Micromachines

23 pages, 2881 KiB

Open AccessArticle

Nondestructive Mechanical and Electrical Characterization of Piezoelectric Zinc Oxide Nanowires for Energy Harvesting

by Frank Eric Boye Anang, Markys Cain, Min Xu, Zhi Li, Uwe Brand, Darshit Jangid, Sebastian Seibert, Chris Schwalb and Erwin Peiner

Micromachines 2025, 16(8), 927; https://doi.org/10.3390/mi16080927 (registering DOI) - 12 Aug 2025

Abstract

In this study we report on the structural, mechanical, and electrical characterization of different structures of vertically aligned zinc oxide (ZnO) nanowires (NWs) synthesized using hydrothermal methods. By optimizing the growth conditions, scanning electron microscopy (SEM) micrographs show that the ZnO NWs could [...] Read more.

In this study we report on the structural, mechanical, and electrical characterization of different structures of vertically aligned zinc oxide (ZnO) nanowires (NWs) synthesized using hydrothermal methods. By optimizing the growth conditions, scanning electron microscopy (SEM) micrographs show that the ZnO NWs could reach an astounding 51.9 ± 0.82 µm in length, 0.7 ± 0.08 µm in diameter, and 3.3 ± 2.1 µm^-2 density of the number of NWs per area within 24 h of growth time, compared with a reported value of ~26.8 µm in length for the same period. The indentation modulus of the as-grown ZnO NWs was determined using contact resonance (CR) measurements using atomic force microscopy (AFM). An indentation modulus of 122.2 ± 2.3 GPa for the NW array sample with an average diameter of ~690 nm was found to be close to the reference bulk ZnO value of 125 GPa. Furthermore, the measurement of the piezoelectric coefficient (d₃₃) using the traceable ESPY33 tool under cyclic compressive stress gave a value of 1.6 ± 0.4 pC/N at 0.02 N with ZnO NWs of 100 ± 10 nm and 2.69 ± 0.05 µm in diameter and length, respectively, which were embedded in an S1818 polymer. Current–voltage (I-V) measurements of the ZnO NWs fabricated on an n-type silicon (Si) substrate utilizing a micromanipulator integrated with a tungsten (W) probe exhibits Ohmic behavior, revealing an important phenomenon which can be attributed to the generated electric field by the tungsten probe, dielectric residue, or conductive material. Full article

(This article belongs to the Special Issue Research Progress on Advanced Piezoelectric Energy Harvesters)

16 pages, 1652 KiB

Open AccessArticle

Cell Partitioning Design for Microfluidic ATPS Devices: A Dynamic Energy Strategy and Calculation Using Chondrocytes and Model Microparticles

by Gabriel Garibaldi, Jimena Alegria, Anita Shayan, Robert Stannert, Nehal I. Abu-Lail and Gongchen Sun

Micromachines 2025, 16(8), 926; https://doi.org/10.3390/mi16080926 (registering DOI) - 12 Aug 2025

Abstract

Sorting and isolating specific cells from heterogeneous populations are crucial for many biomedical applications, including drug discovery and medical diagnostics. Conventional methods such as Fluorescent Activated Cell Sorting (FACS) and Magnetic Activated Cell Sorting (MACS) face limitations in throughput, cost, and the ability [...] Read more.

Sorting and isolating specific cells from heterogeneous populations are crucial for many biomedical applications, including drug discovery and medical diagnostics. Conventional methods such as Fluorescent Activated Cell Sorting (FACS) and Magnetic Activated Cell Sorting (MACS) face limitations in throughput, cost, and the ability to separate subtly different cells. Cell partitioning in Aqueous Two-Phase Systems (ATPSs) offers a biocompatible and cost-effective alternative, particularly when combined with continuous-flow microfluidics. However, it remains challenging to rationally design microfluidic ATPS devices and operation to separate cells with similar origin but different phenotypes. In this paper, using a model ATPS, polyethylene glycol (PEG)—Dextran (Dex) system, and model cells, human chondrocytes (hChs), and carboxylated polystyrene (PS) microparticles, we systematically characterized the material properties affecting cell partitioning in ATPSs, such as surface energies of the solutions and cells and solution viscosities. We developed an energy balance approach between interfacial energy and viscous dissipation to estimate the interface translocation dynamic of cells partitioning into the preferred phase. Combining the experimental measurement and the energy balance model, our calculation reveals that the time required for complete cell partitioning at the ATPS interface can be exploited in microfluidic ATPS devices to separate hChs with different phenotypes (healthy and diseased). We expect our dynamic energy approach to provide a basis and a design strategy for optimizing microfluidic ATPS devices to achieve the efficient separation of phenotypically similar cell populations and further expand the potential of microfluidic cell separation. Full article

