessary for intensification of the phonon scattering. Here, we use a melt-spinning-spark plasma sintering process for making p-type Bi0.36Sb1.64Te3 thermoelectric materials and evaluate [...] Read more.
In order to realize high-performance thermoelectric materials, a way to obtain small grain size is necessary for intensification of the phonon scattering. Here, we use a melt-spinning-spark plasma sintering process for making p-type Bi0.36Sb1.64Te3 thermoelectric materials and evaluate the relation between the process conditions and thermoelectric performance. We vary the Cu wheel rotation speed from 1000 rpm (~13 ms−1) to 4000 rpm (~52 ms−1) during the melt spinning process to change the cooling rate, allowing us to control the characteristic size of nanostructure in melt-spun Bi0.36Sb1.64Te3 ribbons. The higher wheel rotation speed decreases the size of nanostructure, but the grain sizes of sintered pellets are inversely proportional to the nanostructure size after the same sintering condition. As a result, the ZT values of the bulks fabricated from 1000–3000 rpm melt-spun ribbons are comparable each other, while the ZT value of the bulk from the 4000 rpm melt-spun ribbons is rather lower due to reduction of grain boundary phonon scattering. In this work, we can conclude that the smaller nanostructure in the melt spinning process does not always guarantee high-performance thermoelectric bulks, and an adequate following sintering process must be included. Full article
(This article belongs to the Special Issue Materials Processing and Crystal Growth for Thermoelectrics)
Show Figures

Figure 1

3177 KiB
Article
Crystal Growth of High-Quality Protein Crystals under the Presence of an Alternant Electric Field in Pulse-Wave Mode, and a Strong Magnetic Field with Radio Frequency Pulses Characterized by X-ray Diffraction
by Adela Rodríguez-Romero, Nuria Esturau-Escofet, Carina Pareja-Rivera and Abel Moreno
Crystals 2017, 7(6), 179; https://doi.org/10.3390/cryst7060179 - 19 Jun 2017
Cited by 14 | Viewed by 6173
Abstract
The first part of this research was devoted to investigating the effect of alternate current (AC) using four different types of wave modes (pulse-wave) at 2 Hz on the crystal growth of lysozyme in solution. The best results, in terms of size and [...] Read more.
The first part of this research was devoted to investigating the effect of alternate current (AC) using four different types of wave modes (pulse-wave) at 2 Hz on the crystal growth of lysozyme in solution. The best results, in terms of size and crystal quality, were obtained when protein crystals were grown under the influence of electric fields in a very specific wave mode (“breathing” wave), giving the highest resolution up to 1.34 Å in X-ray diffraction analysis compared with controls and with those crystals grown in gel. In the second part, we evaluated the effect of a strong magnetic field of 16.5 Tesla combined with radiofrequency pulses of 0.43 μs on the crystal growth in gels of tetragonal hen egg white (HEW) lysozyme. The lysozyme crystals grown, both in solution applying breathing-wave and in gel under the influence of this strong magnetic field with pulses of radio frequencies, produced the larger-in-size crystals and the highest resolution structures. Data processing and refinement statistics are very good in terms of the resolution, mosaicity and Wilson B factor obtained for each crystal. Besides, electron density maps show well-defined and distinctly separated atoms at several selected tryptophan residues for the crystal grown using the “breathing wave pulses”. Full article
(This article belongs to the Special Issue Protein Crystallization under the Presence of an Electric Field)
Show Figures

Figure 1

11058 KiB
Review
Heteroepitaxy, an Amazing Contribution of Crystal Growth to the World of Optics and Electronics
by Vladimir L. Tassev
Crystals 2017, 7(6), 178; https://doi.org/10.3390/cryst7060178 - 19 Jun 2017
Cited by 13 | Viewed by 10033
Abstract
Advances in Electronics and Optics are often preceded by discoveries in Crystal Growth theory and practice. This article represents in retrospect some of the most significant contributions of heteroepitaxy in these and some other areas—the strong impact of the three modes of heteroepitaxy [...] Read more.
Advances in Electronics and Optics are often preceded by discoveries in Crystal Growth theory and practice. This article represents in retrospect some of the most significant contributions of heteroepitaxy in these and some other areas—the strong impact of the three modes of heteroepitaxy on microelectronics and quantum optics, the big “push” of PENDEO epitaxy in development of Light Emitting Diodes, etc. A large part of the text is dedicated to heteroepitaxy of nonlinear optical materials grown on orientation-patterned templates and used in the development of new quasi-phase-matching frequency conversion laser sources. By achieving new frequency ranges such sources will result in a wide variety of applications in areas such as defense, security, industry, medicine, and science. Interesting facts from the scientific life of major contributors in the field are mixed in the text with fine details from growth experiments, chemical equations, results from material characterizations and some optical and crystallographic considerations—all these presented in a popular way but without neglecting their scientific importance and depth. The truth is that often heteroepitaxy is not just the better but the only available option. The truth is that delays in device development are usually due to gaps in materials research. In all this, miscommunication between different scientific communities always costs vain efforts, uncertainty, and years of going in a wrong scientific direction. With this article we aim to stimulate a constructive dialog that could lead to solutions of important interdisciplinary scientific and technical issues. Full article
Show Figures

Graphical abstract

2345 KiB
Article
The Role of III-V Substrate Roughness and Deoxidation Induced by Digital Etch in Achieving Low Resistance Metal Contacts
by Florent Ravaux, Irfan Saadat and Mustapha Jouiad
Crystals 2017, 7(6), 177; https://doi.org/10.3390/cryst7060177 - 19 Jun 2017
Cited by 2 | Viewed by 3640
Abstract
To achieve low contact resistance between metal and III-V material, transmission-line-model (TLM) structures of molybdenum (Mo) were fabricated on indium phosphide (InP) substrate on the top of an indium gallium arsenide (InGaAs) layer grown by molecular beam epitaxy. The contact layer was prepared [...] Read more.
To achieve low contact resistance between metal and III-V material, transmission-line-model (TLM) structures of molybdenum (Mo) were fabricated on indium phosphide (InP) substrate on the top of an indium gallium arsenide (InGaAs) layer grown by molecular beam epitaxy. The contact layer was prepared using a digital etch procedure before metal deposition. The contact resistivity was found to decrease significantly with the cleaning process. High Resolution Transmission & Scanning Electron Microscopy (HRTEM & HRSTEM) investigations revealed that the surface roughness of treated samples was increased. Further analysis of the metal-semiconductor interface using Energy Electron Loss Spectroscopy (EELS) showed that the amount of oxides (InxOy, GaxOy or AsxOy) was significantly decreased for the etched samples. These results suggest that the low contact resistance obtained after digital etching is attributed to the combined effects of the induced surface roughness and oxides removal during the digital etch process. Full article
Show Figures

