Materials, Volume 10, Issue 7 (July 2017)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story Structural health monitoring often leverages on strain wave analysis for the reconstruction of [...] Read more.
View options order results:
result details:
Displaying articles 1-163
Export citation of selected articles as:

Research

Jump to: Review

Open AccessArticle A Novel Method for Fabricating Wearable, Piezoresistive, and Pressure Sensors Based on Modified-Graphite/Polyurethane Composite Films
Materials 2017, 10(7), 684; doi:10.3390/ma10070684
Received: 7 May 2017 / Revised: 5 June 2017 / Accepted: 14 June 2017 / Published: 22 June 2017
PDF Full-text (5014 KB) | HTML Full-text | XML Full-text
Abstract
A wearable, low-cost, highly repeatable piezoresistive sensor was fabricated by the synthesis of modified-graphite and polyurethane (PU) composites and polydimethylsiloxane (PDMS). Graphite sheets functionalized by using a silane coupling agent (KH550) were distributed in PU/N,N-dimethylformamide (DMF) solution, which were
[...] Read more.
A wearable, low-cost, highly repeatable piezoresistive sensor was fabricated by the synthesis of modified-graphite and polyurethane (PU) composites and polydimethylsiloxane (PDMS). Graphite sheets functionalized by using a silane coupling agent (KH550) were distributed in PU/N,N-dimethylformamide (DMF) solution, which were then molded to modified-graphite/PU (MG/PU) composite films. Experimental results show that with increasing modified-graphite content, the tensile strength of the MG/PU films first increased and then decreased, and the elongation at break of the composite films showed a decreasing trend. The electrical conductivity of the composite films can be influenced by filler modification and concentration, and the percolation threshold of MG/PU was 28.03 wt %. Under liner uniaxial compression, the 30 wt % MG/PU composite films exhibited 0.274 kPa−1 piezoresistive sensitivity within the range of low pressure, and possessed better stability and hysteresis. The flexible MG/PU composite piezoresistive sensors have great potential for body motion, wearable devices for human healthcare, and garment pressure testing. Full article
Figures

Figure 1

Open AccessArticle Early Damage Detection in Composites during Fabrication and Mechanical Testing
Materials 2017, 10(7), 685; doi:10.3390/ma10070685
Received: 2 May 2017 / Revised: 30 May 2017 / Accepted: 19 June 2017 / Published: 22 June 2017
PDF Full-text (9155 KB) | HTML Full-text | XML Full-text
Abstract
Fully integrated monitoring systems have shown promise in improving confidence in composite materials while reducing lifecycle costs. A distributed optical fibre sensor is embedded in a fibre reinforced composite laminate, to give three sensing regions at different levels through-the-thickness of the plate. This
[...] Read more.
Fully integrated monitoring systems have shown promise in improving confidence in composite materials while reducing lifecycle costs. A distributed optical fibre sensor is embedded in a fibre reinforced composite laminate, to give three sensing regions at different levels through-the-thickness of the plate. This study follows the resin infusion process during fabrication of the composite, monitoring the development of strain in-situ and in real time, and to gain better understanding of the resin rheology during curing. Piezoelectric wafer active sensors and electrical strain gauges are bonded to the plate after fabrication. This is followed by progressive loading/unloading cycles of mechanical four point bending. The strain values obtained from the optical fibre are in good agreement with strain data collected by surface mounted strain gauges, while the sensing regions clearly indicate the development of compressive, neutral, and tensile strain. Acoustic emission event detection suggests the formation of matrix (resin) cracks, with measured damage event amplitudes in agreement with values reported in published literature on the subject. The Felicity ratio for each subsequent loading cycle is calculated to track the progression of damage in the material. The methodology developed here can be used to follow the full life cycle of a composite structure, from manufacture to end-of-life. Full article
(This article belongs to the Special Issue Structural Health Monitoring for Aerospace Applications 2017)
Figures

Figure 1

Open AccessArticle Characterization and In Vitro and In Vivo Assessment of a Novel Cellulose Acetate-Coated Mg-Based Alloy for Orthopedic Applications
Materials 2017, 10(7), 686; doi:10.3390/ma10070686
Received: 26 April 2017 / Revised: 12 June 2017 / Accepted: 19 June 2017 / Published: 22 June 2017
PDF Full-text (6125 KB) | HTML Full-text | XML Full-text
Abstract
Despite their good biocompatibility and adequate mechanical behavior, the main limitation of Mg alloys might be their high degradation rates in a physiological environment. In this study, a novel Mg-based alloy exhibiting an elastic modulus E = 42 GPa, Mg-1Ca-0.2Mn-0.6Zr, was synthesized and
[...] Read more.
Despite their good biocompatibility and adequate mechanical behavior, the main limitation of Mg alloys might be their high degradation rates in a physiological environment. In this study, a novel Mg-based alloy exhibiting an elastic modulus E = 42 GPa, Mg-1Ca-0.2Mn-0.6Zr, was synthesized and thermo-mechanically processed. In order to improve its performance as a temporary bone implant, a coating based on cellulose acetate (CA) was realized by using the dipping method. The formation of the polymer coating was demonstrated by FT-IR, XPS, SEM and corrosion behavior comparative analyses of both uncoated and CA-coated alloys. The potentiodynamic polarization test revealed that the CA coating significantly improved the corrosion resistance of the Mg alloy. Using a series of in vitro and in vivo experiments, the biocompatibility of both groups of biomaterials was assessed. In vitro experiments demonstrated that the media containing their extracts showed good cytocompatibility on MC3T3-E1 pre-osteoblasts in terms of cell adhesion and spreading, viability, proliferation and osteogenic differentiation. In vivo studies conducted in rats revealed that the intramedullary coated implant for fixation of femur fracture was more efficient in inducing bone regeneration than the uncoated one. In this manner, the present study suggests that the CA-coated Mg-based alloy holds promise for orthopedic aplications. Full article
(This article belongs to the Section Biomaterials)
Figures

Figure 1

Open AccessArticle A Fatigue Life Prediction Method Based on Strain Intensity Factor
Materials 2017, 10(7), 689; doi:10.3390/ma10070689
Received: 9 May 2017 / Revised: 14 June 2017 / Accepted: 15 June 2017 / Published: 22 June 2017
PDF Full-text (4855 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, a strain-intensity-factor-based method is proposed to calculate the fatigue crack growth under the fully reversed loading condition. A theoretical analysis is conducted in detail to demonstrate that the strain intensity factor is likely to be a better driving parameter correlated
[...] Read more.
In this paper, a strain-intensity-factor-based method is proposed to calculate the fatigue crack growth under the fully reversed loading condition. A theoretical analysis is conducted in detail to demonstrate that the strain intensity factor is likely to be a better driving parameter correlated with the fatigue crack growth rate than the stress intensity factor (SIF), especially for some metallic materials (such as 316 austenitic stainless steel) in the low cycle fatigue region with negative stress ratios R (typically R = −1). For fully reversed cyclic loading, the constitutive relation between stress and strain should follow the cyclic stress-strain curve rather than the monotonic one (it is a nonlinear function even within the elastic region). Based on that, a transformation algorithm between the SIF and the strain intensity factor is developed, and the fatigue crack growth rate testing data of 316 austenitic stainless steel and AZ31 magnesium alloy are employed to validate the proposed model. It is clearly observed that the scatter band width of crack growth rate vs. strain intensity factor is narrower than that vs. the SIF for different load ranges (which indicates that the strain intensity factor is a better parameter than the stress intensity factor under the fully reversed load condition). It is also shown that the crack growth rate is not uniquely determined by the SIF range even under the same R, but is also influenced by the maximum loading. Additionally, the fatigue life data (strain-life curve) of smooth cylindrical specimens are also used for further comparison, where a modified Paris equation and the equivalent initial flaw size (EIFS) are involved. The results of the proposed method have a better agreement with the experimental data compared to the stress intensity factor based method. Overall, the strain intensity factor method shows a fairly good ability in calculating the fatigue crack propagation, especially for the fully reversed cyclic loading condition. Full article
Figures

Figure 1

Open AccessArticle Ion Beam Assisted Deposition of Thin Epitaxial GaN Films
Materials 2017, 10(7), 690; doi:10.3390/ma10070690
Received: 12 May 2017 / Revised: 9 June 2017 / Accepted: 21 June 2017 / Published: 23 June 2017
PDF Full-text (6593 KB) | HTML Full-text | XML Full-text
Abstract
The assistance of thin film deposition with low-energy ion bombardment influences their final properties significantly. Especially, the application of so-called hyperthermal ions (energy <100 eV) is capable to modify the characteristics of the growing film without generating a large number of irradiation induced
[...] Read more.
The assistance of thin film deposition with low-energy ion bombardment influences their final properties significantly. Especially, the application of so-called hyperthermal ions (energy <100 eV) is capable to modify the characteristics of the growing film without generating a large number of irradiation induced defects. The nitrogen ion beam assisted molecular beam epitaxy (ion energy <25 eV) is used to deposit GaN thin films on (0001)-oriented 6H-SiC substrates at 700 °C. The films are studied in situ by reflection high energy electron diffraction, ex situ by X-ray diffraction, scanning tunnelling microscopy, and high-resolution transmission electron microscopy. It is demonstrated that the film growth mode can be controlled by varying the ion to atom ratio, where 2D films are characterized by a smooth topography, a high crystalline quality, low biaxial stress, and low defect density. Typical structural defects in the GaN thin films were identified as basal plane stacking faults, low-angle grain boundaries forming between w-GaN and z-GaN and twin boundaries. The misfit strain between the GaN thin films and substrates is relieved by the generation of edge dislocations in the first and second monolayers of GaN thin films and of misfit interfacial dislocations. It can be demonstrated that the low-energy nitrogen ion assisted molecular beam epitaxy is a technique to produce thin GaN films of high crystalline quality. Full article
(This article belongs to the Special Issue Ion Beam Analysis, Modification, and Irradiation of Materials)
Figures

Figure 1

Open AccessArticle Preparation and Supercooling Modification of Salt Hydrate Phase Change Materials Based on CaCl2·2H2O/CaCl2
Materials 2017, 10(7), 691; doi:10.3390/ma10070691
Received: 3 April 2017 / Revised: 4 June 2017 / Accepted: 17 June 2017 / Published: 23 June 2017
PDF Full-text (6125 KB) | HTML Full-text | XML Full-text
Abstract
Salt hydrates have issues of supercooling when they are utilized as phase change materials (PCMs). In this research, a new method was adopted to prepare a salt hydrate PCM (based on a mixture of calcium chloride dihydrate and calcium chloride anhydrous) as a
[...] Read more.
Salt hydrates have issues of supercooling when they are utilized as phase change materials (PCMs). In this research, a new method was adopted to prepare a salt hydrate PCM (based on a mixture of calcium chloride dihydrate and calcium chloride anhydrous) as a novel PCM system to reduce the supercooling phenomenon existing in CaCl2·6H2O. Six samples with different compositions of CaCl2 were prepared. The relationship between the performance and the proportion of calcium chloride dihydrate (CaCl2·2H2O) and calcium chloride anhydrous (CaCl2) was also investigated. The supercooling degree of the final PCM reduced with the increase in volume of CaCl2·2H2O during its preparation. The PCM obtained with 66.21 wt % CaCl2·2H2O reduced the supercooling degree by about 96.8%. All six samples, whose ratio of CaCl2·2H2O to (CaCl2 plus CaCl2·2H2O) was 0%, 34.03%, 53.82%, 76.56%, 90.74%, and 100% respectively, showed relatively higher enthalpy (greater than 155.29 J/g), and have the possibility to be applied in buildings for thermal energy storage purposes. Hence, CaCl2·2H2O plays an important role in reducing supercooling and it can be helpful in adjusting the solidification enthalpy. Thereafter, the influence of adding different percentages of Nano-SiO2 (0.1 wt %, 0.3 wt %, 0.5 wt %) in reducing the supercooling degree of some PCM samples was investigated. The test results showed that the supercooling of the salt hydrate PCM in Samples 6 and 5 reduced to 0.2 °C and 0.4 °C respectively. Finally, the effect of the different cooling conditions, including frozen storage (−20 °C) and cold storage (5 °C), that were used to prepare the salt hydrate PCM was considered. It was found that both cooling conditions are effective in reducing the supercooling degree of the salt hydrate PCM. With the synergistic action of the two materials, the performance and properties of the newly developed PCM systems were better especially in terms of reducing the supercooling degree of the PCM. The novel composite PCMs are promising candidates for thermal energy storage applications. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1

Open AccessArticle Enhancing the Compatibility of Poly (1,4-butylene adipate) and Phenoxy Resin in Blends
Materials 2017, 10(7), 692; doi:10.3390/ma10070692
Received: 31 May 2017 / Revised: 18 June 2017 / Accepted: 20 June 2017 / Published: 23 June 2017
PDF Full-text (4482 KB) | HTML Full-text | XML Full-text
Abstract
This work concerns the enhancement in the compatibility of blends of poly (1,4-butylene adipate) (PBA) with poly (hydroxy ether of bisphenol-A) (phenoxy) via alcoholytic exchange. Results on the thermal behavior and morphology show that the blended PBA/phenoxy system exhibits a homogeneous phase and
[...] Read more.
This work concerns the enhancement in the compatibility of blends of poly (1,4-butylene adipate) (PBA) with poly (hydroxy ether of bisphenol-A) (phenoxy) via alcoholytic exchange. Results on the thermal behavior and morphology show that the blended PBA/phenoxy system exhibits a homogeneous phase and a composition-dependent glass transition temperature (Tg). The interaction parameter (χ12) of PBA/phenoxy blends was calculated using the melting point depression method and was found to be −0.336. However, the compatibilization of PBA/phenoxy blends can be enhanced by chemical exchange reactions between PBA and phenoxy upon annealing. Annealed PBA/phenoxy blends were found to have a homogeneous phase with a higher Tg than that of the blended samples, and a smooth surface topography that could be improved by annealing at high temperature. The results of this investigation demonstrate that promotional phase compatibilization in the PBA/phenoxy blend can only be obtained upon thermal annealing, thus causing transreactions to occur between the dangling –OH of the phenoxy and the ester functional groups in PBA. Extensive transreactions cause alcoholytic exchange between the PBA and phenoxy to form a network, thus reducing the mobility of the polymer chain. Finally, the crystallinity of PBA decreased as the degree of transreaction in the blends increased. Full article
(This article belongs to the Special Issue Selected Papers from IEEE ICASI 2017)
Figures

Open AccessFeature PaperArticle Biosynthetic PCL-graft-Collagen Bulk Material for Tissue Engineering Applications
Materials 2017, 10(7), 693; doi:10.3390/ma10070693
Received: 12 April 2017 / Revised: 17 May 2017 / Accepted: 19 June 2017 / Published: 23 June 2017
PDF Full-text (7389 KB) | HTML Full-text | XML Full-text
Abstract
Biosynthetic materials have emerged as one of the most exciting and productive fields in polymer chemistry due to their widespread adoption and potential applications in tissue engineering (TE) research. In this work, we report the synthesis of a poly(ε-caprolactone)-graft-collagen (PCL-g
[...] Read more.
Biosynthetic materials have emerged as one of the most exciting and productive fields in polymer chemistry due to their widespread adoption and potential applications in tissue engineering (TE) research. In this work, we report the synthesis of a poly(ε-caprolactone)-graft-collagen (PCL-g-Coll) copolymer. We combine its good mechanical and biodegradable PCL properties with the great biological properties of type I collagen as a functional material for TE. PCL, previously dissolved in dimethylformamide/dichloromethane mixture, and reacted with collagen using carbodiimide coupling chemistry. The synthesised material was characterised physically, chemically and biologically, using pure PCL and PCL/Coll blend samples as control. Infrared spectroscopy evidenced the presence of amide I and II peaks for the conjugated material. Similarly, XPS evidenced the presence of C–N and N–C=O bonds (8.96 ± 2.02% and 8.52 ± 0.63%; respectively) for PCL-g-Coll. Static contact angles showed a slight decrease in the conjugated sample. However, good biocompatibility and metabolic activity was obtained on PCL-g-Coll films compared to PCL and blend controls. After 3 days of culture, fibroblasts exhibited a spindle-like morphology, spreading homogeneously along the PCL-g-Coll film surface. We have engineered a functional biosynthetic polymer that can be processed by electrospinning. Full article
(This article belongs to the Special Issue Naturally-Derived Biomaterials and Biopolymers)
Figures