(This article belongs to the Special Issue Micro/Nanotechnology for Cell Manipulation, Detection and Analysis)

► Show Figures

Figure 1

13 pages, 4450 KiB

Open AccessArticle

Laser-Based Selective Removal of EMI Shielding Layers in System-in-Package (SiP) Modules

by Xuan-Bach Le, Won Yong Choi, Keejun Han and Sung-Hoon Choa

Micromachines 2025, 16(8), 925; https://doi.org/10.3390/mi16080925 - 11 Aug 2025

Abstract

With the increasing complexity and integration density of System-in-Package (SiP) technologies, the demand for selective electromagnetic interference (EMI) shielding is growing. Conventional sputtering processes, while effective for conformal EMI shielding, lack selectivity and often require additional masking or post-processing steps. In this study, [...] Read more.

With the increasing complexity and integration density of System-in-Package (SiP) technologies, the demand for selective electromagnetic interference (EMI) shielding is growing. Conventional sputtering processes, while effective for conformal EMI shielding, lack selectivity and often require additional masking or post-processing steps. In this study, we propose a novel, laser-based approach for the selective removal of EMI shielding layers without physical masking. Numerical simulations were conducted to investigate the thermal and mechanical behavior of multilayer EMI shielding structures under two irradiation modes: full-area and laser scanning. The results showed that the laser scanning method induced higher interfacial shear stress, reaching up to 38.6 MPa, compared to full-area irradiation (12.5 MPa), effectively promoting delamination while maintaining the integrity of the underlying epoxy mold compound (EMC). Experimental validation using a nanosecond pulsed fiber laser confirmed that complete removal of the EMI shielding layer could be achieved at optimized laser powers (~6 W) without damaging the EMC, whereas excessive power (8 W) caused material degradation. The laser scanning speed was 50 mm/s, and the total laser irradiation time of the package was 0.14 s, which was very fast. This study demonstrates the feasibility of a non-contact, damage-free, and selective EMI shielding removal technique, offering a promising solution for next-generation semiconductor packaging. Full article

(This article belongs to the Special Issue Emerging Packaging and Interconnection Technology, Second Edition)

► Show Figures

Figure 1

11 pages, 8091 KiB

Open AccessArticle

Wireless Communication Using a Radiation-Type Metasurface

by Jun Chen Ke, Li Wang, Mingzhu Jiang and Qiang Wang

Micromachines 2025, 16(8), 924; https://doi.org/10.3390/mi16080924 - 11 Aug 2025

Abstract

The rapid development of metasurfaces offers new possibilities to establish novel wireless communication systems with simplified architectures. However, the current demonstration systems are based on the reflection-type metasurfaces, which suffer from high profiles and integration challenges in practice. Such configurations are also inefficient [...] Read more.

The rapid development of metasurfaces offers new possibilities to establish novel wireless communication systems with simplified architectures. However, the current demonstration systems are based on the reflection-type metasurfaces, which suffer from high profiles and integration challenges in practice. Such configurations are also inefficient for handling multiple subcarriers during beam scanning and beam tracking. To address these limitations, a radiation-type metasurface fed by a microstrip array antenna is proposed in this paper, which is used to construct a new-architecture wireless communication system. Compared to the reported metasurface-based communication systems, the proposed design is more flexible for information modulation and transmission, with the system profile significantly reduced. The phase modulation is implemented by changing the transmission phase of metasurface, allowing for baseband signals to be directly imparted to the carrier wave from the feeding source. A real-time signal transmission experiment validates the performance of the proposed metasurface-based communication system. Full article

(This article belongs to the Special Issue Electromagnetic Metamaterials and Metasurfaces: From Design to Applications)

► Show Figures

Figure 1

17 pages, 3231 KiB

Open AccessArticle

Research on Cutting Force Modeling and Machining Performance of Discrete-Edge End Mill

by Ming Song, Minli Zheng, Siyuan Gao, Baojuan Dong and Jianping Zhu

Micromachines 2025, 16(8), 923; https://doi.org/10.3390/mi16080923 - 10 Aug 2025

Abstract

To address the challenges of complex cutting force formation and low prediction accuracy in discrete-edge end mills, this study proposes a precise cutting force modeling method based on an effective chip slot function. An effective chip slot function is established to quantitatively characterize [...] Read more.