Figure 1

1866 KiB
Article
Synthesis and Characterization of a New Cobaloxime-Terpyridine Compound
by Sebastián Pizarro, Priscila Astudillo, Francisco Gajardo, Iván Brito and Alvaro Delgadillo
Crystals 2017, 7(6), 175; https://doi.org/10.3390/cryst7060175 - 19 Jun 2017
Cited by 5 | Viewed by 5083
Abstract
A new cobaloxime was synthesized by the reaction of cobalt chloride and diphenylglyoxime in methanol, followed by the addition of 4′-(4-pyridyl)-2,2′:6′,2′′-terpyridine, pytpy. This complex was characterized by UV–Vis spectroscopy, 1H-NMR spectroscopy, cyclic voltammetry, and single-crystal X-ray diffraction analysis. In cyclic voltammetry experiments [...] Read more.
A new cobaloxime was synthesized by the reaction of cobalt chloride and diphenylglyoxime in methanol, followed by the addition of 4′-(4-pyridyl)-2,2′:6′,2′′-terpyridine, pytpy. This complex was characterized by UV–Vis spectroscopy, 1H-NMR spectroscopy, cyclic voltammetry, and single-crystal X-ray diffraction analysis. In cyclic voltammetry experiments an irreversible reduction wave assigned to Co(III)/Co(II) at Ecp = −0.31 V vs. Ag/AgCl and a quasi-reversible process assigned to the Co(II)/Co(I) reduction at −0.72 V vs. Ag/AgCl were observed. The crystal of the complex belongs to the triclinic space group P1 with a = 12.4698(6) Å, b = 14.1285(8) Å, c = 15.5801(8) Å, α = 109.681(4)°, β = 112.975(4)°, γ = 81.67(96.414(4)°3)°, V = 2284.0(2) Å3, Z = 2, Dc = 1.408 mg·m−3, μ = 0.66 mm−1, F(000) = 996, and final R1 = 0.0564, ωR2 = 0.1502. Full article
Show Figures

Figure 1

1950 KiB
Article
Theoretical Study on Electronic, Optical Properties and Hardness of Technetium Phosphides under High Pressure
by Shiquan Feng, Xuerui Cheng, Xinlu Cheng, Jinsheng Yue and Junyu Li
Crystals 2017, 7(6), 176; https://doi.org/10.3390/cryst7060176 - 18 Jun 2017
Cited by 3 | Viewed by 4073
Abstract
In this paper, the structural properties of technetium phosphides Tc3P and TcP4 are investigated by first principles at zero pressure and compared with the experimental values. In addition, the electronic properties of these two crystals in the pressure range of [...] Read more.
In this paper, the structural properties of technetium phosphides Tc3P and TcP4 are investigated by first principles at zero pressure and compared with the experimental values. In addition, the electronic properties of these two crystals in the pressure range of 0–40 GPa are investigated. Further, we discuss the change in the optical properties of technetium phosphides at high pressures. At the end of our study, we focus on the research of the hardness of TcP4 at different pressures by employing a semiempirical method, and the effect of pressure on the hardness is studied. Results show that the hardness of TcP4 increases with the increasing pressure, and the influence mechanism of pressure effect on the hardness of TcP4 is also discussed. Full article
(This article belongs to the Special Issue Crystal Indentation Hardness)
Show Figures

Figure 1

959 KiB
Article
Evolution in Time of Radiation Defects Induced by Negative Pions and Muons in Crystals with a Diamond Structure
by Yury M. Belousov
Crystals 2017, 7(6), 174; https://doi.org/10.3390/cryst7060174 - 14 Jun 2017
Cited by 4 | Viewed by 3193
Abstract
Evolution in time of radiation defects induced by negatively-charged pions and muons in crystals with diamond structures is considered. Negative pions and muons are captured by the nucleus and ionize an appropriate host atom, forming a positively-charged radiation defect in a lattice. As [...] Read more.
Evolution in time of radiation defects induced by negatively-charged pions and muons in crystals with diamond structures is considered. Negative pions and muons are captured by the nucleus and ionize an appropriate host atom, forming a positively-charged radiation defect in a lattice. As a result of an evolution in time, this radiation defect transforms into the acceptor center. An analysis of the full evolution process is considered for the first time. Formation of this acceptor center can be divided into three stages. At the first stage, the radiation defect interacts with a radiation trace and captures electrons. The radiation defect is neutralized completely in Si and Ge for a short time t 10 11 s, but in diamond, the complete neutralization time is very large t 10 6 s. At the second stage, broken chemical bonds of the radiation defect are restored. In Si and Ge, this process takes place for the neutral radiation defect, but in diamond, it goes for a positively-charged state. The characteristic time of this stage is t < 10 8 s for Si and Ge and t < 10 11 s for diamond. After the chemical bonds’ restoration, the positively-charged, but chemically-bound radiation defect in diamond is quickly neutralized because of the electron density redistribution. The neutralization process is characterized by the lattice relaxation time. At the third stage, a neutral chemically-bound radiation defect captures an additional electron to saturate all chemical bonds and forms an ionized acceptor center. The existence of a sufficiently big electric dipolar moment leads to the electron capture. Qualitative estimates for the time of this process were obtained for diamond, silicon and germanium crystals. It was sown that this time is the shortest for diamond (≤ 10 8 s) and the longest for silicon (≤ 10 7 s) Full article
(This article belongs to the Special Issue Diamond Crystals)
Show Figures