Figure 1

Open AccessArticle Effects of Poly(cyclohexanedimethylene terephthalate) on Microstructures, Crystallization Behavior and Properties of the Poly(ester ether) Elastomers
Materials 2017, 10(7), 694; doi:10.3390/ma10070694
Received: 17 May 2017 / Revised: 14 June 2017 / Accepted: 22 June 2017 / Published: 24 June 2017
PDF Full-text (2300 KB) | HTML Full-text | XML Full-text
Abstract
To understand the role of molecular structure on the crystallization behavior of copolyester in thermoplastic poly(ether ester) elastomers (TPEEs), series of poly(butylene-co-1,4-cyclohexanedimethylene terephthalate) (P(BT-co-CT))-b-poly(tetramethylene glycol) (PTMG) are synthesized through molten polycondensation process. The effects of poly(cyclohexanedimethylene terephthalate) (PCT) content on the copolymer are
[...] Read more.
To understand the role of molecular structure on the crystallization behavior of copolyester in thermoplastic poly(ether ester) elastomers (TPEEs), series of poly(butylene-co-1,4-cyclohexanedimethylene terephthalate) (P(BT-co-CT))-b-poly(tetramethylene glycol) (PTMG) are synthesized through molten polycondensation process. The effects of poly(cyclohexanedimethylene terephthalate) (PCT) content on the copolymer are investigated by Fourier transform infrared spectroscopy (FT-IR), 1H and 13C nuclear magnetic resonance (NMR), gel permeation chromatographs (GPC), wide-angle X-ray diffraction (WAXD), differential scanning calorimetry (DSC), thermogravimetric analysis (TGA), mechanical, and visible light transmittance tests. FT-IR and NMR results confirm the incorporation of PCT onto the copolymer. WAXD and DSC indicate that the crystalline structure of the copolymers changed from α-PBT lattice to trans-PCT lattice when the molar fraction of PCT (MPCT) is above 30%, while both crystallization and melting temperatures reach the minima. An increase in MPCT led to an increase in the number sequence length of PCT, the thermal stability and the visible light transmittance of the copolymer, but to a slight decrease in tensile strength and elastic modulus. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Open AccessArticle Synthesis of Nanoscale CaO-Al2O3-SiO2-H2O and Na2O-Al2O3-SiO2-H2O Using the Hydrothermal Method and Their Characterization
Materials 2017, 10(7), 695; doi:10.3390/ma10070695
Received: 7 May 2017 / Revised: 11 June 2017 / Accepted: 12 June 2017 / Published: 26 June 2017
PDF Full-text (6724 KB) | HTML Full-text | XML Full-text
Abstract
C-A-S-H (CaO-Al2O3-SiO2-H2O) and N-A-S-H (Na2O-Al2O3-SiO2-H2O) have a wide range of chemical compositions and structures and are difficult to separate from alkali-activated materials. Therefore, it is
[...] Read more.
C-A-S-H (CaO-Al2O3-SiO2-H2O) and N-A-S-H (Na2O-Al2O3-SiO2-H2O) have a wide range of chemical compositions and structures and are difficult to separate from alkali-activated materials. Therefore, it is difficult to analyze their microscopic properties directly. This paper reports research on the synthesis of C-A-S-H and N-A-S-H particles with an average particle size smaller than 300 nm by applying the hydrothermal method. The composition and microstructure of the products with different CaO(Na2O)/SiO2 ratios and curing conditions were characterized using XRD, the RIR method, FTIR, SEM, TEM, and laser particle size analysis. The results showed that the C-A-S-H system products with a low CaO/SiO2 ratio were mainly amorphous C-A-S-H gels. With an increase in the CaO/SiO2 ratio, an excess of Ca(OH)2 was observed at room temperature, while in a high-temperature reaction system, katoite, C4AcH11, and other crystallized products were observed. The katoite content was related to the curing temperature and the content of Ca(OH)2 and it tended to form at a high-temperature and high-calcium environment, and an increase in the temperature renders the C-A-S-H gels more compact. The main products of the N-A-S-H system at room temperature were amorphous N-A-S-H gels and a small amount of sodalite. An increase in the curing temperature promoted the formation of the crystalline products faujasite and zeolite-P. The crystallization products consisted of only zeolite-P in the high-temperature N-A-S-H system and its content were stable above 70%. An increase in the Na2O/SiO2 ratio resulted in more non-bridging oxygen and the TO4 was more isolated in the N-A-S-H structure. The composition and microstructure of the C-A-S-H and N-A-S-H system products synthesized by the hydrothermal method were closely related to the ratio of the raw materials and the curing conditions. The results of this study increase our understanding of the hydration products of alkali-activated materials. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Figure 1a

Open AccessArticle Phenolic Modified Ceramic Coating on Biodegradable Mg Alloy: The Improved Corrosion Resistance and Osteoblast-Like Cell Activity
Materials 2017, 10(7), 696; doi:10.3390/ma10070696
Received: 16 May 2017 / Revised: 11 June 2017 / Accepted: 22 June 2017 / Published: 25 June 2017
Cited by 1 | PDF Full-text (5354 KB) | HTML Full-text | XML Full-text
Abstract
Magnesium alloys have great potential for developing orthopedic implants due to their biodegradability and mechanical properties, but the rapid corrosion rate of the currently-available alloys limits their clinical applications. To increase the corrosion resistance of the substrate, a protective ceramic coating is constructed
[...] Read more.
Magnesium alloys have great potential for developing orthopedic implants due to their biodegradability and mechanical properties, but the rapid corrosion rate of the currently-available alloys limits their clinical applications. To increase the corrosion resistance of the substrate, a protective ceramic coating is constructed by a micro-arc oxidation (MAO) process on ZK60 magnesium alloy. The porous ceramic coating is mainly composed of magnesium oxide and magnesium silicate, and the results from cell cultures show it can stimulate osteoblastic cell growth and proliferation. Moreover, gallic acid, a phenolic compound, was successfully introduced onto the MAO coating by grafting on hydrated oxide and chelating with magnesium ions. The gallic acid and rough surface of MAO altered the cell attachment behavior, making it difficult for fibroblasts to adhere to the MAO coating. The viability tests showed that gallic acid could suppress fibroblast growth and stimulate osteoblastic cell proliferation. Overall, the porous MAO coating combined with gallic acid offered a novel strategy for increasing osteocompatibility. Full article
Figures

Figure 1

Open AccessFeature PaperArticle Flower-Like CuO/ZnO Hybrid Hierarchical Nanostructures Grown on Copper Substrate: Glycothermal Synthesis, Characterization, Hydrophobic and Anticorrosion Properties
Materials 2017, 10(7), 697; doi:10.3390/ma10070697
Received: 12 May 2017 / Revised: 28 May 2017 / Accepted: 21 June 2017 / Published: 25 June 2017
Cited by 1 | PDF Full-text (5448 KB) | HTML Full-text | XML Full-text
Abstract
In this work we have demonstrated a facile formation of CuO nanostructures on copper substrates by the oxidation of copper foil in ethylene glycol (EG) at 80 °C. On immersing a prepared CuO film into a solution containing 0.1 g Zn(acac)2 in
[...] Read more.
In this work we have demonstrated a facile formation of CuO nanostructures on copper substrates by the oxidation of copper foil in ethylene glycol (EG) at 80 °C. On immersing a prepared CuO film into a solution containing 0.1 g Zn(acac)2 in 20 mL EG for 8 h, ZnO flower-like microstructures composed of hierarchical three-dimensional (3D) aggregated nanoparticles and spherical architectures were spontaneously formed at 100 °C. The as-synthesized thin films and 3D microstructures were characterized using XRD, SEM, and EDS techniques. The effects of sodium dodecyl sulphate (SDS), cetyltrimethylammonium bromide (CTAB), and polyethylene glycol (PEG) 6000 as surfactants and stabilizers on the morphology of the CuO and ZnO structures were discussed. Possible growth mechanisms for the controlled organization of primary building units into CuO nanostructures and 3D flower-like ZnO architectures were proposed. The hydrophobic property of the products was characterized by means of water contact angle measurement. After simple surface modification with stearic acid and PDMS, the resulting films showed hydrophobic and even superhydrophobic characteristics due to their special surface energy and nano-microstructure morphology. Importantly, stable superhydrophobicity with a contact angle of 153.5° was successfully observed for CuO-ZnO microflowers after modification with PDMS. The electrochemical impedance measurements proved that the anticorrosion efficiency for the CuO/ZnO/PDMS sample was about 99%. Full article
(This article belongs to the Special Issue Zinc Oxide Nanostructures: Synthesis and Characterization)
Figures

Open AccessArticle A Combined High and Low Cycle Fatigue Model for Life Prediction of Turbine Blades
Materials 2017, 10(7), 698; doi:10.3390/ma10070698
Received: 2 May 2017 / Revised: 16 June 2017 / Accepted: 22 June 2017 / Published: 26 June 2017
Cited by 1 | PDF Full-text (4745 KB) | HTML Full-text | XML Full-text
Abstract
Combined high and low cycle fatigue (CCF) generally induces the failure of aircraft gas turbine attachments. Based on the aero-engine load spectrum, accurate assessment of fatigue damage due to the interaction of high cycle fatigue (HCF) resulting from high frequency vibrations and low
[...] Read more.
Combined high and low cycle fatigue (CCF) generally induces the failure of aircraft gas turbine attachments. Based on the aero-engine load spectrum, accurate assessment of fatigue damage due to the interaction of high cycle fatigue (HCF) resulting from high frequency vibrations and low cycle fatigue (LCF) from ground-air-ground engine cycles is of critical importance for ensuring structural integrity of engine components, like turbine blades. In this paper, the influence of combined damage accumulation on the expected CCF life are investigated for turbine blades. The CCF behavior of a turbine blade is usually studied by testing with four load-controlled parameters, including high cycle stress amplitude and frequency, and low cycle stress amplitude and frequency. According to this, a new damage accumulation model is proposed based on Miner’s rule to consider the coupled damage due to HCF-LCF interaction by introducing the four load parameters. Five experimental datasets of turbine blade alloys and turbine blades were introduced for model validation and comparison between the proposed Miner, Manson-Halford, and Trufyakov-Kovalchuk models. Results show that the proposed model provides more accurate predictions than others with lower mean and standard deviation values of model prediction errors. Full article
(This article belongs to the Special Issue The Life of Materials at High Temperatures)
Figures

Figure 1

Open AccessArticle Tunable Multiple Plasmon-Induced Transparencies Based on Asymmetrical Grapheme Nanoribbon Structures
Materials 2017, 10(7), 699; doi:10.3390/ma10070699
Received: 10 May 2017 / Revised: 21 June 2017 / Accepted: 23 June 2017 / Published: 26 June 2017
PDF Full-text (3326 KB) | HTML Full-text | XML Full-text
Abstract
We present plasmonic devices, consisting of periodic arrays of graphene nanoribbons (GNRs) and a graphene sheet waveguide, to achieve controllable plasmon-induced transparency (PIT) by numerical simulation. We analyze the bright and dark elements of the GNRs and graphene-sheet waveguide structure. Results show that
[...] Read more.
We present plasmonic devices, consisting of periodic arrays of graphene nanoribbons (GNRs) and a graphene sheet waveguide, to achieve controllable plasmon-induced transparency (PIT) by numerical simulation. We analyze the bright and dark elements of the GNRs and graphene-sheet waveguide structure. Results show that applying the gate voltage can electrically tune the PIT spectrum. Adjusting the coupling distance and widths of GNRs directly results in a shift of transmission dips. In addition, increased angle of incidence causes the transmission to split into multiple PIT peaks. We also demonstrate that PIT devices based on graphene plasmonics may have promising applications as plasmonic sensors in nanophotonics. Full article
(This article belongs to the Special Issue Advances in Transparent Conducting Materials)
Figures

Figure 1

Open AccessArticle Electrical and Optical Characterization of Sputtered Silicon Dioxide, Indium Tin Oxide, and Silicon Dioxide/Indium Tin Oxide Antireflection Coating on Single-Junction GaAs Solar Cells
Materials 2017, 10(7), 700; doi:10.3390/ma10070700
Received: 31 May 2017 / Revised: 22 June 2017 / Accepted: 23 June 2017 / Published: 26 June 2017
PDF Full-text (3379 KB) | HTML Full-text | XML Full-text
Abstract
This study characterized the electrical and optical properties of single-junction GaAs solar cells coated with antireflective layers of silicon dioxide (SiO2), indium tin oxide (ITO), and a hybrid layer of SiO2/ITO applied using Radio frequency (RF) sputtering. The conductivity
[...] Read more.
This study characterized the electrical and optical properties of single-junction GaAs solar cells coated with antireflective layers of silicon dioxide (SiO2), indium tin oxide (ITO), and a hybrid layer of SiO2/ITO applied using Radio frequency (RF) sputtering. The conductivity and transparency of the ITO film were characterized prior to application on GaAs cells. Reverse saturation-current and ideality factor were used to evaluate the passivation performance of the various coatings on GaAs solar cells. Optical reflectance and external quantum efficiency response were used to evaluate the antireflective performance of the coatings. Photovoltaic current-voltage measurements were used to confirm the efficiency enhancement obtained by the presence of the anti-reflective coatings. The conversion efficiency of the GaAs cells with an ITO antireflective coating (23.52%) exceeded that of cells with a SiO2 antireflective coating (21.92%). Due to lower series resistance and higher short-circuit current-density, the carrier collection of the GaAs cell with ITO coating exceeded that of the cell with a SiO2/ITO coating. Full article
(This article belongs to the Special Issue Selected Papers from IEEE ICASI 2017)
Figures

Figure 1

Open AccessArticle Microstructural Analysis and Wear Performance of Carbon-Fiber-Reinforced SiC Composite for Brake Pads
Materials 2017, 10(7), 701; doi:10.3390/ma10070701
Received: 16 May 2017 / Revised: 14 June 2017 / Accepted: 21 June 2017 / Published: 26 June 2017
PDF Full-text (6438 KB) | HTML Full-text | XML Full-text
Abstract
Carbon-fiber-reinforced silicon carbide (C/C-SiC) composite is widely used as a friction material owing to its good performance, even though it is more expensive than metallic materials. The light C/C-SiC composite is an ideal candidate for weight reduction of frictional parts. In this study,
[...] Read more.
Carbon-fiber-reinforced silicon carbide (C/C-SiC) composite is widely used as a friction material owing to its good performance, even though it is more expensive than metallic materials. The light C/C-SiC composite is an ideal candidate for weight reduction of frictional parts. In this study, the friction and wear behavior of C/C-SiC composite was assessed using a ball-on-disk friction tester under dry reciprocating sliding conditions at different temperatures of 25, 100, and 200 °C. The disk specimens were made of C/C-SiC composite, while the mating counterpart pins were made of bearing steel. The microstructure and wear track of the specimens were characterized using a scanning electron microscopy (SEM) and Raman spectroscopy. The microstructural analysis of the wear track revealed that the wear mechanism was abrasive. The friction coefficient and wear behavior of the specimens was dependent on the temperature, where the friction coefficients and wear rate increased with increasing temperature. Full article
(This article belongs to the Special Issue Tribological Behavior of Materials by Surface Engineering)
Figures

Figure 1

Open AccessArticle High Mobility Thin Film Transistors Based on Amorphous Indium Zinc Tin Oxide
Materials 2017, 10(7), 702; doi:10.3390/ma10070702
Received: 2 May 2017 / Revised: 21 June 2017 / Accepted: 21 June 2017 / Published: 26 June 2017
Cited by 1 | PDF Full-text (2256 KB) | HTML Full-text | XML Full-text
Abstract
Top-contact bottom-gate thin film transistors (TFTs) with zinc-rich indium zinc tin oxide (IZTO) active layer were prepared at room temperature by radio frequency magnetron sputtering. Sintered ceramic target was prepared and used for deposition from oxide powder mixture having the molar ratio of
[...] Read more.
Top-contact bottom-gate thin film transistors (TFTs) with zinc-rich indium zinc tin oxide (IZTO) active layer were prepared at room temperature by radio frequency magnetron sputtering. Sintered ceramic target was prepared and used for deposition from oxide powder mixture having the molar ratio of In2O3:ZnO:SnO2 = 2:5:1. Annealing treatment was carried out for as-deposited films at various temperatures to investigate its effect on TFT performances. It was found that annealing treatment at 350 °C for 30 min in air atmosphere yielded the best result, with the high field effect mobility value of 34 cm2/Vs and the minimum subthreshold swing value of 0.12 V/dec. All IZTO thin films were amorphous, even after annealing treatment of up to 350 °C. Full article
Figures

Figure 1

Open AccessArticle Comparative Study on ZnO Monolayer Doped with Al, Ga and In Atoms as Transparent Electrodes
Materials 2017, 10(7), 703; doi:10.3390/ma10070703
Received: 12 May 2017 / Revised: 21 June 2017 / Accepted: 22 June 2017 / Published: 26 June 2017
PDF Full-text (3927 KB) | HTML Full-text | XML Full-text
Abstract
Transparent anodes are indispensable components for optoelectronic devices. Two-dimensional (2D) materials are attracting increasing research interest due to their unique properties and promising applications. In order to design novel transparent anodes, we investigated the electronic, optical, and electrical properties of 2D ZnO monolayers
[...] Read more.
Transparent anodes are indispensable components for optoelectronic devices. Two-dimensional (2D) materials are attracting increasing research interest due to their unique properties and promising applications. In order to design novel transparent anodes, we investigated the electronic, optical, and electrical properties of 2D ZnO monolayers doped with Al, Ga, and In using the first-principles calculation in combination with the Boltzmann transport theory. When the doping concentration of Al, Ga, and In is less than 12.5 wt %, we find that the average transmittance reaches up to 99% in the visible and UV regions. Moreover, the electrical conductivity is enhanced for the Al, Ga, and In doped systems compared to that of the pristine ZnO monolayer. In particular, a good electrical conductivity with a significant improvement for the In doped ZnO monolayer is achieved compared to Al and Ga doping at the 6.25 wt % level. These results suggest that the ZnO monolayer based materials, and in particular the In doped ZnO monolayer, are promising transparent anodes for nanoscale electronic and optoelectronic applications. Full article
(This article belongs to the Special Issue Advances in Transparent Conducting Materials)
Figures

Figure 1

Open AccessArticle Effects of Cold-Rolling/Aging Treatments on the Shape Memory Properties of Ti49.3Ni50.7 Shape Memory Alloy
Materials 2017, 10(7), 704; doi:10.3390/ma10070704
Received: 3 May 2017 / Revised: 14 June 2017 / Accepted: 20 June 2017 / Published: 26 June 2017
PDF Full-text (2511 KB) | HTML Full-text | XML Full-text
Abstract
In this study, the combined effects of strengthening, precipitates, and textures on the shape recovery ability and superelasticity of thermomechanically treated Ti49.3Ni50.7 shape memory alloy (SMA) in both the rolling and transverse directions were studied by experimental measurements and theoretical calculations. Experimental results
[...] Read more.
In this study, the combined effects of strengthening, precipitates, and textures on the shape recovery ability and superelasticity of thermomechanically treated Ti49.3Ni50.7 shape memory alloy (SMA) in both the rolling and transverse directions were studied by experimental measurements and theoretical calculations. Experimental results and theoretical calculations showed that the 300 °C × 100 h aged specimen exhibited the best shape memory effect because it possessed the most favorable textures, highest matrix strength, and most beneficially coherent stress induced by Ti3Ni4 precipitates. The 30% cold-rolled and then 300 °C × 100 h aged specimen exhibited the highest strength and superelasticity; however, its shape recovery ability was not as good as expected because the less favorable textures and the high strength inhibited the movements of dislocations and martensite boundaries. Therefore, to achieve the most optimal shape memory characteristics of Ni-rich TiNi SMAs, the effects of textures, matrix strength, and internal defects, such as Ti3Ni4 precipitates and dislocations, should all be carefully considered and controlled during thermomechanical treatments. Full article
Figures