To address the challenges of complex cutting force formation and low prediction accuracy in discrete-edge end mills, this study proposes a precise cutting force modeling method based on an effective chip slot function. An effective chip slot function is established to quantitatively characterize the dynamic variation of cutting edge engagement along different axial positions. Based on the instantaneous uncut chip thickness theory by Altintas, a high-precision cutting force model suitable for discrete-edge tools is developed. Experimental results show that the proposed model achieves an average prediction error of 4.82%, with a maximum error below 10%, demonstrating its high accuracy and practical applicability. Comparative experiments with conventional continuous-edge end mills under identical machining conditions indicate that the discrete-edge tool can reduce cutting forces (F_x by 7.2%, F_y by 3.2%), significantly suppress cutting vibrations (fluctuation coefficients reduced by 13.5% and 21.9%, respectively), and lower surface roughness to approximately one-sixth of that produced by conventional tools. The results confirm that discrete-edge end mills exhibit notable advantages in machining stability, cutting force control, and surface quality, providing a solid theoretical foundation for the design and process optimization of high-performance cutting tools. Full article

(This article belongs to the Special Issue Advanced Manufacturing Technology and Systems, 3rd Edition)

► Show Figures

Figure 1

17 pages, 9812 KiB

Open AccessArticle

Study on the Influence of Deformation and Temperature on the Properties of High-Strength Tungsten Alloy Wire

by Junling Fan, Jingwen Du, Jun Cao, Yongzhen Sun and Junchao Zhang

Micromachines 2025, 16(8), 922; https://doi.org/10.3390/mi16080922 - 10 Aug 2025

Abstract

In this paper, high-strength W-1%La₂O₃ alloy wire was obtained by solid-state doping using tungsten powder and lanthanum oxide, large deformation rotary forging and wire drawing, which solved the disadvantages of traditional tungsten alloy wire processing such as the uneven distribution [...] Read more.

In this paper, high-strength W-1%La₂O₃ alloy wire was obtained by solid-state doping using tungsten powder and lanthanum oxide, large deformation rotary forging and wire drawing, which solved the disadvantages of traditional tungsten alloy wire processing such as the uneven distribution of rare earth oxides. The effects of rotary forging and annealing on the microstructure and properties of tungsten alloy were studied, which provided some basis for preparing high-strength tungsten alloy wire. The results indicate that tungsten alloy undergoes recovery at relative high temperatures (1480–1380 °C) during the rotary forging process. After large deformation, subgrains and uneven microstructures appear, so annealing is required before tungsten alloys wire drawing processing. With increasing annealing temperature, the recrystallization degree gradually increases and the hardness of tungsten alloy gradually decreases. When the deformation is less than 81.2%, tungsten alloy wire exhibits brittle fracture. When the deformation increases to 88.4% (ø0.8 mm), the fracture surface of the wire exhibits a plastic–brittle mixed fracture mechanism. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials—Second Edition)

► Show Figures

Figure 1

11 pages, 1580 KiB

Open AccessArticle

Research on a Graded Self-Powered Vibration Sensor for Geological Drilling

by Jingui Zhang and Chuan Wu

Micromachines 2025, 16(8), 921; https://doi.org/10.3390/mi16080921 - 10 Aug 2025

Abstract

Downhole vibration measurement is a key link for optimizing drilling parameters and ensuring operational safety; however, powering conventional vibration sensors reduces drilling efficiency and increases drilling costs. This paper introduces a triboelectric nanogenerator-based, graded, and self-powered vibration sensor designed for geological drilling, enabling [...] Read more.

Downhole vibration measurement is a key link for optimizing drilling parameters and ensuring operational safety; however, powering conventional vibration sensors reduces drilling efficiency and increases drilling costs. This paper introduces a triboelectric nanogenerator-based, graded, and self-powered vibration sensor designed for geological drilling, enabling the concurrent measurement of vibration frequency and amplitude. Experimental results show that the sensor has a measurement range for vibration frequency from 0 Hz to 11 Hz and can measure amplitude thresholds of 10 mm, 25 mm, 40 mm, and 55 mm. The measurement errors for both vibration frequency and amplitude are less than 3%, and it can operate stably under conditions of temperature below 150 °C and humidity below 90%, demonstrating good environmental adaptability. Furthermore, the sensor has self-powering capabilities, with a maximum output voltage reaching 11.8 V, a peak current of 28 nA, and a peak output power of 4 × 10⁻⁷ W into an external resistance of 6 × 10⁷ Ω. In contrast to conventional downhole vibration sensors, this device integrates self-powering with graded amplitude detection, enhancing its suitability for real-world drilling applications. Full article

(This article belongs to the Special Issue Micro/Nanostructures in Sensors and Actuators, 2nd Edition)