Figure 1

553 KiB
Article
First Principles Study on Structure Stability and Mechanical Properties of YNi2B2C and LuNi2B2C under Pressure
by Lili Liu, Xiaozhi Wu, Rui Wang, Zhengquan Hu, Youchang Jiang and Dingxing Liu
Crystals 2017, 7(6), 173; https://doi.org/10.3390/cryst7060173 - 13 Jun 2017
Cited by 3 | Viewed by 3796
Abstract
The pressure effects on the lattice parameters and elastic constants of the tetragonal RNi 2 B 2 C (R=Y, Lu) are investigated by means of the first principles. The predicted lattice constants and elastic constants of YNi 2 B 2 C and LuNi [...] Read more.
The pressure effects on the lattice parameters and elastic constants of the tetragonal RNi 2 B 2 C (R=Y, Lu) are investigated by means of the first principles. The predicted lattice constants and elastic constants of YNi 2 B 2 C and LuNi 2 B 2 C at 0 GPa agree well with the available data. By the elastic stability criteria under isotropic pressure, it is predicted that YNi 2 B 2 C and LuNi 2 B 2 C with tetragonal structure are not mechanically stable above 93 GPa and 50 GPa, respectively. Pugh’s modulus ratio, Poisson’s ratio, Vickers hardness, elastic anisotropy and Debye temperature of YNi 2 B 2 C in the pressure range of 0–100 GPa and LuNi 2 B 2 C in the pressure range of 0-60 GPa are further investigated. It is shown that the ductility and Debye temperature of tetragonal RNi 2 B 2 C (R=Y, Lu) increase with increasing pressure, and LuNi 2 B 2 C is more ductile and lower Debye temperature than YNi 2 B 2 C under different pressures. Full article
Show Figures

Figure 1

15469 KiB
Article
Structural and Electrical Properties Characterization of Sb1.52Bi0.48Te3.0 Melt-Spun Ribbons
by Viktoriia Ohorodniichuk, Anne Dauscher, Elsa Branco Lopes, Sylvie Migot, Christophe Candolfi and Bertrand Lenoir
Crystals 2017, 7(6), 172; https://doi.org/10.3390/cryst7060172 - 13 Jun 2017
Cited by 6 | Viewed by 4233
Abstract
Melt-spinning (MS) has been reported as a promising tool to tailor the microstructure of bulk thermoelectric materials leading to enhanced thermoelectric performances. Here, we report on a detailed characterization of p-type Bi0.48Sb1.52Te3 ribbons produced by melt-spinning. The [...] Read more.
Melt-spinning (MS) has been reported as a promising tool to tailor the microstructure of bulk thermoelectric materials leading to enhanced thermoelectric performances. Here, we report on a detailed characterization of p-type Bi0.48Sb1.52Te3 ribbons produced by melt-spinning. The microstructure of the melt-spun ribbons has been studied by means of X-ray diffraction, scanning and transmission electron microscopy (TEM). The analyses indicate that the ribbons are highly-textured with a very good chemical homogeneity. TEM reveals clear differences in the microstructure at large and short-range scales between the surface that was in contact with the copper wheel and the free surface. These analyses further evidence the absence of amorphous regions in the melt-spun ribbons and the precipitation of elemental Te at the grain boundaries. Low-temperature electrical resistivity and thermopower measurements (20–300 K) carried out on several randomly-selected ribbons confirm the excellent reproducibility of the MS process. However, the comparison of the transport properties of the ribbons with those of bulk polycrystalline samples of the same initial composition shows that MS leads to a more pronounced metallic character. This difference is likely tied to changes in deviations from stoichiometry due to the out-of-equilibrium conditions imposed by MS. Full article
(This article belongs to the Special Issue Materials Processing and Crystal Growth for Thermoelectrics)
Show Figures

Figure 1

1816 KiB
Article
Helical Arrangement of 2-(4-hydroxy-3-methoxyphenyl)-Benzothiazole in Crystal Formation and Biological Evaluation on HeLa Cells
by Roberto I. Cuevas-Hernández, Itzia I. Padilla-Martínez, Sarai Martínez-Cerón, Ismael Vásquez-Moctezuma and José G. Trujillo-Ferrara
Crystals 2017, 7(6), 171; https://doi.org/10.3390/cryst7060171 - 11 Jun 2017
Cited by 4 | Viewed by 4376
Abstract
Benzothiazoles are a set of molecules with a broad spectrum of biological applications. In particular, 2-(4-hydroxy-3-methoxyphenyl)-benzothiazole is a potential breast cancer cell suppressor whose mechanism of action has been previously reported. In the present work, the title compound was synthesized, crystallized, and its [...] Read more.
Benzothiazoles are a set of molecules with a broad spectrum of biological applications. In particular, 2-(4-hydroxy-3-methoxyphenyl)-benzothiazole is a potential breast cancer cell suppressor whose mechanism of action has been previously reported. In the present work, the title compound was synthesized, crystallized, and its biological activity on HeLa cells was evaluated. Its molecular structure was compared to that obtained by molecular modeling. Theoretical calculations suggest that the syn-rotamer is the most stable form and correlates very well with crystallographic data. The crystal structure adopts a helical arrangement formed through O13—H13∙∙∙N3 intermolecular hydrogen bonding that propagates in the (14 -1 -3) plane. These results suggest that the title compound has the capacity to interleave into DNA and better explain its biological effects related to the increased CHIP expression through AhR recruitment. Finally, the biological experiments indicate that the title compound has the capacity to decrease the viability of HeLa cells with an IC50 = 2.86 μM. Full article
(This article belongs to the Section Crystal Engineering)
Show Figures