Figure 1

Open AccessArticle Reuse of Pillaring Agent in Sequential Bentonite Pillaring Processes
Materials 2017, 10(7), 705; doi:10.3390/ma10070705
Received: 27 April 2017 / Revised: 29 May 2017 / Accepted: 30 May 2017 / Published: 27 June 2017
PDF Full-text (2018 KB) | HTML Full-text | XML Full-text
Abstract
This work describes the synthesis and characterization of pillared clays using a new pillaring method: the reuse of the pillaring solution. First, an Al pillared clay (PILC) was synthesized, and after filtration, the pillaring agent was stored and reused for an additional three
[...] Read more.
This work describes the synthesis and characterization of pillared clays using a new pillaring method: the reuse of the pillaring solution. First, an Al pillared clay (PILC) was synthesized, and after filtration, the pillaring agent was stored and reused for an additional three pillaring procedures (P1, P2, and P3). The filtered pillaring solution was stored for one year and then reused for one additional pillaring procedure (P4). The samples were analyzed using XRD, N2 physisorption measurements and chemical analysis (EDX). All of the samples exhibited basal spacings larger than 17 Å and BET surface areas greater than 160 m2/g. After the P4 pillaring, the pillaring agent was precipitated with a Na2SO4 solution, and the resulting solid was analyzed using XRD and SEM. The results indicated that even after a total of five pillaring procedures, Al13 ions were still present in solution. Therefore, it is possible to reuse the pillaring solution four times and to even store the solution for one year, which is important from an industrial perspective. Full article
Figures

Open AccessArticle Controlling Morphology and Aggregation in Semiconducting Polymers: The Role of Solvents on Lasing Emission in Poly[2-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene-vinylene]
Materials 2017, 10(7), 706; doi:10.3390/ma10070706
Received: 22 May 2017 / Revised: 13 June 2017 / Accepted: 23 June 2017 / Published: 29 June 2017
PDF Full-text (6934 KB) | HTML Full-text | XML Full-text
Abstract
Systematic experiments were performed to investigate solvent-dependent morphology and aggregation of the semiconducting polymer film poly[2-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene-vinylene] (MEH-PPV), which was span-cast from nonaromatic strong polarity solvents tetrahydrofuran (THF), trichloromethane (TCM) and aromatic weak polarity solvents chlorobenzene (CB), toluene, and p-xylene. The results indicated that
[...] Read more.
Systematic experiments were performed to investigate solvent-dependent morphology and aggregation of the semiconducting polymer film poly[2-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene-vinylene] (MEH-PPV), which was span-cast from nonaromatic strong polarity solvents tetrahydrofuran (THF), trichloromethane (TCM) and aromatic weak polarity solvents chlorobenzene (CB), toluene, and p-xylene. The results indicated that the conformation of the spin-cast MEH-PPV films with weak aggregation such as THF and TCM demonstrated excellent lasing emission performances because of inhibiting the fluorescence quenching induced by bi-molecule process. The Atomic Force Microscope (AFM) images confirmed the distinct morphologies of the spin-cast MEH-PPV films. The amplified spontaneous emission (ASE) was investigated in a simple asymmetric slab planar waveguide structure by methods of variable stripe length (VSL) and shifting excitation stripe (SES). The amplified spontaneous emission (ASE) experiments confirmed the distinct polymer chain conformation. The conformation, which preserved from the spin-cast process, indicated the distinct interactions between solvents and MEH-PPV polymer chains. The pure film spectra were performed to confirm the effect of distinct conformation on the material energy level. This work provides insights into the morphology and aggregation effect of the spin-cast polymer films on the performances of lasers. Full article
Figures

Open AccessArticle Experimental Investigations on the Pull-Out Behavior of Tire Strips Reinforced Sands
Materials 2017, 10(7), 707; doi:10.3390/ma10070707
Received: 17 April 2017 / Revised: 19 June 2017 / Accepted: 22 June 2017 / Published: 27 June 2017
PDF Full-text (3516 KB) | HTML Full-text | XML Full-text
Abstract
Waste tires have excellent mechanical performance and have been used as reinforcing material in geotechnical engineering; however, their interface properties are poorly understood. To further our knowledge, this paper examines the pull-out characteristics of waste tire strips in a compacted sand, together with
[...] Read more.
Waste tires have excellent mechanical performance and have been used as reinforcing material in geotechnical engineering; however, their interface properties are poorly understood. To further our knowledge, this paper examines the pull-out characteristics of waste tire strips in a compacted sand, together with uniaxial and biaxial geogrids also tested under the same conditions. The analysis of the results shows that the interlocking effect and pull-out resistance between the tire strip and the sand is very strong and significantly higher than that of the geogrids. In the early stages of the pull-out test, the resistance is mainly provided by the front portion of the embedded tire strips, as the pull-out test continues, more and more of the areas towards the end of the tire strips are mobilized, showing a progressive failure mechanism. The deformations are proportional to the frictional resistance between the tire-sand interface, and increase as the normal stresses increase. Tire strips of different wear intensities were tested and presented different pull-out resistances; however, the pull-out resistance mobilization patterns were generally similar. The pull-out resistance values obtained show that rubber reinforcement can provide much higher pull-out forces than the geogrid reinforcements tested here, showing that waste tires are an excellent alternative as a reinforcing system, regardless of the environmental advantages. Full article
(This article belongs to the Special Issue Geosynthetics in Civil and Environmental Engineering)
Figures

Figure 1

Open AccessArticle Influence of Equal Channel Angular Pressing Passes on the Microstructures and Tensile Properties of Mg-8Sn-6Zn-2Al Alloy
Materials 2017, 10(7), 708; doi:10.3390/ma10070708
Received: 5 May 2017 / Revised: 20 June 2017 / Accepted: 23 June 2017 / Published: 27 June 2017
PDF Full-text (10079 KB) | HTML Full-text | XML Full-text
Abstract
An I-phase containing Mg-8Sn-6Zn-2Al (wt %; TZA862) alloy was fabricated and subjected to different number of passes of equal channel angular pressing (ECAP) processing at 300 °C. The results showed that the alloys exhibited a bimodal microstructure, which consisted of fine dynamically recrystallized
[...] Read more.
An I-phase containing Mg-8Sn-6Zn-2Al (wt %; TZA862) alloy was fabricated and subjected to different number of passes of equal channel angular pressing (ECAP) processing at 300 °C. The results showed that the alloys exhibited a bimodal microstructure, which consisted of fine dynamically recrystallized (DRX) grains and coarse non-DRX grains. When increasing the number of ECAP passes from 2 to 6, the fraction of DRX grains and the dispersed second phase particles subsequently increase. However, the fraction and particles then decrease once the number of ECAP passes increases to 8. After 6 ECAP passes, remarkable grain refinement was achieved and increasing the number of passes to 8 cannot further refine the microstructure. Furthermore, the alloys having undergone ECAP exhibited a strong ED-tilted texture, the intensity of which increased with an increase in the number of ECAP passes. The ultimate tensile strength (UTS; 338 MPa) and elongation (El.; 14.2%) of the alloy processed with 6 ECAP passes were considerably higher compared to those of the other materials that had undergone ECAP. These significant enhancements were attributed to extensive grain boundary strengthening, precipitation strengthening and a higher work-hardening capacity. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Open AccessFeature PaperArticle Improving the Flame Retardant Efficiency of Layer by Layer Coatings Containing Deoxyribonucleic Acid by Post-Diffusion of Hydrotalcite Nanoparticles
Materials 2017, 10(7), 709; doi:10.3390/ma10070709
Received: 29 April 2017 / Revised: 18 June 2017 / Accepted: 23 June 2017 / Published: 27 June 2017
Cited by 1 | PDF Full-text (5957 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
This work deals with the use of hydrotalcite nanoparticle post-diffusion in layer by layer (LbL) coatings with the aim of improving their flame retardant action on cotton. The selected LbL components, which encompass polydiallyldimethylammonium chloride and deoxyribonucleic acid, aim at the deposition of
[...] Read more.
This work deals with the use of hydrotalcite nanoparticle post-diffusion in layer by layer (LbL) coatings with the aim of improving their flame retardant action on cotton. The selected LbL components, which encompass polydiallyldimethylammonium chloride and deoxyribonucleic acid, aim at the deposition of an intumescent coating. Infrared spectra pointed out a super-linear growth of the investigated assembly, indicating the ability to deposit thick coatings while maintaining a relatively low deposition number. A post-diffusion process, performed by exposing the LbL-treated fabrics to two different concentrations of hydrotalcite water suspensions (0.1 or 1 wt %), was carried out to improve the fireproofing efficiency of these coatings. Coatings treated with the lowest concentration suspension partially swelled as a consequence of their structural rearrangements while the use of the highest concentration led to nanoparticle aggregates. Horizontal flame spread tests were used for assessing the achieved flame retardant properties. The post-diffusion performed at the lowest hydrotalcite concentration lowers the minimum number of Bi-Layers required for obtaining cotton self-extinguishment while samples treated with the highest concentration showed detrimental effects on the performances of treated fabrics. This behavior is ascribed to the effects of hydrotalcite particles on the intumescence of LbL coatings, as evidenced by the morphological analyses of post-combustion residues. Full article
(This article belongs to the Special Issue Flame Retardant Polymeric Materials)
Figures

Figure 1

Open AccessArticle Effect of Core-shell Ceria/Poly(Vinylpyrrolidone) (PVP) Nanoparticles Incorporated in Polymer Films and Their Optical Properties (2): Increasing the Refractive Index
Materials 2017, 10(7), 710; doi:10.3390/ma10070710
Received: 1 May 2017 / Revised: 2 June 2017 / Accepted: 23 June 2017 / Published: 27 June 2017
PDF Full-text (7261 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
We investigated the preparation of well-dispersed core-shell ceria-poly(vinylpyrrolidone) (PVP) nanoparticles with an average particle size of around 20 nm which were used to produce a hybrid film with a polymer coating of dipentaerythritol hexaacrylate (DPHA). We obtained good dispersion of the nanoparticles in
[...] Read more.
We investigated the preparation of well-dispersed core-shell ceria-poly(vinylpyrrolidone) (PVP) nanoparticles with an average particle size of around 20 nm which were used to produce a hybrid film with a polymer coating of dipentaerythritol hexaacrylate (DPHA). We obtained good dispersion of the nanoparticles in a mixed solvent of 48% 1-methoxy-2-propanol (MP), 32% 3-methoxy-3-methyl-1-butanol (MMB), and 20% methyl i-butyl ketone (MIBK). An ink of the polymer coating consisting of 68.7 wt% nanoparticles and 31.3 wt% DPHA with a polymerization initiator was prepared using this solvent mixture. The surface of the hybrid film showed low roughness and the nanoparticles formed a densely packed structure in the DPHA matrix. The resulting coating possessed excellent transparency and a high refractive index of 1.69. Full article
(This article belongs to the Section Advanced Composites)
Figures

Figure 1

Open AccessArticle Effect of Applied Stress on the Mechanical Properties of a Zr-Cu-Ag-Al Bulk Metallic Glass with Two Different Structure States
Materials 2017, 10(7), 711; doi:10.3390/ma10070711
Received: 5 June 2017 / Revised: 16 June 2017 / Accepted: 21 June 2017 / Published: 27 June 2017
PDF Full-text (3989 KB) | HTML Full-text | XML Full-text
Abstract
In order to investigate the effect of applied stress on mechanical properties in metallic glasses, nanoindentation tests were conducted on elastically bent Zr-Cu-Ag-Al metallic glasses with two different structure states. From spherical P-h curves, elastic modulus was found to be independent on applied
[...] Read more.
In order to investigate the effect of applied stress on mechanical properties in metallic glasses, nanoindentation tests were conducted on elastically bent Zr-Cu-Ag-Al metallic glasses with two different structure states. From spherical P-h curves, elastic modulus was found to be independent on applied stress. Hardness decreased by ~8% and ~14% with the application of 1.5% tensile strain for as-cast and 650 K annealed specimens, while it was slightly increased at the compressive side. Yield stress could be obtained from the contact pressure at first pop-in position with a conversion coefficient. The experimental result showed a symmetrical effect of applied stress on strengthening and a reduction of the contact pressure at compressive and tensile sides. It was observed that the applied stress plays a negligible effect on creep deformation in as-cast specimen. While for the annealed specimen, creep deformation was facilitated by applied tensile stress and suppressed by applied compressive stress. Strain rate sensitivities (SRS) were calculated from steady-state creep, which were constant for as-cast specimen and strongly correlated with applied stress for the annealed one. The more pronounced effect of applied stress in the 650 K annealed metallic glass could be qualitatively explained through the variation of the shear transformation zone (STZ) size. Full article
(This article belongs to the Special Issue Advanced Nanoindentation in Materials)
Figures

Figure 1

Open AccessArticle Scale Up Pillaring: A Study of the Parameters That Influence the Process
Materials 2017, 10(7), 712; doi:10.3390/ma10070712
Received: 28 April 2017 / Revised: 14 June 2017 / Accepted: 14 June 2017 / Published: 27 June 2017
PDF Full-text (968 KB) | HTML Full-text | XML Full-text
Abstract
Pillared clays (PILCs) are interesting materials mostly due to their high basal spacing and surface area, which make them suitable for adsorption and catalysis applications, for example. However, the production of these materials on industrial scale is dependent on research about what parameters
[...] Read more.
Pillared clays (PILCs) are interesting materials mostly due to their high basal spacing and surface area, which make them suitable for adsorption and catalysis applications, for example. However, the production of these materials on industrial scale is dependent on research about what parameters influence the process. Thus, the objective of this work was to evaluate what parameters influence the pillaring procedure. For this, pillared clays were synthesized following three series of experiments. In the first series, the effect of the amount of water in a clay suspension was evaluated. The best results were obtained by using diluted suspensions (1 g of clay to 100 mL of water). In the second series, several pillaring methods were tested. In the third series, the amount of pillared clay was raised to 50 g. Fifty grams of pillared clay can be obtained using the pillaring agent synthesized at 60 °C with further aging for 24 h, and this material exhibited high basal spacing (17.6 Å) and surface area (233 m2/g). These values are comparable with the traditional pillaring method using only 3 g of clay. Full article
Figures

Open AccessArticle Effect of Ultrasonic Nano-Crystal Surface Modification (UNSM) on the Passivation Behavior of Aged 316L Stainless Steel
Materials 2017, 10(7), 713; doi:10.3390/ma10070713
Received: 30 May 2017 / Revised: 20 June 2017 / Accepted: 21 June 2017 / Published: 27 June 2017
PDF Full-text (12017 KB) | HTML Full-text | XML Full-text
Abstract
Stainless steels have good corrosion resistance in many environments but welding or aging can decrease their resistance. This work focused on the effect of aging time and ultrasonic nano-crystal surface modification on the passivation behavior of 316L stainless steel. In the case of
[...] Read more.
Stainless steels have good corrosion resistance in many environments but welding or aging can decrease their resistance. This work focused on the effect of aging time and ultrasonic nano-crystal surface modification on the passivation behavior of 316L stainless steel. In the case of slightly sensitized 316L stainless steel, increasing the aging time drastically decreased the pitting potential, increased the passive current density, and decreased the resistance of the passive film, even though aging did not form chromium carbide and a chromium depletion zone. This behavior is due to the micro-galvanic corrosion between the matrix and carbon segregated area, and this shows the importance of carbon segregation in grain boundaries to the pitting corrosion resistance of stainless steel, in addition to the formation of the chromium depletion zone. UNSM (Ultrasonic Nano Crystal Surface Modification)-treatment to the slightly sensitized 316L stainless steel increased the pitting potential, decreased the passive current density, and increased the resistance of the passive film. However, in the case of heavily sensitized 316L stainless steel, UNSM-treatment decreased the pitting potential, increased the passive current density, and decreased the resistance of the passive film. This behavior is due to the dual effects of the UNSM-treatment. That is, the UNSM-treatment reduced the carbon segregation, regardless of whether the stainless steel 316L was slightly or heavily sensitized. However, since this treatment made mechanical flaws in the outer surface in the case of the heavily sensitized stainless steel, UNSM-treatment may eliminate chromium carbide, and this flaw can be a pitting initiation site, and therefore decrease the pitting corrosion resistance. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1

Open AccessFeature PaperArticle Estimation of Articular Cartilage Surface Roughness Using Gray-Level Co-Occurrence Matrix of Laser Speckle Image
Materials 2017, 10(7), 714; doi:10.3390/ma10070714
Received: 10 June 2017 / Revised: 26 June 2017 / Accepted: 26 June 2017 / Published: 28 June 2017
PDF Full-text (4493 KB) | HTML Full-text | XML Full-text
Abstract
The application of He-Ne laser technologies for description of articular cartilage degeneration, one of the most common diseases worldwide, is an innovative usage of these technologies used primarily in material engineering. Plain radiography and magnetic resonance imaging are insufficient to allow the early
[...] Read more.
The application of He-Ne laser technologies for description of articular cartilage degeneration, one of the most common diseases worldwide, is an innovative usage of these technologies used primarily in material engineering. Plain radiography and magnetic resonance imaging are insufficient to allow the early assessment of the disease. As surface roughness of articular cartilage is an important indicator of articular cartilage degeneration progress, a safe and noncontact technique based on laser speckle image to estimate the surface roughness is provided. This speckle image from the articular cartilage surface, when illuminated by laser beam, gives very important information about the physical properties of the surface. An experimental setup using a low power He-Ne laser and a high-resolution digital camera was implemented to obtain speckle images of ten bovine articular cartilage specimens prepared for different average roughness values. Texture analysis method based on gray-level co-occurrence matrix (GLCM) analyzed on the captured speckle images is used to characterize the surface roughness of the specimens depending on the computation of Haralick’s texture features. In conclusion, this promising method can accurately estimate the surface roughness of articular cartilage even for early signs of degeneration. The method is effective for estimation of average surface roughness values ranging from 0.09 µm to 2.51 µm with an accuracy of 0.03 µm. Full article
(This article belongs to the Special Issue Laser in Nanotechnology and Biomedical Applications)
Figures

Figure 1

Open AccessArticle Studies on Mathematical Models of Wet Adhesion and Lifetime Prediction of Organic Coating/Steel by Grey System Theory
Materials 2017, 10(7), 715; doi:10.3390/ma10070715
Received: 4 June 2017 / Revised: 22 June 2017 / Accepted: 26 June 2017 / Published: 28 June 2017
PDF Full-text (4700 KB) | HTML Full-text | XML Full-text
Abstract
A rapid degradation of wet adhesion is the key factor controlling coating lifetime, for the organic coatings under marine hydrostatic pressure. The mathematical models of wet adhesion have been studied by Grey System Theory (GST). Grey models (GM) (1, 1) of epoxy varnish
[...] Read more.
A rapid degradation of wet adhesion is the key factor controlling coating lifetime, for the organic coatings under marine hydrostatic pressure. The mathematical models of wet adhesion have been studied by Grey System Theory (GST). Grey models (GM) (1, 1) of epoxy varnish (EV) coating/steel and epoxy glass flake (EGF) coating/steel have been established, and a lifetime prediction formula has been proposed on the basis of these models. The precision assessments indicate that the established models are accurate, and the prediction formula is capable of making precise lifetime forecasting of the coatings. Full article
Figures