► Show Figures

Figure 1

18 pages, 4583 KiB

Open AccessArticle

Bright Blue Light Emission of ZnCl₂-Doped CsPbCl₁Br₂ Perovskite Nanocrystals with High Photoluminescence Quantum Yield

by Bo Feng, Youbin Fang, Jin Wang, Xi Yuan, Jihui Lang, Jian Cao, Jie Hua and Xiaotian Yang

Micromachines 2025, 16(8), 920; https://doi.org/10.3390/mi16080920 - 9 Aug 2025

Abstract

The future development of perovskite light-emitting diodes (LEDs) is significantly limited by the poor stability and low brightness of the pure-blue emission in the wavelength range of 460–470 nm. In this study, the Cl/Br element ratio in CsPbCl_xBr_3−x perovskite nanocrystals [...] Read more.

The future development of perovskite light-emitting diodes (LEDs) is significantly limited by the poor stability and low brightness of the pure-blue emission in the wavelength range of 460–470 nm. In this study, the Cl/Br element ratio in CsPbCl_xBr_3−x perovskite nanocrystals (NCs) was modulated to precisely control their blue emission in the 428–512 nm spectral region. Then, the undoped CsPbCl₁Br₂ and the ZnCl₂-doped CsPbCl₁Br₂ perovskite NCs were synthesized via the hot-injection method and investigated using variable-temperature photoluminescence (PL) spectroscopy. The PL emission peak of the ZnCl₂-doped CsPbCl₁Br₂ perovskite NCs exhibits a blue shift from 475 nm to 460 nm with increasing ZnCl₂ doping concentration. Additionally, the ZnCl₂-doped CsPbCl₁Br₂ perovskite NCs show a high photoluminescence quantum yield (PLQY). The variable-temperature PL spectroscopy results show that the ZnCl₂-doped CsPbCl₁Br₂ perovskite NCs have a larger exciton binding energy than the CsPbCl₁Br₂ perovskite NCs, which is indicative of a potentially higher PL intensity. To assess the stability of the perovskite NCs, high-temperature experiments and ultraviolet-irradiation experiments were conducted. The results indicate that zinc doping is beneficial for improving the stability of the perovskite NCs. The ZnCl₂-doped CsPbCl₁Br₂ perovskite NCs were post-treated using didodecylammonium bromide, and after the post-treatment, the PLQY increased to 83%. This is a high PLQY value for perovskite NC-LEDs in the blue spectral range, and it satisfies the requirements of practical display applications. This work thus provides a simple preparation method for pure blue light-emitting materials. Full article

(This article belongs to the Special Issue Advanced Optoelectronic Materials/Devices and Their Applications)

► Show Figures

Figure 1

22 pages, 11628 KiB

Open AccessArticle

Study of the Sensitivity of DC Arc Temperature Field, Pressure Field, and Potential to Process Parameters

by Yongjun Liu, Gaosong Li, Shuai Zhang and Zhenya Wang

Micromachines 2025, 16(8), 919; https://doi.org/10.3390/mi16080919 - 9 Aug 2025

Abstract

DC arcs are widely used in many fields such as shipbuilding, machinery manufacturing, and aerospace due to their advantages of high energy density, simple structure, and low price. However, there are few studies on the sensitivity of the arc pressure and temperature fields [...] Read more.

DC arcs are widely used in many fields such as shipbuilding, machinery manufacturing, and aerospace due to their advantages of high energy density, simple structure, and low price. However, there are few studies on the sensitivity of the arc pressure and temperature fields to current and protective gas flow rate. In order to solve this problem, this paper establishes a numerical model for the coupling of DC arc electric–thermal–flow multi-physical fields. Based on this model, the variation rules of the arc temperature, pressure, and potential field with current or protective gas flow rate are studied, respectively, when the current is 100–600 A or the gas flow rate is 18–48 L/min. The results show that the current is the most important factor in the sensitivity of the arc temperature and potential field to the current and protective gas flow rate. With the increase in current, the Joule heat power increases significantly, and the arc central temperature shows a nonlinear increase to 27,000 K. With increasing current, the peak of the pressure field gradually shifts to the region below the top of the wire arc, and the highest pressure increases by 14 times. When the current is small, the increase in argon flow rate can inhibit the spreading of the temperature field by forced convection; when the current is large, the arc contraction with an increasing argon flow rate leads to an anomalous increase in the arc-central temperature. In addition, the energy accumulation mechanism in the strong-current–high-flow-rate coupling region is also revealed, a coupled mathematical model of arc contraction and turbulent loss under the Lorentz force is constructed, and the thermodynamic properties of the arc under the coupling of multi-physical fields are elucidated. Full article

(This article belongs to the Special Issue Advanced Micro- and Nano-Manufacturing Technologies, 2nd Edition)

► Show Figures

Figure 1

36 pages, 8596 KiB

Open AccessReview

Microrheology: From Video Microscopy to Optical Tweezers

by Andrea Jannina Fernandez, Graham M. Gibson, Anna Rył and Manlio Tassieri

Micromachines 2025, 16(8), 918; https://doi.org/10.3390/mi16080918 - 8 Aug 2025

Abstract

Microrheology, a branch of rheology, focuses on studying the flow and deformation of matter at micron length scales, enabling the characterization of materials using minute sample volumes. This review article explores the principles and advancements of microrheology, covering a range of techniques that [...] Read more.