Figure 1

2166 KiB
Article
Nb-Doped 0.8BaTiO3-0.2Bi(Mg0.5Ti0.5)O3 Ceramics with Stable Dielectric Properties at High Temperature
by Feng Si, Bin Tang, Zixuan Fang and Shuren Zhang
Crystals 2017, 7(6), 168; https://doi.org/10.3390/cryst7060168 - 11 Jun 2017
Cited by 16 | Viewed by 5442
Abstract
Nb-doped 0.8BaTiO3-0.2Bi(Mg0.5Ti0.5)O3 ceramics were prepared by conventional solid-state method. The dielectric properties and the structural properties were investigated. When Nb2O5 is doped into 0.8BT-0.2BMT system, a small amount of Ba4Ti12 [...] Read more.
Nb-doped 0.8BaTiO3-0.2Bi(Mg0.5Ti0.5)O3 ceramics were prepared by conventional solid-state method. The dielectric properties and the structural properties were investigated. When Nb2O5 is doped into 0.8BT-0.2BMT system, a small amount of Ba4Ti12O27 secondary phase is formed. The lattice parameters gradually increase with the Nb2O5 doping. It is found that the temperature-capacitance characteristics greatly depend on Nb2O5 content. With the addition of 3.0 mol% Nb2O5, a 0.8BT-0.2BMT ceramic sample could satisfy the EIA X9R specification. This material is promising for high-temperature MLCC application. Full article
(This article belongs to the Special Issue Crystal Structure of Electroceramics)
Show Figures

Figure 1

768 KiB
Article
Effect of an External Electric Field on the Kinetics of Dislocation-Free Growth of Tetragonal Hen Egg White Lysozyme Crystals
by Haruhiko Koizumi, Satoshi Uda, Kozo Fujiwara, Junpei Okada and Jun Nozawa
Crystals 2017, 7(6), 170; https://doi.org/10.3390/cryst7060170 - 10 Jun 2017
Cited by 12 | Viewed by 4559
Abstract
Dislocation-free tetragonal hen egg white (HEW) lysozyme crystals were grown from a seed crystal in a cell. The rates of tetragonal HEW lysozyme crystal growth normal to the (110) and (101) faces with and without a 1-MHz external electric field were measured. A [...] Read more.
Dislocation-free tetragonal hen egg white (HEW) lysozyme crystals were grown from a seed crystal in a cell. The rates of tetragonal HEW lysozyme crystal growth normal to the (110) and (101) faces with and without a 1-MHz external electric field were measured. A decrease in the typical growth rates of the crystal measured under an applied field at 1 MHz was observed, although the overall driving force increased. Assuming that the birth and spread mechanism of two-dimensional nucleation occurs, an increase in the effective surface energy of the step ends was realized in the presence of the electric field, which led to an improvement in the crystal quality of the tetragonal HEW lysozyme crystals. This article also discusses the increase in the effective surface energy of the step ends with respect to the change in the entropy of the solid. Full article
(This article belongs to the Special Issue Protein Crystallization under the Presence of an Electric Field)
Show Figures

Figure 1

5317 KiB
Article
Investigation into the Effect of Sulfate and Borate Incorporation on the Structure and Properties of SrFeO3-δ
by Abbey Jarvis and Peter Raymond Slater
Crystals 2017, 7(6), 169; https://doi.org/10.3390/cryst7060169 - 07 Jun 2017
Cited by 13 | Viewed by 4959
Abstract
In this paper, we demonstrate the successful incorporation of sulfate and borate into SrFeO3-δ, and characterise the effect on the structure and conductivity, with a view to possible utilisation as a cathode material in Solid Oxide Fuel Cells. The incorporation of [...] Read more.
In this paper, we demonstrate the successful incorporation of sulfate and borate into SrFeO3-δ, and characterise the effect on the structure and conductivity, with a view to possible utilisation as a cathode material in Solid Oxide Fuel Cells. The incorporation of low levels of sulfate/borate is sufficient to cause a change from a tetragonal to a cubic cell. Moreover, whereas heat treatment of undoped SrFeO3-δ under N2 leads to a transformation to brownmillerite Sr2Fe2O5 with oxygen vacancy ordering, the sulfate/borate-doped samples remain cubic under the same conditions. Thus, sulfate/borate doping appears to be successful in introducing oxide ion vacancy disorder in this system. Full article
(This article belongs to the Special Issue Crystal Structure of Electroceramics)
Show Figures

Figure 1

10658 KiB
Review
(Li1−xFex)OHFeSe Superconductors: Crystal Growth, Structure, and Electromagnetic Properties
by Guo-Yong Zhang, Mitch Ming-Chi Chou and Cheng-Tian Lin
Crystals 2017, 7(6), 167; https://doi.org/10.3390/cryst7060167 - 06 Jun 2017
Cited by 6 | Viewed by 9239
Abstract
This review focuses on the growth of high-quality (Li1−xFex)OHFeSe single crystals by a hydrothermal method using floating-zone-grown AxFe2−ySe2 (A = K, Rb, and Cs) as precursors. The structure, superconductivity, and magnetic [...] Read more.
This review focuses on the growth of high-quality (Li1−xFex)OHFeSe single crystals by a hydrothermal method using floating-zone-grown AxFe2−ySe2 (A = K, Rb, and Cs) as precursors. The structure, superconductivity, and magnetic behavior of the obtained crystals are highly influenced by the growth conditions, such as time, temperature, and composition. A phase diagram with temperature against the c-lattice constant is summarized including the antiferromagnetic spin density wave, superconducting, and paramagnetic phases. Full article
(This article belongs to the Special Issue Correlated Electron Crystals)
Show Figures