Figure 1

Open AccessArticle Synthesis of Al2Ca Dispersoids by Powder Metallurgy Using a Mg–Al Alloy and CaO Particles
Materials 2017, 10(7), 716; doi:10.3390/ma10070716
Received: 1 June 2017 / Revised: 21 June 2017 / Accepted: 22 June 2017 / Published: 28 June 2017
PDF Full-text (8044 KB) | HTML Full-text | XML Full-text
Abstract
The elemental mixture of Mg-6 wt %Al-1 wt %Zn-0.3 wt %Mn (AZ61B) alloy powder and CaO particles was consolidated by an equal-channel angular bulk mechanical alloying (ECABMA) process to form a composite precursor. Subsequently, the precursor was subjected to a heat treatment to
[...] Read more.
The elemental mixture of Mg-6 wt %Al-1 wt %Zn-0.3 wt %Mn (AZ61B) alloy powder and CaO particles was consolidated by an equal-channel angular bulk mechanical alloying (ECABMA) process to form a composite precursor. Subsequently, the precursor was subjected to a heat treatment to synthesize fine Al2Ca particles via a solid-state reaction between the Mg–Al matrix and CaO additives. Scanning electron microscopy-energy-dispersive spectroscopy (SEM-EDS) and electron probe micro-analysis on the precursor indicated that 4.7-at % Al atoms formed a supersaturated solid solution in the α-Mg matrix. Transmission electron microscopy-EDS and X-ray diffraction analyses on the AZ61B composite precursor with 10-vol % CaO particles obtained by heat treatment confirmed that CaO additives were thermally decomposed in the Mg–Al alloy, and the solid-soluted Ca atoms diffused along the α-Mg grain boundaries. Al atoms also diffused to the grain boundaries because of attraction to the Ca atoms resulting from a strong reactivity between Al and Ca. As a result, needle-like (Mg,Al)2Ca intermetallics were formed as intermediate precipitates in the initial reaction stage during the heat treatment. Finally, the precipitates were transformed into spherical Al2Ca particles by the substitution of Al atoms for Mg atoms in (Mg,Al)2Ca after a long heat treatment. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Open AccessArticle Magnetic Hysteresis in Nanocomposite Films Consisting of a Ferromagnetic AuCo Alloy and Ultrafine Co Particles
Materials 2017, 10(7), 717; doi:10.3390/ma10070717
Received: 14 June 2017 / Revised: 22 June 2017 / Accepted: 26 June 2017 / Published: 28 June 2017
PDF Full-text (2665 KB) | HTML Full-text | XML Full-text
Abstract
One fundamental requirement in the search for novel magnetic materials is the possibility of predicting and controlling their magnetic anisotropy and hence the overall hysteretic behavior. We have studied the magnetism of Au:Co films (~30 nm thick) with concentration ratios of 2:1, 1:1,
[...] Read more.
One fundamental requirement in the search for novel magnetic materials is the possibility of predicting and controlling their magnetic anisotropy and hence the overall hysteretic behavior. We have studied the magnetism of Au:Co films (~30 nm thick) with concentration ratios of 2:1, 1:1, and 1:2, grown by magnetron sputtering co-deposition on natively oxidized Si substrates. They consist of a AuCo ferromagnetic alloy in which segregated ultrafine Co particles are dispersed (the fractions of Co in the AuCo alloy and of segregated Co increase with decreasing the Au:Co ratio). We have observed an unexpected hysteretic behavior characterized by in-plane anisotropy and crossed branches in the loops measured along the hard magnetization direction. To elucidate this phenomenon, micromagnetic calculations have been performed for a simplified system composed of two exchange-coupled phases: a AuCo matrix surrounding a Co cluster, which represents an aggregate of particles. The hysteretic features are qualitatively well reproduced provided that the two phases have almost orthogonal anisotropy axes. This requirement can be plausibly fulfilled assuming a dominant magnetoelastic character of the anisotropy in both phases. The achieved conclusions expand the fundamental knowledge on nanocomposite magnetic materials, offering general guidelines for tuning the hysteretic properties of future engineered systems. Full article
(This article belongs to the Special Issue Advances in Superconductive and Magnetic Nanomaterials)
Figures

Figure 1

Open AccessArticle A Study on Thermal and Nanomechanical Performance of Cellulose Nanomaterials (CNs)
Materials 2017, 10(7), 718; doi:10.3390/ma10070718
Received: 3 May 2017 / Revised: 11 June 2017 / Accepted: 23 June 2017 / Published: 28 June 2017
Cited by 1 | PDF Full-text (1751 KB) | HTML Full-text | XML Full-text
Abstract
Wood-based cellulose nanomaterials (CNs) (specifically, cellulose nanofibrils (CNFs) and cellulose nanocrystals (CNCs)) are environmentally sourced low-impact materials with remarkable thermal, mechanical, and physical properties. This uniqueness makes them great candidates for creating nanocomposite materials with a wide range of attributes. Investigating the morphological,
[...] Read more.
Wood-based cellulose nanomaterials (CNs) (specifically, cellulose nanofibrils (CNFs) and cellulose nanocrystals (CNCs)) are environmentally sourced low-impact materials with remarkable thermal, mechanical, and physical properties. This uniqueness makes them great candidates for creating nanocomposite materials with a wide range of attributes. Investigating the morphological, thermal, and nanomechanical properties of CNs becomes crucial to intelligent development of novel composite materials. An atomic force microscope equipped with a nanoindenter was used to investigate the compression modulus of CNFs and CNCs using two analytical approaches (denoted as Oliver Pharr (OP) and Fused Silica (FS)). The CNC modulus values (ECNC-FS = 21.1 GPa, ECNC-OP = 28.7 GPa) were statistically larger than those obtained from CNFs (ECNF-FS = 12.4 GPa, ECNF-OP = 15.1 GPa). Additionally, the FS analytical approach provided statistically significant lower estimates. Thermal stability of CNFs and CNCs was investigated using thermogravimetric analysis. Significant differences were found between CNF and CNC onset temperatures (OnsetCNC = 228.2 °C, OnsetCNF = 279.9 °C), decomposition temperatures (DTGACNC = 247.9 °C, DTGACNF = 331.4 °C), and residues (ResidueCNC = 34.4%, ResidueCNF = 22.8%). This research enriches the information on thermal stability and nanomechanical performance of cellulose nanomaterials, and provides increased knowledge on understanding the effect of CNs as a matrix or reinforce in composites. Full article
(This article belongs to the Special Issue Nanocellulose-Based Functional Materials)
Figures

Figure 1

Open AccessArticle Design and Production of Continuously Gradient Macro/Microporous Calcium Phosphate (CaP) Scaffolds Using Ceramic/Camphene-Based 3D Extrusion
Materials 2017, 10(7), 719; doi:10.3390/ma10070719
Received: 24 May 2017 / Revised: 18 June 2017 / Accepted: 24 June 2017 / Published: 28 June 2017
PDF Full-text (3637 KB) | HTML Full-text | XML Full-text
Abstract
This study proposes a new type of calcium phosphate (CaP) scaffolds with a continuously gradient macro/microporous structure using the ceramic/camphene-based 3D extrusion process. Green filaments with a continuously gradient core/shell structure were successfully produced by extruding a bilayered feedrod comprised of a CaP/camphene
[...] Read more.
This study proposes a new type of calcium phosphate (CaP) scaffolds with a continuously gradient macro/microporous structure using the ceramic/camphene-based 3D extrusion process. Green filaments with a continuously gradient core/shell structure were successfully produced by extruding a bilayered feedrod comprised of a CaP/camphene mixture lower part and a pure camphene upper part. The extruded filaments were then deposited in a controlled manner to construct triangular prisms, followed by the assembly process for the production of CaP scaffolds with a gradient core/shell structure. In addition, a gradient microporous structure was created by heat-treating the green body at 43 °C to induce the overgrowth of camphene dendrites in the CaP/camphene walls. The produced CaP scaffold showed a highly macroporous structure within its inner core, where the size of macrochannels increased gradually with an increase in the distance from the outer shell, while relatively larger micropores were created in the outer shell. Full article
(This article belongs to the Section Biomaterials)
Figures

Figure 1

Open AccessArticle Corrosion Behavior of X80 Steel with Coupled Coating Defects under Alternating Current Interference in Alkaline Environment
Materials 2017, 10(7), 720; doi:10.3390/ma10070720
Received: 7 May 2017 / Revised: 19 June 2017 / Accepted: 20 June 2017 / Published: 28 June 2017
PDF Full-text (8056 KB) | HTML Full-text | XML Full-text
Abstract
The corrosion behavior of X80 steel in the presence of coupled coating defects was simulated and studied under the interference of alternating current (AC) in an alkaline environment. The results from electrochemical measurements showed that the electrode potential of the coating defect with
[...] Read more.
The corrosion behavior of X80 steel in the presence of coupled coating defects was simulated and studied under the interference of alternating current (AC) in an alkaline environment. The results from electrochemical measurements showed that the electrode potential of the coating defect with the smaller exposed area was lower than that with the larger area, which indicated that the steel with the smaller coating defect was more prone to corrosion. The result of weight loss tests also showed that the smaller coating defect had induced a higher corrosion rate. However, the corrosion rate of X80 steel at the larger coating defect decreased gradually with the increase of the larger defect area at a constant smaller defect area. The corrosion morphology images showed that the coating defects with smaller areas suffered from more severe pitting corrosion. Full article
Figures

Figure 1

Open AccessArticle Effect of Nanosized NbC Precipitates on Hydrogen Diffusion in X80 Pipeline Steel
Materials 2017, 10(7), 721; doi:10.3390/ma10070721
Received: 7 April 2017 / Revised: 21 June 2017 / Accepted: 21 June 2017 / Published: 28 June 2017
PDF Full-text (5201 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, the effects of dispersed 3~10 nm NbC precipitates on hydrogen diffusion in X80 pipeline steel were investigated by means of high resolution transmission electron microscopy (HRTEM), electrochemical hydrogen permeation, and thermal desorption spectroscopy (TDS). The relationship between hydrogen diffusion and
[...] Read more.
In this paper, the effects of dispersed 3~10 nm NbC precipitates on hydrogen diffusion in X80 pipeline steel were investigated by means of high resolution transmission electron microscopy (HRTEM), electrochemical hydrogen permeation, and thermal desorption spectroscopy (TDS). The relationship between hydrogen diffusion and temperature was determined for Nb-free X80 and 0.055 wt% Nb X80 steel. The temperature dividing reversible and irreversible traps was measured, and the quantity of hydrogen captured by different traps was calculated. Three types of hydrogen trap were designed and applied in the test, and the results revealed that irreversible hydrogen traps formed by nanosized and coherent NbC precipitates markedly hindered hydrogen diffusion, and prolonged breakthrough time in Nb-bearing X80 steel. Full article
Figures

Figure 1

Open AccessArticle A Validation Approach for Quasistatic Numerical/Experimental Indentation Analysis in Soft Materials Using 3D Digital Image Correlation
Materials 2017, 10(7), 722; doi:10.3390/ma10070722
Received: 29 May 2017 / Revised: 20 June 2017 / Accepted: 23 June 2017 / Published: 28 June 2017
PDF Full-text (4684 KB) | HTML Full-text | XML Full-text
Abstract
A quasistatic indentation numerical analysis in a round section specimen made of soft material has been performed and validated with a full field experimental technique, i.e., Digital Image Correlation 3D. The contact experiment specifically consisted of loading a 25 mm diameter rubber cylinder
[...] Read more.
A quasistatic indentation numerical analysis in a round section specimen made of soft material has been performed and validated with a full field experimental technique, i.e., Digital Image Correlation 3D. The contact experiment specifically consisted of loading a 25 mm diameter rubber cylinder of up to a 5 mm indentation and then unloading. Experimental strains fields measured at the surface of the specimen during the experiment were compared with those obtained by performing two numerical analyses employing two different hyperplastic material models. The comparison was performed using an Image Decomposition new methodology that makes a direct comparison of full-field data independently of their scale or orientation possible. Numerical results show a good level of agreement with those measured during the experiments. However, since image decomposition allows for the differences to be quantified, it was observed that one of the adopted material models reproduces lower differences compared to experimental results. Full article
(This article belongs to the Special Issue Advanced Nanoindentation in Materials)
Figures

Open AccessArticle Insight the Luminescence Properties of AlON: Eu, Mg Phosphor under VUV Excitation
Materials 2017, 10(7), 723; doi:10.3390/ma10070723
Received: 27 April 2017 / Revised: 23 June 2017 / Accepted: 26 June 2017 / Published: 29 June 2017
Cited by 1 | PDF Full-text (2549 KB) | HTML Full-text | XML Full-text
Abstract
Owing to high quantum efficiency, adjustable composition and antioxidation properties of oxynitride phosphors, extensive investigations have focused on their photoluminescence properties under low-energy light excitation (UV or blue light). However, the vacuum ultraviolet (VUV) luminescence properties of oxynitride phosphors are rarely researched. Present
[...] Read more.
Owing to high quantum efficiency, adjustable composition and antioxidation properties of oxynitride phosphors, extensive investigations have focused on their photoluminescence properties under low-energy light excitation (UV or blue light). However, the vacuum ultraviolet (VUV) luminescence properties of oxynitride phosphors are rarely researched. Present work studies the structure and VUV luminescence properties of an oxynitride phosphor: AlON: Eu, Mg, which is synthesized by solid-state reaction. Under 147 nm excitation, it was found that AlON: Eu, Mg phosphor shows a blue emission band centered at about 470 nm. The first principle calculation is used to analyze the origin of the VUV absorption. Compared with BaMgAl10O17: Eu2+ phosphor, AlON: Eu, Mg phosphor shows better thermal stability. Full article
(This article belongs to the Special Issue Luminescent Materials 2017)
Figures

Figure 1

Open AccessArticle Characterizing the Conductivity and Enhancing the Piezoresistivity of Carbon Nanotube-Polymeric Thin Films
Materials 2017, 10(7), 724; doi:10.3390/ma10070724
Received: 21 April 2017 / Revised: 22 June 2017 / Accepted: 22 June 2017 / Published: 29 June 2017
PDF Full-text (3301 KB) | HTML Full-text | XML Full-text
Abstract
The concept of lightweight design is widely employed for designing and constructing aerospace structures that can sustain extreme loads while also being fuel-efficient. Popular lightweight materials such as aluminum alloy and fiber-reinforced polymers (FRPs) possess outstanding mechanical properties, but their structural integrity requires
[...] Read more.
The concept of lightweight design is widely employed for designing and constructing aerospace structures that can sustain extreme loads while also being fuel-efficient. Popular lightweight materials such as aluminum alloy and fiber-reinforced polymers (FRPs) possess outstanding mechanical properties, but their structural integrity requires constant assessment to ensure structural safety. Next-generation structural health monitoring systems for aerospace structures should be lightweight and integrated with the structure itself. In this study, a multi-walled carbon nanotube (MWCNT)-based polymer paint was developed to detect distributed damage in lightweight structures. The thin film’s electromechanical properties were characterized via cyclic loading tests. Moreover, the thin film’s bulk conductivity was characterized by finite element modeling. Full article
(This article belongs to the Special Issue Structural Health Monitoring for Aerospace Applications 2017)
Figures

Figure 1

Open AccessArticle In Vitro Degradation of Pure Magnesium―The Effects of Glucose and/or Amino Acid
Materials 2017, 10(7), 725; doi:10.3390/ma10070725
Received: 7 June 2017 / Revised: 25 June 2017 / Accepted: 26 June 2017 / Published: 29 June 2017
PDF Full-text (18032 KB) | HTML Full-text | XML Full-text
Abstract
The influences of glucose and amino acid (L-cysteine) on the degradation of pure magnesium have been investigated using SEM, XRD, Fourier transformed infrared (FTIR), X-ray photoelectron spectroscopy (XPS), polarization and electrochemical impedance spectroscopy and immersion tests. The results demonstrate that both amino acid
[...] Read more.
The influences of glucose and amino acid (L-cysteine) on the degradation of pure magnesium have been investigated using SEM, XRD, Fourier transformed infrared (FTIR), X-ray photoelectron spectroscopy (XPS), polarization and electrochemical impedance spectroscopy and immersion tests. The results demonstrate that both amino acid and glucose inhibit the corrosion of pure magnesium in saline solution, whereas the presence of both amino acid and glucose accelerates the corrosion rate of pure magnesium. This may be due to the formation of -C=N- bonding (a functional group of Schiff bases) between amino acid and glucose, which restricts the formation of the protective Mg(OH)2 precipitates. Full article
(This article belongs to the Section Biomaterials)
Figures

Figure 1

Open AccessArticle Hydrothermal Fabrication of Highly Porous Titanium Bio-Scaffold with a Load-Bearable Property
Materials 2017, 10(7), 726; doi:10.3390/ma10070726
Received: 18 May 2017 / Revised: 12 June 2017 / Accepted: 28 June 2017 / Published: 30 June 2017
PDF Full-text (4618 KB) | HTML Full-text | XML Full-text
Abstract
Porous titanium (P_Ti) is considered as an effective material for bone scaffold to achieve a stiffness reduction. Herein, biomimetic (bio-)scaffolds were made of sintered P_Ti, which used NaCl as the space holder and had it removed via the hydrothermal method. X-ray diffraction results
[...] Read more.
Porous titanium (P_Ti) is considered as an effective material for bone scaffold to achieve a stiffness reduction. Herein, biomimetic (bio-)scaffolds were made of sintered P_Ti, which used NaCl as the space holder and had it removed via the hydrothermal method. X-ray diffraction results showed that the subsequent sintering temperature of 1000 °C was the optimized temperature for preparing P_Ti. The compressive strength of P_Ti was measured using a compression test, which revealed an excellent load-bearing ability of above 70 MPa for that with an addition of 50 wt % NaCl (P_Ti_50). The nano-hardness of P_Ti, tested upon their solid surface, was presumably consistent with the density of pores vis-à-vis the addition of NaCl. Overall, a load-bearable P_Ti with a highly porous structure (e.g., P_Ti_50 with a porosity of 43.91% and a pore size around 340 μm) and considerable compressive strength could be obtained through the current process. Cell proliferation (MTS) and lactate dehydrogenase (LDH) assays showed that all P_Ti samples exhibited high cell affinity and low cell mortality, indicating good biocompatibility. Among them, P_Ti_50 showed relatively good in-cell morphology and viability, and is thus promising as a load-bearable bio-scaffold. Full article
Figures