Microrheology, a branch of rheology, focuses on studying the flow and deformation of matter at micron length scales, enabling the characterization of materials using minute sample volumes. This review article explores the principles and advancements of microrheology, covering a range of techniques that infer the viscoelastic properties of soft materials from the motion of embedded tracer particles. Special emphasis is placed on methods employing optical tweezers, which have emerged as a powerful tool in both passive and active microrheology thanks to their exceptional force sensitivity and spatiotemporal resolution. The review also highlights complementary techniques such as video particle tracking, magnetic tweezers, dynamic light scattering, and atomic force microscopy. Applications across biology, materials science, and soft matter research are discussed, emphasizing the growing relevance of particle tracking microrheology and optical tweezers in probing microscale mechanics. Full article

(This article belongs to the Special Issue Microrheology with Optical Tweezers)

► Show Figures

Figure 1

13 pages, 6459 KiB

Open AccessArticle

Total Ionizing Dose Effect Simulation Modeling and Analysis for a DCAP Power Chip

by Xinfang Liao, Danyang Lei, Yanjun Fu, Yuchen Liu, Kangqi Huang, Yuan Wei, Yinghong Zuo, Yashi Ying, Yi Liu, Changqing Xu and Yintang Yang

Micromachines 2025, 16(8), 917; https://doi.org/10.3390/mi16080917 - 8 Aug 2025

Abstract

In this paper, a systematic study on performance degradation of a 0.18 μm BCD-process DCAP (Direct connection to the output CAPacitor) power chip under a total-dose radiation environment is carried out. The effects of total-dose radiation on the electrical characteristics of an MOS [...] Read more.

In this paper, a systematic study on performance degradation of a 0.18 μm BCD-process DCAP (Direct connection to the output CAPacitor) power chip under a total-dose radiation environment is carried out. The effects of total-dose radiation on the electrical characteristics of an MOS device are analyzed through device-level simulation. Based on the simulation results, a total-dose fault injection model is established and applied to a circuit-level simulation of the DCAP power chip. Our simulation modeling and analysis results show that total-dose radiation degrades output voltage accuracy and switching frequency, to which the bandgap reference circuit is identified as the most sensitive module. The findings presented in this paper provide theoretical support for total-dose radiation hardening designs for the DCAP power chip. Full article

► Show Figures

Figure 1

39 pages, 4438 KiB

Open AccessReview

Graphene-Based Gas Sensors: State-of-the-Art Developments for Gas Sensing Applications

by Aviraj M. Teli, Sagar M. Mane, Sonali A. Beknalkar, Rajneesh Kumar Mishra, Wookhee Jeon and Jae Cheol Shin

Micromachines 2025, 16(8), 916; https://doi.org/10.3390/mi16080916 - 8 Aug 2025

Abstract

Gas sensors based on graphene have gained considerable attention because of graphene’s remarkable properties, such as its extensive surface area, impressive electrical conductivity, and exceptional mechanical strength. This review critically analyzes recent developments in functionalization strategies designed to enhance the sensitivity, selectivity, and [...] Read more.

Gas sensors based on graphene have gained considerable attention because of graphene’s remarkable properties, such as its extensive surface area, impressive electrical conductivity, and exceptional mechanical strength. This review critically analyzes recent developments in functionalization strategies designed to enhance the sensitivity, selectivity, and stability of graphene-based sensors. It discusses various chemical, physical, and hybrid functionalization methods, illustrating how surface alterations affect graphene’s interaction with target gas molecules. The paper also investigates the fundamental sensing mechanisms, including charge transfer, carrier mobility modulation, and Schottky barrier modification, to provide a thorough understanding of sensor response characteristics. Additionally, it highlights emerging applications in environmental monitoring, healthcare diagnostics, and industrial safety, demonstrating the transformative potential of these sensors in real-world settings. Finally, the review addresses challenges concerning reproducibility, long-term stability, and large-scale production, while also offering future insights on utilizing innovative nanomaterials and artificial intelligence to advance the next generation of graphene-based gas sensing technologies. Full article