Figure 1

7399 KiB
Article
Morphology of Diamond Layers Grown on Different Facets of Single Crystal Diamond Substrates by a Microwave Plasma CVD in CH4-H2-N2 Gas Mixtures
by Evgeny E. Ashkinazi, Roman A. Khmelnitskii, Vadim S. Sedov, Andrew A. Khomich, Alexander V. Khomich and Viktor G. Ralchenko
Crystals 2017, 7(6), 166; https://doi.org/10.3390/cryst7060166 - 06 Jun 2017
Cited by 24 | Viewed by 9708
Abstract
Epitaxial growth of diamond films on different facets of synthetic IIa-type single crystal (SC) high-pressure high temperature (HPHT) diamond substrate by a microwave plasma CVD in CH4-H2-N2 gas mixture with the high concentration (4%) of nitrogen is studied. [...] Read more.
Epitaxial growth of diamond films on different facets of synthetic IIa-type single crystal (SC) high-pressure high temperature (HPHT) diamond substrate by a microwave plasma CVD in CH4-H2-N2 gas mixture with the high concentration (4%) of nitrogen is studied. A beveled SC diamond embraced with low-index {100}, {110}, {111}, {211}, and {311} faces was used as the substrate. Only the {100} face is found to sustain homoepitaxial growth at the present experimental parameters, while nanocrystalline diamond (NCD) films are produced on other planes. This observation is important for the choice of appropriate growth parameters, in particular, for the production of bi-layer or multilayer NCD-on-microcrystalline diamond (MCD) superhard coatings on tools when the deposition of continuous conformal NCD film on all facet is required. The development of the film morphology with growth time is examined with SEM. The structure of hillocks, with or without polycrystalline aggregates, that appear on {100} face is analyzed, and the stress field (up to 0.4 GPa) within the hillocks is evaluated based on high-resolution mapping of photoluminescence spectra of nitrogen-vacancy NV optical centers in the film. Full article
(This article belongs to the Special Issue Diamond Crystals)
Show Figures

Figure 1

16697 KiB
Article
Preparation of Regular Cement Hydration Crystals and Ordered Microstructures by Doping GON and an Investigation into Its Compressive and Flexural Strengths
by Shenghua Lv, Jia Zhang, Linlin Zhu, Chunmao Jia and Xiaoqian Luo
Crystals 2017, 7(6), 165; https://doi.org/10.3390/cryst7060165 - 05 Jun 2017
Cited by 8 | Viewed by 6079
Abstract
In this work, we found that by controlling the size of the graphene oxide nanosheets (GON) at 5–140 nm, 5–260 nm and 5–410 nm, respectively, we could prepare regular shaped cement hydration crystals with the shape of nano-needle-like, flower-like, and polyhedron-like crystals, respectively. [...] Read more.
In this work, we found that by controlling the size of the graphene oxide nanosheets (GON) at 5–140 nm, 5–260 nm and 5–410 nm, respectively, we could prepare regular shaped cement hydration crystals with the shape of nano-needle-like, flower-like, and polyhedron-like crystals, respectively. Together, these crystals formed an ordered structure of cement composites on both the micro and macro levels, and the compressive and flexural strengths of the cement composites obviously increased when compared to the control samples. Our results indicated that the smallest structural unit of regular crystals was the nano-polyhedron-like crystals, which consisted of AFt, AFm, CH, and crystallization C–S–H, and could assemble into regular needle-like crystals, flower-like crystals, and polyhedron-like crystals, as well as an ordered structure on the micro and macro levels. Most of the C-S-H was transferred into a monoclinic system crystals and the remainder played the role of an adhesive in the forming process of regular crystals and structure. The cracks and holes in the cement composites disappeared by the self-repairing effect of the growing hydration crystal. The results indicate that ordered structural cement composites with defect-free structures and high strength can be prepared using GON with a suitable size range. Full article
Show Figures

Figure 1

7175 KiB
Article
Elastic, Mechanical and Phonon Behavior of Wurtzite Cadmium Sulfide under Pressure
by Melek Güler and Emre Güler
Crystals 2017, 7(6), 164; https://doi.org/10.3390/cryst7060164 - 04 Jun 2017
Cited by 22 | Viewed by 5875
Abstract
Cadmium sulfide is one of the cutting-edge materials of current optoelectronic technology. Although many theoretical works are presented the for pressure-dependent elastic and related properties of the zinc blende crystal structure of cadmium sulfide, there is still some scarcity for the elastic, mechanical, [...] Read more.
Cadmium sulfide is one of the cutting-edge materials of current optoelectronic technology. Although many theoretical works are presented the for pressure-dependent elastic and related properties of the zinc blende crystal structure of cadmium sulfide, there is still some scarcity for the elastic, mechanical, and phonon behavior of the wurtzitic phase of this important material under pressure. In contrast to former theoretical works and methods used in literature, we report for the first time the application of a recent shell model-based interatomic potential via geometry optimization computations. Elastic constants, elastic wave velocities, bulk, Young, and shear moduli, as well as the phonon behavior of wurtzite cadmium sulfide (w-CdS) were investigated from ground state to pressures up to 5 GPa. Calculated results of these elastic parameters for the ground state of w-CdS are approximately the same as in earlier experiments and better than published theoretical data. Our results for w-CdS under pressure are also reasonable with previous calculations, and similar pressure trends were found for the mentioned quantities of w-CdS. Full article
(This article belongs to the Special Issue Crystal Chemistry of Zinc, Cadmium and Mercury)
Show Figures

Figure 1

1066 KiB
Article
Distribution of Dislocations near the Interface in AlN Crystals Grown on Evaporated SiC Substrates
by Tatiana S. Argunova, Mikhail Yu. Gutkin, Jung Ho Je, Alexander E. Kalmykov, Olga P. Kazarova, Evgeniy N. Mokhov, Kristina N. Mikaelyan, Alexander V. Myasoedov, Lev M. Sorokin and Kirill D. Shcherbachev
Crystals 2017, 7(6), 163; https://doi.org/10.3390/cryst7060163 - 04 Jun 2017
Cited by 9 | Viewed by 5173
Abstract
To exploit unique properties of thin films of group III-nitride semiconductors, the production of native substrates is to be developed. The best choice would be AlN; however, presently available templates on sapphire or SiC substrates are defective. The quality of AlN could be [...] Read more.
To exploit unique properties of thin films of group III-nitride semiconductors, the production of native substrates is to be developed. The best choice would be AlN; however, presently available templates on sapphire or SiC substrates are defective. The quality of AlN could be improved by eliminating the substrate during the layer growth. In this paper, we demonstrate freestanding AlN layers fabricated by an SiC substrate evaporation method. Such layers were used to investigate dislocation structures near the former AlN–SiC interface. Specimens were characterized by synchrotron radiation imaging, triple-axis diffractometry and transmission electron microscopy (TEM). We found that the evaporation process under non-optimal conditions affected the dislocation structure. When the growth had been optimized, AlN layers showed a uniform distribution of dislocations. The dislocations tended to constitute low-angle subgrain boundaries, which produced out-of-plane and in-plane tilt angles of about 2–3 arc-min. Similar broadening was observed in both symmetric and asymmetric rocking curves, which proved the presence of edge, screws as well as mixed dislocation content. TEM revealed arrays of edge threading dislocations, but their predominance over the other threading dislocations was not supported by present study. To explain the experimental observations, a theoretical model of the dislocation structure formation is proposed. Full article
(This article belongs to the Special Issue Plasticity of Crystals and Interfaces)
Show Figures