Figure 1

Open AccessFeature PaperArticle Coordination Driven Capture of Nicotine Inside a Mesoporous MOF
Materials 2017, 10(7), 727; doi:10.3390/ma10070727
Received: 14 June 2017 / Revised: 23 June 2017 / Accepted: 27 June 2017 / Published: 30 June 2017
PDF Full-text (5246 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Metal organic frameworks (MOFs) are a wide class of crystalline porous polymers studied in many fields, ranging from catalysis to gas storage. In the past few years, MOFs have been studied for the encapsulation of organic or organometallic molecules and for the development
[...] Read more.
Metal organic frameworks (MOFs) are a wide class of crystalline porous polymers studied in many fields, ranging from catalysis to gas storage. In the past few years, MOFs have been studied for the encapsulation of organic or organometallic molecules and for the development of potential drug carriers. Here, we report on the study of two structurally-related mesoporous Cu-MOFs, namely PCN-6 and PCN-6′ (PCN stands for Porous Coordination Network), for nicotine trapping. Nicotine is a well-known alkaloid liquid molecule at room temperature, whose crystalline structure is still unknown. In this work, the loading process was monitored by electron ionization mass spectrometry by using a direct insertion probe (DIP-EI/MS), infrared (IR), and ultraviolet/visible (UV/VIS) analysis. Both nuclear magnetic resonance (NMR) spectroscopy and thermogravimetric (TGA) analysis showed evidence that nicotine trapping reaches remarkable uptakes up to 40 wt %. In the case of PCN-6@nicotine, X-ray structural resolution revealed that the guest uptake is triggered by coordination of the pyridine ring of nicotine to the copper nuclei of the paddle-wheel units composing the framework of PCN-6. Full article
(This article belongs to the Special Issue Metal Organic Framework Materials)
Figures

Open AccessFeature PaperArticle 4,2’:6’,4”- and 3,2’:6’,3”-Terpyridines: The Conflict between Well-Defined Vectorial Properties and Serendipity in the Assembly of 1D-, 2D- and 3D-Architectures
Materials 2017, 10(7), 728; doi:10.3390/ma10070728
Received: 12 June 2017 / Revised: 27 June 2017 / Accepted: 28 June 2017 / Published: 30 June 2017
Cited by 1 | PDF Full-text (3428 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
A comparative investigation of the coordination assemblies formed between Co(NCS)2 and two monotopic 4,2’:6’,4’’-terpyridine (4,2’:6’,4”-tpy) ligands or two related ditopic ligands is reported. Crystals were grown by layering MeOH solutions of Co(NCS)2 over a CHCl3 or 1,2-C6H4
[...] Read more.
A comparative investigation of the coordination assemblies formed between Co(NCS)2 and two monotopic 4,2’:6’,4’’-terpyridine (4,2’:6’,4”-tpy) ligands or two related ditopic ligands is reported. Crystals were grown by layering MeOH solutions of Co(NCS)2 over a CHCl3 or 1,2-C6H4Cl2 solution of the respective ligand at room temperature. With 4’-(2-methylpyrimidin-5-yl)-4,2’:6’,4”-terpyridine (6), the 1D-coordination polymer {[Co2(NCS)4(MeOH)4(6)2]∙2MeOH∙8H2O}n assembles with 6 coordinating only through the outer N-donors of the 4,2’:6’,4”-tpy unit; coordination by the MeOH solvent blocks two cobalt coordination sites preventing propagation in a higher-dimensional network. A combination of Co(NCS)2 and 1-(4,2‘:6’,4”-terpyridin-4’-yl)ferrocene (7) leads to {[Co(NCS)2(7)2]∙4CHCl3}n which contains a (4,4) net; the 2D-sheets associate through π-stacking interactions between ferrocenyl and pyridyl units. A 3D-framework is achieved through use of the ditopic ligand 1,4-bis(npropoxy)-2,5-bis(4,2’:6’,4”-terpyridin-4’-yl)benzene (8) which acts as a 4-connecting node in {[Co(NCS)2(8)2].2C6H4Cl2}n; the combination of metal and ligand planar 4-connecting nodes results in a {65.8} cds net. For a comparison with the coordinating abilities of the previously reported 1,4-bis(noctoxy)-2,5-bis(4,2’:6’,4”-terpyridin-4’-yl)benzene (3), a more flexible analogue 9 was prepared. {[Co(NCS)2(9)]∙2CHCl3}n contains a (4,4) net defined by both metal and ligand planar 4-connecting nodes. The noctoxy tails of 9 protrude from each side of the (4,4) net and thread through adjacent sheets; the arene-attached noctoxy chains associate through a combination of van der Waals and C–H...π interactions. Full article
(This article belongs to the Special Issue Metal Organic Framework Materials)
Figures

Open AccessArticle A Parametric Model of the LARCODEMS Heavy Media Separator by Means of Multivariate Adaptive Regression Splines
Materials 2017, 10(7), 729; doi:10.3390/ma10070729
Received: 29 May 2017 / Revised: 28 June 2017 / Accepted: 28 June 2017 / Published: 30 June 2017
PDF Full-text (2199 KB) | HTML Full-text | XML Full-text
Abstract
Modeling of a cylindrical heavy media separator has been conducted in order to predict its optimum operating parameters. As far as it is known by the authors, this is the first application in the literature. The aim of the present research is to
[...] Read more.
Modeling of a cylindrical heavy media separator has been conducted in order to predict its optimum operating parameters. As far as it is known by the authors, this is the first application in the literature. The aim of the present research is to predict the separation efficiency based on the adjustment of the device’s dimensions and media flow rates. A variety of heavy media separators exist that are extensively used to separate particles by density. There is a growing importance in their application in the recycling sector. The cylindrical variety is reported to be the most suited for processing a large range of particle sizes, but optimizing its operating parameters remains to be documented. The multivariate adaptive regression splines methodology has been applied in order to predict the separation efficiencies using, as inputs, the device dimension and media flow rate variables. The results obtained show that it is possible to predict the device separation efficiency according to laboratory experiments performed and, therefore, forecast results obtainable with different operating conditions. Full article
Figures

Figure 1

Open AccessArticle The Influence of Lath, Block and Prior Austenite Grain (PAG) Size on the Tensile, Creep and Fatigue Properties of Novel Maraging Steel
Materials 2017, 10(7), 730; doi:10.3390/ma10070730
Received: 7 June 2017 / Revised: 21 June 2017 / Accepted: 26 June 2017 / Published: 30 June 2017
PDF Full-text (13804 KB) | HTML Full-text | XML Full-text
Abstract
The influence of martensitic microstructure and prior austenite grain (PAG) size on the mechanical properties of novel maraging steel was studied. This was achieved by looking at two different martensitic structures with PAG sizes of approximately 40 µm and 80 µm, produced by
[...] Read more.
The influence of martensitic microstructure and prior austenite grain (PAG) size on the mechanical properties of novel maraging steel was studied. This was achieved by looking at two different martensitic structures with PAG sizes of approximately 40 µm and 80 µm, produced by hot rolling to different reductions. Two ageing heat-treatments were considered: both heat-treatments consisted of austenisation at 960 °C, then aging at 560 °C for 5 h, but while one was rapidly cooled the other was slow cooled and then extended aged at 480 °C for 64 h. It is shown that for the shorter ageing treatment the smaller PAG size resulted in significant improvements in strength (increase of more than 150 MPa), ductility (four times increase), creep life (almost four times increase in creep life) and fatigue life (almost doubled). Whereas, the extended aged sample showed similar changes in the fatigue life, elongation and hardness it displayed yet showed no difference in tensile strength and creep. These results display the complexity of microstructural contributions to mechanical properties in maraging steels. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Figure 1

Open AccessArticle Improved Gene Transfer with Functionalized Hollow Mesoporous Silica Nanoparticles of Reduced Cytotoxicity
Materials 2017, 10(7), 731; doi:10.3390/ma10070731
Received: 29 March 2017 / Revised: 1 June 2017 / Accepted: 2 June 2017 / Published: 30 June 2017
PDF Full-text (3117 KB) | HTML Full-text | XML Full-text
Abstract
Gene therapy is a promising strategy for treatment of genetically caused diseases. Successful gene delivery requires an efficient carrier to transfer the desired gene into host cells. Recently, mesoporous silica nanoparticles (MSNs) functionalized with 25 kD polyethyleneimine (PEI) were extensively used as gene
[...] Read more.
Gene therapy is a promising strategy for treatment of genetically caused diseases. Successful gene delivery requires an efficient carrier to transfer the desired gene into host cells. Recently, mesoporous silica nanoparticles (MSNs) functionalized with 25 kD polyethyleneimine (PEI) were extensively used as gene delivery carriers. However, 25 kD PEI could significantly reduce the safety of the modified MSNs although it is efficient for intracellular delivery of nucleic acids. In addition, limited drug loading remains a challenge for conventional MSNs drug carriers. Hollow mesoporous silica nanoparticles (HMSNs) with high pore volume, tunable pore size, and excellent biocompatibility are attractive alternatives. To make them more efficient, a less toxic 1.8 kD PEI polymer was used to functionalize the HMSNs which have large pore size (~10 nm) and form PEI-HMSNs. Scanning and transmission electron microscopic images showed that HMSNs were spherical in shape and approximately 270 nm in diameter with uniform hollow nanostructures. The maximum loading capacity of green fluorescent protein labeled DNA (GFP-DNA) in PEI-HMSNs was found to be 37.98 mg/g. The loading capacity of PEI-HMSNs was nearly three-fold higher than those of PEI modified solid nanoparticles, indicating that both hollow and large pores contributed to the increase in DNA adsorption. The transfection of GFP-DNA plasmid loaded in PEI-HMSNs was increased two-fold in comparison to that of 25 kD PEI. MTT assays in Lovo cells showed that the cell viability was more than 85% when the concentration of PEI-HMSNs was 120 µg/mL, whereas the cell viability was less than 20% when the 25 kD PEI was used at the same concentration. These results indicated that PEI-HMSNs could be used as a delivery system for nucleic acids due to good biocompatibility, high gene loading capacity, and enhanced gene transfer efficiency. Full article
(This article belongs to the Special Issue Materials for Drug Delivery and Biomedical Consideration)
Figures

Figure 1

Open AccessArticle Experimental and Computational Studies on the Scattering of an Edge-Guided Wave by a Hidden Crack on a Racecourse Shaped Hole
Materials 2017, 10(7), 732; doi:10.3390/ma10070732
Received: 8 June 2017 / Revised: 26 June 2017 / Accepted: 27 June 2017 / Published: 1 July 2017
PDF Full-text (7251 KB) | HTML Full-text | XML Full-text
Abstract
Reliable and quantitative non-destructive evaluation for small fatigue cracks, in particular those in hard-to-inspect locations, is a challenging problem. Guided waves are advantageous for structural health monitoring due to their slow geometrical decay of amplitude with propagating distance, which is ideal for rapid
[...] Read more.
Reliable and quantitative non-destructive evaluation for small fatigue cracks, in particular those in hard-to-inspect locations, is a challenging problem. Guided waves are advantageous for structural health monitoring due to their slow geometrical decay of amplitude with propagating distance, which is ideal for rapid wide-area inspection. This paper presents a 3D laser vibrometry experimental and finite element analysis of the interaction between an edge-guided wave and a small through-thickness hidden edge crack on a racecourse shaped hole that occurs, in practice, as a fuel vent hole. A piezoelectric transducer is bonded on the straight edge of the hole to generate the incident wave. The excitation signal consists of a 5.5 cycle Hann-windowed tone burst of centre frequency 220 kHz, which is below the cut-off frequency for the first order Lamb wave modes (SH1). Two-dimensional fast Fourier transformation (2D FFT) is applied to the incident and scattered wave field along radial lines emanating from the crack mouth, so as to identify the wave modes and determine their angular variation and amplitude. It is shown experimentally and computationally that mid-plane symmetric edge waves can travel around the hole’s edge to detect a hidden crack. Furthermore, the scattered wave field due to a small crack length, a, (compared to the wavelength λ of the incident wave) is shown to be equivalent to a point source consisting of a particular combination of body-force doublets. It is found that the amplitude of the scattered field increases quadratically as a function of a/λ, whereas the scattered wave pattern is independent of crack length for small cracks a << λ. This study of the forward scattering problem from a known crack size provides a useful guide for the inverse problem of hidden crack detection and sizing. Full article
(This article belongs to the Special Issue Structural Health Monitoring for Aerospace Applications 2017)
Figures

Figure 1

Open AccessFeature PaperArticle In Vivo Damage of the Head-Neck Junction in Hard-on-Hard Total Hip Replacements: Effect of Femoral Head Size, Metal Combination, and 12/14 Taper Design
Materials 2017, 10(7), 733; doi:10.3390/ma10070733
Received: 7 May 2017 / Revised: 24 June 2017 / Accepted: 25 June 2017 / Published: 1 July 2017
PDF Full-text (4915 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Recently, concerns have been raised about the potential effect of head-neck junction damage products at the local and systemic levels. Factors that may affect this damage process have not been fully established yet. This study investigated the possible correlations among head-neck junction damage
[...] Read more.
Recently, concerns have been raised about the potential effect of head-neck junction damage products at the local and systemic levels. Factors that may affect this damage process have not been fully established yet. This study investigated the possible correlations among head-neck junction damage level, implant design, material combination, and patient characteristics. Head-neck junctions of 148 retrieved implants were analysed, including both ceramic-on-ceramic (N = 61) and metal-on-metal (N = 87) bearings. In all cases, the male taper was made of titanium alloy. Damage was evaluated using a four-point scoring system based on damage morphology and extension. Patient age at implantation, implantation time, damage risk factor, and serum ion concentration were considered as independent potential predicting variables. The damage risk factor summarises head-neck design characteristics and junction loading condition. Junction damage correlated with both implantation time and damage factor risk when the head was made of ceramic. A poor correlation was found when the head was made of cobalt alloy. The fretting-corrosion phenomenon seemed mainly mechanically regulated, at least when cobalt alloy components were not involved. When a component was made of cobalt alloy, the role of chemical phenomena increased, likely becoming, over implantation time, the damage driving phenomena of highly stressed junctions. Full article
Figures

Figure 1

Open AccessArticle The Impact of Metal Ion Exposure on the Cellular Behavior of Human Osteoblasts and PBMCs: In Vitro Analyses of Osteolytic Processes
Materials 2017, 10(7), 734; doi:10.3390/ma10070734
Received: 10 May 2017 / Revised: 16 June 2017 / Accepted: 27 June 2017 / Published: 3 July 2017
PDF Full-text (2353 KB) | HTML Full-text | XML Full-text
Abstract
Osteolysis in the periprosthetic tissue can be caused by metallic wear particles and ions that can originate from implant surface corrosion. These products influence cellular behavior and stimulate the expression of proinflammatory cytokines. The purpose of this study was to evaluate the impact
[...] Read more.
Osteolysis in the periprosthetic tissue can be caused by metallic wear particles and ions that can originate from implant surface corrosion. These products influence cellular behavior and stimulate the expression of proinflammatory cytokines. The purpose of this study was to evaluate the impact of CoCr29Mo6 ions on cell survival, differentiation, and cytokine expression in human osteoblasts and peripheral blood mononuclear cells (PBMCs). Thus, we exposed cells with a mixture of 200 µg/L ion solution and determined cell viability and apoptosis/necrosis. Gene expression analyses of osteoblastic and osteoclastic differentiation markers as well as pro-osteolytic mediators (IL-6, IL-8, TNF-α, MCP-1, MMP1, TIMP1) were performed. These markers were also investigated in mixed cultures of adherent and non-adherent PBMCs as well as in co-cultures of human osteoblasts and PBMCs. The ion solution induced necrosis in osteoblasts and PBMCs in single cultures. All examined mediators were highly expressed in the co-culture of osteoblasts and PBMCs whereas in the single cell cultures only IL-6, IL-8, and MMP1 were found to be stimulated. While the applied concentration of the CoCr29Mo6 ion solutions had only marginal effects on human osteoblasts and PBMCs alone, the co-culture may provide a comprehensive model to study osteolytic processes in response to Co and Cr ions. Full article
Figures

Figure 1

Open AccessFeature PaperArticle Improving the Strength of ZTA Foams with Different Strategies: Immersion Infiltration and Recoating
Materials 2017, 10(7), 735; doi:10.3390/ma10070735
Received: 30 May 2017 / Revised: 25 June 2017 / Accepted: 28 June 2017 / Published: 1 July 2017
PDF Full-text (19786 KB) | HTML Full-text | XML Full-text
Abstract
The combination of high strength and toughness, excellent wear resistance and moderate density makes zirconia-toughened alumina (ZTA) a favorable ceramic, and the foam version of it may also exhibit excellent properties. Here, ZTA foams were prepared by the polymer sponge replication method. We
[...] Read more.
The combination of high strength and toughness, excellent wear resistance and moderate density makes zirconia-toughened alumina (ZTA) a favorable ceramic, and the foam version of it may also exhibit excellent properties. Here, ZTA foams were prepared by the polymer sponge replication method. We developed an immersion infiltration approach with simple equipment and operations to fill the hollow struts in as-prepared ZTA foams, and also adopted a multiple recoating method (up to four cycles) to strengthen them. The solid load of the slurry imposed a significant influence on the properties of the ZTA foams. Immersion infiltration gave ZTA foams an improvement of 1.5 MPa in compressive strength to 2.6 MPa at 87% porosity, only resulting in a moderate reduction of porosity (2–3%). The Weibull modulus of the infiltrated foams was in the range of 6–9. The recoating method generated an increase in compression strength to 3.3–11.4 MPa with the reduced porosity of 58–83%. The recoating cycle dependency of porosity and compression strength is nearly linear. The immersion infiltration strategy is comparable to the industrially-established recoating method and can be applied to other reticulated porous ceramics (RPCs). Full article
(This article belongs to the Special Issue Porous Ceramics)
Figures