(This article belongs to the Special Issue Advanced Nanomaterials for High-Performance Gas Sensors)

► Show Figures

Figure 1

17 pages, 4004 KiB

Open AccessArticle

Research on Switching Current Model of GaN HEMT Based on Neural Network

by Xiang Wang, Zhihui Zhao, Huikai Chen, Xueqi Sun, Shulong Wang and Guohao Zhang

Micromachines 2025, 16(8), 915; https://doi.org/10.3390/mi16080915 - 7 Aug 2025

Abstract

The switching characteristics of GaN HEMT devices exhibit a very complex dynamic nonlinear behavior and multi-physics coupling characteristics, and traditional switching current models based on physical mechanisms have significant limitations. This article adopts a hybrid architecture of convolutional neural network and long short-term [...] Read more.

The switching characteristics of GaN HEMT devices exhibit a very complex dynamic nonlinear behavior and multi-physics coupling characteristics, and traditional switching current models based on physical mechanisms have significant limitations. This article adopts a hybrid architecture of convolutional neural network and long short-term memory network (CNN-LSTM). In the 1D-CNN layer, the one-dimensional convolutional neural network can automatically learn and extract local transient features of time series data by sliding convolution operations on time series data through its convolution kernel, making these local transient features present a specific form in the local time window. In the double-layer LSTM layer, the neural network model captures the transient characteristics of switch current through the gating mechanism and state transfer. The hybrid architecture of the constructed model has significant advantages in accuracy, with metrics such as root mean square error (RMSE) and mean absolute error (MAE) significantly reduced, compared to traditional switch current models, solving the problem of insufficient accuracy in traditional models. The neural network model has good fitting performance at both room and high temperatures, with an average coefficient close to 1. The new neural network hybrid architecture has short running time and low computational resource consumption, meeting the needs of practical applications. Full article

(This article belongs to the Special Issue Advanced Wide Bandgap Semiconductor Materials and Devices)

► Show Figures

Figure 1

18 pages, 4370 KiB

Open AccessArticle

The Multi-Objective Optimization of a Dual C-Type Gold Ribbon Interconnect Structure Considering Its Geometrical Parameter Fluctuation

by Guangmi Li, Song Xue, Jinyang Mu, Shaoyi Liu, Qiongfang Zhang, Wenzhi Wu, Zhihai Wang, Zhen Ma, Dongchao Diwu and Congsi Wang

Micromachines 2025, 16(8), 914; https://doi.org/10.3390/mi16080914 - 7 Aug 2025

Abstract

With the increasing demand for high integration, low cost, and large capacities in satellite systems, integrating the antenna and microwave component into the same system has become appealing to the satellite engineer. The dual C-type gold ribbon, performing as the key electromagnetic signal [...] Read more.

With the increasing demand for high integration, low cost, and large capacities in satellite systems, integrating the antenna and microwave component into the same system has become appealing to the satellite engineer. The dual C-type gold ribbon, performing as the key electromagnetic signal bridge between the microwave component and the antenna, has a significant impact on the electrical performance of satellite antennas. However, during its manufacturing and operating, the interconnection geometry undergoes deformation due to mounting errors and environmental loads. Consequently, these parasitic geometry parameters can significantly increase energy loss during the signal transmission. To address this issue, this paper has proposed a method for determining the design range of the geometrical parameters of the dual C-type gold ribbon, and applied it to the performance prediction of the microstrip antennas and the parameter optimization of the gold ribbon. In this study, a mechanical response analysis of the antennas in the operating environment has been carried out and the manufacturing disturbance has been considered to calculate the geometry fluctuation range. Then, the significance ranking of the geometry parameters has been determined and the key parameters have been selected. Finally, the chaos feedback adaptive whale optimization algorithm–back propagation neural network has been used as a surrogate model to establish the relationship between the geometry parameters and the antenna electromagnetic performance, and the multi-objective red-billed blue magpie optimization algorithm has been combined with the surrogate model to optimize the configuration parameters. This paper provides theoretical guidance for the interconnection geometry design and the optimization of the integration module of the antennas and microwave components. Full article

► Show Figures

Figure 1

21 pages, 15471 KiB

Open AccessArticle

Tribology of EDM Recast Layers Vis-À-Vis TIG Cladding Coatings: An Experimental Investigation

by Muhammad Adnan, Waqar Qureshi and Muhammad Umer

Micromachines 2025, 16(8), 913; https://doi.org/10.3390/mi16080913 - 7 Aug 2025

Abstract

Tribological performance is critical for the longevity and efficiency of machined components in industries such as aerospace, automotive, and biomedical. This study investigates whether electrical discharge machining recast layers can serve as a cost-effective and time-efficient alternative to conventional tungsten inert gas cladding [...] Read more.