Figure 1

3637 KiB
Article
Theoretical Analysis of Elastic, Mechanical and Phonon Properties of Wurtzite Zinc Sulfide under Pressure
by Melek Güler and Emre Güler
Crystals 2017, 7(6), 161; https://doi.org/10.3390/cryst7060161 - 04 Jun 2017
Cited by 16 | Viewed by 4930
Abstract
We report for the first time the application of a mixed-type interatomic potential to determine the high-pressure elastic, mechanical, and phonon properties of wurtzite zinc sulfide (WZ-ZnS) with geometry optimization calculations under pressures up to 12 GPa. Pressure dependency of typical elastic constants, [...] Read more.
We report for the first time the application of a mixed-type interatomic potential to determine the high-pressure elastic, mechanical, and phonon properties of wurtzite zinc sulfide (WZ-ZnS) with geometry optimization calculations under pressures up to 12 GPa. Pressure dependency of typical elastic constants, bulk, shear, and Young moduli, both longitudinal and shear wave elastic wave velocities, stability, as well as phonon dispersions and corresponding phonon density of states of WZ-ZnS were surveyed. Our results for the ground state elastic and mechanical quantities of WZ-ZnS are about experiments and better than those of some published theoretical data. Obtained phonon-related results are also satisfactory when compared with experiments and other theoretical findings. Full article
(This article belongs to the Special Issue Crystal Chemistry of Zinc, Cadmium and Mercury)
Show Figures

Figure 1

12621 KiB
Review
Role of the Potential Barrier in the Electrical Performance of the Graphene/SiC Interface
by Ivan Shtepliuk, Tihomir Iakimov, Volodymyr Khranovskyy, Jens Eriksson, Filippo Giannazzo and Rositsa Yakimova
Crystals 2017, 7(6), 162; https://doi.org/10.3390/cryst7060162 - 02 Jun 2017
Cited by 28 | Viewed by 7940
Abstract
In spite of the great expectations for epitaxial graphene (EG) on silicon carbide (SiC) to be used as a next-generation high-performance component in high-power nano- and micro-electronics, there are still many technological challenges and fundamental problems that hinder the full potential of EG/SiC [...] Read more.
In spite of the great expectations for epitaxial graphene (EG) on silicon carbide (SiC) to be used as a next-generation high-performance component in high-power nano- and micro-electronics, there are still many technological challenges and fundamental problems that hinder the full potential of EG/SiC structures and that must be overcome. Among the existing problems, the quality of the graphene/SiC interface is one of the most critical factors that determines the electroactive behavior of this heterostructure. This paper reviews the relevant studies on the carrier transport through the graphene/SiC, discusses qualitatively the possibility of controllable tuning the potential barrier height at the heterointerface and analyses how the buffer layer formation affects the electronic properties of the combined EG/SiC system. The correlation between the sp2/sp3 hybridization ratio at the interface and the barrier height is discussed. We expect that the barrier height modulation will allow realizing a monolithic electronic platform comprising different graphene interfaces including ohmic contact, Schottky contact, gate dielectric, the electrically-active counterpart in p-n junctions and quantum wells. Full article
(This article belongs to the Special Issue Integration of 2D Materials for Electronics Applications)
Show Figures

Figure 1

6787 KiB
Article
Synthesis, Crystal Structure and Hirshfeld Topology Analysis of Polymeric Silver(I) Complex with s-Triazine-Type Ligand
by Saied M. Soliman and Ayman El-Faham
Crystals 2017, 7(6), 160; https://doi.org/10.3390/cryst7060160 - 02 Jun 2017
Cited by 1 | Viewed by 4218
Abstract
The synthesis, single crystal X-ray diffraction (SC-XRD) characterization and Hirshfeld topology analysis of molecular packing of the coordination polymer [Ag2L(H2O)2(ClO4)2]n, where L = 2,4,6-trimorpholino-1,3,5-triazine were discussed. The asymmetric unit comprises one [...] Read more.
The synthesis, single crystal X-ray diffraction (SC-XRD) characterization and Hirshfeld topology analysis of molecular packing of the coordination polymer [Ag2L(H2O)2(ClO4)2]n, where L = 2,4,6-trimorpholino-1,3,5-triazine were discussed. The asymmetric unit comprises one Ag2L(H2O)2(ClO4)2 unit. The coordination geometries around the two silver atoms are different where Ag(1) is hexa-coordinated with one L, two bridged water, and two bridged perchlorate augmented with one strong Ag-O interaction from the morpholine O-atom of another ligand (L) unit. The coordination environment is more like to a distorted octahedral arrangement according to the criteria of continuous shape measurements. Ag(2) is coordinated to one L, one terminal water and one terminal perchlorate leading to a distorted trigonal planar arrangement around Ag(2). Hirshfeld analysis of molecular packing indicated that the most important intermolecular contacts affect the molecular packing of the studied complex are the H...H and the O...H interactions. Atoms in molecules (AIM) and natural bond orbital (NBO) analyses were used to describe the strength and nature of the Ag-O and Ag-N interactions. Full article
Show Figures