Figure 1

Open AccessArticle Piezoelectric Ceramics of the (1 − x)Bi0.50Na0.50TiO3xBa0.90Ca0.10TiO3 Lead-Free Solid Solution: Chemical Shift of the Morphotropic Phase Boundary, a Case Study for x = 0.06
Materials 2017, 10(7), 736; doi:10.3390/ma10070736
Received: 18 May 2017 / Revised: 16 June 2017 / Accepted: 26 June 2017 / Published: 1 July 2017
PDF Full-text (13246 KB) | HTML Full-text | XML Full-text
Abstract
Research and development of lead-free piezoelectric materials are still the hottest topics in the field of piezoelectricity. One of the most promising lead-free family of compounds to replace lead zirconate–titanate for actuators is that of Bi0.50Na0.50TiO3 (BNT) based
[...] Read more.
Research and development of lead-free piezoelectric materials are still the hottest topics in the field of piezoelectricity. One of the most promising lead-free family of compounds to replace lead zirconate–titanate for actuators is that of Bi0.50Na0.50TiO3 (BNT) based solid solutions. The pseudo-binary (1 − x)Bi0.50Na0.50TiO3xBa1 − yCayTiO3 system has been proposed for high temperature capacitors and not yet fully explored as piezoelectric material. In this work, the solid solution with x = 0.06 and y = 0.10 was obtained by two different synthesis routes: solid state and Pechini, aiming at using reduced temperatures, both in synthesis (<800 °C) and sintering (<1150 °C), while maintaining appropriated piezoelectric performance. Crystal structure, ceramic grain size, and morphology depend on the synthesis route and were analyzed by X-ray diffraction, together with scanning and transmission electron microscopy. The effects of processing and ceramic microstructure on the structural, dielectric, ferroelectric, and piezoelectric properties were discussed in terms of a shift of the Morphotropic Phase Boundary, chemically induced by the synthesis route. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Figure 1

Open AccessArticle Plasmonic Light Scattering in Textured Silicon Solar Cells with Indium Nanoparticles from Normal to Non-Normal Light Incidence
Materials 2017, 10(7), 737; doi:10.3390/ma10070737
Received: 31 May 2017 / Revised: 27 June 2017 / Accepted: 29 June 2017 / Published: 1 July 2017
PDF Full-text (5915 KB) | HTML Full-text | XML Full-text
Abstract
In this study, we sought to improve the light trapping of textured silicon solar cells using the plasmonic light scattering of indium nanoparticles (In NPs) of various dimensions. The light trapping modes of textured-silicon surfaces with and without In NPs were investigated at
[...] Read more.
In this study, we sought to improve the light trapping of textured silicon solar cells using the plasmonic light scattering of indium nanoparticles (In NPs) of various dimensions. The light trapping modes of textured-silicon surfaces with and without In NPs were investigated at an angle of incidence (AOI) ranging from 0° to 75°. The optical reflectance, external quantum efficiency (EQE), and photovoltaic performance were first characterized under an AOI of 0°. We then compared the EQE and photovoltaic current density-voltage (J-V) as a function of AOI in textured silicon solar cells with and without In NPs. We observed a reduction in optical reflectance and an increase in EQE when the cells textured with pyramidal structures were coated with In NPs. We also observed an impressive increase in the average weighted external quantum efficiency (∆EQEw) and short-circuit current-density (∆Jsc) in cells with In NPs when illuminated under a higher AOI. The ∆EQEw values of cells with In NPs were 0.37% higher than those without In NPs under an AOI of 0°, and 3.48% higher under an AOI of 75°. The ∆Jsc values of cells with In NPs were 0.50% higher than those without In NPs under an AOI of 0°, and 4.57% higher under an AOI of 75°. The application of In NPs clearly improved the light trapping effects. This can be attributed to the effects of plasmonic light-scattering over the entire wavelength range as well as an expanded angle of incident light. Full article
(This article belongs to the Special Issue Selected Papers from IEEE ICASI 2017)
Figures

Open AccessArticle Dealloyed Ruthenium Film Catalysts for Hydrogen Generation from Chemical Hydrides
Materials 2017, 10(7), 738; doi:10.3390/ma10070738
Received: 10 June 2017 / Revised: 28 June 2017 / Accepted: 29 June 2017 / Published: 2 July 2017
PDF Full-text (2410 KB) | HTML Full-text | XML Full-text
Abstract
Thin-film ruthenium (Ru) and copper (Cu) binary alloys have been prepared on a Teflon™ backing layer by cosputtering of the precious and nonprecious metals, respectively. Alloys were then selectively dealloyed by sulfuric acid as an etchant, and their hydrogen generation catalysts performances were
[...] Read more.
Thin-film ruthenium (Ru) and copper (Cu) binary alloys have been prepared on a Teflon™ backing layer by cosputtering of the precious and nonprecious metals, respectively. Alloys were then selectively dealloyed by sulfuric acid as an etchant, and their hydrogen generation catalysts performances were evaluated. Sputtering time and power of Cu atoms have been varied in order to tailor the hydrogen generation performances. Similarly, dealloying time and the sulfuric acid concentration have also been altered to tune the morphologies of the resulted films. A maximum hydrogen generation rate of 35 mL min−1 was achieved when Cu sputtering power and time were 200 W and 60 min and while acid concentration and dealloying time were 18 M and 90 min, respectively. It has also been demonstrated that the Ru content in the alloy after dealloying gradually increased with the increasing the sputtering power of Cu. After 90 min dealloying, the Ru to Cu ratio increased to about 190 times that of bare alloy. This is the key issue for observing higher catalytic activity. Interestingly, we have also presented template-free nanoforest-like structure formation within the context of one-step alloying and dealloying used in this study. Last but not least, the long-time hydrogen generation performances of the catalysts system have also been evaluated along 3600 min. During the first 600 min, the catalytic activity was quite stable, while about 24% of the catalytic activity decayed after 3000 min, which still makes these systems available for the development of robust catalyst systems in the area of hydrogen generation. Full article
Figures

Figure 1

Open AccessArticle Finite Element Analysis of Interfacial Debonding in Copper/Diamond Composites for Thermal Management Applications
Materials 2017, 10(7), 739; doi:10.3390/ma10070739
Received: 15 May 2017 / Revised: 27 June 2017 / Accepted: 27 June 2017 / Published: 2 July 2017
PDF Full-text (4808 KB) | HTML Full-text | XML Full-text
Abstract
Copper/diamond (Cu/D) composites are famous in thermal management applications for their high thermal conductivity values. They, however, offer some interface related problems like high thermal boundary resistance and excessive debonding. This paper investigates interfacial debonding in Cu/D composites subjected to steady-state and transient
[...] Read more.
Copper/diamond (Cu/D) composites are famous in thermal management applications for their high thermal conductivity values. They, however, offer some interface related problems like high thermal boundary resistance and excessive debonding. This paper investigates interfacial debonding in Cu/D composites subjected to steady-state and transient thermal cyclic loading. A micro-scale finite element (FE) model was developed from a SEM image of the Cu/20 vol % D composite sample. Several test cases were assumed with respect to the direction of heat flow and the boundary interactions between Cu/uncoated diamonds and Cu/Cr-coated diamonds. It was observed that the debonding behavior varied as a result of the differences in the coefficients of thermal expansions (CTEs) among Cu, diamond, and Cr. Moreover, the separation of interfaces had a direct influence upon the equivalent stress state of the Cu-matrix, since diamond particles only deformed elastically. It was revealed through a fully coupled thermo-mechanical FE analysis that repeated heating and cooling cycles resulted in an extremely high stress state within the Cu-matrix along the diamond interface. Since these stresses lead to interfacial debonding, their computation through numerical means may help in determining the service life of heat sinks for a given application beforehand. Full article
Figures

Figure 1

Open AccessFeature PaperArticle In Vitro Human Umbilical Vein Endothelial Cells Response to Ionic Dissolution Products from Lithium-Containing 45S5 Bioactive Glass
Materials 2017, 10(7), 740; doi:10.3390/ma10070740
Received: 1 June 2017 / Revised: 24 June 2017 / Accepted: 29 June 2017 / Published: 3 July 2017
PDF Full-text (2136 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Since lithium (Li+) plays roles in angiogenesis, the localized and controlled release of Li+ ions from bioactive glasses (BGs) represents a promising alternative therapy for the regeneration and repair of tissues with a high degree of vascularization. Here, microparticles from
[...] Read more.
Since lithium (Li+) plays roles in angiogenesis, the localized and controlled release of Li+ ions from bioactive glasses (BGs) represents a promising alternative therapy for the regeneration and repair of tissues with a high degree of vascularization. Here, microparticles from a base 45S5 BG composition containing (wt %) 45% SiO2, 24.5% Na2O, 24.5% CaO, and 6% P2O5, in which Na2O was partially substituted by 5% Li2O (45S5.5Li), were obtained. The results demonstrate that human umbilical vein endothelial cells (HUVECs) have greater migratory and proliferative response and ability to form tubules in vitro after stimulation with the ionic dissolution products (IDPs) of the 45S5.5Li BG. The results also show the activation of the canonical Wnt/β-catenin pathway and the increase in expression of proangiogenic cytokines insulin like growth factor 1 (IGF1) and transforming growth factor beta (TGFβ). We conclude that the IDPs of 45S5.5Li BG would act as useful inorganic agents to improve tissue repair and regeneration, ultimately stimulating HUVECs behavior in the absence of exogenous growth factors. Full article
(This article belongs to the Special Issue Bioactive Glasses 2017)
Figures

Figure 1

Open AccessFeature PaperArticle Carbon Coated Boron Nitride Nanosheets for Polymer Nanocomposites with Enhanced Dielectric Performance
Materials 2017, 10(7), 741; doi:10.3390/ma10070741
Received: 15 June 2017 / Revised: 29 June 2017 / Accepted: 30 June 2017 / Published: 3 July 2017
PDF Full-text (3852 KB) | HTML Full-text | XML Full-text
Abstract
Carbon coated boron nitride nanosheets (BNNSs@C) hybrids with different carbon contents were synthesized by a chemical vapor deposition (CVD) method. The content of carbon in as-obtained BNNSs@C hybrids could be precisely adjusted from 2.50% to 22.62% by controlling the carbon deposition time during
[...] Read more.
Carbon coated boron nitride nanosheets (BNNSs@C) hybrids with different carbon contents were synthesized by a chemical vapor deposition (CVD) method. The content of carbon in as-obtained BNNSs@C hybrids could be precisely adjusted from 2.50% to 22.62% by controlling the carbon deposition time during the CVD procedure. Afterward, the BNNSs@C hybrids were subsequently incorporated into the polyvinylidene fluoride (PVDF) matrix to fabricate the BNNSs@C/PVDF nanocomposites through a combination of solution and melting blending methods. The dielectric properties of the as-obtained BNNSs@C/PVDF nanocomposites could be accurately tuned by adjusting the carbon content. The resultant nanocomposites could afford a high dielectric constant about 39 (103 Hz) at BNNSs@C hybrids loading of 30 vol %, which is 4.8 times larger than that of pristine BNNSs-filled ones at the same filler loading, and 3.5 times higher than that of pure PVDF matrix. The largely enhanced dielectric performance could be ascribed to the improved interfacial polarizations of BNNSs/carbon and carbon/PVDF interfaces. The approach reported here offers an effective and alternative method to fabricate high-performance dielectric nanocomposites, which could be potentially applied to the embedded capacitors with high dielectric performance. Full article
(This article belongs to the Special Issue Polymers for Film Capacitors)
Figures

Figure 1

Open AccessArticle Investigation of Rapid Low-Power Microwave-Induction Heating Scheme on the Cross-Linking Process of the Poly(4-vinylphenol) for the Gate Insulator of Pentacene-Based Thin-Film Transistors
Materials 2017, 10(7), 742; doi:10.3390/ma10070742
Received: 29 March 2017 / Revised: 6 June 2017 / Accepted: 20 June 2017 / Published: 3 July 2017
PDF Full-text (2211 KB) | HTML Full-text | XML Full-text
Abstract
In this study, a proposed Microwave-Induction Heating (MIH) scheme has been systematically studied to acquire suitable MIH parameters including chamber pressure, microwave power and heating time. The proposed MIH means that the thin indium tin oxide (ITO) metal below the Poly(4-vinylphenol) (PVP) film
[...] Read more.
In this study, a proposed Microwave-Induction Heating (MIH) scheme has been systematically studied to acquire suitable MIH parameters including chamber pressure, microwave power and heating time. The proposed MIH means that the thin indium tin oxide (ITO) metal below the Poly(4-vinylphenol) (PVP) film is heated rapidly by microwave irradiation and the heated ITO metal gate can heat the PVP gate insulator, resulting in PVP cross-linking. It is found that the attenuation of the microwave energy decreases with the decreasing chamber pressure. The optimal conditions are a power of 50 W, a heating time of 5 min, and a chamber pressure of 20 mTorr. When suitable MIH parameters were used, the effect of PVP cross-linking and the device performance were similar to those obtained using traditional oven heating, even though the cross-linking time was significantly decreased from 1 h to 5 min. Besides the gate leakage current, the interface trap state density (Nit) was also calculated to describe the interface status between the gate insulator and the active layer. The lowest interface trap state density can be found in the device with the PVP gate insulator cross-linked by using the optimal MIH condition. Therefore, it is believed that the MIH scheme is a good candidate to cross-link the PVP gate insulator for organic thin-film transistor applications as a result of its features of rapid heating (5 min) and low-power microwave-irradiation (50 W). Full article
(This article belongs to the Special Issue Stretchable and Flexible Electronic Materials & Devices)
Figures

Figure 1

Open AccessArticle Mechanical Performance of Asphalt Mortar Containing Hydrated Lime and EAFSS at Low and High Temperatures
Materials 2017, 10(7), 743; doi:10.3390/ma10070743
Received: 24 May 2017 / Revised: 20 June 2017 / Accepted: 25 June 2017 / Published: 3 July 2017
PDF Full-text (4700 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, the possibility of improving the global response of asphalt materials for pavement applications through the use of hydrated lime and Electric Arc-Furnace Steel Slag (EAFSS) was investigated. For this purpose, a set of asphalt mortars was prepared by mixing two
[...] Read more.
In this paper, the possibility of improving the global response of asphalt materials for pavement applications through the use of hydrated lime and Electric Arc-Furnace Steel Slag (EAFSS) was investigated. For this purpose, a set of asphalt mortars was prepared by mixing two different asphalt binders with fine granite aggregate together with hydrated lime or EAFSS at three different percentages. Bending Beam Rheometer (BBR) creep tests and Dynamic Shear Rheometer (DSR) complex modulus tests were performed to evaluate the material response both at low and high temperature. Then, the rheological Huet model was fitted to the BBR creep results for estimating the impact of filler content on the model parameters. It was found that an addition of hydrated lime and EAFSS up to 10% and 5%, respectively, results in satisfactory low-temperature performance with a substantial improvement of the high-temperature behavior. Full article
Figures

Figure 1

Open AccessArticle Raman and Photoemission Spectroscopic Analyses of Explanted Biolox® Delta Femoral Heads Showing Metal Transfer
Materials 2017, 10(7), 744; doi:10.3390/ma10070744
Received: 28 April 2017 / Revised: 25 June 2017 / Accepted: 29 June 2017 / Published: 3 July 2017
PDF Full-text (6294 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Biolox® delta has been widely used in joint replacements thanks to its high strength and wear resistance. In this study, eleven Biolox® delta femoral head retrievals affected by metal transfer (MT) were analysed by Raman spectroscopy to estimate the tetragonal to
[...] Read more.
Biolox® delta has been widely used in joint replacements thanks to its high strength and wear resistance. In this study, eleven Biolox® delta femoral head retrievals affected by metal transfer (MT) were analysed by Raman spectroscopy to estimate the tetragonal to monoclinic zirconia phase transformation, whose occurrence may compromise ceramic chemical stability and mechanical strength. The residual stress state was evaluated by both Raman and photoemission spectroscopy. Vm monoclinic zirconia contents were higher near the centre of the articulating surface and in the MT area than in the border control area of the retrievals. In only one retrieval, stress related to MT appeared a more severe condition, able to induce zirconia phase transformation; for all the others, stresses related to loading in the central region and related to MT, were conducive to a zirconia phase transformation of nearly the same extent. Vm depth profiling analyses showed that the transformation involved different thicknesses in different samples. Raman data allowed for the investigation of the mechanism of zirconia phase transformation and confirmed that the growth stage was absent and the nucleation stage was not occurring as freely as it would in unconstrained zirconia. Full article
Figures

Figure 1

Open AccessArticle Influence of Texture on Impact Toughness of Ferritic Fe-20Cr-5Al Oxide Dispersion Strengthened Steel
Materials 2017, 10(7), 745; doi:10.3390/ma10070745
Received: 28 April 2017 / Revised: 16 June 2017 / Accepted: 26 June 2017 / Published: 3 July 2017
PDF Full-text (8915 KB) | HTML Full-text | XML Full-text
Abstract
Fe-based oxide dispersion strengthened (ODS) steels are oriented to applications where high operating temperatures and good corrosion resistance is paramount. However, their use is compromised by their fracture toughness, which is lower than other competing ferritic-martenstic steels. In addition, the route required in
[...] Read more.
Fe-based oxide dispersion strengthened (ODS) steels are oriented to applications where high operating temperatures and good corrosion resistance is paramount. However, their use is compromised by their fracture toughness, which is lower than other competing ferritic-martenstic steels. In addition, the route required in manufacturing these alloys generates texture in the material, which induces a strong anisotropy in properties. The V-notched Charpy tests carried out on these alloys, to evaluate their impact toughness, reveal that delaminations do not follow the path that would be expected. There are many hypotheses about what triggers these delaminations, but the most accepted is that the joint action of particles in the grain boundaries, texture induced in the manufacturing process, and the actual microstructure of these alloys are responsible. In this paper we focused on the actual role of crystallographic texture on impact toughness in these materials. A finite elements simulation is carried out to solely analyze the role of texture and eliminate other factors, such as grain boundaries and the dispersed particles. The work allows us to conclude that crystallographic texture plays an important role in the distribution of stresses in the Charpy specimens. The observed delaminations might be explained on the basis that the crack in the grain, causing the delamination, is directly related to the shear stresses τ12 on both sides of the grain boundary, while the main crack propagation is a consequence of the normal stress to the crack. Full article
(This article belongs to the Special Issue The Failure Micromechanics and Toughening Mechanisms of Materials)
Figures