Tribological performance is critical for the longevity and efficiency of machined components in industries such as aerospace, automotive, and biomedical. This study investigates whether electrical discharge machining recast layers can serve as a cost-effective and time-efficient alternative to conventional tungsten inert gas cladding coatings for enhancing surface properties. The samples were prepared using electrical discharge machining and tungsten inert gas cladding. For electrical discharge machining, various combinations of electrical and non-electrical parameters were applied using Taguchi’s L18 orthogonal array. Similarly, tungsten inert gas cladding coatings were prepared using a suitable combination of current, voltage, powder size, and speed. The samples were characterized using, scanning electron microscopy, optical microscopy, microhardness testing, tribological testing, energy-dispersive X-ray spectroscopy, X-ray diffraction analysis and profilometry. The electrical discharge machining recast layers exhibited superior tribological performance compared to tungsten inert gas cladding coatings. This improvement is attributed to the formation of carbides, such as TiC and Ti₆C_3.75. The coefficient of friction and specific wear rate were reduced by 11.11% and 1.57%, respectively, while microhardness increased by 10.93%. Abrasive wear was identified as the predominant wear mechanism. This study systematically compares electrical discharge machining recast layers with tungsten inert gas cladding coatings. The findings suggest that optimized electrical discharge machining recast layers can serve as effective coatings, offering cost and time savings. Full article

(This article belongs to the Special Issue Recent Developments in Electrical Discharge Machining Technology)

► Show Figures

Figure 1

18 pages, 19901 KiB

Open AccessArticle

A Novel Polysilicon-Fill-Strengthened Etch-Through 3D Trench Electrode Detector: Fabrication Methods and Electrical Property Simulations

by Xuran Zhu, Zheng Li, Zhiyu Liu, Tao Long, Jun Zhao, Xinqing Li, Manwen Liu and Meishan Wang

Micromachines 2025, 16(8), 912; https://doi.org/10.3390/mi16080912 - 6 Aug 2025

Abstract

Three-dimensional trench electrode silicon detectors play an important role in particle physics research, nuclear radiation detection, and other fields. A novel polysilicon-fill-strengthened etch-through 3D trench electrode detector is proposed to address the shortcomings of traditional 3D trench electrode silicon detectors; for example, the [...] Read more.

Three-dimensional trench electrode silicon detectors play an important role in particle physics research, nuclear radiation detection, and other fields. A novel polysilicon-fill-strengthened etch-through 3D trench electrode detector is proposed to address the shortcomings of traditional 3D trench electrode silicon detectors; for example, the distribution of non-uniform electric fields, asymmetric electric potential, and dead zone. The physical properties of the detector have been extensively and systematically studied. This study simulated the electric field, potential, electron concentration distribution, complete depletion voltage, leakage current, capacitance, transient current induced by incident particles, and weighting field distribution of the detector. It also systematically studied and analyzed the electrical characteristics of the detector. Compared to traditional 3D trench electrode silicon detectors, this new detector adopts a manufacturing process of double-side etching technology and double-side filling technology, which results in a more sensitive detector volume and higher electric field uniformity. In addition, the size of the detector unit is 120 µm × 120 µm × 340 µm; the structure has a small fully depleted voltage, reaching a fully depleted state at around 1.4 V, with a saturation leakage current of approximately

4.8 \times 10^{- 10} A

, and a geometric capacitance of about 99 fF. Full article

(This article belongs to the Special Issue Photonic and Optoelectronic Devices and Systems, Third Edition)

► Show Figures

Figure 1

11 pages, 2425 KiB

Open AccessArticle

Single-Layer High-Efficiency Metasurface for Multi-User Signal Enhancement

by Hui Jin, Peixuan Zhu, Rongrong Zhu, Bo Yang, Siqi Zhang and Huan Lu

Micromachines 2025, 16(8), 911; https://doi.org/10.3390/mi16080911 - 6 Aug 2025

Abstract

In multi-user wireless communication scenarios, signal degradation caused by channel fading and co-channel interference restricts system capacity, while traditional enhancement schemes face challenges of high coordination complexity and hardware integration. This paper proposes an electromagnetic focusing method using a single-layer transmissive passive metasurface. [...] Read more.