Graphical abstract

4062 KiB
Article
The CeOX and MnOX Nanocrystals Supported on TiO2–Graphene Oxide Catalysts and Their Selective Catalytic Reduction Properties at Low Temperature
by Zhensong Tong, Xining Lu and Cunyi Song
Crystals 2017, 7(6), 159; https://doi.org/10.3390/cryst7060159 - 02 Jun 2017
Cited by 7 | Viewed by 4602
Abstract
A series of 9%CeOx–MnOx/TiO2–GO nanocomposites with different molar ratios of Ce/Mn were synthesized by the sol-gel and ultrasonic impregnation methods and characterized by field emission scanning electron microscope (FESEM), high resolution transmission electron microscopy (HRTEM), N2 [...] Read more.
A series of 9%CeOx–MnOx/TiO2–GO nanocomposites with different molar ratios of Ce/Mn were synthesized by the sol-gel and ultrasonic impregnation methods and characterized by field emission scanning electron microscope (FESEM), high resolution transmission electron microscopy (HRTEM), N2 adsorption (BET) analysis, X-ray photoelectron spectroscopy (XPS), and Fourier transform infrared spectroscopy (FT–IR). The results showed that various valences of Ce and Mn oxides were uniformly distributed on the surface of TiO2–GO multilayered supports. The coexistence of various valences of Ce and Mn oxides can improve the redox performance of the catalyst. With the introduction of Ce, the amount of MnO2 and non-stoichiometric MnOx/Mn, the total oxygen and chemisorbed oxygen content, and the electron transfer ability of the catalyst increased significantly. When the molar ratio of Ce/Mn was 0.3, the catalysts exhibited high selective catalytic reduction activity (more than 99% at 180 °C) and N2 selectivity. The presence of hydrophilic groups on the surface of the GO was considered as the critical factor influencing the H2O resistance of the catalyst. Due to the pre-sulfuring process of GO, serious sulfation of the active component can be prevented, and the catalyst exhibited excellent SO2 resistance. Full article
(This article belongs to the Special Issue Colloidal Nanocrystals: Synthesis, Characterization and Application)
Show Figures

Figure 1

2824 KiB
Review
Technology, Preparation and Properties of the Cast Glass-Coated Magnetic Microwires
by Serghei A. Baranov, Vladimir S. Larin and Alexander V. Torcunov
Crystals 2017, 7(6), 136; https://doi.org/10.3390/cryst7060136 - 29 May 2017
Cited by 91 | Viewed by 6651
Abstract
Magnetic properties of cast amorphous and nanocrystalline microwires have been reviewed considering their potential application. Microwires were produced from Co Fe Mn Cr Cu B and Si using the Taylor–Ulitovsky method. Technological aspects of the Taylor–Ulitovsky method for fabrication of glass-coated microwire with [...] Read more.
Magnetic properties of cast amorphous and nanocrystalline microwires have been reviewed considering their potential application. Microwires were produced from Co Fe Mn Cr Cu B and Si using the Taylor–Ulitovsky method. Technological aspects of the Taylor–Ulitovsky method for fabrication of glass-coated microwire with different structure are analyzed. Magnetic microwires demonstrate a large variety of magnetic behaviors, which is important for sensing applications. Depending on the chemical composition of the metallic core, for Co-, Fe- and Ni-based composition, the microwires’ properties are very different. The geometrical characteristics (diameter of metallic core and thickness of the glass) of the microwire depend on the physical properties of a metallic composition and of glass and the parameters of the heating inductor and the speed of obtaining a microwire. The diameter of metallic core in these microwires can range from 0.5 to 70 μm, and their thickness of the glass can vary from 1 to 50 μm. Full article
(This article belongs to the Special Issue Advance in Crystalline Thin Wires)
Show Figures

Figure 1

5130 KiB
Article
Effects of Changing Substituents on the Non-Linear Optical Properties of Two Coumarin Derivatives
by Basílio Baseia, Francisco A. P. Osório, Larissa Ferreira Lima and Clodoaldo Valverde
Crystals 2017, 7(6), 158; https://doi.org/10.3390/cryst7060158 - 27 May 2017
Cited by 25 | Viewed by 4090
Abstract
In this article, we study the electric properties of two coumarin derivatives whose difference stems from the change of substituents at 3-position of the pendant benzene ring ( C 18 H 15 NO 3 ) and ( [...] Read more.
In this article, we study the electric properties of two coumarin derivatives whose difference stems from the change of substituents at 3-position of the pendant benzene ring ( C 18 H 15 NO 3 ) and ( C 18 H 15 NO 4 ). We use the supermolecule approach to deal with the molecules under the effect of the crystalline environment to calculate dipole moment, linear polarizability, and second-order hyperpolarizability, for the isolated and embedded molecules, including the static and dynamic cases and the presence of solvents. The (hyper) polarizabilities were derived from an iterative process and an ab initio computational procedure. In addition, we also calculated the HOMO-LUMO energies; at this point, the objective is to verify the effect of the exchange of substituents on the Band-Gap energy, an important parameter related to the excitation properties of coumarin compounds. Full article
Show Figures

Figure 1

2076 KiB
Article
Effect of Al Substitution on Structural, Magnetic, and Magnetocaloric Properties of Er6Fe23−xAlx (x = 0 and 3) Intermetallic Compounds
by M. Jemmali, S. Alleg, E. Dhahri and L. Bessais
Crystals 2017, 7(6), 156; https://doi.org/10.3390/cryst7060156 - 27 May 2017
Cited by 2 | Viewed by 4175
Abstract
The structural, magnetic, and magnetocaloric properties of Er6Fe23−xAlx (x = 0 and 3) intermetallic compounds have been studied systematically. Samples were prepared using the arc furnace by annealing at 1073 K for one week. Rietveld analysis of XRD [...] Read more.
The structural, magnetic, and magnetocaloric properties of Er6Fe23−xAlx (x = 0 and 3) intermetallic compounds have been studied systematically. Samples were prepared using the arc furnace by annealing at 1073 K for one week. Rietveld analysis of XRD shows the formation of pure crystalline phase with cubic Fm-3m structure. Refinement results show that the unit cell volume decreases with increasing Al content. The Curie temperature Tc of the prepared samples was found to be strongly dependent on the aluminum content. This reduces magnetization and the ferrimagnetic phase transition temperature (Tc) from 481 K (for x = 0) to 380 K (for x = 3), is due to the substitution of magnetic element (Fe) by non-magnetic atoms (Al). With the increase of the Al content, a decrease in the values of magnetic entropy is observed. The magnitude of the isothermal magnetic entropy (|∆SM|) at the Tc decreases from 1.8 J/kg·K for x = 0 to 0.58 J/kg·K for x = 3 for a field change 14 kOe. Respectively, the relative cooling power (RCP) decreases with increasing Al content reaching 42 Jkg−1 for x = 0 to 28 Jkg−1 for x = 3. Full article
(This article belongs to the Special Issue Crystal Structure of Magnetic Materials)
Show Figures