Open AccessArticle Amino Acids Aided Sintering for the Formation of Highly Porous FeAl Intermetallic Alloys
Materials 2017, 10(7), 746; doi:10.3390/ma10070746
Received: 31 May 2017 / Revised: 23 June 2017 / Accepted: 28 June 2017 / Published: 4 July 2017
PDF Full-text (5016 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Fabrication of metallic foams by sintering metal powders mixed with thermally degradable compounds is of interest for numerous applications. Compounds releasing gaseous nitrogen, minimizing interactions between the formed gases and metallic foam by diluting other combustion products, were applied. Cysteine and phenylalanine, were
[...] Read more.
Fabrication of metallic foams by sintering metal powders mixed with thermally degradable compounds is of interest for numerous applications. Compounds releasing gaseous nitrogen, minimizing interactions between the formed gases and metallic foam by diluting other combustion products, were applied. Cysteine and phenylalanine, were used as gas releasing agents during the sintering of elemental Fe and Al powders in order to obtain metallic foams. Characterization was carried out by optical microscopy with image analysis, scanning electron microscopy with energy dispersive spectroscopy, and gas permeability tests. Porosity of the foams was up to 42 ± 3% and 46 ± 2% for sintering conducted with 5 wt % cysteine and phenylalanine, respectively. Chemical analyses of the formed foams revealed that the oxygen content was below 0.14 wt % and the carbon content was below 0.3 wt %. Therefore, no brittle phases could be formed that would spoil the mechanical stability of the FeAl intermetallic foams. The gas permeability tests revealed that only the foams formed in the presence of cysteine have enough interconnections between the pores, thanks to the improved air flow through the porous materials. The foams formed with cysteine can be applied as filters and industrial catalysts. Full article
Figures

Open AccessArticle Symmetric Supercapacitor Electrodes from KOH Activation of Pristine, Carbonized, and Hydrothermally Treated Melia azedarach Stones
Materials 2017, 10(7), 747; doi:10.3390/ma10070747
Received: 1 June 2017 / Revised: 26 June 2017 / Accepted: 29 June 2017 / Published: 4 July 2017
PDF Full-text (1679 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Waste biomass-derived activated carbons (ACs) are promising materials for supercapacitor electrodes due to their abundance and low cost. In this study, we investigated the potential use of Melia azedarach (MA) stones to prepare ACs for supercapacitors. The ash content was considerably lower in
[...] Read more.
Waste biomass-derived activated carbons (ACs) are promising materials for supercapacitor electrodes due to their abundance and low cost. In this study, we investigated the potential use of Melia azedarach (MA) stones to prepare ACs for supercapacitors. The ash content was considerably lower in MA stones (0.7% ash) than that found in other lignocellulosic wastes. ACs were prepared by KOH activation of pristine, carbonized, and hydrothermally-treated MA stones. The morphology, composition, surface area, porosity, and surface chemistry of the ACs were determined. Electrochemical measurements were carried out in three- and two-electrode cells, 3EC and 2EC, respectively, using 1 M H2SO4 as the electrolyte. The highest capacitance from galvanostatic charge-discharge (GCD) in 2EC ranged between 232 and 240 F·g−1 at 1 A·g−1. The maximum energy density reached was 27.4 Wh·kg−1 at a power density of 110 W·kg−1. Electrochemical impedance spectroscopy (EIS) revealed an increase in equivalent series resistance (ESR) and charge transfer resistance (RCT) with greater ash content. Electrochemical performance of MA stone-derived ACs was compared with that of other ACs described in the recent literature that were prepared from different biomass wastes and results showed that they are among the best ACs for supercapacitor applications. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1

Open AccessArticle Effect of Molten Pool Size on Microstructure and Tensile Properties of Wire Arc Additive Manufacturing of Ti-6Al-4V Alloy
Materials 2017, 10(7), 749; doi:10.3390/ma10070749
Received: 29 May 2017 / Revised: 25 June 2017 / Accepted: 29 June 2017 / Published: 4 July 2017
PDF Full-text (8625 KB) | HTML Full-text | XML Full-text
Abstract
Wire arc additive manufacturing (WAAM) technique is a cost-competitive and efficient technology to produce large structure components in industry domains. Mechanical properties are mainly dominated by the microstructure of the components, which is deeply affected by the molten pool size. In this work,
[...] Read more.
Wire arc additive manufacturing (WAAM) technique is a cost-competitive and efficient technology to produce large structure components in industry domains. Mechanical properties are mainly dominated by the microstructure of the components, which is deeply affected by the molten pool size. In this work, to investigate the effect of the molten pool size on microstructure and mechanical properties of the components, a series of Ti-6Al-4V alloy blocks with different width of molten pool (WMP) ranging from 7 mm to 22 mm were deposited by adjusting the wire feed speed (WFS) from 100 cm/min to 500 cm/min. It is interesting to find that the macrostructure changes from columnar grains to equiaxial grains, and then returns to large columnar grains with the increase of WMP, which is mainly caused by the different cooling rates and thermal gradients. Nonetheless, the tensile properties of the components have a tendency to decline with the increase of WMP. Full article
(This article belongs to the Special Issue Mechanical Properties of Additive Structures in Materials)
Figures

Figure 1

Open AccessFeature PaperArticle Lithium Hydrazinidoborane Ammoniate LiN2H3BH3·0.25NH3, a Derivative of Hydrazine Borane
Materials 2017, 10(7), 750; doi:10.3390/ma10070750
Received: 14 June 2017 / Revised: 27 June 2017 / Accepted: 29 June 2017 / Published: 5 July 2017
PDF Full-text (1632 KB) | HTML Full-text | XML Full-text
Abstract
Boron- and nitrogen-based materials have shown to be attractive for solid-state chemical hydrogen storage owing to gravimetric hydrogen densities higher than 10 wt% H. Herein, we report a new derivative of hydrazine borane N2H4BH3, namely lithium hydrazinidoborane
[...] Read more.
Boron- and nitrogen-based materials have shown to be attractive for solid-state chemical hydrogen storage owing to gravimetric hydrogen densities higher than 10 wt% H. Herein, we report a new derivative of hydrazine borane N2H4BH3, namely lithium hydrazinidoborane ammoniate LiN2H3BH3·0.25NH3. It is easily obtained in ambient conditions by ball-milling N2H4BH3 and lithium amide LiNH2 taken in equimolar amounts. Both compounds react without loss of any H atoms. The molecular and crystallographic structures of our new compound have been confirmed by NMR/FTIR spectroscopy and powder X-ray diffraction. The complexation of the entity LiN2H3BH3 by some NH3 has been also established by thermogravimetric and calorimetric analyses. In our conditions, LiN2H3BH3·0.25NH3 has been shown to be able to release H2 at temperatures lower than the parent N2H4BH3 or the counterpart LiN2H3BH3. It also liberates non-negligible amounts of NH3 at temperatures lower than 100 °C. This is actually quite detrimental for chemical H storage, but alternatively LiN2H3BH3·0.25NH3 might be seen as a potential NH3 carrier. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1

Open AccessArticle Corrosion and Tribology of Materials Used in a Novel Reverse Hip Replacement
Materials 2017, 10(7), 751; doi:10.3390/ma10070751
Received: 9 April 2017 / Revised: 30 June 2017 / Accepted: 30 June 2017 / Published: 5 July 2017
PDF Full-text (3249 KB) | HTML Full-text | XML Full-text
Abstract
Total hip arthroplasty has been utilized for the past 50 years as an effective treatment for degenerative, inflammatory and traumatic disorders of the hip. The design of these implants has generally followed the anatomy of the hip as a ball and socket joint
[...] Read more.
Total hip arthroplasty has been utilized for the past 50 years as an effective treatment for degenerative, inflammatory and traumatic disorders of the hip. The design of these implants has generally followed the anatomy of the hip as a ball and socket joint with the femoral head representing the ball and the acetabulum representing the socket. We describe a novel hip arthroplasty design in which the “ball” is located on the acetabular side and the “socket” is located on the femoral side. The results of extensive biomechanical testing are described and document wear and corrosion characteristics that are at least equivalent to standard designs. These results support clinical assessment as the next step of the evaluation. Full article
Figures

Figure 1

Open AccessArticle A Printed Xi-Shaped Left-Handed Metamaterial on Low-Cost Flexible Photo Paper
Materials 2017, 10(7), 752; doi:10.3390/ma10070752
Received: 9 May 2017 / Revised: 28 June 2017 / Accepted: 29 June 2017 / Published: 5 July 2017
PDF Full-text (6666 KB) | HTML Full-text | XML Full-text
Abstract
A Xi-shaped meta structure, has been introduced in this paper. A modified split-ring resonator (MSRR) and a capacitive loaded strip (CLS) were used to achieve the left-handed property of the metamaterial. The structure was printed using silver metallic nanoparticle ink, using a very
[...] Read more.
A Xi-shaped meta structure, has been introduced in this paper. A modified split-ring resonator (MSRR) and a capacitive loaded strip (CLS) were used to achieve the left-handed property of the metamaterial. The structure was printed using silver metallic nanoparticle ink, using a very low-cost photo paper as a substrate material. Resonators were inkjet-printed using silver nanoparticle metallic ink on paper to make this metamaterial flexible. It is also free from any kind of chemical waste, which makes it eco-friendly. A double negative region from 8.72 GHz to 10.91 GHz (bandwidth of 2.19 GHz) in the X-band microwave spectra was been found. Figure of merit was also obtained to measure any loss in the double negative region. The simulated result was verified by the performance of the fabricated prototype. The total dimensions of the proposed structure were 0.29 λ × 0.29 λ × 0.007 λ. It is a promising unit cell because of its simplicity, cost-effectiveness, and easy fabrication process. Full article
Figures

Figure 1

Open AccessArticle Effects of Grain Size on Ultrasonic Attenuation in Type 316L Stainless Steel
Materials 2017, 10(7), 753; doi:10.3390/ma10070753
Received: 30 May 2017 / Revised: 27 June 2017 / Accepted: 30 June 2017 / Published: 5 July 2017
PDF Full-text (6673 KB) | HTML Full-text | XML Full-text
Abstract
A lead bismuth eutectic (LBE) spallation target will be installed in the Target Test Facility (TEF-T) in the Japan Proton Accelerator Research Complex (J-PARC). The spallation target vessel filled with LBE is made of type 316L stainless steel. However, various damages, such as
[...] Read more.
A lead bismuth eutectic (LBE) spallation target will be installed in the Target Test Facility (TEF-T) in the Japan Proton Accelerator Research Complex (J-PARC). The spallation target vessel filled with LBE is made of type 316L stainless steel. However, various damages, such as erosion/corrosion damage and liquid metal embrittlement caused by contact with flowing LBE at high temperature, and irradiation hardening caused by protons and neutrons, may be inflicted on the target vessel, which will deteriorate the steel and might break the vessel. To monitor the target vessel for prevention of an accident, an ultrasonic technique has been proposed to establish off-line evaluation for estimating vessel material status during the target maintenance period. Basic R&D must be carried out to clarify the dependency of ultrasonic wave propagation behavior on material microstructures and obtain fundamental knowledge. As a first step, ultrasonic waves scattered by the grains of type 316L stainless steel are investigated using new experimental and numerical approaches in the present study. The results show that the grain size can be evaluated exactly and quantitatively by calculating the attenuation coefficient of the ultrasonic waves scattered by the grains. The results also show that the scattering regimes of ultrasonic waves depend heavily on the ratio of wavelength to average grain size, and are dominated by grains of extraordinarily large size along the wave propagation path. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Figure 1

Open AccessArticle Toxicity of Nine (Doped) Rare Earth Metal Oxides and Respective Individual Metals to Aquatic Microorganisms Vibrio fischeri and Tetrahymena thermophila
Materials 2017, 10(7), 754; doi:10.3390/ma10070754
Received: 22 May 2017 / Revised: 13 June 2017 / Accepted: 30 June 2017 / Published: 5 July 2017
PDF Full-text (2789 KB) | HTML Full-text | XML Full-text
Abstract
Despite the increasing use of rare earth elements (REEs) and oxides (REOs) in various technologies, the information on their ecotoxicological hazard is scarce. Here, the effects of La3+, Ce3+, Pr3+, Nd3+, Gd3+, CeO
[...] Read more.
Despite the increasing use of rare earth elements (REEs) and oxides (REOs) in various technologies, the information on their ecotoxicological hazard is scarce. Here, the effects of La3+, Ce3+, Pr3+, Nd3+, Gd3+, CeO2, and eight doped REOs to marine bacteria Vibrio fischeri and freshwater protozoa Tetrahymena thermophila were studied in parallel with REO dopant metals (Co2+, Fe3+, Mn2+, Ni2+, Sr2+). The highest concentrations of REOs tested were 100 mg/L with protozoa in deionized water and 500 mg/L with bacteria in 2% NaCl. Although (i) most REOs produced reactive oxygen species; (ii) all studied soluble REEs were toxic to bacteria (half-effective concentration, EC50 3.5–21 mg metal/L; minimal bactericidal concentration, MBC 6.3–63 mg/L) and to protozoa (EC50 28–42 mg/L); and (iii) also some dopant metals (Ni2+, Fe3+) proved toxic (EC50 ≤ 3 mg/L), no toxicity of REOs to protozoa (EC50 > 100 mg/L) and bacteria (EC50 > 500 mg/L; MBC > 500 mg/L) was observed except for La2NiO4 (MBC 25 mg/L). According to kinetics of V. fischeri bioluminescence, the toxicity of REEs was triggered by disturbing cellular membrane integrity. Fortunately, as REEs and REOs are currently produced in moderate amounts and form in the environment insoluble salts and/or oxides, they apparently present no harm to aquatic bacteria and protozoa. Full article
Figures

Figure 1

Open AccessArticle Zinc Sorption on Modified Waste Poly(methyl methacrylate)
Materials 2017, 10(7), 755; doi:10.3390/ma10070755
Received: 13 June 2017 / Revised: 28 June 2017 / Accepted: 30 June 2017 / Published: 6 July 2017
PDF Full-text (2408 KB) | HTML Full-text | XML Full-text
Abstract
The new one-pot hydrolysis-crosslinking reaction was used to synthesize a new, waste poly(methyl methacrylate) (PMMA)-based material for zinc(II) ions removal. The alkaline hydrolysis of PMMA in diethylene glycol diethyl ether was used to obtain polymer matrix and it was then crosslinked with Ca
[...] Read more.
The new one-pot hydrolysis-crosslinking reaction was used to synthesize a new, waste poly(methyl methacrylate) (PMMA)-based material for zinc(II) ions removal. The alkaline hydrolysis of PMMA in diethylene glycol diethyl ether was used to obtain polymer matrix and it was then crosslinked with Ca and Mg ions to obtain the sorbent. As a result, the macroporous materials were obtained with a yield of 87% when waste PMMA was used, and about 95% when the commercial PMMAs were used. The degree of hydrolysis was similar, from 32% to 35%. New materials were then tested for their affinity towards zinc(II) ions. Two kinetic models (pseudo-first and pseudo-second order), as well as two isotherms (Langmuir and Freundlich), were used to describe the kinetics and equilibrium of zinc(II) ion sorption on the studied materials, respectively. All the prepared PMMA-based sorbents showed similar or higher sorption capacity (q up to 87.7 mg/g) compared to commercially available materials in a broad pH range (4–7). The study shows sorption was fast—above 80% of equilibrium capacity was achieved after ca. 0.5 h. Presented results show that waste PMMA may be an interesting raw material for the preparation of sorbents for zinc(II) ions removal. Full article
(This article belongs to the Special Issue Sorption Materials for Environment Purification)
Figures

Figure 1

Open AccessArticle Parametric Studies of Titania-Supported Gold-Catalyzed Oxidation of Carbon Monoxide
Materials 2017, 10(7), 756; doi:10.3390/ma10070756
Received: 7 March 2017 / Revised: 21 June 2017 / Accepted: 28 June 2017 / Published: 5 July 2017
PDF Full-text (6320 KB) | HTML Full-text | XML Full-text
Abstract
This paper remarks the general correlations of the shape and crystallinity of titanium dioxide (TiO2) support on gold deposition and carbon monoxide (CO) oxidation. It was found that due to the larger rutile TiO2 particles and thus the pore volume,
[...] Read more.
This paper remarks the general correlations of the shape and crystallinity of titanium dioxide (TiO2) support on gold deposition and carbon monoxide (CO) oxidation. It was found that due to the larger rutile TiO2 particles and thus the pore volume, the deposited gold particles tended to agglomerate, resulting in smaller catalyst surface area and limited gold loading, whilst anatase TiO2 enabled better gold deposition. Those properties directly related to gold particle size and thus the number of low coordinated atoms play dominant roles in enhancing CO oxidation activity. Gold deposited on anatase spheroidal TiO2 at photo-deposition wavelength of 410 nm for 5 min resulted in the highest CO oxidation activity of 0.0617 mmol CO/s.gAu (89.5% conversion) due to the comparatively highest catalyst surface area (114.4 m2/g), smallest gold particle size (2.8 nm), highest gold loading (7.2%), and highest Au0 content (68 mg/g catalyst). CO oxidation activity was also found to be directly proportional to the Au0 content. Based on diffuse reflectance infrared Fourier transform spectroscopy, we postulate that anatase TiO2-supported Au undergoes rapid direct oxidation whilst CO oxidation on rutile TiO2-supported Au could be inhibited by co-adsorption of oxygen. Full article
(This article belongs to the Section Structure Analysis and Characterization)
Figures