In multi-user wireless communication scenarios, signal degradation caused by channel fading and co-channel interference restricts system capacity, while traditional enhancement schemes face challenges of high coordination complexity and hardware integration. This paper proposes an electromagnetic focusing method using a single-layer transmissive passive metasurface. A high-efficiency metasurface array is fabricated based on PCB technology, which utilizes subwavelength units for wide-range phase modulation to construct a multi-user energy convergence model in the WiFi band. By optimizing phase gradients through the geometric phase principle, the metasurface achieves collaborative wavefront manipulation for multiple target regions with high transmission efficiency, reducing system complexity compared to traditional multi-layer structures. Measurements in a microwave anechoic chamber and tests in an office environment demonstrate that the metasurface can simultaneously create signal enhancement zones for multiple users, featuring stable focusing capability and environmental adaptability. This lightweight design facilitates deployment in dense networks, providing an effective solution for signal optimization in indoor distributed systems and IoT communications. Full article

(This article belongs to the Special Issue Novel Electromagnetic and Acoustic Devices)

► Show Figures

Figure 1

16 pages, 3174 KiB

Open AccessArticle

Efficient Particle Aggregation Through SSAW Phase Modulation

by Yiming Li, Zekai Li, Zuozhi Wei, Yiran Wang, Xudong Niu and Dongfang Liang

Micromachines 2025, 16(8), 910; https://doi.org/10.3390/mi16080910 - 5 Aug 2025

Abstract

In recent years, various devices utilizing surface acoustic waves (SAW) have emerged as powerful tools for manipulating particles and fluids in microchannels. Although they demonstrate a wide range of functionalities across diverse applications, existing devices still face limitations in flexibility, manipulation efficiency, and [...] Read more.

In recent years, various devices utilizing surface acoustic waves (SAW) have emerged as powerful tools for manipulating particles and fluids in microchannels. Although they demonstrate a wide range of functionalities across diverse applications, existing devices still face limitations in flexibility, manipulation efficiency, and spatial resolution. In this study, we developed a dual-sided standing surface acoustic wave (SSAW) device that simultaneously excites acoustic waves through two piezoelectric substrates positioned at the top and bottom of a microchannel. By fully exploiting the degrees of freedom offered by two pairs of interdigital transducers (IDTs) on each substrate, the system enables highly flexible control of microparticles. To explore its capability on particle aggregation, we developed a two-dimensional numerical model to investigate the influence of the SAW phase modulation on the established acoustic fields within the microchannel. Single-particle motion was first examined under the influence of the phase-modulated acoustic fields to form a reference for identifying effective phase modulation strategies. Key parameters, such as the phase changes and the duration of each phase modulation step, were determined to maximize the lateral motion while minimizing undesired vertical motion of the particle. Our dual-sided SSAW configuration, combined with novel dynamic phase modulation strategy, leads to rapid and precise aggregation of microparticles towards a single focal point. This study sheds new light on the design of acoustofluidic devices for efficient spatiotemporal particle concentration. Full article

(This article belongs to the Special Issue Surface and Bulk Acoustic Wave Devices, 2nd Edition)

► Show Figures

Figure 1

10 pages, 3553 KiB

Open AccessArticle

A Trench Heterojunction Diode-Integrated 4H-SiC LDMOS with Enhanced Reverse Recovery Characteristics

by Yanjuan Liu, Fangfei Bai and Junpeng Fang

Micromachines 2025, 16(8), 909; https://doi.org/10.3390/mi16080909 - 4 Aug 2025

Abstract

In this paper, a novel 4H-SiC LDMOS structure with a trench heterojunction in the source (referred as to THD-LDMOS) is proposed and investigated for the first time, to enhance the reverse recovery performance of its parasitic diode. Compared with 4H-SiC, silicon has a [...] Read more.

In this paper, a novel 4H-SiC LDMOS structure with a trench heterojunction in the source (referred as to THD-LDMOS) is proposed and investigated for the first time, to enhance the reverse recovery performance of its parasitic diode. Compared with 4H-SiC, silicon has a smaller band energy, which results in a lower built-in potential for the junction formed by P+ polysilicon and a 4N-SiC N-drift region. A trench P+ polysilicon is introduced in the source side, forming a heterojunction with the N-drift region, and this heterojunction is unipolar and connected in parallel with the body PiN diode. When the LDMOS operates as a freewheeling diode, the trench heterojunction conducts first, preventing the parasitic PiN from turning on and thereby significantly reducing the number of carriers in the N-drift region. Consequently, THD-LDMOS exhibits superior reverse recovery characteristics. The simulation results indicate that the reverse recovery peak current and reverse recovery charge of THD-LDMOS are reduced by 55.5% and 77.6%, respectively, while the other basic electrical characteristics remains unaffected. Full article

(This article belongs to the Special Issue Advanced Wide Bandgap Semiconductor Materials and Devices)

► Show Figures

Figure 1
