Special Issue "Selected Papers from IEEE ICASI 2017"

A special issue of Materials (ISSN 1996-1944).

Deadline for manuscript submissions: closed (31 October 2017)

Special Issue Editors

Guest Editor
Prof. Dr. Shoou-Jinn Chang

Department of Electrical Engineering, National Cheng Kung University, Tainan 701, Taiwan
Website | E-Mail
Phone: +886 6 2757575 ext 62391
Fax: +886 6 2761854
Interests: optical and electronic devices; semi-conductive materials; nanotechnology
Guest Editor
Prof. Dr. Teen-Hang Meen

Department of Electronic Engineering, National Formosa University, Yunlin 632, Taiwan
Website | E-Mail
Interests: photovoltaic device; dye-sensitized solar cells; nanotechnology
Guest Editor
Dr. Stephen D. Prior

Aeronautics, Astronautics and Computational Engineering, University of Southampton, Southampton SO17 1BJ, UK
Website | E-Mail
Interests: microsystem design; nanotechnology; applied science

Special Issue Information

Dear Colleagues,

The 2017 IEEE International Conference on Applied System Innovation (IEEE ICASI 2017) will be held in Sapporo, Japan on May 13~17, 2017, and will provide a unified communication platform for material topics. Scientists all over the world actively want to discover new advanced materials in electrical and mechanical engineering. In recent years, the applications of advanced materials have been highly developing fields, in the areas of semiconductor and electronic device technology, design, manufacturing, physics, and modeling. Therefore, the fields of electrical and mechanical materials have been the subjects of review. The scope of IEEE ICASI 2017 not only encompasses material sizes at the nanoscale, but also in various dimensions where the onset of size-dependent phenomena usually enables novel applications.

This Special Issue selects excellent papers from IEEE ICASI 2017 and covers the following topics: fundamental and advanced materials of electrical and mechanical engineering; their synthesis and engineering; their application on optical sensors, magnetic, acoustic, and thermal transduction; their integration with many elements; designing of electrical or mechanical devices; evaluation various performance; and exploring their broad applications in industry, environmental control, material analysis, etc. We invite investigators to contribute original research articles, as well as review articles to this Special Issue. Potential topics include, but are not limited to:

  • Developments of advanced materials for new electrical and optical properties
  • Nanomaterials for preparation and applications
  • Combinatorial methods of advanced materials for mechanical design and optimization
  • Advanced materials for preparation and applications
  • Subjects related to electronic thin films and coating technology
  • Synthesis engineering of advanced materials
  • Advanced materials in mechatronics applications

Chair Professor Dr. Shoou­Jinn Chang
Prof. Teen­Hang Meen
Dr. Stephen D. Prior
Guest Editors



Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All papers will be peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Materials is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 1500 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • Developments of advanced materials for new electrical and optical properties
  • Nanomaterials for preparation and applications
  • Combinatorial methods of advanced materials for mechanical design and optimization
  • Advanced materials for preparation and applications
  • Subjects related to electronic thin films and coating technology
  • Synthesis engineering of advanced materials
  • Advanced materials in mechatronics applications

Published Papers (11 papers)

View options order results:
result details:
Displaying articles 1-11
Export citation of selected articles as:

Research

Open AccessArticle Magnetic Material Assessment of a Novel Ultra-High Step-Up Converter with Single Semiconductor Switch and Galvanic Isolation for Fuel-Cell Power System
Materials 2017, 10(11), 1311; doi:10.3390/ma10111311
Received: 26 October 2017 / Revised: 6 November 2017 / Accepted: 6 November 2017 / Published: 15 November 2017
PDF Full-text (5060 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, a novel step-up converter is proposed, which has the particular features of single semiconductor switch, ultra-high conversion ratio, galvanic isolation, and easy control. Therefore, the proposed converter is suitable for the applications of fuel-cell power system. Coupled inductors and switched
[...] Read more.