Open AccessFeature PaperArticle Zirconia/Hydroxyapatite Composites Synthesized Via Sol-Gel: Influence of Hydroxyapatite Content and Heating on Their Biological Properties
Materials 2017, 10(7), 757; doi:10.3390/ma10070757
Received: 17 May 2017 / Revised: 30 June 2017 / Accepted: 30 June 2017 / Published: 5 July 2017
PDF Full-text (4722 KB) | HTML Full-text | XML Full-text
Abstract
Zirconia (ZrO2) and zirconia-based glasses and ceramics are materials proposed for use in the dental and orthopedic fields. In this work, ZrO2 glass was modified by adding different amounts of bioactive and biocompatible hydroxyapatite (HAp). ZrO2/HAp composites were
[...] Read more.
Zirconia (ZrO2) and zirconia-based glasses and ceramics are materials proposed for use in the dental and orthopedic fields. In this work, ZrO2 glass was modified by adding different amounts of bioactive and biocompatible hydroxyapatite (HAp). ZrO2/HAp composites were synthesized via the sol-gel method and heated to different temperatures to induce modifications of their chemical structure, as ascertained by Fourier transform infrared spectroscopy (FTIR) analysis. The aim was to investigate the effect of both HAp content and heating on the biological performances of ZrO2. The materials’ bioactivity was studied by soaking samples in a simulated body fluid (SBF). FTIR and scanning electron microscopy (SEM)) analyses carried out after exposure to SBF showed that all materials are bioactive, i.e., they are able to form a hydroxyapatite layer on their surface. Moreover, the samples were soaked in a solution containing bovine serum albumin (BSA). FTIR analysis proved that the synthesized materials are able to adsorb the blood protein, the first step of cell adhesion. WST-8 ([2-(2-methoxy-4-nitrophenyl)-3-(4-nitrophenyl)-5-(2,4-disulfophenyl)-2H-tetrazolium, monosodium salt]) assay showed that no cytotoxicity effects were induced by the materials’ extract. However, the results proved that bioactivity increases with both the HAp content and the temperature used for the thermal treatment, whereas biocompatibility increases with heating but is not affected by the HAp content. Full article
(This article belongs to the Special Issue Sol-Gel Chemistry Applied to Materials Science)
Figures

Figure 1

Open AccessArticle A New Biphasic Dicalcium Silicate Bone Cement Implant
Materials 2017, 10(7), 758; doi:10.3390/ma10070758
Received: 12 June 2017 / Revised: 1 July 2017 / Accepted: 3 July 2017 / Published: 6 July 2017
PDF Full-text (38185 KB) | HTML Full-text | XML Full-text
Abstract
This study aimed to investigate the processing parameters and biocompatibility of a novel biphasic dicalcium silicate (C2S) cement. Biphasic α´L + β-C2Sss was synthesized by solid-state processing, and was used as a raw material to prepare the
[...] Read more.
This study aimed to investigate the processing parameters and biocompatibility of a novel biphasic dicalcium silicate (C2S) cement. Biphasic α´L + β-C2Sss was synthesized by solid-state processing, and was used as a raw material to prepare the cement. In vitro bioactivity and biocompatibility studies were assessed by soaking the cement samples in simulated body fluid (SBF) and human adipose stem cell cultures. Two critical-sized defects of 6 mm Ø were created in 15 NZ tibias. A porous cement made of the high temperature forms of C2S, with a low phosphorous substitution level, was produced. An apatite-like layer covered the cement’s surface after soaking in SBF. The cell attachment test showed that α´L + β-C2Sss supported cells sticking and spreading after 24 h of culture. The cement paste (55.86 ± 0.23) obtained higher bone-to-implant contact (BIC) percentage values (better quality, closer contact) in the histomorphometric analysis, and defect closure was significant compared to the control group (plastic). The residual material volume of the porous cement was 35.42 ± 2.08% of the initial value. The highest BIC and bone formation percentages were obtained on day 60. These results suggest that the cement paste is advantageous for initial bone regeneration. Full article
(This article belongs to the Special Issue Dental Implant Materials)
Figures

Figure 1

Open AccessFeature PaperArticle Study of Superbase-Based Deep Eutectic Solvents as the Catalyst in the Chemical Fixation of CO2 into Cyclic Carbonates under Mild Conditions
Materials 2017, 10(7), 759; doi:10.3390/ma10070759
Received: 8 June 2017 / Revised: 28 June 2017 / Accepted: 29 June 2017 / Published: 7 July 2017
Cited by 1 | PDF Full-text (1995 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Superbases have shown high performance as catalysts in the chemical fixation of CO2 to epoxides. The proposed reaction mechanism typically assumes the formation of a superbase, the CO2 adduct as the intermediate, most likely because of the well-known affinity between superbases
[...] Read more.
Superbases have shown high performance as catalysts in the chemical fixation of CO2 to epoxides. The proposed reaction mechanism typically assumes the formation of a superbase, the CO2 adduct as the intermediate, most likely because of the well-known affinity between superbases and CO2, i.e., superbases have actually proven quite effective for CO2 absorption. In this latter use, concerns about the chemical stability upon successive absorption-desorption cycles also merits attention when using superbases as catalysts. In this work, 1H NMR spectroscopy was used to get further insights about (1) whether a superbase, the CO2 adduct, is formed as an intermediate and (2) the chemical stability of the catalyst after reaction. For this purpose, we proposed as a model system the chemical fixation of CO2 to epichlorohydrin (EP) using a deep eutectic solvent (DES) composed of a superbase, e.g., 2,3,4,6,7,8-hexahydro-1H-pyrimido[1,2-a]pyrimidine (TBD) or 2,3,4,6,7,8,9,10-octahydropyrimido[1,2-a]azepine (DBU), as a hydrogen acceptor and an alcohol as a hydrogen bond donor, e.g., benzyl alcohol (BA), ethylene glycol (EG), and methyldiethanolamine (MDEA), as the catalyst. The resulting carbonate was obtained with yields above 90% and selectivities approaching 100% after only two hours of reaction in pseudo-mild reaction conditions, e.g., 1.2 bars and 100 °C, and after 20 h if the reaction conditions of choice were even milder, e.g., 1.2 bars and 50 °C. These results were in agreement with previous works using bifunctional catalytic systems composed of a superbase and a hydrogen bond donor (HBD) also reporting good yields and selectivities, thus confirming the suitability of our choice to perform this study. Full article
Figures

Figure 1

Open AccessArticle Application of Synthetic Layered Sodium Silicate Magadiite Nanosheets for Environmental Remediation of Methylene Blue Dye in Water
Materials 2017, 10(7), 760; doi:10.3390/ma10070760
Received: 13 May 2017 / Revised: 30 June 2017 / Accepted: 3 July 2017 / Published: 6 July 2017
PDF Full-text (4964 KB) | HTML Full-text | XML Full-text
Abstract
The removal of methylene blue (MB) dye from water was investigated using synthetic nano-clay magadiite (SNCM). SNCM was synthesized by a hydrothermal treatment under autogenous pressure. A rosette-shaped single mesoporous magadiite phase with 16.63 nm average crystallite size and 33 m2∙g
[...] Read more.
The removal of methylene blue (MB) dye from water was investigated using synthetic nano-clay magadiite (SNCM). SNCM was synthesized by a hydrothermal treatment under autogenous pressure. A rosette-shaped single mesoporous magadiite phase with 16.63 nm average crystallite size and 33 m2∙g−1 Braunauer-Emmet-Teller (BET)-surface area was recorded. The adsorption results indicated the pronounced affinity of the SNCM to the MB dye molecules, which reached an adsorption uptake of 20.0 mg MB dye/g of SNCM. The elimination of MB dye by the SNCM was kinetically and thermodynamically considered; a pseudo-second-order kinetic model was attained, and its spontaneous, chemical, and endothermic nature was verified. SNCM was shown to be robust without a detectable reduction in the adsorption capacity after up to four times re-use. Full article
(This article belongs to the Special Issue Sorption Materials for Environment Purification)
Figures

Open AccessArticle An Ab Initio and Kinetic Monte Carlo Simulation Study of Lithium Ion Diffusion on Graphene
Materials 2017, 10(7), 761; doi:10.3390/ma10070761
Received: 15 June 2017 / Revised: 1 July 2017 / Accepted: 4 July 2017 / Published: 6 July 2017
PDF Full-text (3331 KB) | HTML Full-text | XML Full-text
Abstract
The Li+ diffusion coefficients in Li+-adsorbed graphene systems were determined by combining first-principle calculations based on density functional theory with Kinetic Monte Carlo simulations. The calculated results indicate that the interactions between Li ions have a very important influence on
[...] Read more.
The Li+ diffusion coefficients in Li+-adsorbed graphene systems were determined by combining first-principle calculations based on density functional theory with Kinetic Monte Carlo simulations. The calculated results indicate that the interactions between Li ions have a very important influence on lithium diffusion. Based on energy barriers directly obtained from first-principle calculations for single-Li+ and two-Li+ adsorbed systems, a new equation predicting energy barriers with more than two Li ions was deduced. Furthermore, it is found that the temperature dependence of Li+ diffusion coefficients fits well to the Arrhenius equation, rather than meeting the equation from electrochemical impedance spectroscopy applied to estimate experimental diffusion coefficients. Moreover, the calculated results also reveal that Li+ concentration dependence of diffusion coefficients roughly fits to the equation from electrochemical impedance spectroscopy in a low concentration region; however, it seriously deviates from the equation in a high concentration region. So, the equation from electrochemical impedance spectroscopy technique could not be simply used to estimate the Li+ diffusion coefficient for all Li+-adsorbed graphene systems with various Li+ concentrations. Our work suggests that interactions between Li ions, and among Li ion and host atoms will influence the Li+ diffusion, which determines that the Li+ intercalation dependence of Li+ diffusion coefficient should be changed and complex. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1

Open AccessArticle Corrosion Behavior of Silver-Plated Circuit Boards in a Simulated Marine Environment with Industrial Pollution
Materials 2017, 10(7), 762; doi:10.3390/ma10070762
Received: 3 June 2017 / Revised: 29 June 2017 / Accepted: 3 July 2017 / Published: 6 July 2017
PDF Full-text (3996 KB) | HTML Full-text | XML Full-text
Abstract
The electrochemical corrosion behavior of a silver-plated circuit board (PCB-ImAg) in a polluted marine atmosphere environment (Qingdao in China) is studied through a simulated experiment. The morphologies of PCB-ImAg show some micropores on the surface that act as the corrosion-active points in the
[...] Read more.
The electrochemical corrosion behavior of a silver-plated circuit board (PCB-ImAg) in a polluted marine atmosphere environment (Qingdao in China) is studied through a simulated experiment. The morphologies of PCB-ImAg show some micropores on the surface that act as the corrosion-active points in the tests. Cl mainly induces microporous corrosion, whereas SO2 causes general corrosion. Notably, the silver color changes significantly under SO2 influence. EIS results show that the initial charge transfer resistance in the test containing SO2 and Cl is 9.847 × 103, while it is 3.701 × 104 in the test containing Cl only, which demonstrates that corrosion accelerates in a mixed atmosphere. Polarization curves further show that corrosion potential is lower in mixed solutions (between −0.397 V SCE and −0.214 V SCE) than it in the solution containing Cl only (−0.168 V SCE), indicating that corrosion tendency increases with increased HSO3 concentration. Full article
Figures

Figure 1

Open AccessFeature PaperArticle Effect of Substitutional Pb Doping on Bipolar and Lattice Thermal Conductivity in p-Type Bi0.48Sb1.52Te3
Materials 2017, 10(7), 763; doi:10.3390/ma10070763
Received: 11 May 2017 / Revised: 29 June 2017 / Accepted: 4 July 2017 / Published: 6 July 2017
PDF Full-text (2684 KB) | HTML Full-text | XML Full-text
Abstract
Cation substitutional doping is an effective approach to modifying the electronic and thermal transports in Bi2Te3-based thermoelectric alloys. Here we present a comprehensive analysis of the electrical and thermal conductivities of polycrystalline Pb-doped p-type bulk Bi0.48Sb1.52
[...] Read more.
Cation substitutional doping is an effective approach to modifying the electronic and thermal transports in Bi2Te3-based thermoelectric alloys. Here we present a comprehensive analysis of the electrical and thermal conductivities of polycrystalline Pb-doped p-type bulk Bi0.48Sb1.52Te3. Pb doping significantly increased the electrical conductivity up to ~2700 S/cm at x = 0.02 in Bi0.48-xPbxSb1.52Te3 due to the increase in hole carrier concentration. Even though the total thermal conductivity increased as Pb was added, due to the increased hole carrier concentration, the thermal conductivity was reduced by 14–22% if the contribution of the increased hole carrier concentration was excluded. To further understand the origin of reduction in the thermal conductivity, we first estimated the contribution of bipolar conduction to thermal conductivity from a two-parabolic band model, which is an extension of the single parabolic band model. Thereafter, the contribution of additional point defect scattering caused by Pb substitution (Pb in the cation site) was analyzed using the Debye–Callaway model. We found that Pb doping significantly suppressed both the bipolar thermal conduction and lattice thermal conductivity simultaneously, while the bipolar contribution to the total thermal conductivity reduction increased at high temperatures. At Pb doping of x = 0.02, the bipolar thermal conductivity decreased by ~30% from 0.47 W/mK to 0.33 W/mK at 480 K, which accounts for 70% of the total reduction. Full article
(This article belongs to the Special Issue Advances in Thermoelectric Materials)
Figures

Figure 1

Open AccessArticle Biomechanical Loading Evaluation of Unsintered Hydroxyapatite/poly-l-lactide Plate System in Bilateral Sagittal Split Ramus Osteotomy
Materials 2017, 10(7), 764; doi:10.3390/ma10070764
Received: 24 May 2017 / Revised: 2 July 2017 / Accepted: 3 July 2017 / Published: 7 July 2017
PDF Full-text (3857 KB) | HTML Full-text | XML Full-text
Abstract
OSTEOTRANS MX® (Takiron Co., Ltd., Osaka, Japan) is a bioactive resorbable maxillofacial osteosynthetic material composed of an unsintered hydroxyapatite/poly-l-lactide composite, and its effective osteoconductive capacity has been previously documented. However, the mechanical strength of this plate system is unclear. Thus,
[...] Read more.
OSTEOTRANS MX® (Takiron Co., Ltd., Osaka, Japan) is a bioactive resorbable maxillofacial osteosynthetic material composed of an unsintered hydroxyapatite/poly-l-lactide composite, and its effective osteoconductive capacity has been previously documented. However, the mechanical strength of this plate system is unclear. Thus, the aim of this in vitro study was to assess its tensile and shear strength and evaluate the biomechanical intensity of different osteosynthesis plate designs after sagittal split ramus osteotomy by simulating masticatory forces in a clinical setting. For tensile and shear strength analyses, three mechanical strength measurement samples were prepared by fixing unsintered hydroxyapatite/poly-l-lactide composed plates to polycarbonate skeletal models. Regarding biomechanical loading evaluation, 12 mandibular replicas were used and divided into four groups for sagittal split ramus osteotomy fixation. Each sample was secured in a jig and subjected to vertical load on the first molar teeth. Regarding shear strength, the novel-shaped unsintered hydroxyapatite/poly-l-lactide plate had significantly high intensity. Upon biomechanical loading evaluation, this plate system also displayed significantly high stability in addition to bioactivity, with no observed plate fracture. Thus, we have clearly demonstrated the efficacy of this plate system using an in vitro model of bilateral sagittal split ramus osteotomy of the mandible. Full article
Figures

Figure 1

Open AccessCommunication Lateral Tension-Induced Penetration of Particles into a Liposome
Materials 2017, 10(7), 765; doi:10.3390/ma10070765
Received: 8 May 2017 / Revised: 3 July 2017 / Accepted: 4 July 2017 / Published: 7 July 2017
PDF Full-text (3843 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
It is important that we understand the mechanism of the penetration of particles into a living cell to achieve advances in bionanotechnology, such as for treatment, visualization within a cell, and genetic modification. Although there have been many studies on the application of
[...] Read more.
It is important that we understand the mechanism of the penetration of particles into a living cell to achieve advances in bionanotechnology, such as for treatment, visualization within a cell, and genetic modification. Although there have been many studies on the application of functional particles to cells, the basic mechanism of penetration across a biological membrane is still poorly understood. Here we used a model membrane system to demonstrate that lateral membrane tension drives particle penetration across a lipid bilayer. After the application of osmotic pressure, fully wrapped particles on a liposome surface were found to enter the liposome. We discuss the mechanism of the tension-induced penetration in terms of narrow constriction of the membrane at the neck part. The present findings are expected to provide insight into the application of particles to biological systems. Full article
(This article belongs to the Special Issue Constitutive Modelling of Biological Tissues and Biomaterials)
Figures

Figure 1

Open AccessArticle Ab-Initio Investigations of Magnetic Properties and Induced Half-Metallicity in Ga1−xMnxP (x = 0.03, 0.25, 0.5, and 0.75) Alloys
Materials 2017, 10(7), 766; doi:10.3390/ma10070766
Received: 5 June 2017 / Revised: 29 June 2017 / Accepted: 29 June 2017 / Published: 7 July 2017
PDF Full-text (4775 KB) | HTML Full-text | XML Full-text
Abstract
Ab-initio calculations are performed to examine the electronic structures and magnetic properties of spin-polarized Ga1−xMnxP (x = 0.03, 0.25, 0.5, and 0.75) ternary alloys. In order to perceive viable half-metallic (HM) states and unprecedented diluted magnetic semiconductors
[...] Read more.
Ab-initio calculations are performed to examine the electronic structures and magnetic properties of spin-polarized Ga1−xMnxP (x = 0.03, 0.25, 0.5, and 0.75) ternary alloys. In order to perceive viable half-metallic (HM) states and unprecedented diluted magnetic semiconductors (DMSs) such as spintronic materials, the full potential linearized augmented plane wave method is utilized within the generalized gradient approximation (GGA). In order to tackle the correlation effects on 3d states of Mn atoms, we also employ the Hubbard U (GGA + U) technique to compute the magnetic properties of an Mn-doped GaP compound. We discuss the emerged global magnetic moments and the robustness of half-metallicity by varying the Mn composition in the GaP compound. Using GGA + U, the results of the density of states demonstrate that the incorporation of Mn develops a half-metallic state in the GaP compound with an engendered band gap at the Fermi level (EF) in the spin–down state. Accordingly, the half-metallic feature is produced through the hybridization of Mn-d and P-p orbitals. However, the half-metallic character is present at a low x composition with the GGA procedure. The produced magnetic state occurs in these materials, which is a consequence of the exchange interactions between the Mn-element and the host GaP system. For the considered alloys, we estimated the X-ray absorption spectra at the K edge of Mn. A thorough clarification of the pre-edge peaks is provided via the results of the theoretical absorption spectra. It is inferred that the valence state of Mn in Ga1−xMnxP alloys is +3. The predicted theoretical determinations surmise that the Mn-incorporated GaP semiconductor could inevitably be employed in spintronic devices. Full article
(This article belongs to the Section Materials for Energy Applications)
Figures

Figure 1