Figure 1

7155 KiB
Article
Extended Defect Propagation in Highly Tensile-Strained Ge Waveguides
by Meng Qi, William A. O’Brien, Chad A. Stephenson, Victor Patel, Ning Cao, Brian J. Thibeault, Marco Schowalter, Andreas Rosenauer, Vladimir Protasenko, Huili (Grace) Xing and Mark A. Wistey
Crystals 2017, 7(6), 157; https://doi.org/10.3390/cryst7060157 - 26 May 2017
Cited by 6 | Viewed by 5230
Abstract
Tensile-strained Ge is a possible laser material for Si integrated circuits, but reports of lasers using tensile Ge show high threshold current densities and short lifetimes. To study the origins of these shortcomings, Ge ridge waveguides with tensile strain in three dimensions were [...] Read more.
Tensile-strained Ge is a possible laser material for Si integrated circuits, but reports of lasers using tensile Ge show high threshold current densities and short lifetimes. To study the origins of these shortcomings, Ge ridge waveguides with tensile strain in three dimensions were fabricated using compressive silicon nitride (SiNx) films with up to 2 GPa stress as stress liners. A Raman peak shift of up to 11 cm−1 was observed, corresponding to 3.6% hydrostatic tensile strain for waveguides with a triangular cross-section. Real time degradation in tensile-strained Ge was observed and studied under transmission electron microscopy (TEM). A network of defects, resembling dark line defects, was observed to form and propagate with a speed and density strongly correlated with the local strain extracted from both modeled and measured strain profiles. This degradation suggests highly tensile-strained Ge lasers are likely to have significantly shorter lifetime than similar GaAs or InGaAs quantum well lasers. Full article
(This article belongs to the Special Issue Crystallography of Functional Materials)
Show Figures

Graphical abstract

4325 KiB
Letter
Effects of In0.82Ga0.18As/InP Double Buffers Design on the Microstructure of the In0.82G0.18As/InP Heterostructure
by Liang Zhao, Zuoxing Guo, Xiangdong Ding, Jingjuan Li, Shen Yang, Min Zhang and Lei Zhao
Crystals 2017, 7(6), 155; https://doi.org/10.3390/cryst7060155 - 25 May 2017
Cited by 1 | Viewed by 3786
Abstract
In order to reduce the dislocation density and improve the performance of high indium content In0.82Ga0.18As films, the design of double buffer layers has been introduced into the In0.82Ga0.18As/InP heterostructure. Compared with other buffer layer [...] Read more.
In order to reduce the dislocation density and improve the performance of high indium content In0.82Ga0.18As films, the design of double buffer layers has been introduced into the In0.82Ga0.18As/InP heterostructure. Compared with other buffer layer structures, we introduce an InP thin layer, which is the same as the substrate, into the In0.82Ga0.18As/InP heterostructure. The epitaxial layers and buffer layers were grown by the low-pressure metalorganic chemical vapor deposition (LP-MOCVD) method. In this study, the surface morphology and microstructures of the heterostructure were investigated by SEM, AFM, XRD and TEM. The residual strains of the In0.82Ga0.18As epitaxial layer in different samples were studied by Raman spectroscopy. The residual strain of the In0.82Ga0.18As epitaxial layer was decreased by designing double buffer layers which included an InP layer; as a result, dislocations in the epitaxial layer were effectively suppressed since the dislocation density was notably reduced. Moreover, the performance of In0.82Ga0.18As films was investigated using the Hall test, and the results are in line with our expectations. By comparing different buffer layer structures, we explained the mechanism of dislocation density reduction by using double buffer layers, which included a thin InP layer. Full article
(This article belongs to the Special Issue Epitaxial Growth of Semiconductor Nanostructures)
Show Figures

Figure 1

1862 KiB
Article
Growth and Characterization of Tetraphenylphosphonium Bromide Crystal
by Guangqiang Wang, Xiaolong Liu, Yan Ren, Chengqian Zhang and Xutang Tao
Crystals 2017, 7(6), 154; https://doi.org/10.3390/cryst7060154 - 25 May 2017
Cited by 5 | Viewed by 4599
Abstract
Multiple-phenyl phosphorous compounds are a group of chemical materials that have been used as reactants, pharmaceutical intermediates, extractants, and catalysts in organic synthetic reactions. However, the crystal growth of bulk crystals of multiple-phenyl phosphorous compounds, which may expand their applications in photonics technology, [...] Read more.
Multiple-phenyl phosphorous compounds are a group of chemical materials that have been used as reactants, pharmaceutical intermediates, extractants, and catalysts in organic synthetic reactions. However, the crystal growth of bulk crystals of multiple-phenyl phosphorous compounds, which may expand their applications in photonics technology, have been largely overlooked. In this article, the crystal growth of tetraphenylphosphonium bromide (TPPB) has been studied in organic solvents and water. The crystal structures and crystallization features are analyzed by X-ray diffraction data. By a slow temperature-lowering method, a single-crystal of TPPB (2H2O) with the size of 27 × 20 × 20 mm3 has been obtained in water. The basic thermal and optical properties were characterized. We find that the TPPB (2H2O) crystal shows excellent transparent property in the near-IR region. Large Raman shifts and strong Raman scattering intensity indicate that TPPB is a potential candidate in Raman-scattering-based nonlinearity applications. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
